2PACK double point double sided presses are the result of a long and fruitful cooperation with our customers. A welded and stress-relieved monobloc frame, a generously dimensioned drive and a long high-precision ram guiding system ensure perfect mechanical operation. The absence of structure below floor level avoids the need for special masonry work, while still providing an ergonomic working height. The tool zone is designed to receive an enormous diversity of tools, especially follow-on tools.
|
|
Double point connecting rod eccentric presses for different cold stamping utilization: cutting, stamping, punching, bending, calibration, sizing, etc.
Press features:
State-of-the-art electronic control by SIEMENS.
Visual indication of current operation
Visual indication of main characteristics
Press meets all safety standards:
European standards for mechanical presses EN 692
Instruction for safety work UVV.11.062
Hydraulic safety device
Automatic change of stroke
Motorized adjustment of carriage position
Roller guides of carriage or
Sliding guides of carriage
Longitudinal shaft or
Transverce shafts
CE approved
|
|
Standard Features
• Hydraulic Clutch and Brake Providing Fast Starting and Stopping.
• Four-Piece Tie Rod Construction Frame.
• Single-Geared Drive with Opposed Twin Helical Driving Gears. (DAC Presses)
• Large Air Bag Pnuematic Counterbalance Cylinders on Inner and Outer Slides.
• Minster patented "Monitorflow" Recirculating Oil Lubrication System.
• Die Plumbing Regulators and Manifold for Front and Rear of Press.
• Air-Operated Flywheel Brake.
• Press Arranged for Front and Left Mounted Feed.
• Quick Lift in Outer Slide for Quick and Easy Die Access (DAC-H200)
• Integral Dynamic Balancer. (DAC-H200)
• Flywheel Drive Providing Higher Speed Capability (DACH Presses)
• Precision Slide Guiding System.
|
|
Standard Features:
- Minster's Production Management Control
- Cast Construction for Reduced Vibration
- Massive Bed for Exceptional Rigidity
- Crown and Eccentric Shaft Provide Strength and Resist Deflection
- Main Bearing Support Block
- Tie Rods Aid Rigidity
- Heavy Slide and Connections
- Shutheight Adjustment and Indication
- Eight Point Gibbing for Precision Slide Guiding
- Drive Arrangement Options for Maximum Press Efficiency
- Minster MonitorFlow... Continuous, Monitored Press Lubrication
- Minster Combination Air Friction Clutch and Brake
|
|
|
Machine up to 500 tonnes capacity have high quality steel one piece fabricated frames. Larger machines are manufacted with four piece construction, where the crown, two uprights and the base tightly hed togheter by four hydraulically pre-loaded steel tie rods. The slide is of high quality fabricated steel scontruction with eight adjustable bronze lined gibways. All machines are equipped with an adjustable hydraulic overload protection system and have a separate electrical control cabinet. Machines control include the following: slide adjustement indication, variable speed, lubrification monitor, bearing temperature display.
|
|
| ... products without technical information |
| |
|
Thanks to its generously dimensioned frame with main plates that lock into each other in order to relieve the welds from shear stress, the PACK-press is very attractive and can suit many purposes. Its rational design allows its use in a lot of blanking and drawing applications. The single point geared PACK-presses are provided with all requested equipment to sustain the most severe production conditions.
|
|
|
|
|
|
Hydraulic double-sided blanking press (HDS)
Hydraulic double-sided drawing press (HDZ)
Standard version:
* Safety 2-hand control in accordance with UVV (German accident prevention regulations)
* Overrun control device NKS with electrical display
* Oil backflow filter with gauge
* Oil cooler (air / water)
* Engine hours meter, stroke counter
* Ram return stroke through pressure/time switch. The holding load of the ram can be selected under pressure between 0.3 - 3 secs.
* Force for ram and drawing cushion infinitely adjustable (approx. 10 - 100%)
* Ram speed infinitely adjustable in the drawing range (min. = pressing speed)
* 8-fold guided ram with individually adjustable guide bars
Accessories:
* Light-barrier control with single and two-stroke, as well as protective barrier
* Flat or column-guided drawing cushion
* Motor-driven backward movement of the drawing cushion
* Mechanical stroke limitation of the ram, motor-adjustable
* Cutting force absorption designed for max. pressing force
* Parallel operation for the ram
* Hydraulically controlled ejector in the ram
* Blank holder in the ram
* Hydraulic tool clamping
* Sliding table
* Automatic lubrication for ram and drawing cushion guides
* Oil cooler (air / water)
* Oil pan for oil leakage fitted underneath the press frame
|
|
Specifications :
- Tonnage possible : 50, 75 and 100 T
- Bed dimensions possible :
2500 x 1200 mm
2200 x 1100 mm
1500 x 1500 mm
1500 x 1200 mm
1500 x 750 mm
1200 x 1200 mm
1200 x 750 mm
- 2 station rotary tool loader
- Linear tool loader with 2 or 3 stations with manually or powered control of movement.
- Hydraulic clamping
- Ball rail to assist loading
- The loading and clamping assembly can be fully programmed.
|
|
Our double-sided presses, also known as frame presses, are extremely flexible and versatile, allowing them to be used in virtually all areas of sheet metal processing. Our comprehensive range of equipment enables us to tailor each press to your particular task.
Our products range from the single-action press to the sophisticated double or triple-action press right through to the full-blown transfer press.
|
|
BASIC FEATURES Steel welded structure
- High rigidity and straight side structure
- Stres relieving operation after welding
- Bosch-Rexroth Hydraulic system
- SIEMENS/MOELLER/TELEMECHANIQUE Electrical parts
- Two hand control button
- Upper � lower table parallelism
Perpendicularity of ram axis � lower table
Upper and lower table flatness
Rigid frame aganst to deflection
In International standards
- 8 Contact surfaces of ram table and side wall
- Manual/automic operation
- Painted surfaces from AKZO epoxy paint
OPTİONAL FEATURES
- Barrier for operator safety
- CE certificate
|
|
Monolithic hydraulic presses
The technologies applied in Omera presses that maximize system efficiency while permitting special types of machining let you lower production costs at the same time. The choice of the most appropriate model and configuration helps meet every productive need.
Reliability and technology
In addition to the components utilized, constructive quality, experience, and the technological choices made all grant our presses extraordinary reliability. Generous sizing and painstaking attention during machining also ensure the repeatability of the production process and the longest working life of the tools.
Applications
- water heater and tank bottoms
- cooking ranges
- electrical appliances
- beverage containers
- stainless steel pots and lids
- pressure vessels
- gas tanks
- fire extinguishers
|
|
Today, our machines all are equipped with a terminal operator (IHM) of the tactile or traditional type. That makes it possible to safeguard the whole of the parameters of configuration, high race, slow speed, low of race and force (water pressure). The adjustment of the pushing force, as well as decompression are managed by a valve of pressure proportional.
By this principle, the changes of campaigns are simple and fast, we can safeguard approximately 50 programs according to the memory automat.
The hydraulic machines with arcade have the advantage of becoming deformed very little; the deformation is primarily axial. They preserve, under effort, a parallelism of the tables higher and lower.
Like the machines with columns, they are particularly suitable for the operations of loading by before and unloading by the back.
|
|
Hydraulic press of stamping to arcade
with 4 effects: 2000 kN + 800 kN + 800 kN + 800 kN.
HYDRAULIC PRESS HAS ARCADE of 1000 kN.
|
|
