Environmental simulation chambers for constant climatic conditions
BINDER KBF series:
The KBF series was particularly designed for absolutely reliable stability tests and precise maintenance of constant climatic conditions. It naturally also complies with all applicable guidelines such as ICH, FDA, GMP and GLP, with respect to programming and documentation requirements; with its large reserve capacity and many optional features, it is designed to meet future challenges for many years to come.
|
|
The PGC 4.5 cu. ft. chamber features our unique humidity control system that enables the user to attain unsurpassed levels of RH/temperature control and uniformity.
These test chambers are designed to accurately produce those temperature and humidity conditions required for applications such as stability studies, package testing, TAPPI, MIL-SPEC, and vapor transmission.
Applications are found in such diverse industries as pharmaceutical development and manufacturing, electronic components, food, semiconductor, paper and pulp, and wherever precise humidity and temperature replications are required.
|
|
Laboratory Test Chambers
Temperature and Climatic Test Chambers
Series VTL and VCL
Compact, quiet, yet powerful units are required to tackle special requirements within limited laboratory space. Also tests are made on smaller specimens - all this directly at the work station.
The VTL and VCL series of temperature and climatic test chambers are ideally suited to such applications.
Test space volumes
34, 64 and 100 l
Temperature range from
+10°C to +180 °C
-40 °C to +180 °C
-70 °C to +180 °C
Humidity range
10 to 98 % RH
Control System:
Controller Board S!MPAC* with Touchpanel
|
|
|
|
|
|
TAPPI Rooms
AN UNSURPASSED RH CONTROL OF ±0.5%
TAPPI Room PDF Parameter Generation and Control (PGC) manufactures TAPPI room systems and conditioners for existing laboratories. These systems provide the precise temperature and humidity control required by TAPPI T402 om-88.
We offer a complete package:
We manufacture your room or chamber to operate at both the TAPPI and TAPPI preconditioning specification. System can automatically cycle between the two conditions.
Complete installation on site anywhere in the world.
On-site start-up instruction.
PC based monitoring systems comes standard with each unit. System monitors temperature, relative humidity, saturator, and mechanical outputs.
Calibration and PM contracts.
Extremely precise control and uniformity within the room or chamber allows for the customer to easily validate at the targeted position.
Our unique dew point control systems utilize much less energy than other stability control systems.
Our systems do not utilize maintenance intensive boilers and steam injectors that require high purity water.
|
|
|
|
|
|
The PGC 7000 series chambers feature our unique humidity control system that enables the user to attain unsurpassed levels of RH/temperature control and uniformity.
These test chambers are designed to accurately produce those temperature and humidity conditions required for applications such as stability studies, package testing, TAPPI, MIL-SPEC, and vapor transmission.
Applications are found in such diverse industries as pharmaceutical development and manufacturing, electronic omponents, food, semiconductor, paper and pulp, and wherever precise humidity and temperature replications are required.
Additionally, PGC’s SmartPad microprocessor controller is a user-friendly system that provides optimum accuracy and control. The SmartPad is equipped with direct readings in both temperature and humidity. It also features 40-segment programming for automatic cycling and ramping and soaking excursions. High-low or deviation alarms as well as digital communications ports are standard features.
The interior chamber is constructed of very durable, corrosion resistant stainless steel. Low watt density heaters are used that also contribute to the unit’s longer life.
Should your application require it, the chamber airflow can be factory configured from the standard horizontal flow to vertical. Other options include extended ranges, chart recorders, a window in the outer door, and a clear inner door with optional iris opening. System includes free logging software.
|
|
Temperature Test Chambers VT³
und Climatic Test Chambers VC³
If you are looking for top quality and unmatched performance, then Vötsch has just what you need !
Our completely new temperature and climatic test chambers VT³ and VC³-available in spring 2007- have almost magical control precision.
With S!MPAC* and S!MCONTROL* our revolutionary concept for operation, control and process visibility, these chambers provide features light-years ahead of all others.
Remote control, remote operation, remote monitoring and diagnostics - operation of these chambers is a real joy.
