With a complete range of Touch Panel PCs, Industrial Panel PCs, and Industrial Flat Panel Monitors, Advantech offers a wide range of HMI products for industrial automation needs. By creating value-added, standard product solutions and by offering customization, Advantech can provide platforms to meet any requirement.
|
|
RAFI produces complete control panels and data entry systems including electronic circuitry and interfaces. We design our systems with special emphasis on reliable data input and convenient operation. A wide range of technological and design options enable RAFI to quickly implement individual solutions. For example, we utilise the following equipment for in-house production:
CAD development tools (3D)
Screen printing machines for the production of overlays
Sheet metal machining equipment for front panels
SMD and conventional assembly of printed circuit boards
Individual assembly and testing facilities
|
|
|
|
|
|
Operator panel BASIC
Operator panels in the product segment “BASIC” are used wherever essential operator functionalities are required. Customers only pay for the features that they need for their applications. With an ideal price/performance ratio, these products help reduce the costs for machine operation, in serial machines, for example. The graphic operator panels demonstrate their strengths for smaller and medium-sized applications,
such as mobile packers, industrial washing machines and baking ovens, die casting systems, automated soldering machines and other small machines.
LHT Series
The LHT product series includes panel units with keypads and touch screen entry in six different sizes between 3 to 10.4 inch display size. The versatile panels are brought to life with the help of the H-Designer, an intuitively used project planning tool with a broad functional scope. Thanks to flexible help programs that facilitate project creation in just a few minutes, the H-Designer is the perfect tool for simple to intermediate applications.
A large number of communications drivers makes it possible to easily connect up almost any conventional control system. Currently, there are more than 100 different driver protocols for PLC’s, frequency converters and servo controllers available.
|
|
|
|
|
|
Operator Panel LXT
The product segment “PREMIUM” offers powerful operator panels that are used in almost all production processes. Typical applications are machine visualization on site with networking to a guidance system, or production processes that require convincing user interfaces. Equipped with a keypad or touch screen data entry option, there are more than 35 panels available with display sizes ranging between 3 to 21 inches in two product groups. A selection that offers the right model for almost any application.
LXT Series
The LXT Series product group comes into use when intuitive operation and ergonomic design is requested. From pure installations to food production to even transport equipment, packaging plants or water treatment and offshore applications, these compact panels can do their job anywhere.
With the Information Designer, you can quickly and efficiently create impressive user interfaces for the entire LXT series. Finished masks and graphic objects are integrated into the interface through simple drag and drop. The Designer also creates detailed documentation. This means that accompanying project documents are quickly prepared for the machine description.
For you, PREMIUM means: A multitude of operator panels, equipped with extensive functionalities, as a comprehensive HMI solution for your special visualization tasks.
|
|
|
|
|
|
PREMIUM
The product segment “PREMIUM” offers powerful operator panels that are used in almost all production processes. Typical applications are machine visualization on site with networking to a guidance system, or production processes that require convincing user interfaces.
Equipped with a keypad or touch screen data entry option, there are more than 35 panels available with display sizes ranging between 3 to 21 inches in two product groups. A selection that offers the right model for almost any application.
WOP-iT Series
The WOP-iT product group has a multitude of powerful user functions. With the help of the client server technology, it is possible to install a simple and flexible network from the PLC to the main frame via the panel without additional hardware. Communication is bidirectional – panel and server PC independently synchronize themselves according to the data entry.
With the WOP-iT Designer, it is possible to handle general project planning via the entire panel family. Users can configure a graphic user interface from comprehensive object libraries rapidly and effortlessly. With the help of numerous additional functions such as comparative arithmetic, Boolean algebra, string processing and user administration, the project planning
expenses are considerably reduced. The easy language setting
feature completes the functional scope.
|
|
Colors for your data
Industrial Operator Panel (HMI) with 7.5" touchscreen color TFT display
64K colors TFT display
VGA (640x480 pixels) resolution
Resistive touchscreen
Connection to industrial bus systems and Ethernet (requires plug-in modules)
32 MB internal Flash memory
32 MB on removable media (option)
SSFDC memory card
IP65 front panel protection
Programmable with "Designer" software tool (option)
|
|
KeMobile - innovation by the leading technology partner
KEBA's KeMobile offers system solutions with the proven KeTop operating terminals at the core. The handheld terminals are characterized by distinctive ergonomics, exceptional robustness and high quality technology with an appealing design. KeMobile additionally offers a comprehensive service package, which does not leave anything to wish for.
