Orbitform Group's line of orbital bench machines are modular and designed for tabletop use across many industries and applications. The flexible design allows components to be added to support many applications.
Bench Machine Features:
Orbitform Group's line of bench machines contain a solution for a wide range of applications. Features of their reliable and durable construction include:
-Precise forming of .06" to .75" (mild steel) finished head diameter or equivalent cross section
-Max downward force ranging from 590 lbs to 7510 lbs
-Adjustable stroke ranging from .06" to 6.00"
-Vertiacal head height adjustment from 5" to 10" (127-254mm)
Orbital bench machines are available with many options and capacities to fit your specific application. These modular machines are available in single, multi-form or roller form configurations.
Orbitform Group supports our customers with factory trained sales engineers and applications specialists. We have the expertise to deliver the solution for any forming requirements.
|
|
|
|
|
|
Hydra-Pneumatic Riveter
With the first major innovation since the 1920s, Orbitform has given rivets a smooth new ride. The HP2000 hydra-pneumatic impact riveter is more controllable and adaptable than any impact riveting machine on the market today. Available with up to a 24 inch throat, the HP2000 can autofeed and quickly set solid rivets up to 7/16 inch diameter.
Orbitform's HP2000 riveter features:
- Twenty ton capacity
- Lubed for life ram assembly (less maintenance)
- Single/multiple tooling available
- Ease of alignment (upper/lower tooling)
- Ability to set rivets at multiple finished heights
- Few moving parts and wear points
- Long stroke range
- Quiet operation
- Optional Watchdawg for force and distance monitoring/control
- Palm buttons, foot switches or light curtains available.
The HP2000 can automatically compensate for minor material thickness or rivet length variances for consistent results. Setting pressure can be accurately controlled, allowing for use on brittle or fragile parts as well as heavy-duty applications.
Profit from over twenty years of industry experience and let Orbitform's new HP2000 guide your process! For further information please call 1-800-816-9661 or email sales@orbitform.com.
|
|
Adtech Heavy Capacity Impact Riveter
Adtech H-4000 direct-drive, high-speed, hydraulic impact riveters are rated at 40 tons with 4 inches of stroke and a cycle time less than one second.
Operator safety is maximized, as the ram stops mid-cycle if palm button actuators are released during the 0.8 second cycle.
Advantages include:
*Rated power available throughout full range of machine stroke
*Smooth and quiet operation
*No perishable drive train components
*Adjustable rivet setting force
*Designed for integrated force and position monitoring (optional)
*Standard H-4001 and H-4002 riveters are pedestal models with free standing hydraulic power units. The machines are available as table-mounted units with hydraulic power unit mounted beneath table for conservation
Recommended Options:
*Watchdawg Package
*Vibratory feeder upgrade
*Probe type safety device
*Dual Opto-touch actuation (requires part holding fixture)
*Spare tooling package (2 Jaws / 3 Drivers / 4 Rollsets)
*(4) Leveling Pads
|
|
Orbitform Group's medium capacity Milford impact riveters are our most popular machines. Designed for semi-tubular rivets up to 5/16" diameter, these machines offer the same speed and dependability as our light capacity riveters.
Medium Capacity Features:
*Rapid feeding and setting for rivets up to 5/16" diameter.
*Ergonomic operation and reduced noise levels.
*Throat depths up to 24".
*Simple hopper changeover.
Typical applications include hand and garden tools, brakes, clutch assemblies, and HVAC components.
All of our riveters are available with an unlimited variety of custom tooling, anvils, anvil holders, and special fixtures, dependent on your application.
Orbitform Group supports our customers with factory trained sales engineers and applications specialists. We have the expertise to deliver the solution to any riveting requirement.
|
|
Orbitform Group's medium capacity Milford impact riveters are our most popular machines. Designed for semi-tubular rivets up to 5/16" diameter, these machines offer the same speed and dependability as our light capacity riveters.
Medium Capacity Features:
*Rapid feeding and setting for rivets up to 5/16" diameter.
