| Density influences the overall quality of manufactured products and density measurements guide the manufacturing process. For this reason, Micromeritics gas pycnometers are used worldwide to characterize raw materials as well as to determine the density of finished products. |
|
The new digital density meter DS7000 gets along with only 0,3 ml of sample quantity!
Additionally the density meter convinces with a measuring accuracy never seen before: in the measuring range of 0.00000 – 1.99999 g/cm³ the measuring accuracy is 0.00005 g/cm³. Whether you want to measure density, specific gravity or the concentration of liquid solutions: by this highly precise measuring instrument you receive results with 5 digits behind the comma. And even better: You receive your measuring result in only 1 second!
Behind these improvements stands a new-developed micromechanical measuring cell which needs only 80 µl of sample volume and provides an integrated temperature measurement of the sample.
Further features: built-in Peltier thermostat ensures precisely regulated temperature with a repeatability of +/- 0.02 °C, calibration certificate in accordance with N.I.S.T. density standard, particularly suitable for application fields in the GLP/GMP range, user-friendly touch-screen operates in 6 languages, interfaces RS232 and Ethernet, LIMS and printer connections.
990 programmable customized measuring methods (9 preset). The SQL data base thus stores and controls 999 results for you. Individual user management with separate passwords can be programmed.
The DS7000 can be used in a widespread range, e.g. for determination of mixing ratios, quality and quantity inspections. Operational fields are among others the chemical industry, pharmaceutical and cosmetics industry, breweries and beverage manufacturers, sugar and sweet material industry, pulp and paper industry, electronic industry, petrochemical industry and waste water management. |
|
Micromeritics new AccuPyc II 1340 Gas Displacement Pycnometry System are fast, fully automatic analyzers that provide high-speed, high-precision volume measurements and density calculations on a wide variety of materials. The AccuPyc completes most analyses in less than three minutes with excellent accuracy by using a gas displacement technique to determine absolute density of powders, solids, and slurries having volumes from 0.01 to 350 cm3.
The instrument can be operated with a keypad or an optional Windowsâ interface that provides exceptional reporting and archiving capability. Both versions include direct sample mass input from a balance and cycle-based displacement volume reporting. With the Windows interface, features such as time-based pressure equilibration reporting and additional calculations such as percent solids content and total pore volume are included.
For those who require high throughput, an integrated control and analysis module can control up to five additional external analysis modules. Each module can have a different size sample chamber (1 cm3, 10 cm3, 100 cm3, 350 cm3) providing even more versatility.
A multivolume option allows analysis of a variety of sample sizes in a single analysis module. A temperature-controlled version of the analysis module performs analyses at user-selectable temperatures.
|
|
| Thermo Scientific gas and liquid density meters measure density or density related variables within the oil and gas, petrochemical, chemical, food and beverage, and general process industries. These highly accurate, online, continuous meters use a proven vibrating element design to provide key information for process monitoring and control, quality control, product interface detection and custody transfer applications. With a twin tube design that is inherently more stable than single tube technology, the meters detect any variation of process constituents or final product quality in near real-time to improve productivity, minimize product waste and reduce costs when compared to sampling methods. The compact, lightweight meters are also easy to install without upstream flow conditioning or instrument supports. Once installed, the straight-through sensor offers an unobstructed flow path to ensure minimal pressure drop and higher flow rates. With hazardous area approvals and secondary containment on all models, these durable instruments withstand tough industrial environments to ensure a significant return on investment. |
|
The contactless and continuos measurement of the density of liquids or bulk material is requested in even more than the following applications:
Concentration measurement of acid, alkali, saline solution and suspension
Crystallisation and polymerisation monitoring
Determination of the solid matter content in slurries, in flue gas desulphurisation suspensions, in aluminium production and in mining
Measurement of the bulk density in washing powder and clinker
|
|
