TECHNICAL FEATURES
Die cast aluminium arch mounted on taper roller bearings
Automatic bar feeding with axe CNC controlled
Cut feed with regulation
Welded structure basement
600 mm stroke bar feeding unit operated by a brushless motor and screw bolts guide
Oil-hydraulics control unit
Semiautomatic and automatic cutting cycle
Double effect arch control cylinder
Piece counter
Diagnostic
Rapid arch down and up stroke controlled by potentiometer
Nodular cast iron vice unit
Reduction gear unit
Adjustable blade guide
Low voltage electric system in accordance to CE specifications
Programmable number of pieces to cut
Variable programmable piece’ cutting length CNC controlled.
Multiple cutting programmes with free programming of pieces’ number and length
Display alarm list
LCD display control unit
Speed variator by inverter manually adjustable
N° 2 lubricating pumps
Pieces’ unloading skid
Blade cleaning brush
Mechanical blade tightening controlled by limit switch
STANDARD CUTTING CYCLE
Feeder pliers clamping (closing)
Vice mouth (opening)
Material’s positioning
Vice clamping (closing) and feeder pliers’ repositioning
Blade starting with cooling liquid output
Rapid arch down-stroke to material’s quote
Cutting cycle starting with speed and pressure manually controlled
Arch down-stroke, blade and cooling liquid stop
Arch rapid up stroke (rising) at material’s quote
Vice mouth (opening) and material’s repositioning
The work cycle is repeated for the programmed number of pieces to cut with continuous overseeing of material’s presence through sensor.
|
|
|
|
|
|
TECHNICAL FEATURES AND STANDARD EQUIPMENT
Cutting unit composed of:
Sturdy, wide base with blade lubricant tank and swarf collecting drawer (not present if there is a swarf extractor)
Highly rigid bow guided by two sturdy, ground round columns for a precise, repetitive downstroke
Automatically adjusted blade guide arm
Bow-guiding columns with antiscuff bushings
Safety device which immediately stops the machine if blade breaks
Blade tilted respect the horizontal axis to easy sections' cutting
Blade lubrication through cooling emulsion driven by motor pump
Hydraulically locking vice with gripping jaws before and after the blade and locking plate made of extremely hard material
Hard metal blade guide plates and pre-alignment bearings
Blade cleaning by motorised metal brush
Bow downstroke speed regulator and manual cutting pressure
Hydraulic blade tightener
CNC control unit with LCD display
Stepless speed change by motovariator and epicycloidal reduction gear
Material feeding carriage composed of:
Opening of both bar feeding clamping jaws while carriage is moving to prevent these from sliding if the rods aren't straight
Large-sized base with 500 mm length stroke feeding carriage, hydraulically driven
Piece's length to be cut readout by linear encoder
Hydraulically-locking bar feeding clamp supported by ground guides and antiscuff bushings
Photo-electric sensor for bar's end feeling
Automation:
Automatic bar feeding with axis CNC controlled
Low voltage electric circuits
Worked piece counter
Diagnostics
Multiple cutting programmes with free programming of pieces' number and length
|
|
Voortman has developed five models of band sawing machines especially for sawing structural steel. Four sawing machines are developed for mitre cutting. The fifth is designed for straight cutting of profiles. The sawing machines are equipped with a control system for the selection of the mitre angle and the automatic sawing cycle.
The band speed is frequency controlled and the feed rate is automatically controlled to suit the profile type and size.
The sawing machines can be combined with a length measuring system with stop truck. The sawing machine can also be combined with a drilling system for sawing and drilling in one continuous process.
