With the Motor Performance Monitor, Baker Instrument Company continues to pioneer new breakthroughs that demonstrate an ongoing commitment to quality, reliability, and competitive advantage. This on-line motor analyzer takes the next step in providing complete P/PM programs. It provides root-cause analysis through the separation of mechanical and electrical issues.
The Explorer Series II was superiorly designed to pinpoint challenges (voltage source, VFD, motor, load) your rotating machinery face. This self-contained portable instrument is computer driven with proven engineering, allowing all testing to be accomplished directly from the MCC or from Baker EP connection. |
|
The testing device 92-7G/-7M is concieved for the control via an external PC/PLC. Therefore display and operating devices were renounced. The modular design of the testing instrument permits an optimal adaptation to the individual requirements of the user. Uneeded functions or equipment are omitted. Together with the device ELABO offers an efficient software package.
HV
The high-voltage is produced primarily over an internal electronic HV-source with a high clock frequency and regulated within less 10 ms. Because of the internal source a low residual ripple < 3% (accordingto VDE 0432-1) can be realised, also for DC tests with high currents. The synchronisation can be carried out on an external signal, on the mains frequency or internal (free-running). An electronic voltage ramp mode (voltage ramp up and ramp down) allows for tests of electronic equipment, at which a non-destructive test can only be carried out if the test voltage is increased slowly or for test items with high self-capacitances. The integrated residual voltage measurement assures a safe discharge of thecapacitances of the test items.
Insulation resistance
Insulation resistance measurement with voltages from 500 V up to 8000 V DC at full HV-current are possible. The resistance measurement is carried out together with the high voltage test at the sametime.
PE resistance
Measuring of the PE resistance or the voltage drop at the protective earth conductor through fully electronicregulated programmable test current 10 ... 32 A at an AC voltage of 6 or 12 V. |
|
EurotestXA is the top of the range installation safety tester with automated testing based on patent pending AUTO SEQUENCE®.
Because of the need to be efficient, fast and competitive but still reliable and concentrated on safety, all the technical content and innovations under AUTO SEQUENCE®, focus on taking care of the testing procedure itself. If you are after a high speed, safety, and reliable least-fuss testing instrument, look no further. |
|
Hipot test to 6kVDC 10mA
Hipot test to 5kVAC 40mA
Ground Bond test to 42 Amps RMS
Insulation Resistance 50 to 1000V
Automated Remote Interface
|
|
The fast and easy solution to voltage, continuity and resistance measurements
Ideal for site conditions, the 3 models of the T100 Series 2-pole testers have a rugged construction and ergonomically formed housing for perfect handling. All models offer a patented three-phase rotation detection system providing quick phase rotation indication. Moreover they have a special electrical torch function for working in low light level environments and have an ingress protection rating of IP65. The T100 Series are compliant with EN 61010-1 and EN61243-3 requirements.
|
|
| OmegaPAT and BetaPAT are suitable for periodic testing, troubleshooting or as a tool for electrical safety testing in workshops. |
|
The future of installation testing is here
The 1650 Series testers verify the safety of electrical installations in domestic, commercial and industrial applications. They can ensure that fixed wiring is safe and correctly installed to meet the requirements of IEC 60364, HD 384 and all relevant local standards. The unique ergonomic design, low weight, and padded neck-strap to free your hands, make operating a Fluke 1650 multifunction tester a pleasure. With easy-to-operate controls and a large display with exceptionally wide viewing angle, it's also comfortable and safe to use. Select from three models: Fluke 1651: Performs all basic installation tests including continuity/insulation/loop impedance and RCD tripping time
Fluke 1652: Also provides RCD tripping current level and RCD auto-testing
Fluke 1653: As Fluke 1652 but with earth resistance and phase sequence measurement. Has internal memory and a PC interface for documentation and reporting
|
|
Electric power lines and telecommunication lines often occupy parallel routes as a result of the utilisation of joint facilities or sharing a common right-of-way. Direct contact with electrical mains power can occur through networks line cable faults. The contact may not cause opening of a power system circuit breaker. A.C. current resulting from direct contact may make effective protection difficult. EMC Partner have a range of products designed to meet the ITU-T K44, ITU-T K20 and ITU-T K21 requirements for both power CONTACT and power INDUCTION testing.
MIG-ITU-K44 is a stand alone system that delivers up to 1,600V for enhanced level testing. NW-K44PC can provide up to 600V to meet basic levels.
