The new JK™ family of Pulsed Nd:YAG lasers from GSI combines higher peak powers with shorter pulse lengths for increased flexibility and maximised process control for faster more precise laser welding and fine cutting applications. GSIG Pulsed Lasers feature:
* Compact footprint
* Fast Control Interfaces and complete cycle programming triggered by a single command through our unique LaserView™ control technology
* Class-leading reliability and built-in back reflection protection with our patented Luminator™ plug-and-play fiber optic delivery system
* Tighter process control and reduced costs via closed loop stability control and Pulse- On- Demand systems
* Fully Integrated time and energy-share options
|
|
|
|
|
|
Among the TEEM PHOTONICS offer, our High energy pulsed Nd:Yag laser Powerchip and Picospark families allow to achieve up to 250uJ of Energy per pulse and ultra high peak power up to 280KW, with picosecond pulses down to 300ps and repetition rates up to 40KHz.
They are proposed with outputs at infrared(1064nm) , green (532nm), or UV (355nm for Powerchip family only).
They are specialized for utilization in applications like Marking, Micro Machining, drilling, scribing, trenching, Laser Induced Fluorescence (LIF), Laser Induced Breakdown Spectroscopy (LIBS), Light Detection and Ranging (LIDAR), etc..
Features & Benefits:
- Ultrashort picosecond Nd:Yag pulses (As low as 300 picoseconds)
- High Energy (Up to 250uJ/pulse)
- Ultra high peak power (Up to 280KW at 25KHz)
- Variety of frequency options
(Up to 40KHz in free running, triggerable up to 4KHz)
- Excellent beam quality (Gaussian, TEM00, M2<1.3)
- Efficient, air cooled
- Long UV life (lifetimes expected to exceed 5k hours)
- Licensed Technology
Passively Q-switched pico-second laser:US Patent 5394413
Fiber amplifier: 4 US patents with IMRA
Optional features:
- Photodiode output for synchronization
- Manual controls for CDRH compliance
|
|
Inlite Series : Industrial Q-switched Nd:YAG laser system
Continuum introduces a new, high energy YAG laser platform designed for Industrial and OEM applications. Providing high levels of performance, Inlite features a hardened design for reliable operation in harsh environments, a robust structure ensuring long-term thermal and mechanical stability, a modular power supply in both rack mount and tower configurations, and easy
flashlamp replacement without realignment of the laser oscillator. The system comes in a compact package. Options and accessories are available to simplify integration. Inlites are perfect for remote sensing, sample testing, mass spectroscopy, LIF, LIBS and other high energy applications.
|
|
At the heart of each Continuum laser system is a very high efficiency pump chamber to couple the flashlamp light into the Nd:YAG rod. Through the use of a diffuse reflector concept, Continuum is able to produce high gain with low heat buildup in the overall system. The result is superior beam quality and excellent passive beam pointing stability without the use of the costly active locking technology used by other companies. Continuum offers five laser platforms based on this technology:
- Powerlite: High power Nd:YAG laser systems
- Surelite: High performance Nd:YAG laser systems
- Inlite: Industrial Nd:YAG laser systems
- Minilite: Compact Nd:YAG laser systems
- Leopard: Picosecond Nd:YAG laser systems
|
|
|
|
|
|
FLS N - pulsed Nd:YAG laser
FLS N series lasers are flexible work-horses with high average power and peak power for deep penetration cutting and drilling at high throughput.
Due to their modular design more than 30 different laser models are available.
Typical applications and markets
- cuts up to 20 mm thick
- precision cuts with kerf width /= 40 µm
- single shot contour welding
- creation of fracture notches
- used for cracking processes on brittle metals as C60
- oxyde-free cut surface
- percussion drilling
- trepanning drilling
- single-pulse drilling
- seam welding of metals
- spot-welds >/= 40 µm
- single shot contour welding
- creation of fracture notches
more advantages:
- high manufacturing flexibility, short retooling times
- time and/or energy sharing for multistation operation
- high production repeatability
- front access and modular design for easy servicing
- remote diagnostic functions via modem
- easy to integrate into manufacturing
- fiber optic and/or conventional beam delivery
- laser control interfaces with any CNC, PLC or PC system
- industrial design compliant with IP 54 / NEMA 12
- modular field upgrades accommodate changing production requirements
Technical Specification
Average power, max.
