The Aeroflex Broadband Signal and Environment Generator (BSG) family provides the widest bandwidth and deepest memory RF/baseband signal sources available today. The BSG combines a very deep memory, very high-speed arbitrary waveform generator and a broadband RF up converter with powerful signal generation software.
The BSGs have bandwidths of up to 500 MHz and full bandwidth signal memory of up to 88 seconds into solid-state memory or 150 minutes from streaming RAID. The bandwidth, memory depth and dynamic range make the BSG a powerful tool for broadband satellite communications, frequency agile radio communications, broadband wireless network communications, and radar test. An open, software defined instrument architecture allows easy imports of user created waveforms. Vector Signal Simulator software (VSS) creates signal files for commercial wireless standards as well as generic nPSK, nQAM, nFSK, MSK, CW, tone combs, and notched noise signals. Any of these generic signal types can be gated or bursted in time, as well as hopped in frequency.
|
|
3410 Series Digital RF Signal Generators
An agile signal generator that combines wide frequency cover and high performance vector modulation in a small package, making it ideal for testing wireless communication systems and components.
- Wide frequency coverage:
-- 250 kHz to 2 GHz (3412)
-- 250 kHz to 3 GHz (3413)
-- 250 kHz to 4 GHz (3414)
-- 250 kHz to 6 GHz (3416)
- Fast RF frequency and level settling for high speed testing
- High performance vector modulation for improved component test
- Optional dual channel arbitrary waveform generator (ARB)
- Low adjacent channel power for receiver selectivity and amplifier linearity testing
- Fast GPIB response to maximize ATE system performance
- Optional List Mode for ultra-fast frequency and level hopping capability
- IQCreator® RF waveform creation software
- Wide bandwidth FM and AM modulation capability
- Optional high speed pulse modulation capability
- Compact, lightweight package
- Simple-to-use touch panel interface
|
|
The 3020 Series includes compact 3U high precision PXI modular RF signal generators with an integrated dual-channel arbitrary waveform generator. Their functionality and performance are ideally matched to the needs of RF test systems for design verification and manufacturing up to 6 GHz. They provide RF output power control ranging from –120 dBm to +6 dBm with modulation bandwidths up to 90 MHz.
The versatile 3020 Series PXI RF Signal Generator modules are designed for use together with a low noise, highly agile local oscillator input from the 3010 Series RF Synthesizer module. The performance of the 3020 Series RF signal generators makes them ideal for generating the complex modulated signals for digital radio communications test applications as well as basic AM and FM modulation and CW applications. Their excellent level accuracy, repeatability and switching speed make them an ideal choice for high-volume automated production test.
|
|
The MR-PRO is an extremely powerful analog audio generator to satisfy every need for the professional engineer. Proprietary user wave forms may be loaded via USB into the internal flash memory.
MR-PRO Features
Generator Functions
* Sine Waveforms, freely selectable frequencies, up to +18 dBu
* Sweep Signals, any frequency interval up to 1/12 octave
* White Noise, Pink Noise
* Polarity Test Signal
* Delay Test Signal
* Wave Files (*.wav)
MR-PRO ImpedanceTest Impedance and Power Test
The impedance test supports the verifications of distributed 70/100V loudspeaker installations and shows detailed information of the connected load.
* Impedance and Phase
* Apparent Power and Phase
True Level Output Stage
The compensated output stage of MR-PRO precisely stabilizes to the specified output level over a wide range of varying loads. Possible deviations at reaching the output current limit are clearly indicated.
|
|
Minirator MR2 is a powerful audio generator, offering a full range of useful analog test signals for calibration, maintenance and repair of professional audio equipment.
The rotary settings wheel combined with surrounding fast access function keys enables instant and intuitive operation without compromising fine adjustment capabilities. Instrument operation is further enhanced with a backlit LCD, illuminated mute button, safety hand strap, jack for external DC power supply and an USB interface for firmware updates.