Excellent technical details and many little things make the difference. Absolute safe function of the test chambers, also during high summer temperatures, along with the maintaining of the water quality of the climatic system is guaranteed.
|
|
Temperature and Climate Test Chambers WTL and WKL
Small, but highly effective!
Reproducible temperature and climate tests can be performed directly at your workplace. This is possible with the WTL and WKL chambers of Weiss. This series was specifically developed for use in laboratories. Compact dimensions - considerable intrinsic values.
Main Advantages
- Interface RS 232C
- Large observation window and illuminated test space
- High-quality double seals
- 50 mm access port
- Upper and lower temperature, specimen protection according to EN 60519-2 (1993) adjustable, with separate sensor
|
|
900 Benchtop Temperature Chamber
The 900E Series chambers are designed for high and low temperature simulation where high performance and close temperature tolerance are required. The units are ideal for small lot qualification testing, burn-in, life test, temperature cycling or research and development. All models may be easily modified to add access ports, fixturing, instrumentation, etc., to meet special customer needs. All 900E Series are bench models designed for continuous use with ease of operation and maintenance in mind.
|
|
Temperature Test Chambers 110/200 l
for the laboratory
VT 4011, VT 7011, VT 4021, VT 7021
Laboratory Scope ...
Temperature test chamber with the ideal performance range for constant and cyclic temperature tests.
All of these extremely compact systems offer a remarkable test space volume. Rapid temperature cycles, high heat compensation and a low noise level make these systems highly favourable for use in electronic and pharmaceutical laboratories. Although these chambers are of a 1-phase design, they are extremely efficient.
The powerful 32-bit control and communication system provides the highest level of operation convenience, with the removable, menu-controlled touchpanel with graphics-capable display.
Test space volumes 110 and 200 l
Temperature range -40 °C to +180 °C and -70 °C to +180 °C
Control System:
Controller Board with removable Colour touchpanel.
|
|
Temperature Test Chamber WT
The test chambers of the WT series are both highly effective and economical. They are equipped with everything which is required to perform cold-heat tests in extreme ranges complying with the relevant standards. Due to their compact dimensions these chambers are perfectly suitable where space is limited in factories and laboratories.
Main advantages:
Compact design
Easy operation
Low sound level
Beneficial price/performance ratio
Plug-in design (single-phase connection)
Low connected load
|
|
optimized design of the refrigerating units as well as of respective vaporizer, compressor and air outputs.
individual electric and mechanic interfaces towards the specimen or the measuring system.
|
|
|
|
|
|
PGC has been providing high quality walk-in chambers since the mid-1970's. These environmental chambers have applications in diverse disciplines such as pharmaceutical stability testing, TAPPI and ASTM testing, biological and biotechnological research, electronics, and many other applications.
Our many years of experience in designing, manufacturing and installing walk-in rooms enable us to provide the user with unparalleled expertise. PGC's staff will assist in planning your room to meet your specific needs.
PGC will provide sole-source responsibility for both room construction and its conditioning equipment. Using modular insulated panels having either a 32 Rvalue (four inch) or a 40 R-value (five inch), enables PGC to deliver maximum efficiencies and uniformities.
FEATURES:
- RH uniformity to ±0.5%
- Temperature uniformity to ±0.5°C
- Multi-range rooms from -30°C to +60°C
- Humidity ranges from 10% to 90% RH
- Modular insulated panels
- Rooms factory-tested prior to
- shipment
BENEFITS:
- Unsurpassed humidity performance
- Superb temperature stability
- Flexibility of operation
- Increased measurement options
- Ease of assembly
- Assurance of proper operation
|
|
Temperature Walk-In Test Chambers
Series VTZ
Standardized temperature test chambers with test space volumes from 8 to 22 m³ and different performance ranges of -60 °C to +150 °C for environmental tests of large or numerous small specimens.
Accelerated and still reproducible tests as well as temperature tests for the quality control of manufacturing processes are possible.