Additional accessories enable power contact testing at 230V up to 20A per line. |
|
MIG2000-6 is a versatile generator capable of delivering impulses to meet MIL-STD-461F including the CS115, CS116 and CS106 requirements. Further modules are available which extend the system to include MIL-STD-1275B for military vehicles, Airbus AMD-24C for the A400M and A350XWB, DO160 sections 17 and 19 and the EFA4 pulses for the Eurofighter typhoon II.
The system is complete and includes all equipment including couplers to perform testing on cable bundles using either series or parallel injection.
A reliable and flexible test system, MIG2000-6 is in use at many facilities worldwide. |
|
EMC Partner offer a range of test equipment to cover the indirect lightning effect tests as defined in documents; RTCA/DO160 and EUROCAE/ED14.
The MIG0600SS, MIG0600MS, MIG0618SS and MIG-OS-MB generators are designed to carry out Pin injection(PIN), Single Stroke(SS), Multiple Stroke(MS) and Multiple Burst(MB) with five different waveforms;
6,4/70 µs (WF1), 0,1/6,4 µs (WF2), 1MHz & 10MHz damped sine (WF3), 6,4/70 µs (WF4), 40/120 µs (WF5A) and 50/500 µs (WF5B).
Multiple Stroke patterns are available with fixed or randon spacing to meet all current requirements including Airbus ABD0100-1-2, Boeing D6-16050-5C and many more.
Avionics test systems include all necessary couplers for PIN injection, Cable induction and Ground injection.
A basic level 3 package comprises the MIG0600MS and MIG-OS-MB geenrators. These can be extended to full level 5 capability by addition of the MIG0618SS and MIG-OS-MB-EXT. MIG-OS-MB-EXT also enables testing with additional waveforms such as 6H or customer specific waveforms.
|
|
Universal mobile
The test system is equipped with a universal tester. With this new developed unit you can also carry out high- voltage tests with AC or DC.
Furthermore you can also realize an insulation- and PE- resistance test. Moreover the test system can be expanded with a leakage current tester for the latest norms. The components are connected with a matrix and they are controlled with a special software package.
The slots are placed in a 19” / 12HE Rack. The whole test system is placed in a mobile. To adapt the test probes serves a connection box. With this box you can contact all kind of test probes.
At the back of the tester are high- voltage sockets. So you can realize a manual high- voltage test.
As an option the mobile is equipped with a PC. |
|
| SIRIUS89N is a complete model to perform all safety tests in compliance to VDE 0413, measure of values of environmental parameters (temperature/humidity, illuminance, sound level with optional probes), leakage current with optional clamp and to perform a network power quality of single phase in compliance to EN50160 guideline.RCDs which suddenly trip out, transformers which overheat, motors which burn out, voltage sags and surges which create problems, all these problems could be easily solved with SIRIUS89N. The meter permits to perform a Loop impedance measurement (P-P, P-N, P-PE) also with high resolution (0.1mOhms) with the use of IMP57 optional accessory and five predefined recording settings are integrated in order to to help the user on the most common situation which are present on the network quality (EN50160, Voltage Anomalies, Harmonics, Start-Up and Power & Energy). SIRIUS89N can perform current measurements up to 3000A AC also by using a flexible clamp type in order to perform measurements on big cables or bars also. Thanks to the PC interface and the powerful software you will create accurate documents qualifying your professionalism more and more. |
|
| SIRIUS 87 is a model to performing all safety tests according to VDE 0413 on electrical installations. Inside model are integrated new fundamental features: the possibility to perform Loop Impedance (P-P, P-N, P-PE) at high resolution (0.1mOhms) with use of IMP57 optional accessory. Thanks to its PC interface and powerful software you will create accurate documents qualifying your profession more and more. |
|
Full Compliance CE Mark test equipment and ANSI transient test solutions. Choice of 4kV or 6kV SURGE generators with Combination, 100 kHz Ring, and 10/700 waves plus your choice of ESD, EFT, and voltage DIPS and Interrupts as needed. Integrated, automated, single phase CDN.
|
|
BS601/602 is a multifunctional electric meter with which the user can measure electric equipment with various functions very easily and accurately. It is a portable and an integrated measuring instrument, which has various measurement functions such as insulation resistance, ground resistance, AC/DC voltage, electroscope test, phase test, and etc
BS601/602 is very convenient for the user because it simultaneously displays the min, max & average value on LCD when the user measures a variation value while Measuring. Especially, this instrument has functions to load measurement output in the inner memory and to transmit measurement output to the external equipment like a PC through IrDA.