These sawing machines are available with different cutting capacities. The VB600 for sawing max. 450 x 620 mm, the VB750 for 450 x 750 mm, the VB1050 for 500 x 1.130 mm and the VB1250 for 600 x 1 250 mm.
|
|
|
|
|
|
Cutting unit composed of:
Sturdy, wide base with blade lubricant tank and swarf collecting drawer (not present if there is a swarf extractor)
Highly rigid bow guided by two sturdy, ground round columns for a precise, repetitive downstroke
Automatically adjusted blade guide arm
Bow-guiding columns with antiscuff bushings
Safety device which immediately stops the machine if blade breaks
Blade tilted respect the horizontal axis to easy sections' cutting
Blade lubrication through cooling emulsion driven by motor pump
Hard metal blade guide plates and pre-alignment bearings
Blade cleaning by motorised metal brush
Bow downstroke speed regulator and manual cutting pressure
Hydraulic blade tightener
CNC control unit with LCD display
Stepless speed change by motovariator and epicycloidal reduction gear
Material feeding carriage composed of:
Opening of both bar feeding clamping jaws while carriage is moving to prevent these from sliding if the rods aren't straight
Large-sized base with 500 mm length stroke feeding carriage, hydraulically driven
Piece's length to be cut readout by linear encoder
Hydraulically-locking bar feeding clamp supported by ground guides and antis cuff bushings
Photo-electric sensor for bar's end feeling
Automation:
Automatic bar feeding with axis CNC controlled with Brusles motor with ballscrews
Worked piece counter
Automatic positioning for cutting angles from 45° to the right to 45° to the left CNC controlled
Possibility to programme cutting cycles with pieces having different lengths and different cutting angles
Multiple cutting programmes with free programming of pieces' number and length
Final swarf of the feeder 770 mm
|
|
|
|
|
|
Gravitation Bandsaw ARG 220 Plus
GRAVITATION:
The band saw arm is lifted manually, the feed occurs by own gravity of the arm while a continuous control by means of the oil damper throttle valve is possible.
The ARG 220 plus model is one of the best selling band saws in all European Union countries!
Enormous saving of material as compared to outdated frame or circular saws. The kerf thickness is only 1.1 mm, the perpendicularity of the cut 0.1 mm and the incomparable cutting speed (up to twenty times higher) ensure fast return of investment.
High infinitely variable cutting range under the angle of 65° on the right and 45° on the left when the position of clamped material is constant.
The sturdy cast-iron frame and the entire concept of the machine ensure long life and accuracy of cut.
The industrial saw blade, size 27×0.9×2600 mm, is manufactured in a number of quality ranges so that all sorts of material may be cut.
The professional European worm gear motor enables to switch over between two saw
blade speeds, 40 or 80 m/min.
Automatic saw blade feed to the cutting position via an oil damper. The saw blade stops when the cut is completed. The saw head is lifted manually.
The three-side hard metal guide ensures the accurate saw blade guide.
Regulation of cutting emulsion supply. A tank with a high-duty European pump is installed in the machine base.
Fine regulation of saw blade feed speed to the cutting position. The sturdy base ensures a smooth run of the machine.
Machine dimensions 1400×660×1400 mm
Weight 250 kg
BEST SELLING MODELS: ARG 220 PLUS, ARG 250 STANDARD, ARG 300 STANDARD
|
|
|
|
|
|
Bandsaw ARG 640 S.A.F.
Bandsaw ARG 640 S.A.F. - Double column hydraulic semi-automatic machine with linear guidance. Maximum cutting diameter is 640 mm, flat material up to 1.100mm width. Sturdy construction of the machine with circular double column design band saw arm guiding. The arm moves on a linear guidance. Gradual cut angles setting of 60° while the position of clamped material is maintained. Machine is equipped in basic version with following accessories: frequency changer which provides speed setting for the band saw in the range from 15-90 m/min. double-sided automatic band saw pressure regulation into the cut according to the characteristics of cut materials vice pressure regulation according to the characteristics of cut materials hydraulic movement of saw blade guide (while setting the diameter of sawn material) electrically powered cleaning band saw blade brush spray gun hydraulic saw blade straining from centrally controled panel automatic chip displacement thanks to worm chip conveyer.
