Protect personnel, analyzers and sampling components from high temperature gases or liquids with a Sentry Thermal Shutoff Valve. The sensor/actuator is directly exposed to the sample providing quick reaction time. Economical replacement for solenoid shutoff valve and temperature controller.
Suitable for system pressures up to 4400 psi (303 barg).
Optional dry contact for remote indication
Standard trip temperature is 120ºF (49ºC) with other temperatures available
316 SS construction
|
|
2-Way Carbon SS Ammonia Ball KZValve (shown with KZCO's EH2 Medium Torque Actuator)
VALVE FEATURES:
- 2-way Carbon/SS ball valve
- Valve size 1" standard port
- Valve body: Carbon SS
- Ball: Vented 316 SS
- Stem: 316 SS
- Seat and Stem Packing: PTFE
- Threaded ports
- Manual override capabilities
- Max PSI 800 @ 70F
ACTUATOR FEATURES:
- High quality, durable actuator housing rated NEMA 6P for waterproof applications and NEMA 7D for Ignition Protection applications
- 12/24 VDC and 24 VAC operation available
- Tough aluminum gear box with metal gears
- Actuator housing available with "indicator flag" or with "blank" lid
- Waterproof wire plug connectors
- Private labeling available
Consult our Engineering or Sales staff for application assistance.
|
|
Our valve cluster is customized to fit your needs. With over 40 years as a leading supplier of hygienic stainless steel process equipment, why trust anyone else but Top Line.
*Our in-house valve cluster manufacturing capability reduces installation time on-site
*Pre-wired control tops in either traditional I/O or with using the AS-i network
*Pre-installed air line connections for easy hookup
*Customized log designs for reduced welds
*Professional welds
*Support frames, hangers and drip pans
Please call Top Line @ 814-362-4626 for more information on our valve cluster
|
|
Series 094 LC - valves
DN 10toDN32PN315
Application:
Service shut-oil valve located in control valve circuits, used at steel mills, steelcasting. floodgates and mining.
Leakage-free maintenance of control units for long pipes.
Low operation torque at working pressure.
Bidirectional throttle valve.
|
|
|
Safety valve type KSE/F, PN 16, angle-type body, certified, body material ductile cast iron EN-JS 1049 acc. to DIN EN 1563 (0.7043 DIN 1693), bellows made of TFM 1705 and seat replaceable, seat, plug and lifting aid made of PTFE carbon, epoxy coating, stainless steel nuts and bolts, face to face for DN 25/50, 50/80 and 80/100: DIN EN 558-1 basic series 1, ISO 5752 series 1, face to face for 100/150: DIN 3320-3, flange connecting dimensions DIN EN 1092-2 type B, ISO 7005-2 type B or flanges drilled to ASME/ANSI B16.5 class 150.
|
|
L-O-X® energy isolation valves are designed to shut off the air supply and exhaust downstream air. This product can be locked and padlocked in closed position, and serves as an energy isolation device as defined by DIN EN 1037 "Safety – Machinery".
EEZ-ON® valves are designed for a gradual buildup of downstream air pressure. This permits cylinders or other work elements to move slowly into their normal working positions before full line pressure is applied.
Consolidated L-O-X®/EEZ-ON® valves combine both pressure buildup and energy isolation functions. They can also be used as energy isolation devices as defined by DIN EN 1037 "Safety – Machinery".
|
|
Application
- as cartridge
- as modular valve
Shut-off valves are used for manually
opening and closing a channel. They
can also be used as drainage valves
against the tank line.
Shut-off valves are suitable for bidirectional
flow.
|
|
|
Skotch burner safety shut-off valves for oil-fired and gas-fired systems combine the function of three valves into one unit for increased safety and reliability while reducing installation time and labor cost. These valves have gained extensive usage in many industries including power generation, pulp and paper, refining, chemical process, pharmaceutical/bioprocessing and pollution control. They have been utilized for over 25 years and are in service on boilers and burners around the world. Since Skotch Trifecta systems are custom built for each project, we are able to modify our standard offerings to suit our customer’s various applications. Whether it involves specialty materials or components, Skotch Trifecta valve systems will simplify your installation and operation while increasing safety and reliability.
|
|
Operation
Push handle in and one quarter turn to detent - inlet open to outlet, exhaust blocked. One quarter turn of operating stem from detent position allows valve to spring return, shutting off supply and simultaneously exhausts downstream air not trapped by some other system component
|
|
|
Providing positive shutdown of an engine by shutting off it's fuel supply line, fuel injection pump, or intake air supply. These devices are typically used together with AMOT safety sensors to provide a complete emergency shutdown system. For indication of which sensor tripped, use Model 4054 Trip Indicator.
|
|
|
Manually operated, pressure relief straight-way valve with shut-off function, lift indicator and screw-in valve insert.
|
|
Shut off valves are used in the liquid line of a refrigeration system. They are generally used as a manual shut off valve.
