The SAF series is specially designed for handling metal sheets. The resulting features permit the accomodation of the very high transverse forces which can occur in machining systems with short cycle times, such as feeder systems for press lines in the automobile industry.
|
|
Modular vacuum suction cup gripper range
The modular design of these suction grippers (ESG) is an outstanding feature which results in more than 2000 possible variants.
Individual features include:
- Suction cup holders and suction cups with the same holder size can be combined as desired.
- 15 different suction cup diameters ranging from 2 to 200 mm
- 6 different suction cup materials: perbunan, polyurethane, vulkollan, silicone, viton and anti-static perbunan
- 6 different suction cup shapes: standard, extra deep, 1.5 and 3.5 convolution bellows, oval and bell-shaped
- 14 different suction cup holders
- Angle compensation with ball joint and filter
|
|
These end effectors offer the user a wide range of advantages over traditional pick and place work holding devices. Simply by varying the air pressure in the picker or gripper, the user can conform the end effector to the diameter that is being handled and the force being applied to the workpiece. This is especially critical in applications with sensitive, thin-walled, or fragile objects. The object being picked up does not have to have a circular configuration. Since it has an elastomer bladder construction, it will conform to any shape.
Each picker or gripper can work with a wide range of diameters and workpiece weights. Firestone offers a wide range of standard configurations and sizes of AirPickers™ and AirGrippers™ end-effectors to meet most industrial applications. Special AirPickers™ and AirGrippers™ end-effectors can be, and in many cases already have been, developed to meet specific needs of a particular customer.
|
|
|
A huge selection and low prices have made us the fastest growing source worldwide for vacuum cups, suction cups, vacuum cup suspensions, and sealing rings in a dozen rubber materials. If it can be picked up with Vacuum, we have the Vacuum Cups and Suction Cups that will do it!
|
|
An impressive selection, yet so easy to understand: you know what you need – we know we have it. We call it industry-focused skills.
Automobile industry and automobile suppliers, CD/DVD industry, plastics engineering, food and beverage industry, packaging machines, automation & mechanical engineering or wood industry - FIPA has the right suction cup e. g. special suction cups individually suited to your industry.
|
|
Material's handling with vacuum pads is very simple low cost and reliable.
It is therefore a solution worth using before considering more complicated handling techniques.
Vacuum pads can lift and hold objects from a few grams up to several kg.
- Easy installation
- Low service requirement
- Low Price
- Does not damage the goods
- Fast attachment and detachment
- Limited forces
- Positioning accuracy
|
|
Rectangular, elliptical, rounded
Designed on request, in minimum lots
SPECIAL COMPOUNDS
Ongoing research and attention to the issues faced by our clients allow us to offer state-of-the-art suckers for contexts like very high or low temperatures, abrasion over large numbers of cycles, electrostatic charges, chemical attack, staining of delicate surfaces, etc
|
|
Extra-flat suction cups, series VPG
The profile of extra-flat suction cups in series VPG provides for accuracy in load gripping and speeding up of cycles rates. These suction cups are used for flat surfaces only.
|
|
|
The VP series flat suction cups are especially recommended for the handling of flat, rigid and smooth objects.
|
|
|
|
|
|
N4100 • 8" Flat Vacuum Cup with ABS Handle for High Elevation
For years, most manually operated vacuum cups have been ineffectual at high elevations; but Powr-Grip's N4100 is a new breed of hand cup that is specifically designed to handle loads at elevations up to 12,000 feet [3650 meters]. In addition to most of the advantages of the N4000, this hand-held vacuum cup also features a blue plunger, to distinguish it from other Powr-Grip vacuum cups. Supplied with protective carrying case. 8" [20 cm] diameter. 100 lbs [45 kg] capacity per vacuum cup.
Features:
•Specifically designed for use at elevations up to 12,000 feet [3650 meters].
•Blue plunger easily enables user to distinguish this vacuum cup from standard cups.
•Lightweight, heavy duty ABS handle.
•Fast attachment on smooth, nonporous flat surfaces.
•Red-line indicator warns user of any vacuum loss.
•Check valve allows repumping without loss of remaining vacuum.
•Release valve lever permits quick and complete release.