Machine can be fitted either with band saw blade 41x1,3 mm, powered with 5 kW engine which is suitable for cutting of profile materials or with larger blade 54x1,6 mm, powered with 7,5 kW engine ideal for industrial cutting of full materials. Band saw blade is at an angle of 5° against the surface of the vice.
Machine dimensions 3780×2260×2050 mm
Weight 4200 kg
|
|
|
|
|
|
Sigma Sigma 1600 PRO are electric workshop band saw machines, for plastic pipes up to 1600 mm. Sigma 1600 is designed to perform easy cuts with a wide range of angles (from - 45° to + 67,5°). It is the ideal equipment to match Alfa fittings fabrication machines.
These data are displayed during the entire welding process, making it easier for the operator. Certain angles, as for example 45°, are automatically reached, which drastically reduces the setting time. A control device immediately stops the cutting operation, whenever the operator sets in a wrong angle, for which the blade risks to strike against the pipe housing bench. Composed of:
pipe housing bench, a blade-housing arm (belt type), moving on a spherical bearings guide, performing settable advancing speed. It can rotate on an arc system, and perform a wide range of share angles;
a continuous control blade guide telescopic system, to reduce to the minimum the blade vibration, regardless of the diameter and/or thickness of the pipe being cut. Provided with a laser-beam pointing system to localize the cutting area;
a safety pilot cabin, where the control panel is located. It is protected by guards for greater operator’s safety
an easy-to-use control panel, featuring a simplified graphics display, where the inclination degree of the cutting arc is displayed.
|
|
|
|
|
|
Fully Automatic Production Horizontal Bandsawing Machine BMSO 320 L
Fully automatic band saws for cutting solid stocks,tubes and profiles of steel , cast-iron light and nonferrous material.Only 90 deg. cut.Complate steel fabricated.Reductioned gear in oil bath and 5 different speed adjusted by a stepped pulley, carbide pads and rollers in the blade guides.The front jaw contains of a number of hardened rollers driven through a worm and wheel by an electric motor.The rear vice consist of a number of free running rollers.A limit switch assemebled on top the vice stops the machine when the block is exhausted. Once the work piece clamped between the rollers no further clampings needed. The work is fed through the vice to the bar stop which contains a micro-switch controlling the bar feed motor. A piece counter controls the number of the cuts.The machines stop automatically at the blade breakage. The machines are fitted with a removable coolant tank incorporating a submerged electric coolant pump which supplies coolant to both guide assemblies. Bi-Metal sawblade and 1,2 meter infeed roller table are supplied as standart.
|
|
|
|
|
|
CM 370 GRA TECHNICAL FEATURES AND STANDARD EQUIPMENT
Die cast aluminium arch mounted on taper roller bearings
Automatic bar feeding and bow with axe CNC controlled
Cut feed with regulation
Welded structure basement
Large-sized base with 1000 mm length stroke feeding carriage, motor brushless driven with screws ball
Automatic positioning for cutting angles driven by Brushless motor
Inverter speed variator
Semiautomatic and automatic cutting cycle
Double effect arch control cylinder
Piece counter
Diagnostic
Rapid arch down and up stroke controlled by potentiometer
Cast iron clamps unit
Reduction gear unit
Adjustable blade guide
Low voltage electric system in accordance to CE specifications
Programmable number of pieces to cut
Variable programmable piece’ cutting length CNC controlled
Multiple cutting programmes with free programming of pieces’ number and length
Display alarm list
LCD display control unit
N° 2 lubricating pumps
Pieces’ unloading skid
Blade cleaning brush
Mechanical blade tightening controlled by limit switch
STANDARD CUTTING CYCLE
Feeder pliers clamping (closing)
Vice mouth (opening)
Material’s positioning
Vice clamping (closing) and feeder pliers’ repositioning
Blade starting with cooling liquid output
Rapid arch down-stroke to material’s quote
Cutting cycle starting with speed and pressure controlled by CNC and Inverter
Arch down-stroke, blade and cooling liquid stop
Arch rapid up stroke (rising) at material’s quote
Vice mouth (opening) and material’s repositioning
The work cycle is repeated for the programmed number of pieces to cut with continuous overseeing of material’s presence through sensor
|
|
HYDRAULIC AUTOMATS PP 501A
Saws are controlled through microprocessor system with display and keyboard for band saw functions programming. Possibility to program the length and number of pieces. Saw stops after the set number of pieces is done,material ends, saw band breaks or an error with its identification. This saw also has electro-hydraulic feed system till 500 mm length of material with mechanical back stop and accuracy indicator 0,1 mm. The feeding length can be multiplied for longer pieces. Increased saw band engine power through frequency inverter with continuous saw band speed regulation.
