Stationary and mobile RFID read/write devices
RFID technology provides the optimum complement to optical systems. The benefits of RFID are brought to bear particularly in hostile environments involving dirt, moisture, low or high temperatures. This technology permits not only in-process reading but also writing (updating) of data. The product portfolio encompasses reading devices working at different ranges and frequencies (125 kHz and 13.56 MHz) as well as the relevant transponders (up to 200°C).
|
|
The ExploreR-HF RFID reader represents a new standard in ultra compact lightweight RFID devices that can be deployed in wireless or wireline environments connecting in a plug and play manner to host computers, handhelds, phones and smart phones.
The device is housed in a credit card sized case (50 x 80 x 13 mm) and weighs little more than 50 grams. It fits conveniently into a shirt pocket and snugly into the palm of your hand.
Combined with Tracient's TraceConnect software suite this product can be up and running in minutes. Bluetooth connectivity makes it a perfect retrofit option for businesses that want to add value to their investment in handheld technology.
Alternatively the USB interface allows for static mounting on a wall or counter for tagged items to be read in proximity. The device is also available as a basic variant without Bluetooth.
The Explore-R HF reader operates with industry standard RFID HF tags at 13.56 MHz and is ideal for Near Field Communications (NFC) type applications. |
|
Turck offers a so-called handheld (programming device) for mobile reading and writing of data carriers.
Thus all BL ident data carriers are easily programmable.
The data is displayed on an illuminated touchscreen (display in decimal, binary, hexadecimal and ASCII code), simple editing and recording of the corresponding data carriers is also possible.
Optional features are WLAN, bluetooth, GPRS and barcode scanner. |
|
Tracient Technologies develops and manufactures HF and UHF RFID readers designed specifically for hand held operation. The readers are wireless, enabling workers to electronically capture information where fixed RFID readers or Barcode readers are not available or not as effective.
The Padl-R UF RFID reader and the Padl-R HF RFID readers share the same form factor and basic functionality. They are lightweight (135g, 4 oz), ergonomic and have a good battery life, lasting in most cases a full 12 hour shift. With just one button they are simple to use, making them suitable for workers of all skill levels.
The Padl-R UF reader reads all Gen2 UHF tags from 862 – 955 MHz. The Padl-R HF reader reads standard 13.56 MHz tags including ISO 14443, ISO 15693, ICODE and Mifare.
The readers are readily paired via Bluetooth with a wide variety of wireless handheld PDAs including Symbol, Psion Teklogix, Intermec, Datalogic, LXE and many more. Alternatively they can be connected via Bluetooth or USB to a laptop or desktop computer.
Their Bluetooth connectivity makes them ideal as a retrofit option for companies that already own handheld devices, effectively maximizing the life of their existing equipment. When matched with new low to middle tier PDAs or smart phones the readers often provide a cheaper mobile RFID solution than RFID embedded devices. This makes them a cost effective option for businesses wishing to test their RFID business case or start their migration from Barcodes to RFID.
The readers are ideal for tracking and monitoring mobile assets, inventory management and mobile field service applications. |
|
RD5000 Mobile RFID Reader
Extend the reach of your RFID network and achieve a new level of visibility into inventory and assets with the RD5000 Mobile RFID Reader. The compact, rugged reader can be installed almost anywhere - on material handling equipment such as forklifts, on mobile carts, portable skate wheel conveyors or even in hard to reach places where a cabled fixed reader would not be practical.
Designed for true mobility and mobile applications, the device provides wireless LAN connectivity so product is easily tracked as it moves throughout your operations. The result is granular real-time information - allowing you to achieve a new level of productivity and efficiency throughout your enterprise. |
|
Features:
- 13.56 MHz Contactless Smart Card. Ability to add a magnetic stripe, barcode, anti-counterfeiting feature, custom artwork, or photo ID.
- 13.56 MHz HID proximity reader (read only) Slim design is perfect for metal mullions or any other space-limited installation. |
|
The new Omni-Access reader line is in-tune with the demands placed on modern architecture. Their contemporary design, in two shades of stainless steel, adds a subtle but elegant accent to their surroundings.
The readers, designed for secure and reliable access control, offer a broad variety of functionalities and technologies. They are ideal for mounting on door frames.
Choose either the Mifare or EM proximity technology with optional pin pad for access security.
|
|
Low Frequency (LF) RFID (125 kHz) LF has a long history (20 years) of being used in industrial environments, as well as in animal tracking/tagging applications.
Escort Memory Systems offers the RS line of LF Read-Only RFID Readers and ES Tags. This rugged line has been used for years by industries such as textile manufacturing, automotive and more.
Tags can be pre programmed with specific IDs based on customer requirements. Once in place these systems have the reputation of needing very little maintenance and they consistently perform in industrial conditions.
Low Frequency Series Features
- Less susceptibility to the effects of metals liquids and other nearby elements compared to frequencies like HF and UHF.
- Extremely robust.
- Read range of up to two feet.
- Single tag read-only systems. |
|
HF Antennas
Escort Memory Systems offers HF RFID systems with a track record of performing consistently in industrial applications. Mounted alongside conveyers, under forklifts and at intersection points the variety of form factors, high levels of connectivity, and integrated intelligence put you in control of your data capture application.
Our HF Controller/Antennas include the Cobalt HF, LRP, and HMS Series.
