MTS MEGA VAC
Performance Data
Max. Suction Depth 25 m +
Max suction distance 120 m +
Technical Data
Container
Spoil capacity 10 m³
Turbines
Multiple
turbine technic
Type Quad turbine
MEGA VAC
Air flow 36.000 m³/h
Negative pressure 55.000 Pa
Turbine performance 2 x 110 kW + 2 x 110 kW
Suction performance In pairs single
controllable (2 + 2)
Suction hose boom
Suction boom a) MTS Telescopic boom extendable up,5 m / 6,5 m
b) MTS Power Arm extendable up to 8 m
Suction hose Ø 250 mm
Air compressor
Air volume 4,5 m³/min at 8 bar
Dust free filter system
3-stage self-cleaning system
based on cyclonique principle
coarse separator, fine separator and fine filter cartridges
Isonorisation
Transport vehicle
Gross weight 32 t
|
|
MTS Suction Excavator DINO 4
Performance Data
Max. Suction Depth 20 m
Max suction distance 100 m
Technical Data
Container
Spoil capacity 9-10 m³
Fans
High performance turbines
(Turbo) Multiple
Turbine technic
Type Single turbine
DINO 2 - 4 Double turbine
DINO 2-4 MEGA Quad turbine
MEGA VAC
Air flow 25.000 – 32.000 m³/h 36.000 m³ /h 36.000 m³/h
Negative pressure Max 20.000 Pa 34.000 Pa 55.000 Pa
Turbine performance 100 – 160 kW 2x 110 kW 2 x 110 kW + 2 x 110 kW
Suction performance in stages controllable in stages controllable In pairs single controllable (2 + 2)
Suction hose boom
Suction boom a) MTS Telescopic boom extendable up,5 m / 6,5 m
b) MTS Power Arm extendable up to 8 m
Suction hose Ø 250 mm
Air compressor
Air volume 4,5 m³/min at 8 bar
Dust free filter system
3-stage self-cleaning system
based on cyclonique principle
coarse separator, fine separator and fine filter cartridges
Isonorisation
Transport vehicle
Gross weight 32 t
|
|
MTS Suction Excavator DINO 3 (26t)
Performance Data
Max. Suction Depth 20 m
Max suction distance 100 m
Technical Data
Container
Spoil capacity 8 m³
Fans
High performance turbines
(Turbo) Multiple
Turbine technic
Type Single turbine
DINO 2 - 4 Double turbine
DINO 2-4 MEGA Quad turbine
MEGA VAC
Air flow 25.000 – 32.000 m³/h 36.000 m³ /h 36.000 m³/h
Negative pressure Max 20.000 Pa 34.000 Pa 55.000 Pa
Turbine performance 100 – 160 kW 2x 110 kW 2 x 110 kW + 2 x 110 kW
Suction performance in stages controllable in stages controllable In pairs single controllable (2 + 2)
Suction hose boom
Suction boom a) MTS Telescopic boom extendable up to 5,5 m / 6,5 m
b) MTS Power Arm extendable up to 8 m
Suction hose Ø 250 mm
Air compressor
Air volume 4,5 m³/min at 8 bar
Dust free filter system
3-stage self-cleaning system
based on cyclonique principle
coarse separator, fine separator and fine filter cartridges
Isonorisation
Transport vehicle
Gross weight 26 t
|
|
MTS Suction Excavator DINO 2
Performance Data
Max. Suction depth 20 m
Max suction distance 100 m
Technical Data
Container
Spoil capacity 4,5 m³
Turbines
High performance turbines
(Turbo) Multiple
turbine technic
Type Single turbine
DINO 2 - 4 Double turbine
DINO 2-4 MEGA Quad turbine
MEGA VAC
Air flow 25.000 – 32.000 m³/h 36.000 m³ /h 36.000 m³/h
Negative pressure Max 20.000 Pa 34.000 Pa 55.000 Pa
Turbine performance 100 – 160 kW 2x 110 kW 2 x 110 kW + 2 x 110 kW
Suction performance in stages controllable in stages controllable In pairs single controllable (2 + 2)
Suction hose boom
Suction boom a) MTS Telescopic boom extendable up to 5,5 m / 6,5 m
b) MTS Power Arm extendable up to 8 m
Suction hose Ø 250 mm
Air compressor
Air volume : 4,5 m³/min at 8 bar
Dust free filter system
3-stage self-cleaning system
based on cyclonique principle
coarse separator, fine separator and fine filter cartridges
Isonorisation
Transport vehicle
Gross weight 18/19 t
|
|
|
|
