THE LUNEBERG REFLECTOR
The Luneberg reflector significantly increases the Radar Cross Section of any system which has little or none at all.
Its Radar Cross Section is several hundred times the RCS of a metallic sphere of same diameter.
TRIHEDRAL REFLECTORS
ACTIVE RADAR REFLECTOR
Integration of amplifiers with wide band antennae (1–18GHz), and adjustable gain in order to adjust RCS
* antenna with specific polarization and aperture
* amplifier with low noise
* filters: highpass – lowpass – band pass – stopband, alone or combined together
* programmable attenuator
Applications:
Target and drone equipment, radar calibration, navigation aid
|
|
| ... products without technical information |
| |
Model KR1228 has a Red LED and a photo transistor with non-sphere lens on emitter and detector. This model has high resolution function and As a series, Shinkoh Electronics can provide KR1226(red point light), KR1227(IR point light), KR1229(IR bar light).
Feature
1.High resolution(0.25mm at distance/5mm)
2.Red bar light
Application
1.Bar-code reader
2.Paper edge detection
3.Mark detection of OMR and OCR
|
|
Model KR865 consists of an Infra Red LED and a light modulation type of Photo IC, and has one piece seamless plastic housing. As a series, Shinkoh Electronics can provide KR866, KR895, KR1207 having function of light modulation and KR864, KR894 having Direct Current function.
Feature
1.Long detecting distance(7-25mm by 90% reflective paper)
2.Dust protection housing
3.Light modulation
Application
1.Paper detection in OA equipments
2.Coin/Object detection in Vending machines and banking machine
3.Other industrial instruments
|
|
Model KR1571 consists of an ultraviolet LED and silicon photodiode. KR1571 is specified for detecting visible light reflected from fluorescence of object by UV light. As a series, Shinkoh Electronics can provide KR1570 which does not have visible light cutting filter on emitter.
Feature
1.Peak wavelength 365nm
2.Visible light cutting filter on emiiter
3.UV light cutting filter on detector
4.Cylindrical lens installed
Application
1.Banking Machine(Bill validator and Bill discrimination)
2.Industrial machine handling relevant documents or governmental documents
|
|
|
|