* Complete functionality even after being dropped from a height of 1.5 m
* Equally suitable for right- or left-handed operation
* Allows hours of fatigue-free working
* Three-stage consent button for controlled and safe operation
* Optimized keyboard layouts for differing branches
* Individual fitting with operating elements
* Multiple visualization possibilities from a pixel display to a touch screen
|
|
|
|
|
|
Operator Interfaces - Human Machine Interfaces
FEATURES:
Many PLCs supported
Friendly multiple languages supported to the end users
Temperature controllers & inverters directly connected to HMI via Modbus
Data logging, bargraphs, trends and alarms
Animation: display/hide, flash, color changed
Data entry and data displayfrom/to PLC registers directly
Free configuration software, configuration for all HMIs from PC software
Upto 65535 screens in each project, pop-up screen and associated screen supported
Ladder programming (Soft PLC) supported in HMI and Ladder online monitoring
Screen security
Floating point suppored
Ready made registers for Real Time Clock
Unique Tag database for HMI and PLC registers
256 real time alarms, and 30 or 2000 historical alarms
Global tasks, power-on tasks, list of predefined tasks and screen tasks-before, while and after
Ready made objects for lamps, botton , data entry, data display, trend, alarm, bitmaps, meters
Action for graphical objects from list of predefined tasks
Ready-made system coils for changing RTC data by sec., min., hour, day, month, year
|
|
Customised touch screen systems
Individual touch screen systems
Can be combined with other technologies (e.g. with membrane keyboards)
Customised electronic circuitry
|
|
Hardware
QVGA 320x240 pixels, lighted, STN colour graphics LCD display measuring 145 mm (5.7") diagonal, (TFT, enhanced TFT and greyscale displays are optional).
Module with display, CPU board, touch screen and mounting bracket is available for integration into your panel.
Resistive analogue touch screen. Options include PS/2 keyboard / keypad interface
EIA-232, -422 or -485 serial interface. Second EIA-232,-422 or -485 port available.
Ethernet 10/100Base-T Power-over-Ethernet.
TCP/IP, Modbus™ and other protocols. 4 Mbytes of flash and 16 Mbytes RAM. 200 MHz Intel® XScale™ core platform. Speaker and real-time clock.
NEMA4 sealing.
HMI Software
QlarityTM - Object-based programming language makes application design easy for all user levels. Design with pre-defined objects, edit current objects or design new objects for your application. Qlarity Foundry - Windows® programming environment for screen design and integration. Qlarity Foundry is available free of charge.
|
|
Our Lowest-Priced Graphic OIT
When you need an operator interface that displays intuitive graphics, but need to keep cost to a minimum, consider the Blue Series graphic OIT. With a list price lower than most alphanumeric OITs, yet loaded with high-value features, these OITs are designed to meet your size and price needs.
Smaller than a 4 x 6 index card, the Blue Series OIT is made to fit in tight spaces. The membrane style keypad has five user-definable function keys and keys that support screen control and read/write access to PLC data. Each function key can be screen-dependent and allow two operations when used with the Shift key.
The graphics screen supports a resolution of 128 x 64 pixels on a high-contrast LCD. TrueType fonts allow a variety of text sizes, including international characters. With a graphics display, you can create a more intuitive OIT using bar graphs, meters & imported custom bitmaps that aren't available on a text display.
|
|
|
|
|
|
A New Generation of Graphic OITs
The Silver Series Plus operator interface terminals offer a wide array of display sizes and connectivity options, high quality displays, enhanced data management and monitoring features, & high quality graphics & design options.
The enhanced displays come in 6”, 8”, 10” & 12” sizes, & all units feature 65K-color high-brightness, high-contrast TFTs with high-precision touchscreens.
The OITs deliver a wide variety of connectivity options. 10/100BaseT Ethernet allows for multiple high-speed network configurations. There are three USB 2.0 host ports, three COM ports, audio in/out ports, CompactFlash port, & 44-pin IDE interface.
Many enhancements have been made to the Silver Series Plus’s configuration software. One of these is data management tools – which now includes data sampling & data logging features. Other enhancements include the ability to program projects in up to eight different languages & improved security features with up to six levels of password protection.
Pricing for the Silver Series Plus operator interfaces is extremely affordable – with the 6” display listed at just $600.
|
|
Beijer Electronics EXTER™K10 keypad panel with Monochrome FSTN display
Display: Graphic monochrome FSTN, resitive touch
Presentation form: 160 x 32 pxl
Function keys: 6 (6 with integrated LED and text strip)
Front protection class: IP66 (waterproof even when exposed to high pressure washing).