| The UGC Vibrating Densitometer accurately measures the density of a flowing fluid at actual operating conditions. This Densitometer was primarily developed for extremely accurate fluid metering (custody transfer), plus many other applications, such as pipeline interface detection, blending, process control, etc. The frequency output of the Vibrating Densitometer is compatible with most flow computers. |
|
Density Meter Series DIMF 2.0
Swagelok-screw joints, flange DN 15 PN 40, milk threads according to DIN 11851 PN 10
accuracy ± 0,2 kg/m³
reproducibility 0,05 kg/m³
operating temperature according to design -40°C to 210°C Accessoires
electronical transmitter
pre-amplifire
strainer
gas separator
processing peripherals
Density Meter Series DIMF 2.1
flange DN 25 / 50 PN 40
accuracy ± 0,2 kg/m³
reproducibility 0,05 kg/m³
operating temperature according to design -40°C to 150°C |
|
| The DENSITRAK® Model D625 liquid density meter utilizes the spring mass principle for measuring the fluid density. A portion of the "u" tube is energized to vibrate at its natural resonant frequency by using an electrical feedback driving system. A change in the vibrating mass, (as a result of change in the fluid density) shifts the resonant frequency. A CSI SPUD signal processing unit for density uses temperature, pressure and the shift in frequency to determine the density of the measured fluid. |
|
Digital density meters measure density, specific gravity and other related values (I.e. alcohol%, BRIX°, API degrees) with high precision and short measuring time.
Measuring principle:
A hollow glass tube vibrates at a certain frequency. This frequency changes when the tube is filled with the sample: the higher the mass of the sample, the lower the frequency. This frequency is measured and converted into density.
Benchtop instruments are equipped with a built-in Peltier thermostat to control the temperature (no water bath required). |
|
Applications
: In-line density measurement of liquids or multiphase-mixtures
Special features:
Reliability
Robust construction with magnetic transmission of measured values.
Can be used in hazardous areas.
No by-pass required
Wide and clear scale
|
|
The Wallace High Precision Densimeter is a cost efficient inspection instrument, calculating an accurate measurement of specific gravity. With a scale capacity of up to 300g and specific gravity resolution to three decimal places. The X22B is ideal for the inspection of rubber, plastic, sintered metals, glass and ceramics, foods and other materials. Using the optional liquid measuring kit the specific gravity of a liquid can be determined.
The innovative design makes specific gravity measurement simple and results are displayed after an elapsed time which varies according to the mode selected. Zero and tare are set through touch button operation on the front panel. The angle accessory (supplied as standard) enables samples with an SG of less than 1, to be tested. Compensation for temperature and for fluids other than water can be set by the operator. A built-in accuracy check is a standard feature so that if sample weight is insufficient, the final digit will flash. A wind shield is provided to protect the instrument from draughts and dust during operation.
Also available: X21 C with resolution to four decimal places |
|
| ... products without technical information |
| |
Pycnometer, Model 290
To measure the density of coating materials and similar liquids. Robust and light weight design, made of black anodized aluminium, or alternatively, stainless steel. Available for 50 or 100 ml capacity, also with official calibration certificate. |
|
PART # SBS-2500
DIGITAL SPECIFIC GRAVITY TESTER
Battery testing has never been this easy. Simply insert the nozzle of the digital hydrometer into the battery, depress the finder pump, and extract a few drops of electrolyte. Touch one button and the processor does the rest. Within seconds you have an accurate reading of temperature compensated specific gravity and electrolyte temperature.
Field studies show time savings of at least 5 times (500%) using the SBS-2500 Digital Hydrometer over a standard glass hydrometer and thermometer.
This digital hydrometer will log up to 1,100 individual S.G. & temperature readings that can later be uploaded to a laptop or PC running the included software
ADDITONAL PARTS:
SBS-2500 O-RING
SBS-2500 SAMPLE PUMP
SBS-2500 PRINTER
SBS-2500 TUBE/WASH
SBS-2500 SPARE PARTS KIT
SBS-2500 CASE
SBS-2500 CD
SBS-2500 LIGHT
SBS-2500 LIGHT BATTERY
SBS-2500 COMM CABLE
SBS-2500 ADAPTER |
|
PART #SBS-2002
DIGITAL SPECIFIC GRAVITY TESTER KIT
Battery testing has never been this easy. Simply insert the nozzle into the battery, depress the finder pump, and extract a few drops of sulfuric acid (H2S04) electrolyte. Touch one button and the processor does the rest. Within three seconds you have a temperature compensated accurate reading of specific gravity and temperature.