|
|
|
|
|
|
High-Perormance, Fully Automatic Production Horizontal Bandsawing Machine
BMSO 550
The Beka-Mak Twin-Pillar horizontal bandsaws have been designed to give a low cost compact and rugged machines.The bow is constructed in heavy gauge steel and mounted two chromed and grinding pillars offer a strong rigid sawframe, providing a high degree of accurancy when cutting. Fully automatic band saws for cutting solid stocks,tubes and profiles of steel , cast-iron light and nonferrous material.Only 90 deg. cut.Complate steel fabricated.Reductioned gear in oil bath and 5 different speed adjusted by a stepped pulley, carbide pads and rollers in the blade guides.The rear jaw contains of a number of hardened rollers driven through a worm and wheel by an electric motor.The front vice consist of a number of free running rollers.A limit switch assemebled on top the vice stops the machine when the block is exhausted. Once the work piece clamped between the rollers no further clampings needed. The work is fed through the vice to the bar stop which contains a micro-switch controlling the bar feed motor. A piece counter controls the number of the cuts.The machines stop automatically at the blade breakage. The machines are fitted with a removable coolant tank incorporating a submerged electric coolant pump which supplies coolant to both guide assemblies. Bi-Metal sawblade and 1 meter infeed roller table are supplied as standart.
|
|
HORIZONTAL CUTTING BANDSAWS
Bandsawing machines with cutting capacity up to 2500 mm, both automatic and semi-automaticIntegral cutting magazinesShuttle table bandsaw "transfer"Cutting installations with displacing head "GANTRY"
MITRE CUTTING BANDSAWS
Cutting and drilling installations with capacities up to 1200 mm. Complete cutting installations with storage and feed of materials
VERTICAL CUTTING BANDSAWS
Vertical cutting bandsaws with capacities up to 2500 mm. Longitudinal and/or transversal cutting
|
|
|
The CM 370 CNC is a completely automatic machine at oil hydraulics operating that adds to the basic features of the semiautomatic band saw the advantage of material's automatic feeding. It's designed for the cutting of massive bars and profiles of small and medium dimensions with fix cut up to 90° or variable with manual set up to 60° right side. The reduced dimensions and the high reliability make the machine suitable for every company.
|
|
|
|
|
|
CNC Automatic Bandsaw ARG 300 CF-NC
Fully automatic NC band saw. The work piece feed, the work piece clamping and the arm forward and return movements are controlled hydraulically. The setting of number of pieces to be cut including the start-up is done on the control unit display. Fault reports are also displayed there. Maximal length of one-time feed 500mm. The cutting length is in fact unlimited because the control unit enables a multiple feed of the work piece. The sturdy design of the band saw arm and the individual components, the particularly robust feed system and the machine designs guarantee the accuracy and quality of the cut and a long life of the machine. The NC automatic machines are provided with a removable metal chips vessel. When the machine is set in manual mode, all the machine functions may be controlled separately. The pressure control devices of both the feed and rigid vice are included in the standard version equipment.
Enormous saving of material as compared to outdated frame or circular saws. The kerf thickness is only 1.1 mm, the perpendicularity of the cut 0.1 mm and the incomparable cutting speed (up to twenty times higher) ensure fast return of investment.
The sturdy cast-iron frame and the entire concept of the machine ensure long life and accuracy of cut.
The industrial saw blade, size 27×0.9×3110 mm.