The ABV isolates suction, discharge, and liquid line pipework during maintenance shutdown periods.
Featured with :
- Forged brass body
- Hermetic design
- Compatible with new refrigerants/lubricants
- Full internal ports through 2 1/8"
- Bi-directional fl ow characteristics
- Valve stem cap retained by strap attached to main body
- Integrated access port available on all sizes
|
|
Shut off valves are used in the liquid line of a refrigeration system. They are generally used as a manual shut off valve.
The ACK check valve is a normally closed magnetic check
valve that prevents reverse refrigerant fl ow in liquid lines and compressor discharge lines.
Featured with :
- Copper Connection Sizes 1/4" through 2-5/8"
- Hermetic Spun Copper Design
- Near Zero Internal Leak Rate
- Magnetic Checking Action
- Built-In 30 Mesh Stainless Steel Strainer
- Can Be Installed In Any Position
The ABV isolates suction, discharge, and liquid line pipework during maintenance shutdown periods.
Featured with :
- Forged brass body
- Hermetic design
- Compatible with new refrigerants/lubricants
- Full internal ports through 2 1/8"
- Bi-directional fl ow characteristics
- Valve stem cap retained by strap attached to main body
- Integrated access port available on all sizes
|
|
Performance, reliability and durability: 3 reasons MAXON valves have been the leading choice of industry since the 1920's. MAXON gas valves are the only fuel shut off valves with metal-to-metal seats that "wear in", not out. Powerful closing springs provide a reliable closing force for assurance of safe fuel shut off. The natural guillotine action of MAXON shut off valves add a self-cleaning stroke to the valve operation.
All MAXON valves are 100% tested for function and seal before leaving the factory. All MAXON valves are available with international agency approvals for a wide variety of services including hazardous areas. Nobody makes industrial gas valves better than MAXON. In today's industry environment, your smart choice for safety, loss prevention and lowest cost of ownership is a durable, long-lasting MAXON valve.
|
|
These fuel shutoff valves are semi-automatic devices for shutdown of natural gas fueled engines. The valve is opened manually and closes when the electromagnet is energized and trips the latch.
The M2582 is a 1 inch (25 mm) valve with 1 NPT connections. It has one SPDT snap-switch. The valve body is made of sandcast aluminum. It does not include the open/close indicator button.
|
|
Combustion Control Accessories Automatic Shut-off Valves (ASOV)
Automatic shut off valves are necessary in combustion systems to provide reliable, positive shut off of fuels.
|
|
High Pressure Stop Valve, forged Form with
screwed bonnet and internal stem thread
universal applications.
Typ : AVD, AVI
|
|
Since 1962, we have been improving our designs and expanding our product line in order to offer the vacuum industry stainless steel valves for almost every application. Our valves provide outstanding performance in the most demanding applications such as semiconductor and compound semiconductor processing.
General Specifications:
- Electropolished 304 stainless steel die-formed body
- 15 micron filter on air cylinder exhaust
- Full opening
- Viton® poppet O-ring, standard
- .38 to 4.0 inch port ODs
- Helium leak rate 10-9 std. cc./sec. or less
- Viton® Seal Bonnet: 10-9 Torr vacuum rating, Bakeable to 204°C intermittent, CF, NW, ISO and ASA flanges
- Copper Seal Bonnet: 10-10 Torr vacuum rating, CF flanges, bakeable to 204°C intermittent
- Pneumatically Operated: Normally closed, 60 to 80 psig operating air pressure
- Maximum differential pressure 20 psi across valve seat
- External differential presures greater than 5 psi on the bellows may result in premature bellows failure
|
|
- Model / code: R040
- Category: Stop Valve
- Body Material: Stainless steel
- Internal Ø: 6 mm
- Connections: 1/4" bspp
- Tightness: 10-4 N cm 3/s
|
|