•Easily replaceable handle/release valve and plunger.
•Supplied with protective carrying case.
Specifications:
•Vacuum Pad: Flat, 8" [20 cm] diameter
•Load Capacity: 100 lbs [45 kg] per vacuum cup
All Powr-Grip products are manufactured to comply with relevant safety and design standards, including those from ASME, CE and ISO 9001.
|
|
|
|
|
|
N4950 Vacuum Cup
Built for heavy-duty production and delivery applications, the N4950 Vacuum Cup features an all-metal pump and handle for maximum durability in the factory or the warehouse. Its flat vacuum pad is ideal for handling appliances or rigid sheet materials. Supplied with protective carrying case. 8" [20 cm] diameter. 125 lbs [57 kg] capacity per vacuum cup.
Features:
• Durable metal handle.
• Fast attachment on smooth, nonporous flat surfaces.
• Red-line indicator warns user of any vacuum loss.
• Check valve allows repumping without loss of remaining vacuum.
• Release valve lever permits quick and complete release.
• Eligible for Powr-Grip Exchange Program.
• Supplied with protective carrying case.
Specifications:
• Vacuum Pad: Flat, 8" [20 cm] diameter (model G0695)
• Load Capacity: 125 lbs [57 kg] per vacuum cup
Wood's Powr-Grip has been setting the standard for vacuum lifting and mounting equipment since 1964. Every Powr-Grip hand-held vacuum cup is equipped with features to enhance worker safety, such as a patented red-line indicator, which warns the user of any vacuum loss, and a check valve that allows the user to restore vacuum without losing a grip on the load. We individually test every vacuum cup before it ships from our manufacturing facility, to make sure it functions properly and satisfies all quality standards. All Powr-Grip products are manufactured to comply with relevant safety and design standards, including those from ASME, CE and ISO 9001.
|
|
|
|
|
|
N4000 • 8" Flat Vacuum Cup with ABS Handle
The N4000 is an economical vacuum cup for use in moving desks, filing cabinets or any object with flat surfaces. The ABS polymer used in the pump and handle makes the cup lightweight, strong and rust-resistant. Supplied with protective carrying case. 8" [20 cm] diameter. 125 lbs [57 kg] capacity per vacuum cup.
Features:
• Lightweight, heavy duty ABS handle.
• Fast attachment on smooth, nonporous flat surfaces.
• Red-line indicator warns user of any vacuum loss.
• Check valve allows repumping without loss of remaining vacuum.
• Release valve lever permits quick and complete release.
• Easily replaceable handle / release valve and plunger.
• Supplied with protective carrying case.
Specifications:
• Vacuum Pad: Flat, 8" [20 cm] diameter (model G0695)
• Load Capacity: 125 lbs [57 kg] per vacuum cup
Wood's Powr-Grip has been setting the standard for vacuum lifting and mounting equipment since 1964. Every Powr-Grip hand-held vacuum cup is equipped with features to enhance worker safety, such as a patented red-line indicator, which warns the user of any vacuum loss, and a check valve that allows the user to restore vacuum without losing a grip on the load. We individually test every vacuum cup before it ships from our manufacturing facility, to make sure it functions properly and satisfies all quality standards. All Powr-Grip products are manufactured to comply with relevant safety and design standards, including those from ASME, CE and ISO 9001.
|
|
|
|
|
|
N5450 • 9" Flat Vacuum Cup with Metal Handle
In addition to all the advantages of the N4950, the N5450 Vacuum Cup features a slightly higher capacity and flexible edges on the vacuum pad, to handle Lexan®, Plexiglass® and other materials that may bend when lifted. Supplied with protective carrying case. 9" [23 cm] diameter. 150 lbs [68 kg] capacity per vacuum cup.
Features:
• Durable metal handle.
• Fast attachment on smooth, nonporous flat surfaces.
• Flexible vacuum pad edge for materials that may bend or flex when lifted.
• Red-line indicator warns user of any vacuum loss.
• Check valve allows repumping without loss of vacuum.
• Release valve lever permits quick and complete release.
• Eligible for Powr-Grip Exchange Program.
• Supplied with protective carrying case.
