A complete ground support system for underground hard rock mines. The benefits of safety, productivity, versatility and quality of installation combine to provide the ideal tool for the mine development cycle and rehabilitation operations.
The MacLean Advantage:
* All operations carried out from beneath supported ground
* Physical effort and fatigue are minimized compared to traditional rock bolting methods
* The scissor bolter is designed for single person operation
* Transverse feed enables drilling and bolting of a complete ring from a single set up
* Single pass drilling allows for rapid installation of bolts
* Versatility
Features
* Self-propelled, high speed four wheel drive articulated carrier
* Electric hydraulic control system with remote drive system
* Hydraulic positioning, rock drilling/bolting systems
* Operating protocol prevents exposure to loose rock hazards
* Multiple types of bolts can be installed (rebar, mechanical anchor, friction bolts)
* Long hole drilling capability
* Proven heavy duty scissor lift mechanism
* High capacity storage for bolting supplies
* 2000 lbs ( 900 kg) deck payload capacity
* Forward shifting hydraulic deck
|
|
Wheel bolting rig is a working machine to be used for mounting extension bolts 1,6 m or 1,8 m at the headings of methane-free mines that mine non-ferrous metals ores and/or mineral raw materials.
The rig is adapted to supply the working system from two alternative sources i.e. pneumatic pumps driven from combustion engine of the rig or from mine’s electrical network 500V (hydraulic set driven by electrical engine with the power of 37 kW).
Bolting rig is equipped with a cabin that ensures protection for the operator seating there; the protection against collapse during vertical stroke with the energy of 60 kJ.
Good stability and relevant power transmission system enables the use of the said machine to exploit deposits at headings with the longitudinal grade of (in the traffic direction) to 15° and at headings with across grades to 5°.
|
|
|
Atlas Copco's fully mechanized bolting rigs are the most cost effective and safest method of installing rock bolts in mines, tunnels, underground power plants and storage facilities. Boltec rigs also offer outstanding ergonomical solutions and a very user friendly design. The bolting unit MBU with its unique design and well proven Atlas Copco quality makes it the most reliable and versatile bolter. The Boltec series handles the most commonly used bolts on the market.
|
|
Gemini Bolter
# DESCRIPTION
The Gemini is a Top Hammer, long hole, drill for production drilling and cable bolting scissor platform. It is mounted on a mobile center articulated carrier.
# PERFORMANCE
The Gemini is used for:
· Production drilling 1 5/8 in. (41 mm) to 3 in. (76 mm) diameter holes to a depth greater than 78 ft. (23.77 m).
· Cable bolting with precut multi-strand cables installed through a remote operated cable pusher.
· Drawing
|
|