Generator Functions
* Sine Waveforms, freely selectable frequencies, up to +8 dBu
* Sweep Signals, any frequency interval up to 1/12 octave
* White Noise, Pink Noise
* Polarity Test Signal
* Delay Test Signal
Frequency Range: 10 Hz - 20 kHz
Accuracy: 0.01%
Sweep Function: 1/1, 1/3, 1/6, 1/12 octave
Level Units dBu, dBV, V
Level range: -80 dBu to + 8 dBu
Flatness: ± 0.5 dB
Accuracy: ± 0.5 dB
res. THD+N <-90 dB (0.0032 %) @ 8 dBu
|
|
Description
Benchmark baseband, RF and microwave signal generators
Agilent offers the widest selection of signal generators from baseband to 67 GHz, with frequency extensions to 325 GHz. From basic to advanced functionality, each signal generator delivers benchmark performance in its class to address your test requirements in design and manufacturing.
Signal Creation Software
Agilent provides a comprehensive collection of application-specific software. Used with our vector signal generators, Signal Studio or embedded software will cut the time you spend on signal simulation.
Baseband Generation
Baseband Studio is a suite of digital baseband hardware, software application tools, and accessories that enable digital baseband and RF designers to generate, capture, impair, playback, and emulate real world signal conditions
|
|
|
|
|
|
Model 725 Multi-Trigger Digital Delay Generator
Researchers and system integrators, needing controls and diagnostics for their experiments and systems, are regularly forced to build from scratch or to piece together several boxes. Many hours are spent learning the idiosyncrasies of each box and how to properly couple boxes to each other. Each box has its own programming protocol. Valuable time is lost to tracking connections, taming noisy signals, adjusting timing on multiple boxes and other aggravating chores. Now one box will eliminate much of this.
The Model 725 coordinates, integrates and synchronizes complicated setups, simply, reliably and affordably. Featuring eight timing channels with programmable logic, unique timing modes and 10 ns resolution, the Model 725 outperforms a rack full of instruments, specialized boxes, filters and cables. Inputs can be logic signals, switches, transducers, interlocks, computer commands and gauges. The model 725 can be programmed and controlled easily via Labview or Windows. It contains sophisticated logic, gating and filtering. It has eight inputs, eight outputs and eight separate timers.
The model 725%u2019s logic is engineered for fast data throughput (11 ns) and minimal throughput spread (~1 ns). It would be difficult to match this performance with external cabling and hard-wired logic.
|
|
|
|
|
|
Giga-tronics' RF and Microwave signal generators utilize Giga-tronics' patented Accumulator High Frequency Feedback (AHFF™) technology delivers fast switching speed along with low phase noise performance. Giga-tronics offer two series of signal generators, the 2400C and the 2500B:
The 2500B series Microwave Signal Generators which cover 100 kHz to 50 GHz, with extremely low phase noise, high rejection of harmonics, sub-harmonics and spurious, high output power level and all with the fast frequency switching that Giga-tronics is famous for.
The Giga-tronics 2500B design team optimized the design for no compromise between speed and signal purity. Six models are available covering 2.5 GHz, 8 GHz, 20 GHz, 26.5 GHz, 40 GHz and 50 GHz. The new 50 GHz model is the flagship of the product line, offering a combination of fast switching speed and low phase noise not previously available.
The 2400C series Microwave Signal Generators which cover 10 MHz to 40 GHz, with low phase noise, high rejection of harmonics, sub-harmonics and spurious, all with fast frequency switching speed.
The Giga-tronics 2400C Microwave Signal Generators are available covering 8 GHz, 20 GHz, 26.5 GHz and 40 GHz, offering high value with a combination of fast switching speed and low phase noise at an economical price.
|
|
Generating E- and H-fields orthogonally in a ratio and conformation typical of free space, the AT5000 adds a new and needed dimension to shielded room or anechoic chamber testing.
Essentially a 2.4 x 1 meter section of parallel conductor transmission line, the AT5000 offers the 377-ohm wave impedance of free space and extends the frequency range of field generators nearly two octaves - to 100 MHz.
The open area between conductors accommodates entire assemblies within the maximum field volume. Test items too large for insertion between the elements can be brought near the parallel conductors and radiated - the AT5000 easily rotates to any horizontal, vertical or diagonal position.