Specifications:
• Vacuum Pad: Flat, 9" [23 cm] diameter (model G0725)
• Load Capacity: 150 lbs [68 kg] per vacuum cup
Wood's Powr-Grip has been setting the standard for vacuum lifting and mounting equipment since 1964. Every Powr-Grip hand-held vacuum cup is equipped with features to enhance worker safety, such as a patented red-line indicator, which warns the user of any vacuum loss, and a check valve that allows the user to restore vacuum without losing a grip on the load. We individually test every vacuum cup before it ships from our manufacturing facility, to make sure it functions properly and satisfies all quality standards. All Powr-Grip products are manufactured to comply with relevant safety and design standards, including those from ASME, CE and ISO 9001.
|
|
|
|
|
|
TL6FH & LP6FH • 6" Vacuum Cups with Flip Handles
The narrow profile of these vacuum cups makes them an excellent tool for pulling sheet materials from narrow storage locations, as well as for general-purpose handling. They are large enough for most manual lifts, yet small enough to fit in a toolbox or large pocket, making them convenient to use in the warehouse or at delivery locations. The TL6FH Vacuum Cup is designed to grip curved surfaces, the LP6FH to grip flat surfaces. Supplied with vacuum pad protector. 6" [15 cm] diameter. 70 lbs [32 kg] capacity per vacuum cup.
Features:
• Flip-over bail handle permits load to swing or change orientation as needed.
• Narrow profile allows for attachment in tight storage locations.
• Available in styles for gripping smooth, curved (TL6FH) or smooth, flat nonporous surfaces (LP6FH).
• Red-line indicator warns user of any vacuum loss.
• Check valve allows repumping without loss of remaining vacuum.
• Lift tabs on vacuum pad edges permit instant release.
• Supplied with vacuum pad protector.
TL6FH Specifications:
• Vacuum Pad: Concave, 6” [15 cm] diameter (model TL6)
• Minimum Radius for Curved Load: 12” [305 mm]
• Load Capacity: 70 lbs [32 kg] per vacuum cup
LP6FH Specifications:
• Vacuum Pad: Flat, 6” [15 cm] diameter (model LP6)
• Load Capacity: 70 lbs [32 kg] per vacuum
All Powr-Grip products are manufactured to comply with relevant safety and design standards, including those from ASME, CE and ISO 9001.
|
|
|
ANVER Soft-Touch Vacuum Cup Suspensions feature spring suspensions made from stainless steel and a wide variety of bellows-style vacuum suction cups for gently handling delicate loads with minimal force. Compensating for variations in object height, these spring-loaded suspensions and cups absorb shock and provide constant pickup pressure for optimum load control.
|
|
|
Range of the suction cups high performances Series a.c. developed to fulfill the requirements of the applications of production of the Automobile sector. The increased characteristics of the range Série C make it possible to optimize the production equipments in all the spheres of activities. A range supplements forms and diameters to meet each need. Butted antiglissements ensuring an optimal positioning of oily sheets. Suction cups structured for fine sheet gripping without deformation. Ideal for robotized applications. Use more precisely in the sectors of stamping and the door-fitting.
|
|
Bag opening suction cups, series MVS
The suction cups in series MVS are specially designed for the handling, opening and gripping of bags, etc...
|
|
|
A huge selection and low prices have made us the fastest growing source worldwide for vacuum cups, suction cups, vacuum cup suspensions, and sealing rings in a dozen rubber materials. If it can be picked up with Vacuum, we have the Vacuum Cups and Suction Cups that will do it!
|
|
|
Exact duplicates with a complete selection and low prices have made us the fastest growing source worldwide for vacuum cups, suction cups, vacuum cup suspensions, and sealing rings in a dozen rubber materials. If it can be picked up with Vacuum, we have the Vacuum Cups and Suction Cups that will do it!
|
|
Bellows type suction cups 1.5, series VSA
The bellows type suction cups in series VSA combine the advantages of flat suction cups( accuracy, positioning at stop) and the freedom offered by bellows (angle and flexibility). They offer flexibility, precision and small inside volume suitable for rapid cycles.
