Intel-based computers that deliver full PC functionality to the user from a centralized location. The blades are compact and house the latest PC components including Intel® Core™ 2 Duo, Xeon® and Pentium® 4 processors with Hyper-Threading, DDR2 memory, SATA hard drives and NVIDIA® graphics cards.
|
|
FPGA Processors
TS Series Processor boards are the foundational element of our FPGA Computing family. Each TS Series board has an Altera FPGA processor chip, a PCI interface, SRAM, SDRAM, an I/O module, and expansion slots for additional FPGA Computing power. These elements are interconnected by a high speed bus on the board.
If your needs are for advanced signal processing using multiprocessors, click here to see those products within the Multiprocessors family, including the V4DSP.
|
|
The new SLC-8550-LVA is the 5-inch bay sized (203mm×145mm) CPU board and is a lead-free and RoHS-compliant product. This CPU board supports the Intel 855GME + ICH4 chipset and is compatible with 1.6G-2.0GHz (FSB400MHz) Intel Pentium M processor and 1.3G-1.5GHz (FSB400MHz) Intel Celeron M processor. The main memory complies with PC2700 DDR SDRAM (supports both ECC and non-ECC memory) and is able to contain up to 1 GB.
The SLC-8550-LVA provides the expansion capability including six 232C serial communication ports (two of them are pin header connector), six USB 2.0 ports, CF slot (enables boot-up), AC97 audio and PCI slot, making it ideal for complicated embedded applications. LVDS interface and analog RGA enables the dual independent displays. CONTEC strives to customize contained devices and BIOS of the new SLC-8550-LVA as its custom ordered (OEM) product.
|
|
|
Computer-on-Module is a series of complete CPU modules that mount onto easily designed application-specific solution boards. Avalue offers COM Express CPU modules, ETX CPU modules and various baseboards to fit different demands. With the modular design, Avalue is able to provide customers 30-day Baseboard Prototyping Service for faster time to market.
|
|
|
The nanoETXexpress specification, a form factor driven by Kontron, is targeted to deliver extremely power-saving COMs with mid to high performance x86 technology on a footprint that is a mere 55 mm x 84 mm. This is 39 percent of the original COM Express™ module Basic form factor 125 x 95 mm footprint and 51 percent of microETXexpress (95mm x 95mm). This new COM form factor is compliant to COM Express™ module size nano from PICMG and is based on COM.0 Type 1 connector. The locations of the identically mapped pin-outs are also 100 percent COM.0 compliant.
|
|
|
|
|
|
Nexcom has expanded its range of Industrial Computer Solutions with the launch of several new embedded boards and systems which are based on the energy-efficient Intel® Atom™ CPU. For years, Embedded Systems designers have been waiting for a low-power Intel architecture CPU that provides sufficient performance capability for a broad spectrum of applications to be addressed. The new Intel® Atom™ processor fulfils this key role and enables many new embedded and mobile power-efficient applications to be considered.
Nexcom has utilized Intel® Atom™ based technology in a number of its new Embedded Computing Platforms including the ICES 170 ETX Module, the ICES 270 Com-Express Module and EBC 540 5.25” Embedded CPU Board. In addition, the robust NISE 2000 range of Fan-less Computer Systems has also been launched for applications that require a complete system based solution.
All platforms are based on the energy-efficient, yet surprisingly cost-effective Intel® Atom™ N270 1.6GHz processor and offer industrial-grade computing at a commercially acceptable cost. In addition, the N270 CPU is included on Intel’s Embedded Roadmap and therefore has an extended life-time support. The development of these rugged Intel® Atom™ based platforms underlines Nexcom’s commitment to develop new industrial computing solutions for vertical markets such as Control and Automation, Digital Signage, Retail, POS, Infotainment and Gaming.
|
|
Avalue’s XTX-US15WP is the pioneer of XTX module incorporated with eMenlow platform in the market. The XTX is an extension of ETX form factor. The x2 connector on XTX has advanced functions such as PCIe, SATA, LPC Interface, digital audio and USB. The XTX-US15WP has two LVDS signals for dual display, and a Micro-SD slot on the module for more flexible expansion.
Features:
Intel® Atom™ Z510P / Z530P CPU
Intel® US15WP Chipset
Dual View, Dual LVDS
2 SATA, 6 USB, 1 Micro-SD Slot, 4 COM
1 PCIe x1
Fanless Operation
114mm(L) x 95mm(W)
|
|
Full Size PICMG 1.3
High performance slot CPU offering PCI express
Fast The PCI-960 combines Intel‘s latest low power processor, the Core 2 Duo, with the 945GM chipset to deliver outstanding performance and bandwidth. It allows you to set the pace with innovative applications today ...
|
|
MIP10 Family, PC/104-Plus CPU Boards for extreme environments!
