Features and benefits:
- In-mould cutting ensuring consistent and accurate trim
- Oversized tiebars
- Low energy consumption
- Double toggle system
- Multi-zone heating
- Minimum floor space requirements
- Static eliminator
- Low air consumption
- Photo scanning available for preprinted sheet
- Electric preheater
- Stacking equipment available
|
|
|
|
|
|
CannonForma offers a wide range of products, from simple single station to complete production systems, ensuring efficiency of product solutions to specific customer’s requirements
1) Single Station
It provides total versatility across many applications and all types of material.
2) Rotary thermoforming machine
This is a cost-effective, tried and tested format especially appreciated for high production requierements, and significantly enhanced excellent service for many years, producing items such as refrigerators, pallets, sanitary ware components and automotive products.
3) High speed thermoforming machine
SPEEDFORM Series is ideal for the production of industrial parts manufactured from thick gauge materials.
Speedform is extremely valuable for producing automotive trim parts and other similar products using "In Mould Decoration". This is the process in which thermoformed parts are reinforced by injection moulding onto the back of the forming.
4) Twin sheet thermoforming machine
This process allows the production of hollow parts welding together two sheets formed in two moulds separately.
After the manufacture has been trimmed, there is not any loss in the welding zone characteristics.
CannonForma has revolutionised the approach to twinsheet technology developing very innovative plants dedicated to the production of fuel tanks.
5) IMD thermoforming machine (in mold decoration)
IMD process allows to thermoform a colour matched or pre-printed graphics using thick gauge material, which is then strengthened by injection moulding on the back surface.
|
|
FP series thermoforming machinery is dependable, economical to run, easy to use and ensure identically formed and trimmed parts. The process combines the best aspects of both pressure forming and vacuum forming technologies: precision and speed at the same time. By utylizing these technologies, FP thermoforming machinery produces uniform, high quality plastic packages in variety of rollfed thermoplastic materials, including OPS, PVC, HIPS, PET, PP and other thermoformable grade materials.
MACHINE MAIN FEATURES:
- positive and negative forming
- aluminium and resin moulds
- easy and fast mould replacing
- temperature regulation of each section
- minimal operator training required
MAIN USE:
- cosmetics and accessories
- packaging (toys and electronics)
- medical and healthcare equipment
- automotive interiors and parts
- technical parts
|
|
Design Features:
- Electronic control of camshaft with variable cam speed within one cycle
- Horizontal Stacking
- Servo-drive sheet transport system
- Double guided spike chains
- Multi-zone heating
- Production setting storage for up to 32 moulds
- Multi-zone heating
- Pneumatic roll lift
|
|
The GN1914DM with patented technology is a plug-assisted, Dual Mould Thermoforming Machine equipped with multi-zone upper and lower ovens. It will thermoform parts to a depth of 152mm (6") in two negative moulds each having a maximum forming area of 482mm x 355mm (19" x 14"). The GN1914DM utilizes an in-mould trim that guarantees the production of 100% identical parts while keeping tooling costs at a fraction of other in-mould cutting systems. Parts are handled by a robotic part handling system ensuring the steady, dependable delivery of stacked product. This extemely smooth operating machine truly is a high-output, high-volume Thermoformer.
Features and Benefits
- Robotic product handling system
- Built-in diagnostic system
- Multi-zone upper and lower ovens incorporating an infrared heating system
- Positive and negative forming
- Quick tool changes
|
|
» VACUUM-FORMING PRESSES
Double superior and inferior heating table with driven infrared radiant elements. Positive and negative bubbling system. Mould holder carriage and counter mould punch holder with pneumatic driving
» Vacuum-forming equipment optimized for the following materials :
. Thermoplastics
» Technology :
. Driving of all parameters and all actuators by microprocessor on industrial PC
. Display on a 15-inch graphic colour screen
. Electronic adjustment of the heat distribution on the superior and inferior table tops, control of the heat and cooling temperature by pyrometers
. Blank holder frame with pneumatic parallel tightening and complete opening
» Highly-versatile equipment
|
|
|
|
|
|
This new high performance machine for food products, sterile medical goods and industrial products offers an entirely new dimension in hygiene. It is entirely capable of being wet-cleaned, inside and out! This is ensured by numerous technical innovations for even more process reliability, dependability, robustness and productivity. And you profit from Multivac's 40 years of experience as the world's leading thermoform packaging authority.
