CNC swiss-type automatic lathes
The SPEED linear series, is the flexible, and highly productive, automatic lathe of the future. An efficient combination made from years of experience and innovative know-how, makes this completely redesigned series, truly fascinating. The completely user-friendly work area allows machining with up to 3 tools in simultaneous operation, this results in maximum productivity for machining simple parts, or more complex workpieces, that have higher requirements. These features make the SPEED linear series ideally-suited for applications in industries such as hydraulics, shaft, automobile, electronics and medicine. For the first time, the successful linear technology is available for a complete series, guaranteeing the highest precision and processing safety.
|
|
|
|
|
|
CNC sliding head automatics from TRAUB are designed for the exact and productive manufacturing of long and slim parts with a maximum diameter of 32 mm. The multitude of variants, miniturization and precision of the workpieces are but a few of the demands on a CNC sliding headstock automatic. The TNL-series is characterized through high performance in combination with easy setup and programming. The machines are based on a modular building block system with up to four independent tool carriers.
TNL12
- High production rates due to simultaneous machining with up to four tool carriers at two identical spindles; 0.3 sec chip-to-chip time
- Two tool carriers with X- and Z-axis and six stations each for driven tools
- Front and rear working each have one tool carrier, which have four stations per carrier
- Minimal tool interference because of the patented arrangement of four tool carriers in two intersecting planes
- Universal tooling, short setup times using the comprehensive tooling system, the patented tool mounting and preset tool holders
- Good accessability in spite of the compact architecture; exterior dimensions are independent of equipment options
|
|
Large output and high precision processing capability.
- User-friendly design for easy maintenance.
- Outstanding precision processing capability through the 3-axis control.
- Excellent expandability with polygon, gun drill, and so forth.
|
|
Automatic Lathes equipped with Star Motion Control System : SR-20R III
- A control system and high-speed feed to reduce dramatically non-cutting time
- A structure of superb rigidity thanks to Star original design
SPECIFICATIONS
Max. machining diameter ø20mm (25/32in)
Max. headstock stroke
- Standard 205mm(8in)
- with RMGB 172mm(6-25/32in)
4-spindle sleeve holder
- Max. drilling capacity ø10mm(25/64in)
- Max. tapping capacity M8×P1.25
- Max. die cutting capacity M8×P1.25
Power-driven attachment
- Max. drilling capacity ø8mm(5/16in)
- Max. tapping capacity M6×P1.0
- Max. milling capacity ø10mm(25/64in)
- Max. slotting capacity 1.5mm(W)×4mm(D)
Main spindle speed max.10,000min-1
Main spindle motor(continuous/15min.) 2.2kw/3.7kw
Dimension(W×D×H) 2,200×1,200×1,700mm
Weight 2,200kg
|
|
Deco
This range combines the advantages of cam-operated lathes - speed, reliability and productivity with the advantages of NC machines: versatility, flexibility and precision.
- user-friendly, versatile and fast operation
- fast accessibility to all elements
- abiliy to work with three to four tools simultaneously
- optimising movements by managing feed rates
- machining calculated in real time
- outstanding thermal stability
- large swarf bins
- powerful and efficient motor drives
DECO
- DECO 7/10a
- DECO 13a
- DECO 20a
- DECO 26a
- Options Single Spindle
|
|
| ... products without technical information |
| |
- short tool changing times
- high precision guaranteed for smooth cutting
- very good surface finish on the threads
- high tool life per edge due to even cutting action
|
|
WhizCut offers a complete range of toolholders and indexable carbide inserts specially developed for swiss automatic lathes.
The WhizFix toolholder system for external turning uses a bent pin and a nut to index the insert. Indexing an insert is easy, accurate and quick. You can index or change the insert while the toolholder is in the machine even if there only is access from the back side of the toolholder
|
|
WhizCut provides an efficient solution to the problem of limited space when indexing inserts in a modern cnc Swiss Type Automatic lathe. Almost all types of external applications can be performed using two toolholders, one for axial turning and one mainly for radial turning (parting off etc.). The WhizCut system enables each toolholder to clamp up to 40 different kinds of inserts for various applications.
The WhizFix toolholder system uses a pin and a nut to make it possible to index or change the insert from the opposite side of the toolholder. The inserts can be indexed within 15 seconds even without access to the insert, making it the most effective system on the market today for cnc automatic lathes.
|
|
Posimatic™ - Swiss Automatic
Stellram has a range of tools for use on Swiss Auto type lathes with small cross section shanks from 0.375" (10mm) square to 0.750" (20mm) square. Grades and geometries are available to handle the specific feeds and speeds associated with these machines.
Some other features of this program are:
Nose radii starting at 0 for excellent surface finishes and sharp internal corners
New - 62 geometry and new PVD technology
Equal shank and tool tip dimensions on all toolholders for programming ease
Boring bars with standard coolant holes to aid in chip evacuation
Part-off inserts from 1.6mm/0.063" to 3.0mm/.118" widths
Integral shank cutoff and grooving holders for maximum rigidity
Back turning holders and inserts for turning behind a shoulder eliminates additional operations
Tungsten Carbide reinforced boring bars to eliminate chattering
New ultra-mini boring, grooving and threading tools for holes as small as 0.110"
|
|
| ... products without technical information |
| |
PartMaker applies a Patented "divide and conquer" programming strategy to simplify the programming of CNC Swiss-Type Lathes. The software helps the operator break a complicated part surface into a set of planes or faces. Machining tasks, such as turning, plane milling and cylinder milling are carried out separately for each face in an intuitive manner.
A patented visual programming approach assures quicker learning and ease of use. PartMaker supports virtually all CNC Swiss-type lathe models on the market including machines from Citizen, Star, Tornos, Tsugami and others. To learn more about specific machines supported, please see the compatibility chart below or visit our Gallery of Parts.
|
|
|
|