Features include:
- Integrated Controller/Antenna Designs
- Conveyer style antennas designed to fit in between the metal rollers on a conveyer
- Short range tubular remote antenna heads
- Mobile handheld RFID models
- Large, multiple tag in field, plate-style antennas
- Built-in Macro intelligence allows each reader to act as an independent thinker, making logical decisions based upon the data it reads
Cobalt HF Series
- Integrated controller/antenna design
- Reads/Writes to all LRP and HMS tags as well as other vendors ISO15693 tags
- Wide variety of Antenna sizes from 10cm to 30cm and conveyor types
- C-Macro logic drives intelligence down to the point-of-use unloads factory network, and simplifies building and maintaining RFID applications operating on PLC's
- Software-The Dashboard; a Windows PC-based lets users configure, debug and maintain Cobalt HF™ products and networks
- An expanded command set called CBx builds on the familiar ABx Fast command set used by previous generations of Escort Memory Systems products and is backward compatible |
|
Features
- Industrial UHF Solutions
- Long range antennas capable of reading EPC Gen1 and Gen2.
- UHF tags capable of surviving the harshest industrial applications and environments.
UHF systems feature long range, and high speed read/write rates. Small antennas and even smaller tags have proven this to be an effective frequency for tracking pallets through dock doors, as well as trucking and transportation applications. Industrial UHF applications have also begun to effectively be developed for tracking parts, product and carriers through production. For industrial applications involving significant environmental obstructions HF is a preferred frequency.
Escort Memory Systems offers Industrial UHF Solutions including long range antennas capable of reading EPC Gen1 and Gen2. EMS has supplemented its UHF reader offering with ruggedly engineered UHF tags capable of surviving the harshest industrial applications and environments. |
|
LockToo Reader is an inspecting device of extremely advanced autonomous access. Developed around one of the optical sensors most powerful of the market, it also has a screen LCD as well as keyboard making its use intuitive and convivial.
Integrating up to 3 technologies of identification - Biometrics and/or RFID and/or Code -, it offers a wide pallet of functionalities and guarantees a total security and an optimal comfort of use to you.
Without PC nor software, you record the prints of the users and encodez their badges directly on the reader. |
|
| rmec's fixed readers are not only configurable using either single- or multiple antenna setups, they're smart. From reading pallets to cartons on high speed conveyor belts, fixed readers provide data filtering and control of peripherals for effective, accurate RFID supply chain management. |
|
AN200 RFID Antenna
Motorola's general purpose AN200 RFID antenna can be used reliably in a wide range of indoor and outdoor environments from the warehouse to the production line to the docking zone.
The rugged design withstands environmental conditions such as extreme heat and cold, as well as moisture and vibration making this antenna ideal for nearly any application. The AN200 Antenna can be used in both standard RFID applications at power levels of up to 1 watt and in customized applications at power levels up to 20 watts. |
|
| Joining the diverse line of RFID readers are the Intermec RFID antennas, including antennas specifically designed for fixed applications as well as vehicle mount applications where shock and vibration can far exceed average industry specifications. |
|
| ... products without technical information |
| |
The Indala 125 kHz Standard product line is part of HID's latest line of highly-secure proximity readers. With a read range of up to five inches, Indala Standard Proximity readers are suitable for a variety of applications. These high-quality Indala Proximity Readers deliver outstanding and consistent performance with intelligent programming technology, uniform core modules, and a range of stylish bezel designs including Curve, Arch, Linear, and Wave in a variety of colors. All Indala Standard Proximity readers are available in three popular form factors: Classic, Mullion (Slim) and Wallswitch for the ultimate choice.
Exclusive FlexSecur® Security Technology.
All HID Indala 125 kHz Proximity Readers feature FlexSecur technology, which provides an added level of access system security through a verification process at the reader. A feature unique to the HID Indala product line, FlexSecur screens out unauthorized cards prior to sending access control data to the host system.
Indala FlexSecur® Technology for the Industry's Most Secure Proximity Readers - Exclusive Indala FlexSecur® Password-Protected Security between card and reader screens out unauthorized cards prior to sending access control data to the host system.
Superior Format Control for the Most Application Choices - Requirement - The HID Indala Proximity portfolio includes classic, mullion/slim, wallswitch, mid-range, long-range, and heavy-duty keypad readers for every application.
Classic Reader:
- Uniquely designed to replace a Wiegand Reader.
- Dimensions are the same as the Classic Wiegand Swipe reader. Mounting holes match.
- Ideal for transitioning existing Wiegand users to proximity.
Mullion (Slim) Reader:
- Can be mounted on any wall where limited space is an issue or where a slim, modern look is preferred to a wallswitch-size reader.
- Ideal for mounting on door frames.
- Suitable for indoor or outdoor use.
Wallswitch Reader:
- The Wallswitch reader is similar in size to most U.S. switch plates.
- Wallswitch reader can be mounted on a single gang box.
- Suitable for indoor or outdoor use. |
|
SB02 SMARTCARD READER
Making it easy for companies to monitor employee work-time
Many organizations need to be able to monitor their employees’ work-time. SB02 is a complete clocking solution designed to meet their need for ease-of-use and accuracy, allowing companies, municipalities and associations of all kinds to setup efficient and reliable systems for monitoring staff presence.
* Smartcard reader available for RS-232, Ethernet or Modem connections
SB02 uses contactless smartcard technology (RFID) to read employees’ cards as they pass by the reader, thus recording their time of entry or exit. Using the provided SL01 or SL02 software, administrators can setup their own solutions and data collection methods (manual or automated).
* SB02 readers are designed specifically for software integrators who wish to include clocking features in their time management applications. |
|
