General-purpose, clear RTV indoor/outdoor sealant. Seals, bonds, repairs, mends and secures glass, metal, plastics, fabric, vinyl, weather stripping and vinyl tops. Protects and repairs electrical wiring. May be applied to horizontal or vertical surfaces. Waterproof and flexible. Temperature range -75°F to 400°F (-59°C to 204°C); resists oil, water, weather, vibration, grease.
|
|
|
The products in the ThreeBond 5200 series are silicone sealants that have excellent adhesion, durability, and weather resistance. They are used in the construction of public facilities such as bridges or buildings. They are stable when exposed to sunlight, ozone, water, or changing temperature, and they remain elastic for a long time with no change in colour or degradation in quality. Provided in a variety of colours, they assist in the sophisticated finish of buildings and other facilities.
|
|
WEICON Black Seal is a one-component special grade silicone rubber, dispensed from the practical spray can. It allows nearly unlimited applications and simplified handling without applicator gun.
WEICON Black Seal will remain flexible even at high temperatures and provides excellent adhesion on aluminium, steel, wood, glass, glass fiber cloth, ceramics and many other materials.
|
|
|
Depending upon type FIXED O FLEX is applicable as sealing material in mechanically particularly strongly burdening joints, e.g. industrial plants, lanes etc. Due to its high chemical resistance FIXED O FLEX is particularly suitable for chemically loaded ranges.
|
|
|
|
|
|
MAPESIL LM : Single-component, neutral cross-linking, low modulus silicone sealant for movement joints with maximum 25% expansion of the initial size. Flexible sealing of interior and exterior expansion joints in ceramic wall tiling as well as for windows, mirrors, metals, PVC, polycarbonate etc., both intermediate and for sealing to wood, concrete, etc. Highly suitable for flexible sealing of external façades particularly those covered with limestone sensitive-to-acids. Does not stain. Unsuitable for continuous water immersion. Consumption depending on the size of the joint.
MAPESIL Z : Universal acetic-cross-linking silicone sealant. Mapesil Z is formulated for use as a sealant and for forming perfectly elastic gaskets between various elements used in construction, mechanical engineering, ship-building, automobile manufacturing, and other industries. Mapesil Z is a silicone sealant with acetic cross-linking in a thixotropic paste easily applied horizontally or vertically. Mapesil Z cross-links at ambient temperatures, forming an elastic material. When applied on concrete or wood, first apply Primer FD. Colours: clear, white, gray. Consumption calculated according to the volume of the joint and the density of the sealant (1.00 g/cm3 for clear and 1.24 g/cm3 for coloured compounds).
|
|
|
The products in the ThreeBond 5200 series are silicone sealants that have excellent adhesion, durability, and weather resistance. They are used in the construction of public facilities such as bridges or buildings. They are stable when exposed to sunlight, ozone, water, or changing temperature, and they remain elastic for a long time with no change in color or degradation in quality. Provided in a variety of colors, they assist in the sophisticated finish of buildings and other facilities.
|
|
Sealant tapes compatible with most bagging films.
Ideal for use on all type of tools.
Sealant tapes are used to from a seal between the vacuum bagging film and the moulding tool surface.
|
|
The Flat or shaped range of lifting bags is used in a very wide spectrum of applications: tightness, squeezing, flanging, handling, isolation...
Significant means in engineering and design departments, and a flexible production tool wich will provide the best response to your needs. Do not hesitate to contact us and we will answer you very quickly.
|
|
- Extensive assortment
- Combination on foam tapes and PVC
- EMI/RFI shielding gasket
- Window Seals
- Buffers
|
|
Extruded and jointed "O" rings are our preferred method of production, but moulded versions are available if specifically requested.
Both silicone & fluorosilicone with all varieties of fillers are available for the manufacture of "O" rings.
The advantages of vulcanised "O" rings are:
- Cost Effective
- No tooling costs
- Reduced lead times
- Better surface finish (zero flash)
- Allows hollow sections to be used for lower compression force
-Custom lengths easily produced (up to approx 2m developed length)
|
|
|
|
|
|
TechSeal offers many standard extruded profiles in Solid & Hollow-O, Solid & Hollow-D, U-Channel, Rectangular, Solid & Hollow Square, and Hollow-Dart configurations. These profiles are typically used for fabrication into spliced rings or custom gaskets; they also can be supplied in bulk cord. See pages 13 through 19 for a complete listing of standard profiles and groove recommendations.
