The Kaba drive units for sliding doors
The compact sliding door drive units of the DBX range not only open single-winged and bi-parting sliding doors but are also suitable for automating bi-parting telescopic doors. The systematic locking mechanism guarantees utmost positioning precision in the closed state and assists the dynamic deceleration procedure in the closed en position. A wide range of available options make sure that the optimal solution can be found for any application.
|
|
Hörmann sliding doors are a sound economic choice, above all for aircraft hangars, industrial halls, vehicle depots, large-capacity garages, building yards and maintenance halls.
They are available single and double-leaf, single and double-skinned with thermal insulation, with or without windows and, if required, also with integral wicket door.
Hörmann sliding doors are technically advanced, exceptionally robust, impact-resistant and offer effective protection against corrosion. They hardly ever need repairing and are easy to maintain.
|
|
|
A sliding gate built by Gunnebo combines development, design and production. It belongs to the most technically advanced gates in the market. Gunnebo provides steel- aluminium- cantilevered and tracked gates as well as the telescopic and special gates which offer limitless opportunities.
|
|
All the “industrial” products developed by Gantois over a period of more than 100 years are well adapted to applications in architecture and decoration.
The diversity of our offer has created for us a unique profile, because we are capable of extending our skills beyond a simple family of products.
Our knowledge and experience, associated with a policy of constant alertness and innovation, are the principal tools of our success and your satisfaction.
|
|
|
The function of the door is done in semi or full automatic version. One can open by push-down-button, key-push-down-button, photo cells, induction loop, radar, remote control or magnetic control card systems. The door can be shut by actuating the above mentioned means or an automatic time relay. A combination is possible. In case of power failure the door can easily be moved by hand.
|
|
Standard Features
- Stainless steel material contact points.
- Dust tight seals.
- Lightweight aluminium frame, corrosion resistant.
- Rated for 82°C (180°F).
|
|
These versatile valves are designed for a wide range of gravity flow applications. All share the same one-piece cast housings and heavy duty components that ensure reliable low maintenance operation for many years. Slides are sealed internally by a replaceable polyurethane or steel wiper ring. The end of the slide plate is sealed with an adjustable packing gland. Between the two seals is a wiper blade that ensures long seal life. Both the inlet and outlet flanges are drilled and tapped with identical patterns to simplify installation. A range of actuators is available to accommodate most applications.
SB-Twin Piston
- Sizes 6" through 16"
- A very compact design
|
|
|
|
|
|
Integral-passage slide valves are suitable for all those uses where perfect tightness has to be assured both to material (VLPM/ VLPC/VLPP) and pressure (VLRM/VLRC/VLRP) even in the presence of high temperature and with abrasive products.
They are used for powders and granules under silos, hoppers, batchers and screw conveyors.
Anyhow our technical service is at your complete disposal to meet any requirement.
- Valves are suitable for tightening between counterflanges UNI-PN 10 or ANSI 150 lb.
- Interior tightness is assured by a toroidal gasket acting on the blade in closed position ((VLRM/VLRC/VLRP).
- Tightness towards the outside is assured by an adjustable packing gland system.
- The manual valve control is achieved by a handwheel (VLPM/VLRM) and by a pulley with chain (VLPC/VLRC)
- The electropneumatic valve control is achieved by a double-effect cylinder activated by 1/4" Gas 5/2 single solenoid valve.
- Two proximity inductive limit-switches ø 18 are used to remote-indicate the blade position.
- Electropneumatic slide valves in special execution may be supplied with 3 positions for course / fine batching on balances.
- Electropneumatic slide valves are designed and manufactured in compliance with Community Regulations 89/392/EEC.
|
|
Shut-off valves for bulk materials must close trouble-free in
the flowing bulk material and in the product column. The
slide gate should not jam or block, and the bulk material
should not be squeezed. Slide gates from Coperion Waeschle
fulfil exactly these requirements.
|
|
Used in control loops with neutral and aggressive media in chemical and process industries. Exact control of the valve opening is assured by positioners (pneumatic or electropneumatic). As a standard the valve is equipped with an integrated top-mounted positioner.
|
|
