WRAPPING MACHINE TOSA 125E
AUTOMATIC PALLET STRETCH WRAPPING MACHINE WITH ROTATING RING
EQUIPPED WITH WATERTIGHT TOP SHEET DISPENSER
This machine, with rotating film-roll, allows to obtain a steady and compact packing of all sorts of palletized load by a differentiated wrapping on products of sundry nature. An overall packing (five sides) is guaranteed for all sorts of palletized products by the waterproof top sheet dispenser integrated in the machine. Such a wrapping provides an excellent protection against the action of the weather. The possibility of carrying out different wrapping cycles is the main feature of this machine. The wrapping program, in addition to the complete cycle, allows to carry out a downward cycle only, an upward cycle only, a wrapping of the top or the bottom of the pallet only and a waterproof cycle. This machine can be installed on any existing packing line and it perfectly meets high production needs. It is complete with top pneumatic presser, powered pre-stretch assembly, film hooking and cutting unit, film sealing unit, boundary safety-guards, control board with PLC and different adjusting and control units.
|
|
Octopus 303 Automatic :
- Wraps up to 60 loads per hour
- Heavy duty construction
- Pre-stretches film up to 300%
- Rotary ring design increases film savings
- Installs over existing conveyor or can beprovided with conveyor
- Allen-Bradley PLC control
- Octo-Thread carriage allowseasy film threading
|
|
Octopus 808 Automatic
- Wraps up to 120 loads per hour
- Heavy duty construction
- Pre-stretches film up to 300%
- Cut and heat seal design increases film savings
- Installs over existing conveyor or can be provided with conveyor
- Allen-Bradley PLC
- Banding and split wrap capabilities
- Optional Pak-Air carriage for load ventilation requirements
- Octo-Thread carriage allows easy film threading
- Strain gauge film delivery control
- Optional integral top sheet dispenser
|
|
SATURN S6 HIGH PRODUCTION
. Automatic Envolvedora of ring for palletized loads.
. Production 60-90 palets/hour.
. Double desbobinador mall pillow.
. System rammer.
. Dispenser from film it leaves superior of the load.
|
|
SATURN S8 DOUBLE PRODUCTION
. Automatic Envolvedora of ring for palletized loads.
. Production 90-150 palets/hour.
. Double desbobinador mall pillow.
. System rammer.
. Dispenser from film it leaves superior of the load.
|
|
The fastest fully automatic rotating ring machine in the world for wrapping palletized loads.
Technical features
- Std. conveyor height from ground 500 mm ± 50
- Max. rotation speed adjustable by frequency changer up to 70 rpm
- Total installed power 8 Kw
- Standard voltage 400 V - 50 Hz - 3 PH.+ N + G
- Electric plant and motors protection degree IP 55
- Pneumatic flow 6 bar
- Acceleration/deceleration ramps adjustable by frequency changer
- Spool carriage upwards/downwards speed adjustable by frequency changer
|
|
The stretch wrapper for high throughput.
Special customer benefit:
• Compact, clearly arranged design
• High machine capacity due to servo drive
• Variable speeds for the rotary movement and ring travel
• Flexible - handles various pallet widths
• Minimal servicing - no open slip rings
• High protection class - IP 54, insensitive to dust and moisture
• Precise, reproducible stretch-wrap parameters with Cyklop-Power-Eco-Stretch up to 300% in 7 stages (patented)
|
|
|
Designed to meet the demands of high-volume operations, the Octopus 202 delivers high speed wrapping and superior film economy while producing secure, attractive pallet loads. The Octopus 202 automatic stretch wrapping system features a patented rotary wrapping ring, which can be programmed to start and stop film application at any height on the load without returning to the starting point. This reduces film costs by up to 50% and generates a virtually unlimited selection of wrapping patterns. This compact machine uses minimal floor space so it fits easily into tight spaces and can mount over existing conveyor or be equipped with its own conveyors. The Octopus 202 wraps up to 50 loads per hour.
|
|
Fully-Automatic Stretch Wrapping Machine with Rotating Ring:
Machine Description:
- Fully automatic stretch wrapping machine with rotating ring
- Capacity up to 110 pallets / hour
Options:
- Roller conveyor
- Top film coating
- Special size 1450 mm x 1450 mm
- Hold-down device
- Film change system
|
|
|
|
|
|
The Mancon 1710-2265 with its fabricated steel construction frame is designed for high speed stretchwrapping with a low maintenance in continuous end of line production environments. The machines technology will easily and effectively wrap pallets with palletised goods on them (usually presented inside the machine by conveyors), secured enough for transportation.
The machine is fitted with an easy film loading Power Pre-stretch Film Carriage for film savings due to cost effective wrapping and pallet stability programs. The machine can automatically apply mid cycle top sheet for dust or water protection.
Advance controls on the machine enable simple and reliable operational view of the stretchwrapping sequences and fault finding. The pallet remains stationary whilst the high speed (40rpm) graphite rotation ring (patent) with Film Carriage circles, and moves up and down applying film to the pallet. Infrared welding (patent) and cutting of the film at cycle end ensure complete secure encapsulation. The Mancon 1710-2265 is CE marked for safety and performance. Full service and spares support.
|
|
|
|
|
|
A wide range of rotating ring stretch wrapping machines to wrap and stabilise loads on pallets with stretch film suitable for all industry sectors.
The Genesis Futura series of pallet stretch wrapping machines operate without sliding electrical contacts and feature the exclusive system that powers the pre-stretch driven rollers using batteries which are charged during machine pauses at pallet infeed and outfeed. This technical and highly innovative solution, in addition to eliminating all the typical problems of sliding contacts, also significantly reduces the overall machine weight and correctly balances the rotating masses.
This results in low electrical energy consumption, reduced maintenance, high reliability and long working life.
Furthermore, construction solutions have been adopted to minimise transport costs and installation time giving economic advantages for the end user.
Futura L max load 1450 x 1450 Maximum output capacity 55 Pallet/h depending on line speed and the total number of revolutions of film required.
|
|
AVR 400
Versatility, speed and hi-technology of the AVE - 400 are key features for the new generation of rotating ring _ wrapping machines.
|
|
AVR 400 TS
Versatility, speed and hi technology of the AVR 400 TS are key features for the new generation of rotating ring wrapping machines.
|
|