* soldered Intel Pentium M and Celeron M CPUs
* soldered ECC RAM
* lockable headers
* including CF-Slot & Gigabit Ethernet
* comes with integrated conductive cooling concept
* extreme low power consumption
* extended Temperature from -40° to +75°C
* long term available (Embedded Program)
|
|
* CPU modules in PC/104 form factor and other sizes
* Embedded solutions with x86, Power PC and ARM9 CPUs
* Extended temperature solutions
* Embedded designs for reliable and rugged industrial use
* Low power consumption starting at 2 watt
* Total solutions with housings (up to IP 67)
* High flexibility, depopulation for cost optimization
|
|
PICMG 1.0 CPU Board
PICMG 1.3 CPU Board
PCISA CPU Board
PICO/PICOe CPU Board
ISA CPU Board
5" 1/4 CPU Board
Embedded CPU Board
ETX CPU Board
ATX CPU Board
Mini ITX CPU Board
PIAGP CPU Board
|
|
|
|
|
|
Product Name : Embedded Single Board Computer
Description :
3.5” Embedded Board for AMD Geode LX800 Low Power processor
With VGA/LAN/PC104/Audio/LVDS/CF/USB
Features :
★Support AMD Geode LX 800 0.9W processor, FSB 500MHz
★Bulit-in AMD Geode LX800 Chipset + Geode CS5536
★Realtek 8100C Chipset 10 / 100 Base-TX Ethernet
★Support 1 x 200 pin DDR SODIMM up to 1GB
★Realtek ALC202 Chipset, Support 5.1 Channel Audio
★Watchdog Software BIOS Setup
Specification :
★Processor: Support AMD Geode LX800 0.9W processor
★Chipset: AMD Geode LX800@0.9W chipset + AMD Geode CS5536 chipset
★Front Side Bus Speed: 500 MHz
★Memory: Support 1 x 200-pin SODIMM DDR400,up to 1GB
★VGA Interface: Improved Graphics
★LVDS Transmitter: 18-bit LVDS transmitter(optional)
support pixel rate up to 330M pixeis/sec
★USB Port: Support 2 x USB 2.0 ports
★Printer Port: Support 1 x SPP/EPP/ECP parallel port by pin-header
★Serial Port: Support 4 x COM ports, Winbond 83627 EHF COM1,
COM2 /RS232/485(optional), Fintek F81216D chipset COM3/4
★LAN Port: Realtek 8100C chipset 10/100M Fast Ethetnet
or Realtek 8100S chipset 10/100/1000 Gigabit Ethetnet(optional)
★Keyboard/Mouse: Support 1 x PS/2 Keyboard/Mouse
★Audio: Realtek ALC202 chipset support 5.1 channel audio
★Watchdog Timer: Watch Dog software BIOS setup
★Other Connector: Onboard 1 x PC/104 Plus
★Power: 12V AC to DC adapter or DC 12V input with P4 addition connector
★Dimensions(W x H): 146 x 101mm
★Operating Temperature: 0 to 60oC
★Relative Humidity: 10% to 90%(non-condensing)
|
|
Evaluation carrier board for ETXexpress® modules
Based on the COM Express™ standard from the PCI Industrial Computer Manufacturers Group (PICMG)
Evaluation Carrier Board
For express evaluation purposes
Includes all connectors for a quickstart
|
|
Maxiflex Process Automation Controllers
The PAC is based on the Maxiflex P3 CPU platform. The Maxiflex Process Automation Controllers (PAC) run the IEC 61131 Control Applications and are available in a number of variants to suit network preferences.
Ethernet (with Modbus TCP)
Ethernet (Conet)
Modbus
Conet/c
Conet/m (Packet Radio Protocol)
This provides a flexible Network environment satisfying most networked applications and plant topologies. Process Control Applications invariably involve the following functionality for effective implementation.