Please refer to page 11 for TechSeal’s standard material offering of our most commonly used compounds. Please contact the TechSeal Division if you have a requirement for a material other than those listed. TechSeal offers a broad range of materials for many different markets. Many TechSeal compounds meet or exceed specialty grade standards set by the UL, ASTM, Military, FDA, USP Class VI, NSF and other agencies.
TechSeal ParFab - Product Types ParFab products contained in this brochure or any custom extruded profile can be supplied as:
Spliced Rings (Hollow and Solid)
4-corner PSA-backed spliced "picture frame" gaskets
Custom fabricated gaskets
Cut-to-length product
Bulk cord with or without PSA - coiled or spooled
Please contact the TechSeal Division’s Sales and Marketing Department for part number assignment for all nonstandard cross-sections for spliced or fabricated parts.
Spliced Rings All TechSeal Spliced Rings are "Hot Vulcanized" and can be provided in any of TechSeal's standard or customer specified cross-sectional configurations. Minimum spliced diameter is 1.500" (38.1mm) inside diameter, however this is cross-sectional dependant.
|
|
|
Essential part of which depends the perfect running and security of entire plants, the sealing device must be definited since the products studying process, and taking into account all conditions of use ; but nevertheless, some sealing problems can arise in duty. That is the reason why Jicey conceives, designs and makes at your demands the flat stactic sealing devices that you need, around its basic technologies: industrial lamination and the carving of thin and ultrathin materials, but also in all materials and all shapes according to your plans.
|
|
|
|
|
|
From High performance aircraft engines to swimming pool lights, Seal Science has met the gasket requirements. Whether die-cut gaskets or molded gaskets, our organization has the capability to meet your related sealing requirements.
We furnish the most simple gaskets at a very competitive prices, or items that must survive in environmental extremes; whether for high temperature, low temperature, or chemical resistant applications. Gaskets that provide EMI Shielding, conductive sealing, or dissipative characteristics also fall in our area of expertise. The Gasket is thought of as a simple component, but it has its own unique technology. A technology that must be honored to achieve reliable long-lived sealing. Seal Science engineers have mastered this technology. We are anxious to help you with your gasket requirements.
- Pro E, Solidworks Design
- Mil Spec Gasket Materials
- Custom Rubber Compounding -all materials
- EMI,RFI,ESD materials
- Silicone - medical grades ,industrial and military
- Viton ,60,75 and 90 A
- Graphite
- High Temperature Materials
- Teflon for chemical resistance or temperature extremes
- Viton ,60,75 and 90 A
- EPDM rubber and sponge
- R134a sealing
- HNBR -automotive and tough applications
- Neoprene rubber and sponge
- Fabric inserted calendered rubber and silicone
- Diaphragms
- ANSI Flange Gaskets
- PSA Application
- MS 52000 Connector Gaskets
- Many other materials - call or Email !!
- High Speed Presses
- 72" width capability
- Fabrication Dept.
- Bonding,Splicing
- Lab Testing
|
|
|
|
|
|
Metal-O-rings and C-rings for extreme operating conditions
From ultrahigh vacuum up to 6800 bar (100000 psi) pressure and temperatures from -269°C cryogenic up to +980°C (-425°F up to 1800°F).
Resistant to chemicals to a large extent.
GFD metal O-rings have been developed as a secure sealing of gases and liquids. They even can be used in case of extreme conditions. These static and metallic sealing elements can be applied in ranges of ultrahigh vacuum and up to a pressure of 6800 bar. They are suitable in case of continous temperatures from 269 degrees centigrade below zero up to 980 degrees centigrade above zero and resistant to radioactive radiation, chlorides, corrosion and other aggressive influences. They neither age in use or during storage.
Advantages:
With conventional flanged joints many technical data, from which only very few are precisely available during the design state, have to be known for the calculation. Also the values for the rigidity of the flange, the screws etc. have to be available. The consequence are extensive calculations with imprecise or assumed values and the involved disadvantages. There is always a defined initial tension, no setting and smaller flange and screw dimensions with the GFD metal-O-rings or lip seals. The proof has not to be furnished with complicated and difficult calculations about unknown quantities but simply by adding the forces of pressure to the operating pressures.
|
|
Layers of all metal gaskets are formed into four cross-sectional profiles (round, rectangular, round with tail and double round with tail) and into a range of sizes to suite a large number of applications. Available in seven wire types: monel, tinned copper clad steel, stainless steel, beryllium copper, tinned copper, aluminium.
