The RX3G is a PLL synthesiser based miniature PCB mounting UHF radio data receiver. With the matching TX3B-869-64 transmitters, RX3G allows the simple implementation of wireless data links at speeds up to 64kbps and distances up to 75 metres in-building or 300 metres over open ground.
* Designed to comply with harmonised radio standard EN 300 220-3
* Designed to comply with harmonised EMC standard EN 301 489-3
* Data rates up to 64kbps
* Usable range up to 300m
* Versions available on 868.3MHz, 869.5MHz and 869.85MHz
* Regulated and Unregulated versions available
* Fully screened
* Improved blocking performance
* Fast data settling time
Available for operation at 868.3MHz, 869.5MHz and 869.85MHz in Europe, the RX3G combines full screening with internal filtering to ensure EMC compliance by minimising spurious radiation and susceptibility.
The module suits one-to-one and multi-node wireless links in applications including car and building security, EPOS and inventory tracking, remote industrial process monitoring and computer networking. Because of the small size and low power requirements, the RX3G is ideal for use in portable, battery-powered wireless applications such as hand-held terminals.
|
|
The TH71112 FSK/FM/ASK double-conversion superheterodyne receiver IC is designed for applications in the European 868 MHz industrial-scientific-medical (ISM) band, according to the EN 300 220 telecommunications standard. It can also be used for any other system with carrier frequencies ranging from 750 MHz to 990 MHz (e.g. for applications according to FCC part 15).
|
|
|
|
|
|
Code hopping receiver with up to 5 relay outputs
KDEC is designed to provide the user with a complete receiver interface for Radiometrix transmitters such as KTX2 and KFX2. No additional parts needed to implement a complete system suitable for applications requiring high security RF remote control.
Boards are pre-programmed to process messages from code-hopping transmitters and includes a high-performance UHF or VHF FSK receiver module.
The board has relays and screw terminations so that you can realise your own secure control application immediately.
There are momentary and latching modes and user-select KTX or KFX optimisation modes. Press the “Learn” button, initiate a transmission from your KFX2 or KTX module and the “Learn” indicator will flash to show that the KDEC will now act upon controls received from your transmitter.
Features
* Up to 5 relays to control mains powered devices rated up to 8A, 250VAC/30VDC
* Volt-free changeover contacts
* Learn button - remembers up to 16 different transmitters
* Remembers transmitters when switched off
* Visual indication of Learn function
* Visual indication of low supply voltage at the Transmitter
* Visual indication of activated relays
* Momentary or Latched outputs
* Basic antenna included - setup is simple Plug-and-Play
* Receiver module on-board
* Terminal block to connect external power supply
* SMA RF connection
* 9 – 16VDC supply
Applications
* RF interface for Security and Alarm systems
* Status reporting and monitoring secure systems
* Industrial controls
* HVAC controls
* Wireless door entry systems
* Simple On/Off switching
|
|
|
|
|
|
Leica GRX1200 Series
High Performance GNSS Reference Receivers
The Leica GRX1200 Series, part of Leica’s new System 1200, is designed specifically for use at reference stations. With these new receivers, GNSS reference stations be-come more accurate, more powerful, more versatile and more reliable than ever be-fore, yet they are easier to set up and operate.
SmartTrack+ Best GNSS and RTK technology
The Leica GRX1200 Series incorporates an ultra-precise GNSS (Global Navigation Satellite System) measurement engine that supports both GPS and GLONASS - benefit from up to 100 % more satellites than GPS alone.
Acquisition within seconds
Excellent signal strength
Reliable tracking to low elevations
Suppresses phase and code multipath
Jamming resistant
Top quality GPS and GLONASS measurements up to 20 Hz
Totally reliable
Low power consumption
Receivers of Leica GRX1200 Series
GRX1200 Pro with Ethernet port and external frequency input
GRX1200 GG Pro – GNSS receiver with Ethernet and frequency input
|
|
Ready to use radio modules make life easier for the design engineer who has to develop a complete system containing a radio link. Radio modules are an interesting option for low to medium quantities up to several 1000 pcs per year.
Thanks to our SMD production plant we also have optimized parameters according to the customers need. We support you individually in integrating the modules successfully into the final application.
|
|
Radiofrequency keyfobs transmitters, AM & FM transmitter ideal for gate door opener, burglar alarms, personal security and remote controls.