The professional European worm gear motor equipped with a frequency changer enabling a continuous saw band control within 15-90 m/min.
The three-side hard metal guide ensures the accurate saw blade guide.
Machine dimensions 2100×1500×1600 mm
Weight 890 kg
|
|
Varispeed type P (PNEUMATIC) is a highly professional fret-saw, versately, and excellent precision cutting.
The PNEUMATIC CONTROL of slope and down stroke of the upper clamp, consent to obtain a fast fixing of the blade and reduction in working times.
Varispeed is particularly suitable for fine inlay work, handcraft work, and marquetry, it can satisfay the numerous straight or finely shaper angle fretwork.
The elevation of the blade respect the working table is basic for cutting out the flet dies in the paper and cardboard industry.
ON REQUEST:
Varispeed can be supplied with THE AUTOMATIC COUPLING OF THE BLADE into the lower clamp, with an ELECTRONIC SPEED VARIATOR manual operated or by PEDAL POTENTIOMETER.
The large and strong working top, allows a millimetre TILTING INCLINATION UP TO 45°.
|
|
|
The CM 370 S is a completely semiautomatic machine at oil-hydraulics operating that adds to the basic features of the manual band saw the advantage of material's automatic cutting cycle. It's designed for the cutting of massive bars and profiles of medium dimensions with angular cutting up to 60° right (RGT). The reduced dimensions and the high reliabilitymake the machine suitable for ever company.
|
|
BMSY 440 DGH
Our Double Coloumn bandsawing machines are ideal models for changable cutting quantities with angle cutting. Cutting with +60° right, -60°left degree is possibble with turning the bow. It is the biggest model of its type with 400mm/610mm flat cutting at 90 degree angle and 440 diameter cutting. Cutting is hydraulic and the bow rise up automaticly at the end of cutting. Material should pushed manual until the lenght-stop and cutting repeat.
|
|
BMSY 650DG Semi Auto. Mitre Horizontal Bandsawing Machine
The capacity of the machine is 600/1000 and projected for fast cuttings straight or with angle . Sensetivity of the machine lets cutting with percentage angles. 650 DG NC has PLC system and open to future developments. Touch panel supply easy usage. You can easily find the failure, follow the cutting process or choose the opsions with control panel menus. Rollers on the table are designed for easy movement of the materials on machine. Automatic blade tentioning reduces the failure at cutting process. Blade is under control by hydraulicly and magneticly. The bow goes down fast until see the material so it gain time at cutting different dimensions of materials. Turn table obtains area disposal , no need to change the angle of the material, changing the angle of the bow is enough
|
|
|
|
|
|
Bandsaw ARG 500 PLUS S.A.F.
HYDRAULIC SEMI-AUTOMATIC MACHINES S.A.
The whole cutting cycle clamping the work piece, switching-on the saw band, cutting, saw blade stop, raising the arm to the initial (adjustable) position, opening the vice - takes place after depressing a single switch. This, in connection with a hydraulic feed, substantially increases the cutting productivity, especially in full materials. Individual control of all functions. Manual work piece feed. S.A.F. versions are equipped with stronger and frequency changers, which provides for an optimum speed control of the saw band between 20 and 90 m/min. The optimum setting of the saw band speed improves the machine productivity, the accuracy of cutting and the saw band life. A vice pressure control device is also included in the standard version equipment.
ARG 500 PLUS S.A.F. machine with the most advanced conception in regards to band saw arm and the whole machine as such, is allowing cutting of large profiles even under an angle. The range of cutting angle is 60° right and 60° left. The complex sturdy construction of the machine guarantees precise cuts in large cross-sections . It offers a long durability of band saw blades. Each machine is equipped with frequency changer which provides speed setting for the band saw in the range from 20-90 m/min. and with vice pressure regulation. Band saws are ideal for the heavy industries and nonstop production lines in these there is a demand for cutting of large material cross-sections . Band saw blade is at an angle of 3° against the surface of the vice.