The AT5000M3 version comes with a special stand which allows rotation of the field generator in three axis as well as height adjustment. Rotation accommodates test items that can't fit between conductors.
|
|
|
The MTI Instruments Model 1510A Precision Signal Source features dual-channel Direct Digital Synthesis (DSS) that produces high accuracy signals over a wide amplitude and frequency range in a compact, portable device. It generates both voltage and charge (pC) signals to simulate a variety of transducers and sensors. With multiple wave shapes, adjustable frequency, amplitude and phase, a sweep function, and 40 memory locations, it’s the ideal tool for all your test and calibration needs. The 1510A also includes a new low-voltage bridge mode that generates 5-100,000µV, with closed-loop control, allowing accurate calibration of strain gage circuits and similar sensors.
|
|
|
The GC1300 is a single-channel PCI-based Arbitrary Waveform Generator. It is a high performance waveform generator that combines many powerful functions in one small package. Supplied free with the instrument is Arbconnection software, which is used for controlling the GC1300 and for generating, editing and downloading waveforms from a remote computer.
|
|
Arbitrary waveform generator with four independently controllable channels
Even for Complex Signals, Evaluation is made easy
Easy Touch Panel Operation
Multiple Channels, 4CH (7075 ), 2CH (7075-01)
Large 128,000-Word/Channel Memory, Sweep Sequence Functions
|
|
|
National Instruments PXI and PCI signal generators include versatile arbitrary waveform generators, function generators, and RF vector signal generators. Whether generating simple sine and clock signals or complex I/Q modulated communications waveforms, the broad NI offering of signal generators can improve your prototyping and test systems by offering world-class generation performance and higher system throughput.
|
|
|
|
|
|
The R&S®SMU200A has been designed to meet all requirements encountered in research and development of modern communication systems as well as in their production. The R&S®SMU200A Vector Signal Generator not only combines up to two independent signal generators in one cabinet of only four height units, it also offers unrivalled RF and baseband characteristics.
Two signal generators in one
* Frequency options from 100 kHz to 2.2/3/4/6 GHz for the first RF path
* Optional second RF path up to 2.2 GHz or 3 GHz
* Up to two complete baseband paths
* Lossless combination of baseband signals in the digital domain (e.g. for testing multistandard base stations)
Outstanding signal quality
* I/Q modulator with 200 MHz RF bandwidth
* Very low SSB phase noise of typ. -135 dBc (f = 1 GHz, 20 kHz carrier offset, 1 Hz measurement bandwidth), typ. -139 dBc with the enhanced phase noise performance option
* Wideband noise of typ. -153 dBc (CW, f = 1 GHz, >10 MHz carrier offset, 1 Hz measurement bandwidth)
* Excellent ACLR of typically +70 dB for 3GPP FDD
* Very high level repeatability of 0.05 dB
* High output power up to +19 dBm (PEP), overrange + 26 dBm
* High-stability reference oscillator as standard
|
|
|
|
|
|
Performance:
The CDX dual frequency RF generator comes in a 1000 or 2000 watt design. The high frequency (HF) section of the CDX provides 600 or 1000 watts of power, with optional frequencies from 2 to 60 MHz. The low frequency (LF) section can deliver 600 or 1000 watts, with optional fixed or variable frequencies ranging from 20 kHz to 2 MHz.
Applications:
This solid-state generator is ideal for plasma applications including bias, etch, deposition and ashing.
Features:
Compact packaging reduces space, service (electrical and plumbing), and spare inventory requirements
Complies to CE-Mark standards and is ETL Marked and SEMI F47 compliant
Protection circuits safeguard the amplifiers from over-voltage, over-current and over-power operating conditions
Gain-control circuitry stabilizes output power against line and load variations, and limits power during high VSWR conditions
Unique power monitoring in the low-frequency section measures delivered power into any impedance load
Optional phase locked output in the low- frequency section eliminates the need for a matching network in many applications
|
|
The DTG5000 Series combines the power of a data generator with the capabilities of a pulse generator, shortens the duration of building complex test procedures and simplifies the generation of low-jitter, high-accuracy clock and serial data signals across multiple channels.
Features & Benefits
* Versatile Platform Combines Features of Data Generator, Pulse Generator, and DC Source
* Up to 3.35 Gb/s Data Rate
* From 1 to 96 Data Channels (Master/Slave)
* Class Leading Delay Resolution of 0.2 ps (DTG5274/DTG5334), 1 ps (DTG5078), up to 600 ns of Total Delay
* Modular Architecture Helps to Protect Your Investment and Allows the Instrument to Expand With Your Growing Needs
* Advanced Control Over Signal Parameters to Meet Most Current Testing Needs, Including Stressed Eye Generation
o External Jitter Injection (DTGM31, DTGM32 Modules)
o Level Control with 5 mV Resolution
|
|