Features:
- Insulation test of cables, transformers & motors
- Sensitive Ohmmeter for checking resistance of motor windings
- AC/DCV, Electroscope Meter & Phase Meter
- Basic accuracy of +/-0.2% for accurate measurement
- Digital graphic LCD with 9999 counts & Back-light
- Precise and Quick Response, 24-bit high speed A/D converter
- Internal Memory over 100 measured data
- MIN, MAX, Average & Data Hold
- Auto Power & Back-Light Off
- Ground Resistance Measurement with 2 or 3 points & down to 2 decimal places
- Low resistance measurement & continuity test (BS601)
- AC current & leakage current (BS602)
- Data Communication to PC through IrDA port
- Real Time Clock |
|
Testers for lightning tests on telecommunication equipment based on the following standards or recommendations: ITU-T, IEC, Bellcore and FCC.
|
|
E-Ze TEST NON-TRIP EARTH LOOP IMPEDANCE TESTER - EZ2100 - £199.00
A revolutionary new 17th Edition tester with T-Safe™
non-trip earth loop impedance check.
The E-Ze Test performs:
• non-trip earth loop test
• voltage test
• socket test
Test readings scroll through in sequence on the clear,
back lit, 32 character display to show socket problems,
or high/low voltage conditions. Then the earth loop
impedance test result is displayed. |
|
Featuring
RS232, PCL & GPIB Control
AC Hipot to 5KV
DC hipot to 6KV
Insulation Resistance to 10GW
ARC Detection
Ground Continuity to .001W
|
|
OMICRON's CT Analyzer is a unique lightweight electronic multifunctional instrument designed to meet the highest standards for performing excitation, ratio, polarity and winding resistance tests on current transformers (CTs) as well as burden-impedance measurement.
Benefits
* Extremly small and lightweight (< 8kg/17 lb), beneficial for on-site testing
* Reduced commissioning time due to fully automatic testing
* Allows testing and result assessment according to IEC 60044-1, IEC 60044-6 or IEEE C57.13 (ANSI standard)
* Accuracy level (0.02 %/1 min.) enables field calibration and verification of class 0.1 CTs for metering
* Testing of specialized CTs such as TPS, TPX, TPY and TPZ
* Automatic analysis of CTs with unknown data ("name plate guesser" function)
* Recalculation of test results after tests with different burden and different primary current (no further on-site measurements)
* High level of safety - all tests utilize low voltages (120V)
European Patent EP 1 398 644 A1
* Almost unlimited in: Ratio (50 000 : 1), Primary current (999 000A max.),
Knee point voltage (15kV max.)
* Automatic demagnetization of the CT after the test
* Data storage on a removable Compact Flash (CF) card, which can be read by any standard memory card reader
* Remote interface to integrate CT-Analyzer into an automatic production process
* Easy importing and editing into MS OfficeTM standard software |
|
| Self-adjusting fault indicator for system-wide application. Provides clear visual indication of fault path to line crews in the field to help reduce fault-locating time. Automatically adjusts its trip value based on the load current, eliminating the need to specify a trip value. Allows line crews to easily distinguish between temporary and permanent faults. The inrush restraint feature allows coordinated integration with automatic reclosing schemes. Patented Ramp Down Restraint feature prevents false activation after extended circuit outage. Distinct eight-hour temporary fault indication allows line crews to investigate the cause of self-clearing faults and successful trip and reclose operations to improve circuit reliability. |
|
This world-wide unique system allows for automated testing of power transformers, CTs, VTs, resistance testing, and more.
Providing up to 800 A (or 2000 A with current booster) and 2000 V, it comes complete with an integrated PC. Its software routines test a wide range of substation equipment, and automatically create customizable reports. The compact design (29 kg / 64 lbs) and the innovative software save testing time and minimize transportation costs.
Benefits
- Lightweight (29 kg / 64 lbs)
- One test unit for multiple uses
- Automated testing and reporting
- Safety Features
- Prepared for the future |
|
CM-Line Secondary Injection test sets are the right choice for Utilities, Industry and Railway as well as for Relay, Meter and Measurement Device Manufacturers. The combination of a robust, truly portable, reliable and accurate Hardware designs together with the incomparable Test Universe Software is the basis for OMICRON’s ongoing success in maintaining its place as World Leader in the 3-Phase secondary injection test set market.