Field studies show time savings of at least 5 times (500%) using the SBS-2002 Digital Hydrometer over a standard glass hydrometer and thermometer.
ADDITIONAL PARTS:
SBS-2002 KIT SPARE PARTS KIT
SBS-2002 SAMPLING TUBE
SBS-2002 O-RING GASKET
SBS-2002 HOLSTER W/BELT
SBS-2002 CALIBRATION
SBS-2002 CALIBRATION CERTIFICATE |
|
For density measurements on:
- milk, fruit juice, other food liquids
- oil products
- colours, paints
- galvanic baths
- pharmaceutical and cosmetics products
Features:
- Accuracy and readout: 5 x 10-5
- Net weight: 7,5 Kg
- Autocalibration with internal calibration mass
- Range of the relative density measurement: 0.5-2.25
- Termometric probe Pt 100 1/3 DIN, accuracy ± 0.05 °C, readability 0.1 °C
- Availability of grams readout
- RS 232 serial output
- Mains supply voltage: 220 V -15% /+10% 10 VA
- Dimensions: W210xD355xH350 mm
- Metrological approval
|
|
Density/Specific Gravity/Concentration Meter - DMA 4500
The DMA 4500 was built to measure round the clock. Its rugged design and minimum required lab space make it a welcome addition to any lab.
The patented reference oscillator (AT 399051) allows measurement immediately after changing the measuring temperature, so you don't have to wait for long periods of time between measurements.
The DMA 4500 requires only 40 seconds to measure each sample, increasing the efficiency in your lab. Connect a sample changer to automate filling and cleaning procedures, freeing lab personnel for other tasks. |
|
| The compact, rugged Thermo Scientific SGD-O is the most reliable non-contacting density gauge for monitoring fluid density, including PPG, PPA and SGU, in the oilfield during fracturing and cementing. Capable of enduring high shock and vibration yet lightweight, this advanced device features rapid response and high accuracy to improve consistency, safety and overall performance. Engineered to withstand the extreme moisture and high humidity of oilfield environments, it rapidly indicates variations in slurry density and proppant concentration during fracturing and cementing operations. The SGD-O is comprised of three components: the source and detector work together to measure the fluid density while the remotely located electronic transmitter provides a clear digital display of the measurement. This advanced gauge measures through any pipe thickness, with the detector providing response in three to five seconds and accuracy of ±0.1 pounds per gallon. The transmitter can be mounted up to 100 feet away from the gauge to ensure worker safety. It can be powered by a readily available 12 or 24 volt power supply and features quick disconnect connectors for cable and transmitters. The SGD-O is also easy-to-install and use and has minimal maintenance requirements. |
|
Concentration, Water Content and Dry Substance measured by microwaves
Your Advantages:
High selective sensitivity to water
High accuracy and long-term stability
even for difficult products
Simple installation, insertion directly
on the existing pipelines, vessels, chutes etc.
Simple start-up, system supported sample taking,
automatic calibration and graphic display
Accurate and reliable measurement
due to two highly stable PLL-synthesizers
and multi-frequency technology
Durable sensor measuring cells with wear resistant
smooth walled PTFE lining
Contactless measuring cell without installed
measuring antenna
High operational safety and standards of quality |
|
| Das batteriebetriebene tragbare Dichtemessgerät ist weltweit das meistverwendete dieser Art. Entwickelt für den Einsatz im anspruchsvollen industriellen Alltag, misst das DMA 35n Dichte, relative Dichte sowie diverse Konzentrationen (z.B. Alkohol oder API-Zahl). Alle Messergebnisse sind temperaturkompensiert. Über eine Pipettenpumpe wird die Messzelle befüllt. Sekunden später erscheinen die Ergebnisse. |
|
| ... products without technical information |
| |
|
|