With EXTER™, you get an operator panel that is ready to impress you. Its high-performance Intel Xscale® processor, robust construction and multiple communication ports make it a futureproof choice for your machines and processes. There are fourteen models to choose from - seven with touchscreen display, six with keypad control and one mobile operator panel. The award-winning, slim design and the powerful performance make EXTER™ an operator panel beyond the ordinary.
|
|
AutoLog® AL121CE - HMI
Graphical 12.1 " Windows CE touchscreen which has full support for Web Studio SCADA development tools. More than 200 device drivers. Powerful CPU processor. Versatile connections.
Type TFT Color LCD
Screen size (diagonal) 12.1"
Max. colors 65536
Resolution 800x600
Pixel size (HxV, mm) 0.3075 x 0.3075
Viewing angle (°) 95 down / 95 up / 120 left / 120 right
Luminance (cd/m2) 250
|
|
Beijer Electronics EXTER™ K100, keypad panel with TFT-LCD 10.4" color display
Display: Graphic 64K color TFT-LCD, resistive touch
Presentation form: 10.4", 800 x 600 pxl
Function keys: 22 (10 with integrated LED and text strip)
USB Host, USB Device
Front protection class: IP66 (waterproof even when exposed to high pressure washing).
With EXTER™, you get an operator panel that is ready to impress you. Its high-performance Intel Xscale® processor, robust construction and multiple communication ports make it a futureproof choice for your machines and processes. There are fourteen models to choose from - seven with touchscreen display, six with keypad control and one mobile operator panel. The award-winning, slim design and the powerful performance make EXTER™ an operator panel beyond the ordinary.
|
|
|
|
|
|
Large-character, 20×4, lighted display is readable from four meters (12 feet).
24- or 40-key tactile keypad with high-quality steel snap domes, a shift LED, a power-on LED and a column of user-programmable indicator LEDs (four on the 24-key keypad and five on the 40-key keypad).
Optional lighted keypad for operating in dark environments.
EIA-232, EIA-422, EIA-485, 5-volt Buffered or -422m interfaces supported.
20 Kbytes of user data storage (5 Kbytes with EIA-485 or -422m).
Extremely rugged NEMA-4 enclosure is ideal for industrial environments.
Every key supports two-key rollover and key release strings.
The QTERM-P40 can operate in any of three modes: full-duplex, block or multidrop mode; multidrop mode supports up to 32 terminals per host.
Every key can be programmed with six parameters: unshifted key string, key release string, key repeat flag and shifted key string, key release string and key repeat flag.
48 programmable macro strings allow complete operator menus using simple host commands. Macros can include local commands and display data.
Make the terminal part of your product with a custom key legend and company logo label.
industrially hardened to operate in many environmental conditions and meets NEMA-4 specifications. CE certified.
Optional emergency-stop switch (E-stop) with large mushroom head.
|
|
Text Displays with Customizable Keys
The MicroOIT Series have alphanumeric displays with membrane-style keys. Each key is programmable, allowing users to define a unique keypad to match their particular application. The legendable insert feature means users don't have to pay extra for custom overlays to get a custom look.
A wide range of communications drivers are available: from Allen-Bradley, Modicon, and GE Fanuc to Keyence, Contro Microsystems & Bristol Babcock - over 74 families of PLCs and motion controllers in all.
The configuration software includes recipes, menus, alarms & the ability to create over 500 screens. Designed for harsh industrial environments, these OITs carry a Class I, Div 2 rating & operate under a wide temperature range.
|
|
SIGMATEK offers a wide range of text and graphic terminals for automation.
The selection of HMIs ranges from non-intelligent control terminals to panel PCs with integrated CPUs; from two-line text terminals to high resolution TFT color displays with up to 19”. The optimal and most economic solution is available for any task.
During development particular attention was given to creating a compact design with comfortable control features. An emphasis was also placed on dependability and optimal connectivity to the system.
For fast, flexible and dependable communication with the control or other components, numerous interface connections are available ranging from DIAS over VARAN to Ethernet and CAN. Customer specific front labels and button layouts allow individual configuration of the terminal.
|
|
Bernstein’s MBDT-L family of hand-held operator control units provides the right solution approach for any application.