Machine dimensions 3000×1600×1750 mm
Weight 1530 kg
|
|
A range of bandsaws which combines accurate cuts and high speeds, adapted to all types of profiles used in steel construction.
Internationally well-known for their robustness, accuracy and speed of execution, Behringer saws allow the straight and mitre cut of all types of profiles.
Being a natural additional equipment to our HD fast drilling machines, the drilling sawing line represents the key element of the performance in steel construction workshops.
|
|
ZIP 30
Manual band sawing machine for solid and metal profiles.
Also steel, stainless steel, brass, aluminium, copper.
Robust, versatile and handy, for artisan metal works and professional duty.
One way miter cutting (from 0° to 60°)
Cast-iron sawframe on twin tapered bearings and ring nut to provide greater stability.
Precision blade-guide with hard metal pads, bearinga and anti-corrosion treatment.
Two cutting speeds.
Vice with quick lock lever.
|
|
SUPER TRAD 350 AOCN EVOLUTION
Automatic band sawing machine with numerical control for solid and metal profiles. Also steel, stainless steel, brass, aluminium, copper. Robust, versatile for professional duty.
Multi-function digital controller with piece-counter, piece presetting, work timer, diagnosis and alarm messages.
Automatic control over cutting lenght and sawframe return stroke. Hydraulically powered multi-feed system moves the material into the cutting zone, reducing indexing time and speeding the cutting process. Adjustable sawframe downfeed speed.
One way miter cutting (from 0° to 45°). From 45° to 60° on semiautomatic mode.
Two cutting speeds or electronic speed variator. (Optional)
Cast-iron sawframe on twin tapered bearings and ring nut to provide greater stability.
|
|
|
|
|
|
SUPER TRAD 380 SO DIGIT
Semi-automatic band sawing machine for solid and metal profiles. Also steel, stainless steel, brass, aluminium, copper. Robust, versatile and handy, for professional duty.
Multi-function digital controller with piece-counter, piece presetting, work timer, diagnosis and alarm messages.
Adjustable sawframe downfeed speed.
Cast-iron sawframe on twin tapered bearings and ring nut to provide greater stability.
Precision blade-guide with hard metal pads, bearings and anti-corrosion treatement.
Two cutting speeds.
Large and round working table.
The digital controller offers three different operating functions:
Semi-automatic cutting cycle: manual vice adjustment through handwheel - semi-automatic start through pedal switch or control panel switch - the machine carries out a complete cutting cycle including vice locking, sawframe downfeed, cut, sawframe return and vice opening.
Manual cutting cycle: manual vice adjustment through handwheel - material vice locking through switch key - sawband start through gripswitch - manual sawframe pull down and cut - material vice opening through switch key.
Multi-Mode cutting cycle: manual vice adjustment through handwheel - manual approach of the sawframe to the material - cutting cycle start through gripswitch including vice locking, sawframe downfeed, cut, sawframe return and vice opening.
|
|
|
These band sawing lines are specifically designed to meet the demand for processed sections in steel construction industries and service centers. They are equipped with Ficep stand-alone saws BH series and an automatic measuring length gauge that can be controlled by a panel (semi-automatic) or with a CNC (automatic).
|
|
|
|
|
|
Shark 452 CCS, bandsawing machine TO EXECUTE SINGLE CUTS WITHOUT THE NEED OF AN OPERATOR on sections and beams up to 450x330 mm at 0°.
- It is a very versatile machine to cut from 60° left up to 60° right.
- Functioning: after having manually fed the bar and clamped the material, you start the cut which is done using the weight of the head controlled by a spring so as to balance the sawing head. By means of an hydraulic brake with a valve you can regulate the downfeed speed. Once the cut has been finished the sawing head is raised manually so that you can feed the bar again (as OPTIONAL you can have the head which returns to top position by means of an hydraulic unit after each cut).
In the Shark 452 CCS MA model (with an automatic vice) vice opens/closes by means of a button on the control panel.