|
|
Flat suction cup:
- Stability in quick production rate
- Anti-distortion stops
- Ø2 to 320 mm
- Force: 0.01 to 267 kg
- Materials and Filling as one chooses
1.5 bellow suction cup
- Stability in translation
- Gripping flexibility
- Ø5 to 285 mm
- Force: 0.05 to 98 kg
- Materials and Filling as one chooses
2.5 bellows suction cup
- Gripping flexibility
- Compression stroke
- Ø5 to 90mm
- Force: 0.06 to 18 kg
- Materials and Filling as one chooses
Special suction cups
- Suction cup for cheese, bakery, bottles, detectable...
|
|
GROUND LIP
For a perfect seal on minimum contact with the item to be handled
ANTI-AGEING TREATMENT
Designed exclusively by us, it allows the definition of the chemicophysical characteristics of the compounds we use, ensuring a product that is unalterable through time.
SPECIAL COMPOUNDS
Ongoing research and attention to the issues faced by our clients allow us to offer state-of-the-art suckers for contexts like very high or low temperatures, abrasion over large numbers of cycles, electrostatic charges, chemical attack, staining of delicate surfaces, etc.
|
|
Our more than 1000 vacuum cup sizes and 30 standard molding compounds make our vacuum cup product line one of the most comprehensive and used worldwide.
For our product listings of vacuum cups, vacuum generators, and vacuum accessories
Seal Science engineers are versed in vacuum cup technology. That can design a vacuum cup that will securely move your parts, in whatever environment, at the rate you require.
We stock many sizes and can manufacture vacuum cups of almost any size and dimension.
Our range of elastomeric compounds allows us to choose a vacuum cup that will meet your conductive and dissipative specifications, ESD needs, or low tack and non marking requirements. Usually a vacuum cup from our large inventory will insure that your downtime is minimized. Also, you will find our vacuum cup prices very competitive.
|
|
|
ZP series vacuum cups are available in 19 diameters from 2 to 200mm, 6-cup materials, and 4 cup designs, offers a wide selection to choose from. The 4-cup designs flat, flat with ribs, deep and bellows are standard, but if these don’t meet your application requirements, contact us about your special application. Our engineers have custom made many designs and shapes using a variety of materials.
|
|
The vacuum created by dual cups allows easy lifting of heavy weights. The suction is broken only when the fingertip-operated bar is lifted. Aluminum handle is 10" long with dual 4" & 5" cups, and 7" long with dual 3" cups.
•Model A6541 Dual 5" cups
•Model A6540 Dual 4" cups
•Model A6520 Dual 3" cups
|
|
Practical application grabber cups for follow operating ranges:
- Glass
- Wood
- Plastics
- Plates
- Ceramic
Your advantages:
- No vacuum pump requiered
- High holding power
- Easy use
- With release button
- Available in 5 different sizes
|
|
Vacuum cups are used extensively by the packaging and printing industries. They are also used in a wide variety of automated material handling applications involving metal, plastic, glass, wood, and stone. With so many applications, All-Vac has made it a priority to carry a vast stock of vacuum cups to meet our customers’ needs.
Our supply of over 700 different kinds of cups is either ready-to-go when you place your order, or can be made quickly and easily to your specifications. From round to oval cups; large to small cups; cups made of rubber, vinyl, silicone or urethane; cups with fittings or through holes; cups that are tall with bellows or low profile with cleats; All-Vac can fill your vacuum cup orders. We pride ourselves on our knowledge of the industry, and our ability to get our product to you quickly and reliably, no matter what size your order.
Order our catalog to see mechanical drawings, pictures and specs for over 700 different vacuum cups.
|
|
|
Several short bellows cups in one lifting device can handle objects with height differences and varying shapes. The bellows also provide a slight lifting movement to separate thin items. DURAFLEX® are suction cups manufactured in a specially developed material that features the elasticity of rubber and wear resistance of polyurethane. The material is mark-free.
|
|
Force table suction cups
Round suction cups
Round suction cups with threaded connection
Round suction cups for thin materials
Bellows-type suction cups with 11/2 folds
Bellows-type suction cups with 21/2 folds
|
|
The SPHERICAL SUCTION CUPS are general purpose suction cups.
Realised in silicon with hardness 45 Shore, they can withstand temperatures of up to 250°C.
|
|
|
|