Control System:
Controller Board S!MCON/32-NET with installed Colour touchpanel.
|
|
Walk In Temperature and Climatic Chambers
Our Walk In Chambers are a range of temperature and climate test chambers especially developed for large test specimens that cannot normally be tested in a standard-sized test chamber.
Attributes
Best stability of wall elements, non-slip floor, lighted test space
Heating to prevent formation of condensate at the door frame
Uniform temperature conditioning of test space
Easy access to machine unit for maintenance purposes
Global and competent after-sales service
Variable size and performance for individual application
|
|
Range of enclosure of laboratory
Temperature and climatic
Type VTL and VCL
Of compact construction, powerful, especially adapted for a use in laboratory when the place is limited.
Volumes of work
34 liters and 100 liters
Beach of work in temperature
+10°C with +150°C
-40°C with +150°C
-60°C with +150°C
Beach of relative humidity
10 to 98% hr
For more information to consult us
|
|
Rooms of tests in temperature standardized with volumes of 8 m ³ to 22 m ³ and various ranges of temperature of 60°C with +150°C for the tests of environment the large ones or many small specimens.
Accelerated tests and reproducible as well as of the tests in temperature for the quality control in process of manufacture are possible.
Control system:
Control board with touchscreen touchpanel.
|
|
|
|
|
|
Associated Environmental Systems supplies Temperature/Humidity Chambers to program controlled conditions of combined temperature and relative humidity.
All chamber components offer maximum resistance to the corrosive effects of moisture combined with extreme conditions. Consult the AES design engineering services for special temperature and humidity conditions.
BHD-500 and BHD-200 Series
The BHD-500 Series use a single-stage mechanical refrigeration system that can produce dry bulb temperatures down to 35°F/-37°C.
The BHD-200 Series produces dry-bulb temperatures down to -100°F/-73°C.
* Non-corrosive, stainless steel finned heaters are baffled to eliminate direct radiation to the test items at high temperatures of up to +350°F/+177°C.
* Chamber liners are hermetically sealed and made of heliarc welded stainless steel.
LH Series
* Self-contained systems use a two-channel microprocessor digital controller.
* Easy to operate.
* Standard units are available from stock in three (3) sizes: 1.5 cubic feet, 5.8 cubic feet, and 10 cubic feet.
* Temperature range is 0°C to +94°C with an optional temperature range of -20°C to +94°C.
* Humidity range is 20% to 98% 2 RH.
|
|
Simulate high and low temperature environments in Associated Environmental Systems bench top or floor model test chambers.
* Working volume from 2 to 64 cubic feet.
* Conform to commercial and military standards for low temperature tests.
* Self-contained single-stage refrigeration systems support low temperatures to -35°F/-37°C.
* Two-stage cascade refrigeration systems support low temperatures to -100°F/-73°C. The two separate closed refrigerant circuits each use a different refrigerant with its own compressor
Standard features include:
* High performance programmable controller with RS232 Interface
* Stainless steel welded interior
* Adjustable CE-approved low temperature fail-safe
* 2" diameter access port and plug
* Multipane viewing window
* Internal light with external switch
Optional features include:
* IEEE-488 computer interface
* CO2 or LN2 for fast pull-down
* Durable floor stand with casters
* Additional ports
* Programmable chart recorders
|
|
|
|
|
|
Associated Environmental Systems offers a range of prefabricated, tight-tolerance environmental walk-in rooms that are easy to ship and install. Major features include:
* Forced air circulation systems distribute air evenly and constantly recirculate it, maintaining uniform and accurate temperatures and humidity.
* Temperature Ranges are from -73°C (-100°F) to +85°C.
* Refrigeration system meets the room's load demand and operates continuously in cooling mode. Single-stage mechanical units operate at -35°C and above and two-stage cascade units at below -35°C.
* Electric heating system provides very accurate and straight line control of temperatures. System is reliable and has a long life.
* Humidity System choices are the conditioned fine Mist System or the Steam Generator System. Different ranges are available including special dehumidity ranges to 5% RH.
* Prefabricated room construction consists of modular, sandwich-type panels with a metal skin inside and outside. Panels are easy to ship and assemble.