FM (FSK/ ASK) Super-het low cost receiver of modulated digital data, working at 433.92 MHz frequency. High selectivity and sensibility obtained by SAW filter. Output voltage is low when no carrier is on air.
|
|
|
The RCR-315-EPR high performance RF receiver modules offer an extremely low cost solution for remote control type applications. The receivers are compatible with almost any ASK or OOK data transmitter and can receive legally transmitted signals from distances as far away as 600 feet. The receivers operate at 5V and draw only 4.5mA. The receiver is industrial temp spec -40C to 85C.
|
|
austriamicrosystems offers a high performance, low power UHF transmitter for wireless data transmission between 300 and 1000 MHz and a low power LF wake-up receiver supporting operation between 19 and 150 kHz.
|
|
ECEPTEUR FOR MOBILE SYSTEMS
9 Automobile standard relays TOR + 1 relay of safety + extension 4 analogical ways.
Leger: 2,5Kg.
Electronic key of appairage.
FOOD AVAILABLE:
12 or 24 Vcc
MECHANICS:
Painted aluminum case, IP 65.
Dimensions: 220 X 120 X 90 mm, mass: 2,5 kg
EXITS:
8 relays + 1 from safety and 1 affected with the function Work/Klaxon + extension 4 ways analogical.
Automobile standard relay, 15A, 250Vca.
Consumption: 150mA by relay.
OPTIONS:
Industrial connectors (10, 16,24 or 32 points) + wiring.
COMPATIBLE TRANSMITTERS:
RC7, RC11, RC13, RC20, RC20ATEX, RC30.
|
|
| ... products without technical information |
| |
|
|
|
|
The RX3G is a PLL synthesiser based miniature PCB mounting UHF radio data receiver. With the matching TX3B-869-64 transmitters, RX3G allows the simple implementation of wireless data links at speeds up to 64kbps and distances up to 75 metres in-building or 300 metres over open ground.
* Designed to comply with harmonised radio standard EN 300 220-3
* Designed to comply with harmonised EMC standard EN 301 489-3
* Data rates up to 64kbps
* Usable range up to 300m
* Versions available on 868.3MHz, 869.5MHz and 869.85MHz
* Regulated and Unregulated versions available
* Fully screened
* Improved blocking performance
* Fast data settling time
Available for operation at 868.3MHz, 869.5MHz and 869.85MHz in Europe, the RX3G combines full screening with internal filtering to ensure EMC compliance by minimising spurious radiation and susceptibility.
The module suits one-to-one and multi-node wireless links in applications including car and building security, EPOS and inventory tracking, remote industrial process monitoring and computer networking. Because of the small size and low power requirements, the RX3G is ideal for use in portable, battery-powered wireless applications such as hand-held terminals.
|
|
The TH71112 FSK/FM/ASK double-conversion superheterodyne receiver IC is designed for applications in the European 868 MHz industrial-scientific-medical (ISM) band, according to the EN 300 220 telecommunications standard. It can also be used for any other system with carrier frequencies ranging from 750 MHz to 990 MHz (e.g. for applications according to FCC part 15).
|
|
|
|
|
|
Code hopping receiver with up to 5 relay outputs
KDEC is designed to provide the user with a complete receiver interface for Radiometrix transmitters such as KTX2 and KFX2. No additional parts needed to implement a complete system suitable for applications requiring high security RF remote control.
Boards are pre-programmed to process messages from code-hopping transmitters and includes a high-performance UHF or VHF FSK receiver module.
The board has relays and screw terminations so that you can realise your own secure control application immediately.
There are momentary and latching modes and user-select KTX or KFX optimisation modes. Press the “Learn” button, initiate a transmission from your KFX2 or KTX module and the “Learn” indicator will flash to show that the KDEC will now act upon controls received from your transmitter.
Features
* Up to 5 relays to control mains powered devices rated up to 8A, 250VAC/30VDC
* Volt-free changeover contacts
* Learn button - remembers up to 16 different transmitters
* Remembers transmitters when switched off
* Visual indication of Learn function
* Visual indication of low supply voltage at the Transmitter
* Visual indication of activated relays
* Momentary or Latched outputs
* Basic antenna included - setup is simple Plug-and-Play
* Receiver module on-board
* Terminal block to connect external power supply
* SMA RF connection
* 9 – 16VDC supply
Applications
* RF interface for Security and Alarm systems
* Status reporting and monitoring secure systems
* Industrial controls
* HVAC controls
* Wireless door entry systems
* Simple On/Off switching
|
|
Ready to use radio modules make life easier for the design engineer who has to develop a complete system containing a radio link. Radio modules are an interesting option for low to medium quantities up to several 1000 pcs per year.
Thanks to our SMD production plant we also have optimized parameters according to the customers need. We support you individually in integrating the modules successfully into the final application.
|
|
Radiofrequency keyfobs transmitters, AM & FM transmitter ideal for gate door opener, burglar alarms, personal security and remote controls.