*Ergonomic operation and reduced noise levels.
*Throat depths up to 24".
*Simple hopper changeover.
Typical applications include hand and garden tools, brakes, clutch assemblies, and HVAC components.
All of our riveters are available with an unlimited variety of custom tooling, anvils, anvil holders, and special fixtures, dependent on your application.
Orbitform Group supports our customers with factory trained sales engineers and applications specialists. We have the expertise to deliver the solution to any riveting requirement.
|
|
|
|
|
|
Orbitform Group's multi-forming heads are used for applications where more than one form is required per powerhead cycle. These multi-forming heads are the solution for wide variety of center distances, number of forms, form sizes and form heights.
Multi-form Head Features:
Orbitform Group's multi-form heads are available in wide range of sizes, capacities, number of forms, form heights and reaches. Features of their reliable and durable construction include:
*Forming capacities ranging from .125" - 1.0" (3.18 - 25.4 mm) finished head diameter (mild steel)
*Number of forming points ranging from 2 - 10
*Center distances ranging from .188" - 12.0" (4.78 - 304.8 mm)
Multi-forming heads provide solutions for application that require more than one form per machine cycle. Each of these heads come with removable peen tools. These peens are available in a wide variety of styles to meet your finished form geometry needs.
Orbitform Group supports our customers with factory trained sales engineers and applications specialists. We have the expertise to deliver the solution for any forming requirements.
|
|
Orbital forming offers many advantages over other methods of forming, riveting and fastening, yet there are occasional applications where orbital forming may not be the optimal solution.It is for these delicate or lighter duty applications Orbitform has engineered a spiral form cartridge into its standard product line.
Spiralform (SF) is for customers with unique or very light duty applications. It is also available as a “standard option” for new machines and systems and designed to retrofit existing Orbitform machines. Additionally, the SF has been designed to accommodate an integral load cell into its spindle package. This allows the SF to provide the same Watchdawg capabilities as the rest of the Orbitform product line.
|
|
|
|
|
|
Orbitform Group's line of orbital pedestal machines are stand-alone designed for large forming applications. These pedestal machines have built-in height adjustment tables for comfortable work positioning and unrestricted access.
Pedestal Machine Features:
Orbitform Group's line of pedestal machines contain a solution for a wide range of applications. These pedistal machines are designed for larger forms and are composed of a fixed powerhead with an adjustable saddle attached to a heavy duty steel frame. Features of their reliable and durable construction include:
*Precise forming of up to 1.50" finished head diameter (mild steel) or equivalent cross section
*Max downward force ranging from 4400 lbs to 38500 lbs
*Adjustable stroke ranging from .06" to 6.00"
*Vertical head height adjustment of ±1.0" (25.4mm)
*Vertical saddle height adjustment of 10-12" (254-304.8mm)
For regular and large parts that require loading clearance under the peen tool, Orbitform Group's pedestal machines are the answer. These stand alone machines are available in single, multi-form or roller form configurations.
Orbitform Group supports our customers with factory trained sales engineers and applications specialists. We have the expertise to deliver the solution for any forming requirements.
|
|
|
|
|
|
Orbitform Group's line of Adtech and Milford light duty riveters are rugged and versatile. Designed for semi-tubular rivets up to 1/8" diameter, these dependable machines can be used alone or in combination to deliver the best solution for your riveting requirements.
Light Capacity Features:
Orbitform Group's line of Milford light duty riveters are engineered for a lifetime of hard work. Features of their dependable and rugged construction include:
*Rapid feeding and setting for rivets up to 1/8" diameter.
*The industry's most robust clutch's, drives, and cylinders.
*Throat depths up to 12".
*Simple hopper changeover.
Typical applications include contact setting, small electronic components, lighting fixtures, and plastic and ceramic assemblies.
All of our riveters are available with an unlimited variety of custom tooling, anvils, anvil holders, and special fixtures, dependent on your application.