* Multipane viewing windows can be ordered in custom sizes.
* Incandescent or fluorescent lighting is vapor-proofed and sealed.
* Instrumentation consists of single or two-channel microprocessor programmers with an accuracy of ±.25°C or better at the sensor. Other options include: RS-232C, RS-422A, IEEE-488 interface.
* Safety standard is a redundant control circuit with its own controller and failsafe contactor. Many other options are available.
|
|
Connect
Auto industry
Automobile industry of subcontracting
Application
Resistance and endurance tests of the hinges of automobile door.
Description of the equipment
Together including/understanding:
The climatic room with its conditioner in temperature and rails of drive,
The machinery placed behind the room, including/understanding the refrigerating circuit and the production of moisture,
The electrical equipment box placed on with dimensions one of the machinery with the orders in frontage,
The condenser of the refrigerating circuit placed outside the building,
Software SIRPAC under WINDOWS XP (Integrated system of Regulation, Programming, Acquisition and Control) and the computer material (PC, printer,...)
|
|
The high-flyer in testing technology!
Fast and precise temperature changes from - 42 °C to +190 °C lastingly reduce your process times! Innovative technology and the highest operating comfort combined to create a powerful duo for controlled material and function tests, with the TTC temperature test chamber and the CTC climatic test chamber with active humidification and dehumidification.
A top performance by the experts for controlled atmosphere. Efficient and flexible environmental testing and simulation. Worldwide.
|
|
We have developed these insulation rooms to be used for high-temperature and climate simulations.
Their basic design corresponds to the ILKAsim system and features mineral-wool insulation as well as a vapour-tight welding of the interior.
This guarantees perfect tightness even under extreme conditions.
Of course, this system can be tailored to your needs and requirements, too.
|
|
|
vibration cabinets for horizontal and vertical vibration combined with various types of shakers. Very high rates of increase and decrease for the temperature.
|
|
Vibration test systems
Temperature and Climatic Type VTV and VCV
Vötsch vibration test systems enable you to simulate dynamic processes, i.e. mechanical and thermal processes affecting components and assemblies.
Regardless of whether mechanical, hydraulic or electro-dynamical vibrators are required, we cooperate with all well-known national and international manufacturers of vibrators.
The standard range comprises of 36 different types of systems. Special equipment is available and can be customized as required (see special applications).
Test space volumes
600 l, 1200 l and 2200 l
Temperature range
-40 °C to +180 °C and -70 °C to +180 °C
Humidity range (VCV)
10 % to 95 % RH
Temperature rate of change
5 K/min, 10 K/min and 15 K/min (optional to 30 K/min)
Control System:
Controller Board S!MCON/32-NET with removable Colour touchpanel.
|
|
Vibration test chambers for simultaneous testing of the influence of vibration, temperature and temperature changes as well as humidity, e.g. on components in the engine bay of vehicles. With a closed floor element these cabinets can be used as fully functional temperature testing cabinets (WT-V series) and, additionally, as climate test cabinets (WK-V series) as well as for ESS testing.
Advantages
- Powerful, homogeneous temperature and/or climate conditioning of the test chamber.
- Easily accessible maintenance elements ensure minimum service times.
- Precise adjustment of system height to accommodate standard shakers.
- Simple integration of all standard shakers. Networking of chamber control software and shaker control software possible
|
|
Climatic chamber of 2,8 m ³
On pot and mobile plate
Wet Hot cold
ATEX
Zone 1 interior/Zone 2 outside
Connect
Research laboratory
Auto industry (tests of combustible pile for auto industry)
Application
Realization of tests in temperature and moisture controlled in an enclosure adapting on dischargers (pot & table). So the enclosure, interdependent of its technical compartment, has a height of easily adjustable plate (by the means of a lifting table) and mobile (thanks to the wheels of the table).
Description of the equipment
Cast solid unit including/understanding:
The enclosure (with before) of tests with its conditioning,
Conditioning by:
- Cold: circuit cascades R23/R404
- Heat: coolant
|
|