Interlock Controls
Analogue Signal Processing
Control Algorithms - including PID with Auto-tune
Network Communications
Alarm and Events Monitoring
Date and Time Stamping at source for Sequence of Events monitoring
The ability to service Windows based SCADA systems
|
|
|
|
|
|
Processor modules MPE200 series
* CPU 400 / 650 / 700 MHz Pentium class
* SRAM: up to 512 Kb (battery backed)
* FRAM: 64 Kb (no battery necessary)
* DRAM: 64 or 128 MB
* FLASH: 8 MB internal
* 1x USB, 1x RS232, 1x RS232 / 422 / 485
* 2x Ethernet 10 / 100 Mbit/s
* Slots: PCC201 / xx, CF200 / xx, 2 PCI slots (M20 system)
Processor modules MPC200 series
* CPU 400 / 650 / 700 MHz Pentium class
* SRAM: up to 512 Kb (battery backed)
* FRAM: 64 Kb (no battery necessary)
* DRAM: 64 or 128 MB
* FLASH: 8 MB internal
* 1x USB, 1x RS232, 1x RS232/422/485
* 2x Ethernet 10 / 100 Mbit / s
* Slots: PCC201 / xx, CF200 / xx
Processor modules MX200 series
* CPU x86 66 MHz Pentium class / CPU 133 MHz Pentium class
* Integrated power supply 17 W / 24 V (MX213)
* NVRAM: 512 Kb
* DRAM: 256 MB
* FLASH: 16 MB internal
* 1x USB
* 1x RS232, 1x RS232 / 422 / 485 (MX213)
* 1x CAN
* Ethernet 10 / 100 Mbit / s
* Slots: PCC201 / xx, CF200 / xx (MX213)
Processor modules ME203 series
* Intel 80386 EX, 33 MHz
* Integrated power supply 17 W / 24 V
* SRAM: 512 Kb (battery backed)
* DRAM: 8 MB
* FLASH: 8 MB File Flash, 2 MB Boot Flash
* 1x RS232, 1x RS232 /422 / 485
* 1x Ethernet 10 / 100 Mbit /s or 1x CAN
* Slots: PCC201 / xx
|
|
Embedded Processors
Embedded processors provide solutions for real-time systems for mass storage, automotive body and power-train, industrial and networking applications.
|
|
DIMM-PC®/520-I with AMD® Elan™ SC520 (133 MHz) CPU with 32MByte DRAM, 32MByte IDE compatible Flash Disk
AMD® Elan™ SC520 CPU with 133MHz
16/32 Mbyte DRAM and 16/32 MB IDE Flashdisk on board
Two serial ports (TTL)
IDE Interface
|
|
Intel XScale IXP420 based Computer-on-Module. Feature optimized and price aggressive.
Intel XScale Processor IXP420
32/64MB soldered SDRAM, 4/8MB soldered Flash
Dual Fast Ethernet
2 terminal interfaces (Rx/Tx)
|
|
CP6000-V
CPCI/PICMG 2.16 ULV Celeron® (Pentium® M-like) 600 MHz
CPCI/PICMG 2.16 cost optimized value oriented design
Low Power Celeron® 600 MHz
Single slot 4HP CPU with passive cooling
Scalable memory size up to 2GB PC333 SDRAM
|
|
X-board® with Intel® PXA255 400MHz, 32MB SDRAM, 16MB Flash
The most cost-efficient multimedia ready board in it´s class
More compact & cost efficient for embedded PC Systems
All advantages of X-Scale architectures at business card size
Low power design - no cooling needed
|
|
|
|
|
|
Matrox Odyssey eA/XA
Matrox Odyssey eA/XA is a fourth generation entry-level x4 PCIe / PCI-X® vision processor board with proprietary custom ASIC, freescale G4 PowerPC microprocessor and analog video capture.
Matrox Odyssey eCL/XCL
Matrox Odyssey eCL/XCL is a fourth generation entry-level x4 PCIe / PCI-X® vision processor board with proprietary ASIC, freescale G4 PowerPC microprocessor and Camera Link® video capture.
Matrox Odyssey eD/XD
Matrox Odyssey eD/XD is a fourth generation entry-level x4 PCIe / PCI-X® vision processor board with proprietary ASIC, freescale%u2122 G4 PowerPC microprocessor and 64-bit LVDS/RS-422 video capture.
Matrox Odyssey Xpro
Matrox Odyssey Xpro is a fourth generation scalable PCI-X® vision processor board with proprietary ASIC, freescale G4 PowerPC microprocessor and analog, Camera Link® or LVDS/RS-422 digital video capture.
Matrox Odyssey Xpro
Matrox Odyssey Xpro is a enhanced fourth generation scalable PCI-X® vision processor board with proprietary ASIC, customizable co-processor FPGA, freescale G4 PowerPC microprocessor and analog, Camera Link® or LVDS/RS-422 digital video capture.
|
|