A FEW FEATURES:
Electric panel (wiring totally identifiable, stand-by, main lockable disconnect switch, pole change switch, emergency stop, motor magneto thermal overload, minimum tension coil, protection against missing phase, low tension safety device 24V).
Mechanical variator to adjust infinetly variable blade speed from 20 to 100 mt/min.
Cabinet which can be easily positioned keeping a visual control over the machine.
Manual band tensioning with visualization on LCD by electronic transducer.
Front bandguide with sideways movement on a linear guide with recirculating ballscrews.
Manual clamping system by means of vice screw which slides on preloaded linear guides with recirculating ballscrews
Coolant tank inside the steel base and drawer to collect chips which can be replaced with a motorized chip evacuator (OPTIONALS)
Electric pump to lubricate and refrigerate the blade.
Wire chip brush for blade cleaning which is driven by the motor pulley.
Adjustable cut to measure device to make cuts of the same length.
Machine predisposed for handling with movement equipment.
Bi-metal band for solids and sections.
Service keys and instructions manual, for maintenance and spare part list.
|
|
|
|
|
|
SPIDER CARRIAGE
THE SPIDER BRINGS TOGETHER ALL OUR KNOW-HOW
A GREAT DEAL OF EXPERIENCE OF POSITIONING CARRIAGES
* Speed. Precision. Sturdiness.
* Pneumatic or Hydraulic.
* Opening 1060 to 1460.
* Clamps opening: 800 to 1200mm.
* Double round column Ø120.Shock absorber.
* Triplex chain drive,
* or Ball Screw drive (great precision).
* 4-position extending clamps.
* Centralized lubrication.
* Slab FLIPPERS.
* SINGLE OR "V" LOG TURNERS.
* Serrated chain with a 38.1mm pitch.
* Electric motor.
* Ergonomic control panel.
* Air-conditioned cab.
* LINEA 2000 SETWORK
* 260mm touch screen.
* User-friendliness and speed. Maintenance aid.
* 1/100th of a mm resolution. Extensive memory: up to 2000 programs.
* Control of servo-motors which pilot and control the position of the headblocks in real time and in a closed loop.
* Extreme sawing precision irrespective of the timber's kick-back forces.
* Moving speed from 0 to 37m/min
* CARRIAGE DRIVE
* Direct current 37 to 100 HP
* Pneumatic return pulley.
* Safety brake.
|
|
KBS 400 DG NA - Automatic mitre cutting band sawing machine with material feed gripper
Double mitre cutting band sawing machine with material feed gripper unit for automatical sawing of single bars as well as bundles, ideal for medium-to-high batch production.
Material feed gripper unit for automatic feed
NC-controlled angle setting
Graphic display with touch screen monitor
Frequency controlled drive motor for high flexibility
Automatic cut-off-sorting possible (see KBS 400 DG NA ABG)
|
|
SLAB CHIPPER - CT600
EFFICIENT AND VERY COST-EFFECTIVE
* max. chipping depth = 150mm.
* max. opening face = 650mm.
* 9 cutters, 3 circular segments.
* Cast-iron head and body.
* Anti-overheating, free central disc.
* Clearance = 800mm.
* Precise, fast positioning by ball screw + servo-motor, in a closed loop.
* Motor 100 to 180 HP.
* Good surface finish and very good channelling of large chips.
|
|
Dual column band saws with numeric control multi-microprocessor designed to cut solids up to 400 mm.
|
|
HORIZONTAL BAND SAW
SAWING OF EXOTIC WOODS
The CD horizontal saw is extremely simple to install and maintain, whilst being very sturdy and provided with good cutting capacities. Sawing of woods Ø1.3m to 1.65m according to model.
Also for sawing long lengths or for having several clamping posts.
CD 5, 6, 8 and 10 horizontal saws
* softwoods or hardwoods,
* of max. diameter 1650 mm,
* sawing possible up to 20 m,
* electric or diesel version,
* with or without pre-board edger,
* transport in dry 20' container.
|
|
|
|
