- Big keys for use with gloves
- Programmable characteristic curve end points (up to 24 control points)
MIN/MAX value detection,
- Display-Hold
- Auxiliary power output for measuring transducer/sensor
- Optocoupler or relay outputs
- Programmable limit values
- Optional: with serial interface
|
|
|
The Tecal Accu-Temp is a good choice for use as a laboratory grade reference thermometer. It's available in a single or dual channel model, along with direct temperature readout in degrees F, C and ohms. Combine the Tecal Accu-Temp with one of our secondary standard PRT's for a high accuracy temperature measurement system. Don't rely on battery operated, low accuracy hand-held model PRT indicators for your critical temperature measurements.
|
|
Enhanced indicator
Double input Indicator - Transmitter with four addressable alarms
1/8 DIN 96x48
Universal input for temperature sensors, mA, mV, Volt, IR, custom
High level second input 0/4...20 mA, 0/1...5, 0...10 V
3 digital inputs
3 SPST relays NO, 1 SPDT relay
0/4...20 mA retransmission output
4 addressable alarms with delay, latching and blocking functions
ISA sequence on alarms
Display of MIN, MAX value
Hold and temporized hold to display peaks
Dedicated alarm acknowledge key
5 digits 2 colors display with different combinations
RS 485 serial communications
Power supply 100...240 Vac, 24 Vac,dc
Transmitter power supply
IP65 front panel protection
|
|
S1305
Format: 96x96 mm (1/4 DIN)
Installation depth: 122 mm
The universal monitoring instrument
* Instrument with 3 limit contacts
* Universal Input (Pt 100, TC, 0 / 4...20mA, 0...10Vdc)
* Easy handling
|
|
|
|
|
|
MOLTEN METAL TEMPERATURE INDICATOR
PRODUCT DESCRIPTION:
Libratherm offers microcontroller based Molten Metal Temperature Indicator model LMI-2010, which is designed to accurately measure temperature of the molten metals, both ferrous and non ferrous. The measurement of this temperature is a critical process, since the expendable thermocouple is dipped for merely 3 to 4 seconds and then withdrawn. In this short measurement time, the operator is guided through the measurement cycle by audio/visual alarms for thermocouple continuity, measurement in progress and measurement over. Any error in measurement or thermocouple open condition is also immediately detected by activating the audio/visual alarm.
User can select the desired type of thermocouple (either K, R, S, or B type, (depending upon the measuring range from 1200 to 1800oC), and can also set other parameters using front panel key board. During measurement, the indicator ignores the slag temperature and the Average or Plateau reading is determined using the advanced algorithm and the same is latched and displayed on the bright 7 segment 2” LED display. This reading can also be displayed on 4” remote display LRU-2010 and can be logged on to a computer using serial RS485 MODBUS RTU protocol for recording and analysis purpose. Libratherm offers supporting window based software.
|
|
The powerful indicator N1500 offers among its universal input and the 2 relay outputs for the monitoring of the threshold values many other functions. The Min.- and Max.-values can be prompted with just a keystroke. Also there is a Hold and a Peak-Hold Function whose readouts can be deleted using either the function key or the digital input. The high tact frequency of 15 measurements/second (5 measurements/second when using linear input, thermocouples or Pt100) allows the N1500 indicator to monitor fast processes. It offers also the possibility to linearise the measurement signal when using non-linear input signals (mV, V, mA).
Features:
- Universal input
- Linearization of mV, V, mA signals
- 2 Relay outputs
- 6 Alarm features
- Voltage output 24 VDC for external 2-wire transmitter
- Memory for MAX and MIN values, hold and peak features
See more information in our shop:
***www.temperature-shop.de***
|
|
Various sizes displays with or without alarm functions.
Different mounting types f.ex wall or panel mounting.
|
|
| ... products without technical information |
| |
1/8 DIN Standard
The K3MA series consists of a process indicator, a frequency/rate indicator and a temperature indicator. All models are equipped with a highly visible LCD display with 2-colour (red and green) LEDs, have a 96 x 48mm front housing and the same short depth of 80mm.
|
|
Programmable panel meter for process, temperature and load cells.
Size: 96x48x60 mm.