Orbitform Group supports our customers with factory trained sales engineers and applications specialists. We have the expertise to deliver the solution to any riveting requirement.
|
|
The AGME radial riveting system is based on planetary movement. The excellent results obtained from this riveting method are far superior to the outdated hammering and orbital systems.
The AGME Riveting System offers perfectly riveted components and allows the material to flow naturally in three directions:
- Radially outwards
- Radially inwards
- Tangentially
This fast and efficient riveting machines will solve any riveting problem.
|
|
Riveting tools are a feather in FAR’s cap.
There are more than 30 models, to comply with the most different needs: manual, pneumatic or battery suitable for fastening blind rivets or threaded inserts.
The range of FAR riveting tools offers world-wide advanced articles, from hand tool to oil-pneumatic tools with automatic loading of the rivet.
|
|
Riveting tools are a feather in FAR’s cap.
There are more than 30 models, to comply with the most different needs: manual, pneumatic or battery suitable for fastening blind rivets or threaded inserts.
The range of FAR riveting tools offers world-wide advanced articles, from hand tool to oil-pneumatic tools with automatic loading of the rivet.
|
|
Orbital riveting technology
Control ST 2
for high-quality automatic and manual riveting
❏ simple menu-guided operation of all functions via display
❏ positioning in 0.01 mm or 0.01 bar increments
❏ up to 6 mm stroke range
(depending on measuring system (e.g. laser) 10 mm also possible)
❏ 1 - 10 bar pressure range
Same features as ST 1 plus:
❏ stroke monitoring with measured value display
❏ or alternative pressure monitoring with measured value display
❏ part counter
❏ service menu
❏ installed software – pressure or displacement
|
|
CP Industrial Rivet Hammers:
These tools are suitable for high production rates where high durability is required and the tools are used frequently. Our Industrial tools combine the best of quality, durability and ergonomics for your most demanding applications.
The unique features of these tools include a progressive 'teasing' throttle for improved controllability.
CP RediPower Rivet Hammers: Product RP9311 Hammer
RediPower tools are suitable for MRO (Maintenance, Repair, Operations) applications where the tool is used intermittently for industrial maintenance or non-intensive production.
|
|
New high performance, lightweight hydro-pneumatic handtools for breakstem rivets.
Features
Lightweight tool
Toughened plastic body and heavy duty rubber base
Quick release stem collector
Vacuum air supply cut-off on trigger
Enhanced tool life
Soft touch rubber grip on handle
Integral cycle counter (except nG1)
nG1 and nG2 feature a quick release nose equipment
Benefits
Reduces operator fatigue
High placement speed
Robust tool
Minimized air consumption
Reduced time to empty stem collector
Places a wide range of fasteners
Ergonomic
|
|
The ECO-Line brings new dimensions to the BalTec range of riveting machines, providing an even greater choice of models and most important, we can now also give you the most economical solution to all your riveting requirements.
Built to same high standards as standard range.
Stand alone model or complete machine
|
|
Standard version:
* Mutually opposing double riveting
* Force preselection, infinitely variable
* Ram speed, infinitely variable
* Stroke limitation infinitely variable by micrometer screw
* Setting of riveting time, infinitely variable
* Central clamping device
* Safety 2-hand control
* Standard rivet head
Accessories:
* Foot operation
* Stroke counter
* Maintenance unit
* Rivet head, reinforced
* Rivet head 3° for parts with difficult access
* Riveting for special rivet operations
|
|
Standard version:
* Force preselection, infinitely variable
* Ram speed, infinitely variable
* Stroke limitation infinitely variable by micrometer screw
* Setting of riveting time, infinitely variable
* Safety 2-hand control
* Automatic riveting process
* Standard rivet head
Accessories:
* Table base
* Stand base
* Foot operation
* Stroke counter
* Maintenance unit
* Rivet head, reinforced
* Rivet head 3° for parts with different access
* Riveting die for special rivet operations
* Multiple riveting mechanism
|
|
Riveting tools are a feather in FAR’s cap.