All metal gaskets offer excellent EMI shielding performance, providing electrical continuity when compressed between two mating surfaces.
|
|
|
These exceptionally versatile gaskets solve many flange sealing problems for industry. They have either a metal core with sealing materials on both flat surfaces, or a pliable core encased in a thin metallic casing.
|
|
|
|
|
|
The DONIT TESNIT® grooved gasket is the preferred gasket when improved performance at low seating stresses is required. It features excellent anti-blowout properties linked with the reliability of a solid metal-to-metal seal combined with a soft sealing face to provide a tighter joint. Metal gaskets with grooved faces have proven to be very effective for sealing flange connections, and are particularly suitable for applications where high temperatures, pressures and fluctuating conditions are encountered. Non-metal cover layers ensure that flanges are not damaged, even at extreme loads, and provide excellent sealing properties when supported by the grooved metallic gasket. The DONIT TESNIT® grooved gasket is an ideal replacement for problem applications associated with jacketed gaskets, for heat exchangers, vessels and reactors and various flanged connections.
Advantages
* Capable of sealing pressures exceeding 250 bar.
* Capable of withstanding temperatures up to 700°C.
* Particularly effective in maintaining performance under condition of fluctuating temperatures and pressures.
* Solid construction provides stability even for large diameters and ensures trouble-free handling and installation.
* Gaskets can be fitted to existing assemblies without modification.
Shape and construction
The DONIT TESNIT® grooved gaskets are produced in several types to fit the most demanding applications.
|
|
|
O-Rings Seals in standard and metric dimensions and different compounds always available ex stock.
|
|
Our seven million stocked 'O' rings include inch sizes and metric sizes to a range of international, national and industry standards.
These are held in a variety of general and high performance elastomers to suit the vast majority of industrial and specialist oil and gas sector applications.
|
|
- Featuring Simriz proprietary perfluoroelastomers
- In-house tool shop
- Clean room molding and packaging
- Off-the-shelf availability from Simrit warehouse
- Tooled on all AS568a sizes and most standard metric sizes
- Compression and injection molding
- Cryogenic and punch trim deflashing
- Facility locations: Santa Ana, CA; LaGrange, GA; Cuautla, Mexico Tokyo, Japan; Pinerolo, Italy
- Certifications: ISO 9001, ISO 9002, QS-9000, AS-9000, BQMS/ D1-9000, A2LA Laboratory, EN9100, VDA 6.1
|
|
|
|
|
|
O-rings are a Seal Science specialty. Utilizing advanced material science, SSI provides O-ring solutions in many types of elastomeric/ rubber compounds. SSI incorporates advanced materials in its design methodology ranging from Perfluoroelastomers to alloy filled conductives elastomers.
SSI utilizes on-site molding making capabilities to provide molded O-rings from .030” inches OD to over 40.0 inches. SSI has the capability for performance molding of O-rings with ultra critical measurement tolerances, as well as providing less critical, economically costed, high volume supply alternatives.
Seal Science incorporated finite element analysis (FEA) in its O-ring design to develop the most optimal size seal for an application.
SSI has a complete compound development capability to provide O-rings made from current off-the-shelf (COTS), and custom engineered elastomers made from the following:
- Silicones
- Fluorosilicones
- Isoprene
- Nitriles (Lubricated and High Strength)
- Conductive Elastomers
- Perfluoroelastomers
- Styrene-Butadiene (SBR)
- Ethylene acrylic
- Aflas®
- Butyl
- Chloroprene (Neoprene®)
- Ethylene Propylene (EPDM)
- Fluorocarbon GLT & GFLT
- Fluoroelastomers (Viton®)
|
|
O-Rings
To national and international standards: AS 568A, ISO 3601, DIN 3771, JIS and metric. Custom sizes of almost any dimension
Miniature O-rings and large special O-rings continuously molded from spliced cord
Perfluorinated (FFKM) O-rings. Broadest chemical resistance, highest purity and temperature resistance of any elastomeric family - up to 320°C/608°F
Compounds
O-rings can be molded in a wide range of compounds in hardnesses
from 30 to 95 Shore A. These materials include:
Acrylonitrile-Butadiene (NBR)
Butyl (IIR)
Chloroprene (CR)
Ethylene Acrylic (AEM)
Ethylene Propylene (EPDM)
Fluorocarbon (FKM)
Fluorosilicone (FVMQ)
Hydrogenated Nitrile (HNBR)
Perfluoroelastomer (FFKM)
Polyacrylate (ACM)
Polytetrafluoroethylene (PTFE)
Silicone (VMQ)
Parker O-ring compounds are formulated to meet the most stringent
industry standards, including NSF, Underwriters Laboratories (UL),
Military (MIL-SPEC), Aerospace (AMS), NASA, FDA, USDA, USP, and many customer-specific requirements.