Tricolor display: ±19999 (4 ½ digits)
|
|
|
|
|
|
HUMLOG 10 series humidity/temperature data loggers permit the exact and professional recording of humidity and temperature values. Low power consumption and large memory size enable long-term data capture for a wide range of applications.
HUMLOG 10 / HUMLOG 10TSE:
The elegant 2-part housing, which consists of a display module and a plug-in sensor module, enables easy installation and a fast exchange of the sensor unit when service is required.
The current measurement data on the large display is easy to read even from a distance of several metres.
HUMLOG 10THC:
The compact HUMLOG 10THC version does not have a display and is equipped with internal H/T sensors.
Measurement Data - Evaluation & Configuration:
Measurement data evaluation and instrument configuration can be conveniently performed via the serial RS232 interface with a PC or notebook computer by means of the Smartgraph TM 2 software, which runs under MS Windows TM.
Smartgraph TM 2 can display the recorded measurement data in graphical form or as a table. The layout of the display can be individually configured by the user.
|
|
|
|
|
|
Product Guide
Temp. and Humidity recorder TR-71U/TR-72U
Single Temperature datalogger + Timer DTM-317
Daul Temperature datalogger DTM-318
0 °C ~ 50°C+/-3°C; 10 ~ 95% +/- 5%
USB Connection
One Year Continual
Use on One Set of Batteries
Simultaneous Monitoring of Multiple
Channels of Data
High Speed Data Transfer
Large Data Capacity: 8,000 Readings X 2
Channels
Adjustment Function
Accurate, Compact,
Lightweight and Affordable
Easy to Read Multi-Functional Display
Humidity/Temp Meter w/Dual Input
Model : DTM-321/DTM-322
Temp:-20°C ~ 60°C (-4°F ~ 140°F ); K-type:
-200°C ~ 1,370°C (-328°F ~ 2,498°F);
Humidity: 0 ~ 100% RH
4 Digit, Triple display.
K-type Termocouple.
Reading hold °C or °F annunciators.
MAX, MIN. function.
Auto power off.
ÄREL function. (DTM-321)
Automatic low battery indication.
RS-232 computer interface.
RS-232 cable and software for Windows( DTM-
322).
TR-71W Web Temperature Data Logger (USB)
TR-72W Web Temperature / Humidity Data
Logger (USB)
About the TR-7W Series Web Viewer
View Reading on a Cell phone
Recording Settings Monitor Current
Readings
Downloading Recorded Data Graph
Send Warning Messages by E-mail Main
Unit Settings
Wireless Lan Option Brings Flexibility &
freedom
Compact / Lightweight / Water Resistant!
No Switches means No Fuss / No Mistakes /
No Tampering
Wide Temperature Measuring Range:-60°C
to 155°C
Two Types to meet your Needs
Large Data Capacity: up to 16,000 Readings
Battery Life Good for up to
Two Years of Continued Use
Wide Selection of Recording Intervals
|
|
Only Download Data When You Need To!
24/7 feedback through Min/Max or Real-Time Display, bolstered by visual and audio high/low alarms. Features: USB-enabled triple-speed downloading, FLASH memory card data transfer-capability, +/-0.8F accuracy, large display, and visual/audio alarms
|
|
Datalogger ECOLOG TH1
- Connection for 1 integrated (-35°C ..+55°C; 0% ..+100% rH) orup to 2 external humidity and temperature probes (-35°C ..+70°C; 0%..100% rH) orand second temperature probe(-50°C..+140°C)
- Calibrated, exchangeable humidity and temperature probes
- Memory capacity for 64,000 measured values
- Large display with alarm information
- Key pad with 4 keys, external start, alarm reset, measured value and alarm scroll
- 1 digital input
- DB15 multifunction connection with alarm output and RS232
- Direct printout of measured values and alarm data at printer
- Ecolog TH1 with white housing Part No.: 2423-W
- Ecolog TH1 EEX with approval for EEX zone 1
|
|
Data logger HygroGuard 10 / 20
- Complete, battery powered, ready to use data logger system
- Included data acquisition/configuration software
- Included data transmission cable
- High storage capacity of 120'000 data points
|
|
The DRAABE HumSpot steers and supervises the humidification of the individual zones (e.g. different areas, work areas). The simple menu guidance and the lit color display guarantee high convenient operation. Their advantages:
• Point-exact activation of the air moisturizers on falling below of the adjusted dampness desired value
• High measuring precision by digital, capacitive dampness measuring technique
• Permanent status indication of relative dampness and ambient temperature
|
|
| ... products without technical information |
| |
|
The CT224 consists of a 12-Channel Temperature Monitor and MincoSoft™ CT224 Software. It is the next generation in temperature monitoring equipment from Minco designed to meet the needs of electric machinery protection. The 12-channel scanning capability, standard RS485/RS232 interface and Windows-compatible software utility for system configuration and data logging provide overtemperature and undertemperature protection and critical feedback to safeguard expensive machinery.