There are more than 30 models, to comply with the most different needs: manual, pneumatic or battery suitable for fastening blind rivets or threaded inserts.
The range of FAR riveting tools offers world-wide advanced articles, from hand tool to oil-pneumatic tools with automatic loading of the rivet.
|
|
KMT rivet plants
Tumbling rivet plants for rotating indexing plates and workpiece carriers of transport systems
Tumbling rivet cells for rotating indexing plates and workpiece carriers of transport systems with and without coordinate oh system
TN 2000 over head
Special productions for overhead assembly
TN 750 with blank stand
Special productions for rotating indexing plate plants with Winkelgetriebe
|
|
Our Standard solution provides the basis for customised riveting applications.
2 or 4 indexing table positions
300 x 200 mm working range
Machine and riveting process control with freely selectable quality assesment logic
Highly cost-effective for small runs due to high-speed job changes
Change workholder. Standardised workpiece holders can easily be converted into customised holders
Insert matching riveting tool
Activate programme...
... and the machine is ready for the next run
|
|
|
|
|
|
NEW !!! TECTOOL TF25
TECRIVETcutter - For difficult accessible places
NEW !!! TECTOOL TF50
TECRIVETcutter
TECTOOLbasic TF 70
Shears rivet
- Nosepieces 3,0 - 6,4 mm
TECTOOLbasic TF 165
Hand riveter
- Nosepieces 3,0 - 5,0 mm
- with opening spring
TECTOOLbasic TF170
Hand riveter
- Nosepieces 2,4 - 5,0 mm
TECTOOLbasic TF 190
Hand riveter
- Nosepieces 2,4 - 5,0 mm
- with extra long nosepieceholder
- from horizontal and vertical use
TECTOOLpremium TF 200
Hand riveter
- Nosepieces 2,4 - 5,0 mm
TECTOOLbasic TF 270
Lever riveter
- Nosepieces 3,0 - 6,4 mm
- with mandrel collector
TECTOOLbasic TF 300
Lever riveter
- Nosepieces 4,8 - 6,4 mm
- with mandrel collector
TECTOOLbasic TF 365 SET
Hand nut riveter
- incl. various TECNUT
- incl. mandrel and nosepieces M4/M5/M6
TECTOOLpremium TF 400
Lever riveter
- Nosepieces 4,8 - 6,4 mm and for TECLOCK/Monobolt/Magna-Lok
- with mandrel collector
TECTOOLpremium TF 606
Hand nut riveter
- with quick change mandrels
- Nosepieces M3/M4/M5/M6
- optional nosepieces for blind rivet bolts M4/M5
TECTOOLpremium TF 610
Hand nut riveter
- with quick change mandrels
- Nosepieces M5/M6/M8/M10
- transport box
- inklusive Transportkoffer
TECTOOLpremium TF 611 Screw spindel
Hand nut riveter
- with quick change mandrels and screw spindel
- Nosepieces for Blind rivet nuts M5/M6/M8/M10
- Nosepieces for Blind rivet bolts M5/M6/M8
- transport box
|
|
TECTOOL TF N12A
pneumatic-hydraulic Rivet nuts TECTOOL N12A
- Nosepieces for rivet nut M3 - M12
- Quick change system
- Pressure required max. 7,0 br
- Traction power 20 kN at 6 bar
- Air consumption 5,5 ltrs pro stroke
TECTOOL TF R68
Pneumatic-hydraulic riveting tool
- Nosepieces 3,0 - 6,4 mm
- Vacuum absorption for the mandrel with automatic switch off
- Pressure requirde max. 7,0 br
- Traction power 13 kN at 6 bar
- Air consumption 2,0 ltrs. per stroke
TECTOOL TF R55
Pneumatic-hydraulic riveting tool
- Nosepieces 3,0 - 5,0 mm
- Without vacuum absorption
- With mandrel collector
- Pressure required max. 6 bar
- Traction power 8 kN at 6 bar
|
|
Riveting tools are a feather in FAR’s cap.