The R535 is engineered to be washed down in its entirety. On the outside, corners, edges and dead spaces have consistently been avoided. Cleaning water and dirt residues simply roll off of the smooth, slanted exterior surfaces. And the interior of the machine is optimized for hygiene all the way down to the smallest design details: The chain guide and design, lifting mechanisms and mechanical elements, motors and valves, as well as all cabling. Optional special equipment:
- CIP (Cleaning in place), an automatic (self-)cleaning system and
- the cleaning position of the formatting equipment.
|
|
|
|
|
|
Lines for polished / thermoforming sheets - versatile, economic, indispensable
Thanks to the wide scope of possible applications, thermoforming sheets made of high-quality raw materials such as polystyrene, polypropylene or polyester have become an integral part of everyday life. For many decades, thermoforming sheet lines have been a standard feature of Reifenhäuser's product program. In addition to the versatility and profitability of our technical developments, their main target and tasks are meeting the product demands of our customers.
Areas of application
Everybody comes across thermoforming sheet products regularly on the shelves of the supermarket. Whether in the form of yoghurt or icecream cups, margarine or milk containers, or as trays for TV or microwave meals or as blister packs, thermoforming sheets have become indispensable for transport and protection of foodstuffs and drinks. This is not the only place where we daily meet polished sheet products - they also abound in the office and especially in our cars. The automotive industry in particular uses thermoforming sheet with smooth or embossed surfaces for high-quality inner panelling.
|
|
Matrasur Composites offers a large range of thermoforming machines totally equipped and controlled by electric motors with a greater production rate compared to machines working with pneumatic or hydraulic power. Among other things, these machines are equipped with a system for mould changing and tooling replacement that reduces idle time resulting in improved productivity. These machines are designed for the manufacturing of technical parts for industries such as automobile, sanitary ware, etc.
For specific applications such a spa production from acrylic thermoformed sheets of 4mm, Matrasur Composites supplies thermoforming machines specially developed to work with large dimensions. These machines are available at very affordable prices and work with moulds of low cost.
|
|
- The thermoforming press SOLARA SB is designed for the production of disposable paperboard items such as : plates, trays, bowls, pastry and bakery moulds, etc.
- The thermoforming press SOLARA SB works from cardboard reels integrating functions of unwinding, scoring and punching, forming, stacking, counting and piling up.
- The design of the thermoforming press SOLARA SB makes easy its use and its maintenance.
- The strong forming force exerted by the press, combined with a long lasting pressure, guarantees a high quality thermoforming.
|
|
|
|
|
|
Dispocon
Thermoforming Machines
Dispocon thermoformers are exceptionally sturdy, durable and low maintenance machines firmly established as industry?s most energy efficient and least vibrating plug-assist thermoformers with in-mould cutting.
Electro-Hydro-Pneumatic plug-assist Thermoformer with in-mould cutting for PP and PS containers are the most versatile solution in Dispocon range of thermoformers.
Market acceptability of Dispocon PP series thermoformers is evident from over 100 installations in just 3 years of its introduction. Specially designed for high cutting force required for PP, these hydraulic thermoformers also incorporate touch screen PLC control and inching facility during mould setting.
Infrared heaters with phase angle temperature control, solid state relays, excellent safety interlocks and central lubricating system are salient part of standard machine. The elimination of clutch-cam mechanism ensures least maintenance and trouble-free longer runs.
The forming stations are fabricated from heavy duty steel profiles / plates and graded cast iron. The frame is entirely stress relieved.
Features like pneumatic roll lifting, cup stacking assembly, pre-heating station are offered as optional. High operating speed with flexibility to accommodate a variety of moulds and containers results in highest productivity covering the full range of market requirement of end products.
|
|
Professional thermoform packages, automatic and extremely cost-efficient at the same time?
The R 125 makes it possible. This machine requires minimum space and is ideal for small volumes.
Small in size, big on performance.
The R 125 sets the standard in its class, offering you three decisive advantages:
1. innovative technology by Multivac, customized for the special requirements of packaging smaller batches;
2. an excellent price/performance ratio;
3. perfectly sized: at three square meters it fits everywhere.
|
|
|
|
|
|
Formpack F3 model is an in-line thermoforming machine suitable to satisfy medium production requirements.
This model, thanks to high versatility, can be applied in food, industrial and medical fields.
- The machine can thermoform both flexible and rigid materials, included foam film. The sealing materials can be plastic, medical paper and tyvec.
- It is available in N version for sealing only and V/G version to get vacuum, vacuum/gas or skin packaging.
- The machines can be customized regards length of frame, mould motion, thermoforming system, loading area, number and type of cutting stations.
- IP65 protections class: frame and protection covers made of stainless steel make the machine suitable to work in damp and aggressive environments. It can be washed by water jets as well.