600 W
Pulse length
0.1 - 20 ms
Pulse repetition rate
0.1 - 1000 Hz
Pulse energy, max.
60 - 150 J
Peak power, max.
50 kW
|
|
|
|
|
|
KLS 246 - pulsed Nd:YAG laser
KLS series lasers provide excellent beam-quality and high peak power, which are ideal for fine cutting, drilling, scribing, precision joining and multiple-use applications. Due to their modular design 6 different laser models are available.
Typical applications and markets
Fine cutting of challenging fine sheets and thin-walled tubules to Medical Device Industry and Electronics
Precision drilling of thin material like fuel filters to Automotive Industry
Scribing of connecting rods to Automotive Industry
Spot welding of electrical contacts or hermetic sealing of housings
Multiple applications to subcontracters
Technical characteristics
Outstanding beam quality at high peak power
Conventional beam delivery, optional Fiber beam delivery with up to 6 outputs
Compact and modular design
Multiple interface options
Easy integration into production
Technical Specification
Average power, max.
15 - 250 W
Pulse length
0.012 - 20 ms
Pulse repetition, max.
5000 Hz
Pulse energy, max.
50 J
Peak power, max.
5.5 kW
|
|
|
|
|
|
SLS 200 - pulsed Nd:YAG laser
SLS series laser has been exclusively engineered to process materials via Fiber Optic Beam Delivery. Due to their modular design more than 30 different laser models are available.
Typical applications and markets
Precision seam & spot welding of challenging materials and material combinations
Extended capabilities for joining of brittle or high carbonized steels
Smooth weld surfaces, especially for biocompatible materials
Hermetic, pressure-tight and crack-free welds
High-speed SHADOW welding applications
Precision cutting, drilling and other kinds of micromachining
Technical characteristics
Fiber Optic Beam Delivery up to 6 outputs, Fiber diameter 50 - 600 µm
State of the art RTPS technology through
- Exciting pulse to pulse stability down to 0.5% even for lowest peak power
- High pulse energy & long pulses up to 100ms
- Peak-power control, high-resolution pulse forming, pulse-on-demand, power burst
Unique RTCP technology through
- Real-time of check of actual laser performance, lamp life and power reserve
- Control & monitoring of each single laser pulse with read-out capabilities
Active water or air-cooling, depending on power output
Multiple interface options
Easy integration into production
Technical Specification
Average power, max
10 - 220 W
Pulse length
0.1 - 100.0 ms
Pulse repetition
0.1 - 500 Hz
Pulse energy, max.
70 J
Peak power, max.
7.0 kW
|
|
In 2001, with industry showing ever greater interest in treating or preparing surfaces with switched solid-state lasers (deflashing, cleaning, deoxydation, marking, etc.), Quantel launched the Yasmin line of nanosecond-pulsed laser systems.
Since the materials to be treated are very diverse, Yasmin switched Nd:YAG lasers can emit in the infrared (1064 nm), visible (532 nm) or ultra-violet (355 nm) spectrum. Five models are currently available.
|
|
High Energy laser systems with industry leading spatial homegenity - ideally suited to applications such as Ti:S pumping, Dye laser pumping and deflashing.
The LPY700 Series models feature twin rod oscillator design with birefringence compensation leading to high beam homegeneity and conversion efficiencies. The LPY600 Series models are single rod oscillators or oscillator-amplifiers. Telescopic resonators produce low-divergence output beams that are spatially smooth in the near field suiting them to a host of pump source appliactions.
|
|
|
RG Series diode pumped pico-second lasers produces over 3mJ per pulse at 1kHz, and more than 10Watts at 10kHz at 1064nm with ~15ps nominal pulse widths in a compact, industrial reliable package. It is the most compact, the highest pulse energy in kHz range in the market. Higher power versions(25W and 40W @10kHz) or pulse energy (5mJ/pulse and 8mJ/pulse @1kHz) are also available with added amplifier stages. Harmonic output such as 532nm, 355nm, 266nm and 213nm can be ordered as needed
|
|
|
|
|
|
Diode-pumped laser sources
for marking, cutting and trimming.
The high electro-optic conversion efficiency of the SagittaTM allows low electrical power consumption with a reduction footprint for the cooling element. This high efficiency also allows to reduce ageing of the diode laser for long life applications, which reduced replacement costs upon consumption of the diode after an average of 10,000 working hours without any maintenance interventions.