There are more than 30 models, to comply with the most different needs: manual, pneumatic or battery suitable for fastening blind rivets or threaded inserts.
The range of FAR riveting tools offers world-wide advanced articles, from hand tool to oil-pneumatic tools with automatic loading of the rivet.
|
|
Riveting tools are a feather in FAR’s cap.
There are more than 30 models, to comply with the most different needs: manual, pneumatic or battery suitable for fastening blind rivets or threaded inserts.
The range of FAR riveting tools offers world-wide advanced articles, from hand tool to oil-pneumatic tools with automatic loading of the rivet.
|
|
POP Rivets - How do you fasten something when you do not have access to the back of the item you are fastening to? Sometimes you just cannot reach, or it is hidden under machinery and simply unaccessible. This is the beauty of Blind Rivet POP® technology. "Blind Setting" allows for fastening from the front, and the POP® line of products has solved numerous industrial problems since it's creation. From the standard rivet, to threaded inserts and POP® Rivetools, explore POP® for your application today.
|
|
Riveting tools are a feather in FAR’s cap.
There are more than 30 models, to comply with the most different needs: manual, pneumatic or battery suitable for fastening blind rivets or threaded inserts.
The range of FAR riveting tools offers world-wide advanced articles, from hand tool to oil-pneumatic tools with automatic loading of the rivet.
|
|
The hydropneumatic tool, RIV 912, is used to place Rivsert threaded female insert, from M3 to M12, and Rivbolt threaded male insert, from M4 to M8.
Rivit has designed this new model, to meet the requirement of the market, which was asking for a tool with a one-position trigger mechanism. In the new RIV 912 one pull is enough to start the automatic stroke. This innovative technical device makes your work quicker and easier, and surely less tiring.
Handle casing has been replaced with a plastic one, while both piston and cylinder are made of aluminium, giving as result a more lighten and handy tool.
Finally, in order to avoid the use of a special rod, a system has been projected to lodge an allen screw (hardness class 12.9), easy to find on the market and to replace.
|
|
Freedom:
Fire Bird: The versatile cableless Riveting Tool for outdoor and indoor applications.
High Performance:
Large working range, from M3 to M8 in aluminium and steel, M6 stainless steel and M10 in aluminium. High battery autonomy. High efficiency through ball screw drive power transmission.
High Speed Setting:
Safe and easy drill-on of the blind rivet nuts. Constant speed setting and automatic switching to drill-off at the end of the setting process.
Quick mandrel exchange:
Quick mandrel exchange and stroke adjustment without tools.
Operating Voltage: 12 Volt DC
Pulling Strenght: 13.000 N
Weight: 2,3 kg
Battery:
Nominal Voltage: 12 V
Nominal Capacity: 1,4 Ah
Number of cells: 10
Cells composition: Nickel-Cadmium with thermic overcharge protection
Weight: 0,62 kg
Quick battery charger:
Input Voltage: 230V/50 Hz
Charging Time: Approx 1 hour (full charge)
Weight: 1,4 kg
|
|
PowerBird: The versatile cableless Riveting Tool for outdoor and indoor aplications.
High Performance: The PowerBird can set all types of structure blind rivets; High battery autonomy; High total stroke of 20 mm.
High Speed Setting: Constant forward and backward speed of the jaw assembly. Immediate repositioning of the jaw assembly after completion of the setting process saves energy and increases setting.
Operating Voltage: 12 Volt DC
Pulling Strength: 13.000 N
Total stroke: 20 mm
Weight: 2,2 kg with battery
Power-Accu:
Nominal Voltage: 12 V; 1,7Ah
Number of cells: 10
Cells composition: Nickel/Cadmium with thermic overcharge protection
Weight: 0,62 kg
Quick battery charger:
Input Voltage: 230V/50 Hz
Charging Time: appox. 1 hour (full charge)
Weight: 1,4 kg
|
|
|
|