- No external lubrication required.
- Friendly use control panel able to store several working programs.
- High performance due to electronic ultimate innovations.
- Changeover with quick release.
- Several options such as shape cutting, printed top web, coding units, in line printing and labelling systems, dosing systems, AISI 316 stainless steel frame and covers.
|
|
FS 950
The high-speed thermoforming line: easy to use, robust.
Modular. Max bed width 620 mm. Standard frames blend into any production configuration.
FS 950 HIGHLIGHTS
- Fully stainless steel machine.
- Automatic motion of the station.
- Fast changeover of the tooling: less than 5 minutes.
- Central lubrication for the chains and lifting station.
- Long machine advance.
- Several cutting systems.
- Thermoforming machine that adapts to all kind of accessories: double additional reel, slicers, dosing units, labelling...
|
|
LT: thermoforming systems for PS or PE film lining of EPS boards, obtained by standard PM machinery.
The LT line is designed especially for a 60 sec production cycle of floor-heating boards.
LT's main features are:
- Rapid shift of production with different films or varying board thickness (from 35 to 100 mm) and same format
- Working surface: min 800x800, max 1000x1400 mm.
- Film thickness: min 0.15 max 1 mm, different colors.
|
|
Easy and precise sheet positioning.
The sheets are easily positioned on extractable pallet and are kept in the correct position during the whole lifting operation so that they cannot be displaced accidentally.
Flexible and automatic mould unloading.
Unloading formed automated pieces can frontal or longitudinal.
Mixed hydraulic mould movement.
Movements can be completely pneumatic or mixed hydraulic.
The hydraulic system uses accumulators to reduce the installed power, to avoid noise and to eliminate the need of cooling. The proportional valves allow checking and storing mould speeds.
|
|
FS 910
The compact thermoforming packaging solution when space is at a premium
High performance, every feature you might need and technology that meets the latest safety and hygiene standards.
A compact thermoforming machine: the efficiency of a larger machine.
Flexible or semi-rigid packaging materials
Air pack, vacuum and MAP options.
Fast and simple tool change.
FS 910 Highlights
- Plexiglas guarding easily removable.
- Quick format changing. Very easy transformation from 1 to several pockets.
- Various widths.
|
|
|
|
|
|
TFS 200
Hygienic thermoforming machine for flexible or rigid film with modified atmosphere (MAP) and vacuum options. The most suitable solution for upgrading manual packaging systems to automatic systems.
The TFS 200 is a thermoforming machine designed to pack food non-food or medical products. The package is created directly by the machine using two rolls of film. The film may be flexible or rigid. Vacuum with gas flushing is availableas an option.
The TFS Series offers the ideal way to advance from manual packaging to automatic packaging. These machines provide an economical solution with the same cost saving advantages of larger thermoforming machines:
- Reduced Package Cost
- Increased Productivity
- Improved Product Appearance
- Faster Product Loading
The machine characteristics make it highly desirable for mixed production requirements,Since formats can be easily changed to meet the needs of the customer. It’s versatility, easy operation, and quick size change also make it suitable as a support machine for short run products.
|
|
Specification of QV Series
Model No. QV-360 QV-260
Output 10-40 cycle/min
Forming Dimension 1000 x 1100 x 200mm 600 x 400 x 120mm
Material PS, PP, PVC, OPS, PET, ABS, PSP
Infrared Ceramic Heater 120 x 120 x 0.4kw x 128pcs 120 x 120 x 0.4kw x 42pcs
Motor 15 HP 7.5 HP
Servo Motor 2.9 kw 2.2 kw
Air Compressor 30 HP (optional) 20 HP (optional)
Water Chiller 5 tons (optional) 5 tons (optional)
|
|
| ... products without technical information |
| |
Professional thermoform packages, automatic and extremely cost-efficient at the same time?
The R 125 makes it possible. This machine requires minimum space and is ideal for small volumes.
Small in size, big on performance.
The R 125 sets the standard in its class, offering you three decisive advantages:
1. innovative technology by Multivac, customized for the special requirements of packaging smaller batches;
2. an excellent price/performance ratio;
3. perfectly sized: at three square meters it fits everywhere.
|
|
|
|
|
|
Formpack F3 model is an in-line thermoforming machine suitable to satisfy medium production requirements.
This model, thanks to high versatility, can be applied in food, industrial and medical fields.
- The machine can thermoform both flexible and rigid materials, included foam film. The sealing materials can be plastic, medical paper and tyvec.