The laser resonator is designed specifically for marking, engraving and thin gauge cutting application by optimizing beam quality for higher processing power and speed.
SagittaTM is often required on precision marking components, surgical instruments, tools and ball bearings. Using 100 and 160 mm focal length objectives, SagittaTM is able to engrave metals with a very high material removal capacity. The high power density of laser beam combined with the high speed of the scanning head, allows fast, deep engraving on metals.
The beam quality resulting from Laservall’s design philosophy also makes SagittaTM High Power an interesting tool for precision cutting of thin metal sheet, including highly refl ective materials such as silver and gold. This can be achieved using the 100 mm focal lens directly, or a special Head to obtain very high power density in the spot. By using an appropriate gas cover, it is also possible to perform jobs on stainless steel and titanium materials with no oxidation. This High Power laser also meets demanding industrial applications in precise trimming on Indium Tin Oxide (ITO).
|
|
|
|
|
|
Rugged, invar stabilised, pulsed Nd:YAG lasers with high energy and high Performance for industrial and scientific applications.
The LPY600/700 series of pulsed Nd:YAG lasers have been designed to suit almost any industrial or research application in which a high-energy or high-specification Nd:YAG laser is required. Based around a fully self supporting Invar rail the LPY600/700 series exhibit both exceptional mechanical and thermal stability. A ‘no-compromise’ design approach is evidenced in the build quality, a parameter that sets these lasers well apart from any of their competitors.
The modular design of the laser head allows a wide variety of resonator configurations to be offered, from single rod oscillators to fully birefringence compensating twin-rod-oscillator, twin-rod-amplifier systems. Furthermore, a choice of stable, stable-telescopic or unstable Gaussian-coupled resonators is available, allowing the customer to specify a system that suits their requirements.
Energies of up to 3J and repetition rates of up to 200Hz are standard. Applications include Dye laser pumping, OPO pumping, Spectroscopy, LIBS, LIDAR, PIV and many more.
|
|
Nano O Series Ultra Compact Pulsed Nd:YAG Lasers
Ultra compact q-switched pulsed Nd:YAG lasers for industrial applications such as mask repair, LIBS and spectroscopy.
The Nano O is the smallest in the range with the head measuring just 230mm x 78mm x 55mm. It has been specifically designed for incorporation into OEM equipment. It offers energies of up to 100mJ per pulse and repetition rates of up to 50Hz, although the maximum power loading on the lamp will determine the maximum energy and repetition rate for a given application. An air cooled option is available in applications where a water supply is not desired such as portable LIBS applications.
|
|
General description:
The "Spitlight" Nd:YAG laser systems offers newst technology as well as highly reliable and solid construction. Being a price/performance optimized compact system, it covers a very broad range of scientific and high-quality industrial laser applications.
Like all other models of the "SpitLight" series the SL 1200 have a maintenance-free pumping chamber with ceramic reflector and exhibit a particularly robust and stable resonator structure. At a pulse duration of approx. 7.0 nsec, it generates laser pulses of 24 mJ to 1300 mJ at a wavelength of 1064, 532, 355, 266 nm or 213nm. In the double pulse mode, a pulse sequence with a time difference of 10 to 1000 µsec is infinitely adjustable.
The unique selling point in its price range is the possibility of operating the "Spitlight" as a narrow-band injection seeder (SLM option). In the case of fibre coupling via light guides it provides a line width of <90 MHz.
|
|
| ... products without technical information |
| |
|
|
|
|
The 7210 and 7310 pulsed fibre laser markers (10 Watt and 20 Watt respectively) are compact and versatile and can be used reliably, quickly and economically on metals, plastics and other hard-to-mark materials. This makes the Videojet 7210 and 7310 ideal for marking tools and instruments, as well as for use in the electronics, automotive and automotive supplier industries. They mark complex, variable data (codes, logos, symbols, serial numbers, individual data, etc.) on to both stationary and moving products and with a multi-lingual user interface, they also offer ease of integration into host equipment.
Compact, simple integration
The compact design and smallest marking head on the market combined with tried-and-tested flexible software and hardware platforms makes integration into end customer lines and OEM equipment extremely simple.
Wide range of applications
A large range of options (high-performance software, superior galvanometer scanners, compact marking heads, beam deflection options [0°/90°], etc.), enables the VJ 7210 and VJ 7310 to mark virtually anything to the highest quality.