|
|
|
|
|
|
Multi-funcitonal Thermocouple Thermometer ( DTM-3105 )
Thermocouple Thermometer Model DTM-3105
FUNCTION:
ON/OFF, HOLD/TEST, °F/°C, MIN/MAX ( °F/°C) MEMORY RECALLING
* Carrying Case and 4 TC probes Included
PROBE MODEL NO.:
1. DTM-3105-TPK4 Surface probe (230 mm)
2. DTM-3105-TPK5 Air probe (235 mm)
3. DTM-3105-TPK03R Round head immersion probe (130mm)
4. DTM-3105-TPK03S Pin point head immersion probe(125 mm)
FEATURES:
Rubber coated product case
High degree of accuracy
Extra EVA box for easy and protective storage
Four probes included
Comprehensive and variety use for different object (e.g. surface, semi-solid, air)
Large LCD display
MEASUREMENT RANGE
-100°C ~ +300°C or -148°F ~ + 572°F
RESOLUTION:
0.1° for -199.9° ~ +300.0°
ACCURACY:
± 2°C from -200°C ~ -50°C (or 4°F from -328°F ~ -58°F)
± 1°C from -49°C ~ +300°C (or 1.8°F from -56.2°F ~ +572°F)
Accuracy is specified for operating temperatures over the range of 18°C to 28°C (64°F to 82°F). The basic accuracy specification does not include the error of the thermocouple probe.
|
|
Limit value monitoring devices
SG-mc Digital
Limit Indicator
35 mm DIN - rail mounting
* Universal sensor input
* (Pt 100,TC, 0 / 4...20mA, 0...10VDC)
* Alarmcontact free programmable with latch function or without latch function.
* Latch-reset by mini-switch or by power on/off
* Easy handling
|
|
|
|
|
|
The LumaSense Accufiber®TR solution provides temperature monitoring with automatic emissivity correction. Emissivity changes are due to changing material properties during certain types of material deposition or processing. For specular (smooth) surfaces, the deposition surface’s emissivity can be calculated from its reflectance. By constantly measuring this reflectance, the AccufiberTR instrument can automatically perform the emissivity correction in-situ and calculate the surface’s true temperature.
AccufiberTR seamlessly integrates ultra precise reflectance measurements with LumaSense’s class leading, lowest signal-to-noise ratio radiation detectors. If the n and k values are known for the materials, then the amplitude and periodicity of the thin film reflectance (often referred to as “fringes”) at specific wavelengths can be used to calculate film thickness. For thin films, it is critical to use both the highest quality measurement systems and shorter wavelengths to offer “resolution” into the film’s fringes to monitor film thickness.
|
|
Turbine Sentry - System Overview
An overview of the complete system and how this system is of benefit to gas turbine operators.
A typical system comprises three parts:
Blade Sentry - Measurement Pyrometer
The non-contact thermometer is mounted through the gas turbine casing and measures the temperatures of individual rotor blades.
Rotor Sentry - Data Acquisition System
The DAS logs individual blade temperature readings taken by the measurement pyrometers, samples and processes the data for use by the data analysis software, Data Sentry.
Data Sentry - Data Analysis Software
This powerful pc-based software utility has all the tools and functions necessary to obtain a complete picture of how efficiently the gas turbine is running, as well as identifying potential problems at an early stage.
|
|
| ... products without technical information |
| |
|
|