Each control unit comes pre-configured and is immediately operational. The operator no longer needs to conduct extensive configuration. The integrated backlit LED displays are available in two resolution types (4 x 20 and 16 x 40 digits). A serial interface (RS-232, RS-422/RS-485) or bus system (CAN, Profibus) provides the necessary access for control communication. The units can communicate in a range of protocols making the dialog terminals compatible with a broad range of control systems from various manufacturers.
As with all Bernstein hand-held control units, the MBDT-L family stands out with a modern, ergonomically designed housing and high degree of protection. The comprehensive assortment of operator control elements and option, such as emergency STOP buttons, electronic dials or dead man switch, leave absolutely nothing to desire.
|
|
Allen-Bradley graphic terminals from Rockwell Automation offer rugged electronic interface solutions in a variety of sizes and configurations. These robust devices are fully packaged (hardware, software, and communications) and tested for HMI (human machine interface) operation. Simply download your configured application file, set appropriate communication parameters, and connect the communication cable.
PanelView Plus CE terminals are optimized for machine level interface, providing tight integration with the control system. They replace traditional wired panels as the input and output mechanism for operator interaction machines. Choose from a stand-alone single system to a multi-layer, enterprise-wide solution. These terminals are capable of providing process information over a variety of communication protocols including DeviceNet, ControlNet, EtherNet/IP, DH+, DH-485, Remote I/O, DF1, and other third party vendor networks.
|
|
Beijer Electronics H-series H-T70t, touchscreen panel with TFT-color 7" colour widescreen display
Display: Graphic 64K color TFT-LCD, resistive touch
Presentation form: 7" (diagonal), 800 x 480 pxl
Keypad: 1 Meny key and 6 user-defined function keys
2 USB Hosts, 1 USB Device and a built in CF-card slot
The H-series offers valuable HMI functionality at an affordable level. The series include keypad and touch screen interfaces and is available in seven different sizes from 3 to 10.4 inches. Offering three levels of functionality – Standard, Plus and Network – the H-series enables you to select and pay for what level of HMI technology you need.
|
|
|
Industrial RS232/RS422 character based terminals with alpha/numeric keypad input. Very low cost ( priced as low as $205) and very dependable. Many different models to choose from !!
|
|
Beijer Electronics H-series H-T60b, touchscreen panels with mono/color STN LCD 5.7” display
Display: Mono STN LCD
Presentation form: 5.7” (diagonal), 320 x 240 pxl
Keypad: 1 Meny key and 5 user-defined function keys
The H-series offers valuable HMI functionality at an affordable level. The series include keypad and touch screen interfaces and is available in seven different sizes from 3 to 10.4 inches. Offering three levels of functionality – Standard, Plus and Network – the H-series enables you to select and pay for what level of HMI technology you need.
|
|
|
|
|
|
Hardware
VGA 640x480 pixels, lighted, TFT colour graphics LCD display 10.4". (An enhanced TFT display is available as an option).
Resistive touch screen.
Optional PS/2 keyboard / keypad interface.
Ethernet options available. Supports TCP/IP, ModbusTM and other protocols.
4 Mbytes of flash memory and 16 Mbytes RAM.
EIA-232, -422 or -485 serial interface. Additional serial ports available.
RISC 92 MHz MIPS R3000 processor.
The terminal is industrially hardened to operate in rugged environments and meets NEMA-4 specifications for washing, ice and salt spray.
Modular form factor also available.
Software/Firmware·
QlarityTM - Object-based programming language makes application design easy for non-programmers whilst also having the capability of highly complex applications.
Design with pre-defined objects, edit current objects or design new objects for your application
Windows® programming environment - Qlarity Foundry is available for free.
Support for select partner hardware (distributed/remote I/O, motion control).
Keys around the display can be customised and your logo can be added to the legend. Custom hardware, firmware and software options are also available.
Contact us for a free trial demonstration terminal.
|
|
|
|
|
|
NEW RED LION G306A OPERATOR INTERFACE PANEL FEATURES ADVANCED TFT DISPLAY FOR CRISP IMAGES, EXCELLENT READABILITY
The 5.7" 256 color QVGA 320x240 pixel LCD display also offers three front-panel LED indicators, and a five-button keypad for on-screen menus. In addition, as with all G3 panels, the G306A arrives standard with an Ethernet port, USB programming port, support for up to five high-speed serial ports, integrated protocol converter, built-in web server, standard CompactFlash socket and IT-ready data logging.