|
|
- Dedicated manufacturing facilities
- Quick quote ability
- Multiple material colors
- Banded piston technology
- Global manufacturing
- Small lot manufacturing
- Custom material compounding
- Facility locations : Troy, OH; Findlay, OH
- Certifications: ISO 9001, ISO 9002, QS-9000
|
|
The requirement for low coefficients of friction, less than .08, temperatures ranging from -300F to +550F, pressures in excess of 5000 psi, the need to seal a corrosive acid .....These are the typical kinds of factors that tell you that an elastomeric seal probably wont fit your application.
Seal Science PTFE or Teflon® Seals and Seal Science Perflex perfluoroelastomer are often the answer. Possibly something as simple as a PTFE O-Ring, or a PTFE compound cap to protect the elastomer will do. Or maybe, spring energized PTFE U-Cups, like those in our Polyspring line might be needed.
|
|
|
|
|
|
Metal Seals/Resilient Metal Seals are designed for applications that require temperature and chemical resistance beyond that of even Parofluor Series elastomers. These seals are offered in many cross-sections, including "C," "U," "E," and "V," with spring-energized variations.
Parker S-Shape and Omega Metal Seals are high performance, resilient metal seals intended for separable joint type applications requiring
resistance to temperature and pressure extremes, resistance to corrosive fluids, zero leakage and exceptionally long life.
The Parker S-Shape Metal Seal features low seating load, high resilience. They are self energizing and pressure assisted. Parker S-Shape Metal Seals are reusable and require a very simple cavity design.
The high strength base metal "spring" is coated with a softer sealing material. When compressed between flat surfaces, the spring seal forces the soft coating material into the mating surface roughness, blocking all potential leak paths. Once initiated, the intimate contact is maintained by the seal's resilience, overcoming the effects of temperature, pressure, flange separation and reduction of bolt torque.
The Parker O-Seal Division also produces two additional types of resilient metal seals for use in super-critical sealing of nuclear, aerospace and aircraft engine applications. Both the Parker Mark I and Mark II Metal Seals are available in a wide range of base metals and surface coatings from PTFE to gold plating. For "zero leakage" applications, the Parker Mark I is
recommended and is available in either internal or external pressure versions, depending upon customer requirements.
The cavity for a Parker SShape Metal Seal must provide controlled squeeze, seal location, adequate sealing surface and structural support.
Parker S-Shape Metal Seals are recommended for use in applications beyond the limits of elastomeric O-ring seals. Typical applications for the Parker S-Seal include jet engine fuel and exhaust seals, nuclear couplings, cryogenics, bakeable vacuu hardware, steam systems, turbine engines, cylinder heads and plastics processing equipment. For complete information on available sizes, metals, coatings and dimensional requirements for S-Seal glands, contact the Parker O-Seal Division Technical Services Department at 310
|
|
Rubber Gaskets (Flat seals) in different dimensions.
For further informations, visit our catalogue.
|
|
Packing made of expanded graphite yarns reinforced with Inconel wires and coated with a graphite-based mix. LATTYgraf 6940 contains a sacrificial anode to protect the valve stem and the stuffing box.
This special structure withstands high pressures without graphite extrusion.
High-performance valves.
Thermal oils and all high-temperature fluids, power stations, refineries, boiler plants, etc.
Limitation: precautions in oxydising environment.
Approval: BAM (oxygen), amended fire test API 607.
|
|
|
O-Rings made with Parofluor Series materials provide both static and dynamic sealing solutions for hydraulic, pneumatic, vacuum and other applications. These o-rings are available in AS568B inch sizes, as well as a wide range of metric and JIS sizes. Large diameter molded o-rings and non-standard sizes are also available.
|
|
Seal Science has been supporting the medical and medical device industries for many years providing clean room produced silicone liquid injection molded (LIM) seals and components. Through the incorporation of design engineering, materials science, and precision manufacturing, Seal Science offers customers complete application solutions ranging from product development to value engineering.
Through testing and development, SSI provides LSR materials closely matching material physical properties of traditional transfer and compression molded products. SSI also provides LSR seals and components in both clear and pigmented materials.
Silicone LIM molding provides customers with ultra-clean, high tolerance sealing products in high production at very competitive costing.
|
|
|
|
