The design of EE07 humidity and temperature transmitter series is based on a new electronic concept and on the SMD miniaturized E+E humidity sensor element type HC103.
EE07 transmitters are fully interchangeable, the connector enables their replacement within few seconds.
Calibration and sensor element data such as linearization and temperature compensation are stored in the elec- tronics integrated in the probe.
Digital E2Bus output signals for humidity and temperature allow easy and cost-effective interfacing to customers' electronics.
The choice of filter caps make the EE07 suitable for a large variety of applications.
Technical data
Measuring range: 0-100% RH; -40...80°C
Outputs: Digital output (E2Bus, 2 wire)
Accuracy: +/-2% RH; +/-0.3°C
Supply: 3.8 - 5.5V DC
|
|