FM (FSK/ ASK) Super-het low cost receiver of modulated digital data, working at 433.92 MHz frequency. High selectivity and sensibility obtained by SAW filter. Output voltage is low when no carrier is on air.
|
|
|
The RCR-315-EPR high performance RF receiver modules offer an extremely low cost solution for remote control type applications. The receivers are compatible with almost any ASK or OOK data transmitter and can receive legally transmitted signals from distances as far away as 600 feet. The receivers operate at 5V and draw only 4.5mA. The receiver is industrial temp spec -40C to 85C.
|
|
austriamicrosystems offers a high performance, low power UHF transmitter for wireless data transmission between 300 and 1000 MHz and a low power LF wake-up receiver supporting operation between 19 and 150 kHz.
|
|
| ... products without technical information |
| |
|
When it says future proof GNSS, it means maximum productivity and reliability. More satellites, more GNSS signals. Today and tomorrow! With Leica GPS1200+ you can be certain that you’re ready for the future. Invest today in future proof GNSS technology and be sure that your equipment can track all satellites today and tomorrow. GPS1200+ is the only real future proof GNSS System.
|
|
|
|
|
|
Trimble R6 GPS System - A Base Station and Rover Receiver for RTK GPS / GNSS Surveying
The Trimble® R6 GPS System is a multi-channel, multi-frequency GPS receiver, antenna, and data-link radio combined in one compact unit. An R-Track technology option provides GLONASS augmentation to the Trimble R6 GPS solution. Use the Trimble R6 for RTK or static surveying, or in a Trimble VRS™ infrastructure network. The Trimble R6 is ideal for multiple surveying applications, including topographic, cadastral, and stakeout.
Your Competitive Edge Is the Trimble "System"
The Trimble R6 offers industry-leading GPS receiver technology in a proven rover/base design that's lightweight, rugged and cable free. All system components-including the receiver, controller and field and office software-are designed to work together.
Trimble Integrated Surveying
The Trimble R6 GPS system seamlessly integrates with complementary technologies on the job site. Trimble software such as Trimble Survey Controller receives GPS and optical data in one job file for effortless transfer. The Trimble R6 also functions as a Trimble I.S. Rover, and works optimally as part of a GNSS infrastructure solution.
|
|
|
|
|
|
The Trimble® SPS550H GPS Receiver is a heading add-on receiver that can be connected to another primary Trimble SPS550, Trimble SPS750 (Max) or Trimble SPS850 GPS Receiver so the precise heading from dual Global Positioning System (GPS) antennas can be output. The heading is determined no matter whether the primary GPS is receiving differential corrections or not. This is the ideal add-on receiver for construction projects that require precise orientation of a structure or a vessel-for either placement or for removal tasks.
Features and Benefits:
-Affordable, lower price point of entry for GPS Heading
-No moving parts ensures service-free operation compared to a mechanical gyro compass
-Continuous operation even when primary GPS is not receiving satellite corrections for reduced downtime and increased productivity
-Can be paired with another Trimble SPS550 GPS Receiver, Trimble SPS750 (Max) GPS Receiver, or Trimble SPS850 GPS Receiver for added flexibility and reduced costs
-Dual Site Positioning System GPS receiver mounting bracket, interconnecting cable and antenna included for a compact, rugged system
Applications:
-Dredging and marine piling
-Oil rig positioning
-Rock dumping for sub-sea pipeline construction
-Harbor construction
|
|
An all-in-one model placing importance on mobility in RTK-GPS work. Simple equipment changes RTK-GPS work. TOPCON's unique GNSS technology is naturally incorporated. The GGD and GGDM types can receive signals from the GPS and GLONASS satellites. Stable signal reception under adverse condition and fast initialize time promise an enhanced efficiency of RTK-GPS.
All-in-one GNSS receiver
The GDM and GGDM types contain a receiver, antenna and batteries, as well as small-area radio for reception's are superb all-in-one receivers exceeding RTK-GPS. Just connect the controller to the simple configuration and complexity of cable connection is eliminated. Excellent mobility is assured.
Small area radio contained (GDM and GGDM types)
A wireless modem needed for RTK-GPS is contained. A small area radio with a longer communication distance compared with specified low power radio stations is incorporated. Only a report is needed. License is no longer needed.
|
|
Mikrofyn Laser Receivers
A laser receiver system consists of two primary components - a rotation laser and a laser receiver mounted on the machine. MIKROFYN offers just the right receiver for your needs, and they are all very simple to operate.
The MD 40 and MD 10 Laser Receivers can be combined with our various Machine Control systems.
In a number of countries we can also deliver the MD 3 Laser Receiver, which features plum indicators for increased accuracy.
|
|
| ... products without technical information |
| |
|
|