- It is available in N version for sealing only and V/G version to get vacuum, vacuum/gas or skin packaging.
- The machines can be customized regards length of frame, mould motion, thermoforming system, loading area, number and type of cutting stations.
- IP65 protections class: frame and protection covers made of stainless steel make the machine suitable to work in damp and aggressive environments. It can be washed by water jets as well.
- No external lubrication required.
- Friendly use control panel able to store several working programs.
- High performance due to electronic ultimate innovations.
- Changeover with quick release.
- Several options such as shape cutting, printed top web, coding units, in line printing and labelling systems, dosing systems, AISI 316 stainless steel frame and covers.
|
|
FS 910
The compact thermoforming packaging solution when space is at a premium
High performance, every feature you might need and technology that meets the latest safety and hygiene standards.
A compact thermoforming machine: the efficiency of a larger machine.
Flexible or semi-rigid packaging materials
Air pack, vacuum and MAP options.
Fast and simple tool change.
FS 910 Highlights
- Plexiglas guarding easily removable.
- Quick format changing. Very easy transformation from 1 to several pockets.
- Various widths.
|
|
|
|
|
|
TFS 200
Hygienic thermoforming machine for flexible or rigid film with modified atmosphere (MAP) and vacuum options. The most suitable solution for upgrading manual packaging systems to automatic systems.
The TFS 200 is a thermoforming machine designed to pack food non-food or medical products. The package is created directly by the machine using two rolls of film. The film may be flexible or rigid. Vacuum with gas flushing is availableas an option.
The TFS Series offers the ideal way to advance from manual packaging to automatic packaging. These machines provide an economical solution with the same cost saving advantages of larger thermoforming machines:
- Reduced Package Cost
- Increased Productivity
- Improved Product Appearance
- Faster Product Loading
The machine characteristics make it highly desirable for mixed production requirements,Since formats can be easily changed to meet the needs of the customer. It’s versatility, easy operation, and quick size change also make it suitable as a support machine for short run products.
|
|
Design Features:
G.N. stacking units can easily be attached to any G.N. thermoformer to create a completely automated and efficient high speed thermoforming production system.
G.N. stacking units accurately count, stack and deliver the formed parts onto the receiving table.
|
|
Technical DetailsNominal working width [mm] 480
Nominal draw-off length [mm] 160
Max. drawing depth [mm] 90
Max. reel diameters:
Bottom material [mm] 1.200
Lid material [mm] 400
|
|
Technical DetailsNominal working width [mm] 480
Nominal draw-off length [mm] 80
Max. drawing depth [mm] 90
Max. reel diameters:
Bottom material [mm] 1.200
Lid material [mm] 400
|
|
The GN Robotic Stacking unit is a complete product handling system designed to improve the performance of the GN thermoformer.
Vacuum cups attach themselves to the product prior to stripping from the web and places the parts in stacks.
Design Features
- Ensures consistent part separation from web
- Simple, inexpensive tool specific change parts
- 5 minute set-up
- User friendly operation
- Easily adapts to existing GN thermoformer
|
|
|
|
|
|
Battenfeld Extrusionstechnik is a leading supplier of inline and out-of-line extrusion systems which are also available as high-performance lines:
- mono- and multi-layer deep drawn PP, PS or PET film up to 7 layers
- film thicknesses of 200 µm - 2 mm
- main applications in food packaging, esp. packaging of dairy products
inline extrusion systems can be combined with all automatic thermoforming machines currently on the market.
Battenfeld Extrusionstechnik offers a specially tailored line of extruders for the production of deep drawn films/sheet that enables processors to run their own production process very efficiently.
- high specific output rates
- degassing extruders for optimum melt quality
- constant mass throughput and therefore excellent thickness tolerances through the use of melt pumps
- state-of-the-art flat dies adapted to end product
- raw material savings and recycled material can be used without problems
low energy consumption
- modern, compact, maintenance-free drive technology for main- and co-extruder
For the production of thermoforming films/sheet, Battenfeld Extrusionstechnik manufactures especially tailored roll stacks that ensure superior end product quality.
|
|
Battenfeld Extrusionstechnik manufactures complete inline and out-of-line extrusion systems for Polyester (PET) film:
- film thicknesses of 100 µm - 1200 µm
- multi-layer and laminated film
- main applications are in food packaging
With Battenfeld Extrusionstechnik's specially designed co-rotating twin-screw extruders for A-PET film extrusion, non-pre-dried material can be run without problems.
Thus, processors benefit from:
- energy savings
- higher flexibility
- better film quality
|
|
... see all the products in the category
Extruders
|
|
|