Minimum waiting time, maximum runtime
Shorter setup times, an air-cooled, highly efficient, virtually maintenance-free laser and the option of PC-independent operation increase production times and lower costs.
|
|
|
|
|
|
The ML20-PL-R-OEM Module is a compact 1mJ Pulsed Ytterbium Fibre Laser delivering up to 20W of average output power, through a near diffraction limited beam (M²<1.5). It allows to obtain more than 20 kW of peak power due to a pulse duration lower than 50 ns. One of the key features is the possibility to operate the Fibre Laser in Pulsed or CW mode. Pulse repetition rate and output power can be controlled either by 8-bits TTL signal or RS232 or Analog. The excellent beam quality and power stability make the Manlight Fibre Laser a multi-purpose tool. Our patented “Injection Technology” allows the use of highly reliable broad area laser diode pumps, for a cost-effective and maintenance-free operation. The all-fibre design guarantees the robustness of the laser, without any optical parts to align or to stabilise. The simple integration of the system requires no after-installation service. The ML20-PL-R-OEM is the ideal solution for a broad range of industrial applications.
It also exists in a 0,5mJ version (ML10-PL-R-OEM) and in a 19" 3U Tunrkey version.
|
|
|
|
|
|
General description: Talisker
Fiber based industrial laser for micromachining
Features :
- Scalable fiber laser platform
- High peak power picosecond pulses for precision machining
- Industrial packaging and reliability
- Minimizing thermal damage and heat affected zone
Talisker™ is a new family of high peak power and high average power picosecond lasers designed specifically for materials processing. Based on a scalable fiber laser platform Talisker is designed for an industrial environment and meets availability requirements of demanding industries. Delivering picosecond pulses these lasers minimize thermal damage and heat affected zone to enable smaller feature sizes for high precision micromachining. Minimizing thermal damage and heat affected zone enables a new range of high precision applications such as silicon machining, wafer dicing, solar cell manufacturing or glass scribing. Available at wavelengths of 1064 nm, 532 nm and 355 nm Talisker processes a wide variety of materials, including: silicon, polyimide, metals,"hard materials," and glass.
|
|
Applications:
- LADAR/ Rangefinding
- Surveillance
- Mapping
- Sensing
- Seed for power Amp
Features
- Fully self contained
- Ultra Low Jitter
- High beam quality
- Optical trigger out (to)
- EMI filtering MIL-STD-461E
- Transient protection MIL-STD-704F
|
|
The YLP Series are maintenance-free MOPFA and Q-switched pulsed Ytterbium fiber lasers designed for OEM applications.
These lasers deliver a high power 1.07 µm laser beam directly to the work site via a flexible metal-sheathed fiber cable. Collimated, and then typically focused to a spot size of a few microns or less, the near diffraction-limited beam can mark, drill or machine a variety of materials.
YLP Series provides a wide choice of pulse durations, repetition rates and peak powers.
Main Features:
- Up to 2mJ energy per pulse
- Up to 200W average output power
- 40 to 500ns pulse duration
- 20 to 400kHz tunable rep. rate
- 10% wall-plug efficiency
- Maintenance free operation
- Compact, rugged air-cooled package
Applications:
- Marking
- Trimming
- Micromachining
- Precision Drilling
- Welding
- Cutting
|
|
|
|
|
|
The YLP Series high energy series of pulsed fiber laser is designed to be easily integrated into OEM applications, such as marking, drilling or machining systems. It delivers high peak power (up to 25kW) and high average power (up to 200W) in 400 nanosecond pulse durations. The increased power levels allow you to work more efficiently and use thicker materials.
These lasers embody all of the advantages of IPG's fiber laser technology including compactness, high efficiency and reliability at a reasonable price. The 100% solid state design is robust, maintenance-free and requires no consumables.
Like IPG's other industrial pulsed lasers, this laser is based upon IPG's ultra-reliable pumping technology and comes with a heavy duty optical isolator that improves output pulse stability and eliminates back reflection.
Main Features:
- Up to 10mJ energy per pulse
- Up to 200 W average output power
- 400 ns pulse duration
- Output optical isolator
- Output power tunability 5-100%
- High beam quality M2~10
- Maintenance-free operation
Applications:
. Marking
. Trimming
. Micromachining
. Precision Drilling
. Welding
. Cutting
|
|