The G306A is both robust and simple to operate. Users can easily enter data on the G306A through the resistive analog touchscreen or front panel keypad. Plus, this model comes with an increased onboard flash memory of 8 MB, and it can be configured using Red Lion’s free Crimson Programming Software. With these exceptional features, the G306A is ideal for collecting and displaying data or interfacing with a variety of devices, including PLCs, PCs, drives, PID controllers and others, all while offering exceptional visual properties.
The Red Lion G3 series offers the most powerful communications platform available today, providing a cost-effective solution for protocol conversion, remote system control and monitoring, as well as historical data logging. By utilizing innovative technology to display sharp, high-quality images and easy-to-read data, the G306A delivers a superior HMI solution.
- Configured using Crimson 2.0 Software (FREE)
- Up to 5 RS-232/422/485 Serial ports
- 10 Base T/100 Base-TX Ethernet Port
- Remote Web Access and Control Facility
- UL Listed for use in Hazardous Locations
- IP66
|
|
Beijer Electronics EXTER T70, touchscreen panel with TFT-LCD 6.5” color display
Display: Graphic 64K color TFT-LCD, resistive touch
Presentation form: 6.5”, 640 x 480 pxl
USB Host, USB Device and built in CF-card slot
Front protection class: IP66 (waterproof even when exposed to high pressure washing).
With EXTER™, you get an operator panel that is ready to impress you. Its high-performance Intel Xscale® processor, robust construction and multiple communication ports make it a futureproof choice for your machines and processes. There are fourteen models to choose from - seven with touchscreen display, six with keypad control and one mobile operator panel. The award-winning, slim design and the powerful performance make EXTER™ an operator panel beyond the ordinary.
|
|
|
|
|
|
Touch screens are often used as an alternative—or in addition to—more traditional human-machine interface technologies, such as a membrane switch or keyboard. The use of a touch screen allows the keypad to be reconfigured as desired to suit the application. Because of their intuitive nature, touch screens are often used in applications where the user cannot be trained to interface with the device. Kiosks and point of sale devices exemplify these applications.
The process of authentication or the fundamental skills of communicating and learning can be enhanced with a touch screen that provides tactile feedback. Devices that provide synchronized sound and graphics upon touch are more intuitive, personal and satisfying. Now the predictive sensation of touch and response can be applied to touch screens to heighten interaction and usability.
Advanced Input Systems can help Original Equipment Manufacturers heighten the level of interactivity and build a more engaging user experience with TouchSense® technology. This programmable technology by Immersion® adds tactile feedback to touch screens. And sensory-based touch screens that “touch back”, supply distinct benefits and give users a new and more satisfying experience—one that’s more interactive, engaging, intuitive, and fun.
|
|
Beijer Electronics H-series H-T50b, touchscreen panel with mono STN LCD 4.7” display
Display: Mono STN LCD, 16 shades of blue
Presentation form: 4.7”(diagonal), 240 x 128 pxl
The H-series offers valuable HMI functionality at an affordable level. The series include keypad and touch screen interfaces and is available in seven different sizes from 3 to 10.4 inches. Offering three levels of functionality – Standard, Plus and Network – the H-series enables you to select and pay for what level of HMI technology you need.
|
|
Beijer Electronics EXTER T40/T40m, touchscreen panels with 3.5” display
Display: Graphic 64K color TFT/Graphic 16 grayscales
Presentation form: 3.5”, 320 x 240 pxl
USB Host
Front protection class: IP66 (waterproof even when exposed to high pressure washing).
With EXTER™, you get an operator panel that is ready to impress you. Its high-performance Intel Xscale® processor, robust construction and multiple communication ports make it a futureproof choice for your machines and processes. There are fourteen models to choose from - seven with touchscreen display, six with keypad control and one mobile operator panel. The award-winning, slim design and the powerful performance make EXTER™ an operator panel beyond the ordinary.
|
|
AGP3000 Series : 20 models of Graphic Operator Interfaces ... 6 screen sizes. (3.inch/5.7inch/7.5inch/10.4inch/12inch//15inch/).
- TFT colour screens (65.536 colours) or STN (4096 colours), B&W or Amber.
- Aluminium die-cast bodies.
- Connectivity with numerous devices : serial interfaces, Ethernet, Expansion Unit, USB (x 1 ou 2), CF-card, sound out, very powerful CPU. 5 multimedia models= Video In + Sound In.
- All protocols available: Unitelway, Modbus, MPI, Sysmac...
Pro-face, world leader on touch panels invits you to discover a powerful and easy-to-use range of products.
|
|
|
|