CMC 356
"The workhorse" - The CMC 356 is designed to optimally cover the modern requirements for commissioning and maintaining substations and protection devices. Its specifications cover applications in generation (including distributed generation), transmission, distribution, industry and railways - in high, medium and low voltage levels.
CMC 256plus
"The reference" - The CMC 256plus is the universal solution for testing old and new generations of relays and calibrating all kinds of meters, power quality devices and transducers. It is the first choice for all applications requiring the highest versatility and accuracy. The CMC 256plus supersedes the well-known CMC 256-6 test set.
CMC 156
The compact solution for three-phase testing of relays, meters and transducers, weighing only 9.8 kg / 22 lb. Ideal for applications requiring a high degree of portability (routine testing, etc.). |
|
The OMICRON Transformer Diagnostic System is a unique test equipment which provides automatic testing of important transformer parameters within one portable system. The test system is comprised of the CPC 100 Multi-function Primary Test System and the CP TD1 Tangent Delta unit.
The patented CPC 100 is the main control unit for the test system and the CP TD1 unit is used for testing of insulation condition. Together, the system is the ideal tool for comprehensive testing of the
following parameters of a power transformer:
• Winding resistance
• Turns ratio and excitation current
• On-load tap changer condition
• Leakage reactance
• Insulation condition (capacitance, tangent delta, power factor) |
|
Damped oscillatory waves are phenomena associated with the opening and closing of High Voltage (HV) busbars in power transmission stations. The physical environment influences the fundamental oscillation frequency and repetition of the impulses. Repetition frequencies are dependant on the power frequency and distance between contacts. For gas insulated stations this could be up to 5kHz.
The new IEC61000-4-18 standard introduces additional fast damped oscillatory waves at frequencies of 3MHz, 10MHz and 30MHz. These are for testing of signalling and control equipment installed in Gas Insulated Substations (GIS) where the transients occur in metallic enclosures containing SF6 gas.
MIG-OS-OM-EXT has been designed to add fast oscillatory wave capability to existing EMC Partner generators.
MIG-OS-OS1 and MIG0603OSI generators deliver 100kHz and 1MHz slow damped oscillatory waves that were previously included in the IEC61000-4-12 standard.
As the application is for power distribution stations, the equipment to be tested is generally connected to 3-Phase power lines. CDN3000-06-25 (manual) and CDN3000A-06-25 (automatic) enable coupling of both fast and slow oscillatory waves. |
|
Simply the best HARMONIC and FLICKER test system available today. HAR1000 does not require expensive and bulky AC sources, it uses a novel technique to provide active compensation of distortion on the national power mains.
Featuring dual analysers, the input and output signal are constantly monitored to ensure compliance. HAR1000 conforms to the latest IEC61000-3-2 Edition 2 but also allows testing to previous standard editions.
HAR1000 can be enhanced with the following accessories.
HAR-EXT1000, three phase system
Adds two further phases to the HAR1000. Simple connection without any hardware modifications mean this powerful extension can be added at any time to an existing single phase system.
HARCS Immunity software
This package can be added to both the single and three phase systems. It extends the system’s emission capability to include power line immunity tests such as harmonic immunity according to IEC61000-4-13, voltage fluctuations according to IEC61000-4-14 and ripple on DC according to IEC61000-4-17.
Adding the EMC Partner PS3, allows testing to IEC61000-4-28 for frequency fluctuations.
|
|
Breakers are situated at the key points of electrical energy transmission and distribution systems. Their reliability has a decisive influence on the availability, safety and economic efficiency of electrical supply networks.
Initially, the reliability of newly installed breakers depends on their construction, the manufacturing quality and the type and scope of final factory inspections and tests. However, once installed on site, only regular tests can guarantee perfect functioning throughout the operational life of a breaker.
Automatic test systems provide precise information as to the state of the switching chamber and drive unit throughout the entire operational life of a breaker without requiring these to be opened. The sheer number of parameters to be calculated, the wide variety of different breakers in use and the harsh environmental conditions encountered during on-site tests make extremely high demands on the test technology involved. |
|
Features
Programmable Test Sequences
Multi-link Solution Software
Tests DCR/ACR/L/C/Z/LL to 200KHz
20 Independent Channels
Versatile I/O RS-232 Interface
Q Factor and Phase Angle
Hi-speed Production Testing |
|
|
