STANDARD EQUIPMENT
OPTIONS
SNT3 base - Coolant unit - 24V illuminating attachment - Electrical tapping attachment - Quill powerfeed box 0,1 mm/t - Raising column - Intermidiate table - Micrometric feed box - 1PH motor - 3PH motor - Chuck guard security - Attachments - 2 speeds motor
|
|
| ... products without technical information |
| |
Die spotting press / try-out press
* 4-column presses (HTP)
* 4-column presses (HS4-W)
* Hyd. double-sided presses (HD-W)
Pressing force: 630–25.000 kN
|
|
|
|
|
|
DESCRIPTION
The press BV or MIL is used for splitting, adjusting, maintenance and try-out operations on dies and moulds (thermoplastics, die casting, thermosetting, rubber and blanking) and it is possible to inject special waxes, at low pressure, into the mould.
CONSTRUCTION
The very sturdy structure consists of a welded and normalized steel basement and cast iron base-plate.
The lower plate is idraulically extensible and therefore it makes easier the carrying-out of the mould loading and unloading. Furthermore it makes possible to draw the die or mould lower part out of the press by carrying-out the treatments in effortless work position.
The upper plate slides vertically by hydraulic actuation on the four guide columns and can be overturned by 360° way it is possible to put the upper part of the die or mould upper part in effortless work position. The upper plate clamping in the exact horizontal positioning will be given by four hydraulic actuated locating pegs.
CONTROL PANEL
Each button on the control panel is marked with a clear function. The sequence of movements is controlled by PLC-SIEMENS S7 to prevent any mistake of the operator.
MACHINE CONTROLS
Pre-programmed SIEMENS S7- electronic controls.
ADVANTAGE
- Digital control of the parallelism
- Digital monitoring of stroke
- Digital monitoring and setting of pressure
- Self-learning system for recording of mould stroke
- Multi-languages diagnostic error search
- Management of all press functions
|
|
|
REIS try-out and spotting presses guarantee perfect dies prior to production run. High quality, precision and economic efficiency of our spotting presses offer decisive advantages for any tool and die maker. REIS spotting presses reduce the production costs for a die and also result in reduction of fixed costs.
|
|
| ... products without technical information |
| |
Enter the value of X mm
Enter the value of Y mm
Utilisation with nozzle
Height disc of support bottom mm
Height disc of support top mm
|
|
