Precision sensors for fast, accurate acquisition of component dimensions and surface data.
The world's leading range of touch-trigger and scanning measurement systems for co-ordinate measuring machines (CMMs), plus the revolutionary Renscan5%u2122 5-axis scanning technology.
|
|
|
3-D touch probes from HEIDENHAIN were conceived for use on machine tools – in particular milling machines and machining centers. 3-D touch probes help to save costs in the workshop and in medium-size production runs: NC controls can automatically run setup, measuring and verification tasks – and most controls can also run them under program control.
|
|
The GapGun handheld laser gauge is a quality assurance
tool that checks product build geometry in production,
maintenance and repair facilities.
Our GapGun customers are spread across the globe from the Far East through Europe to the USA, and include the worlds leading aerospace and automotive companies (see logos).
Typical applications include:
Chamfer, radius and Break Sharp Edge measurement
Automotive painted and Body in White (BIW)
Aerospace panels, doors and hatches.
Interiors, dashboards and trim
Proven to meet or exceed QS9000-MSA for a wide variety of measurement types, the GapGun will boost your measurement capability and data collection rates.
GapGun - Save Time, Save Money, Increase Accuracy
|
|
|
The 3D-Sensor NG is a further development of our worldwide accepted and proven Universal 3D-Sensor. Its distinguishing features are improved mechanics and a new and compact design.
|
|
• Measuring Range 0.5 mm
• Resolution Programmable to <0.01 µm
• Tip Forces down to 5 g
• Excellent Repeatability
• Up to 3906 Readings/Second
• Industry Standard Styli
• Compact Size
• Direct Reading in mm/inch
Solartron's new Digital Lever Probe has been conceived for the precision measurement market. This probe is ideally suited to applications where the use of axial measuring probes is not possible, and where a low tip force and a high number of probing points are required. Its simple design and exceptional reliability result in a reduced cost of ownership without any reduction in performance.
|
|
• 0.5 mm Total Measurement Range
• Resolution Programmable to < 0.01 µm
• Simple Installation and Sensor Change
• Excellent Repeatability and Robustness in two planes
• Suitable for Operation in Bores with key slot
• Very Compact Size
• Changeable Tips
• Up to 3,906 Readings/Second
• IP65 Protection
• Traceable Calibration
• CE Marked
The Solartron Digital Mini Probe is a compact, low profile, transducer intended for measurements in confined spaces such as bores. The product is based on a parallel spring structure that is significantly more robust than a single leaf arrangement. This greatly improves the reliability of the sensor, extending its working life and allowing it to be used in more demanding applications, such as automatic gages. The parallel spring also ensures a high level of repeatability, both on axis and across axis, so that it can be used in dynamic applications where profiling is required.
|
|
Leica T-Probe is a “Walk-Around” armless wireless probing device for probing of hidden, hard-to-reach points and measuring of up to 9 cars in one setup with minimal setup times, sets new standards by increasing accuracy, offering a ten-fold increase in point acquisition rate and providing user-assignable multi-function buttons
Small, light, user-friendly, and more accurate than any other hand-held probe in the world, the Leica T-Probe gives you more than 6 Degrees of Freedom: It gives you the right way to measure. Now featuring longer styli, Leica T-Probe reaches up to 30m (98ft) in any dimension.
|
|
Features:
- Automatic, real-time target identification
- Track up to 512 targets
- Measure up to 4500 measurements per second
- Report in a fixed frame of reference or dynamically reference relative to other moving targets
Key Benefits:
- High speed 3D tracking of targets
- Real-time 6DOF tracking of multiple objects
- Measure dynamic behaviour of parts, structures, and assemblies
|
|
DIT 10
Precision measuring Probe
- for universal applications
- stroke length 10 mm
- flat version
- mounting on shaft sleeve
- with cable lifter
- sealing bellows optional
|
|
Features:
» Gemodek Probe
» Probes
» Probe-Changing system
» Optical measuring systems
» Handbox
» Wireless control panel
» Control panel
» Marking tool
|
|
One probe head for every inspection task.
With its own family of probe heads integrating a high-precision SWISS MADE
mechanics, TESA offers a complete solution for three-dimensional measure-
ment.
|
|
Features:
- Hardened and ground steel plunger, and rest plate
- Masters on any flat service, no special master required
- 3 Blade contact insures accurate repeatable readings
- .001"/0.02mm dial indicator, standard
- Optional digital indicator -.0002" resolution on 90° or .0004" resolution on 127° model
- Inch or metric indicators available
- Includes fitted storage box
|
|
|
|
|
|
General
Measuring surface and hardened steel taper
Scale graduation of indicators: 0.01 mm
Calibration at factory or via setting master
Special designs on request
Internal taper gauge (IKT)
Direct gauging of major diameter of internal tapers or tapered slots
Models with 60°, 90° and 127° taper
Application range: Ø 0.5 mm to 120 mm
Measuring range: 11.5 mm for 60° taper/19.5 mm for 90° and 127° taper
The low-cost Alternative: The Internal Taper Gauge IKT-OS
The term OS is an abbreviation which means "without stop bar". By the omission of the bar, the alternative internal taper gauge can be manufactured at a lower cost which in turn renders a favourable sales price.
The IKT-OS is implemented to measure the largest diameter of internal tapers or tapered grooves. In contrast to its brother product, the IKT-OS requires a contact surface and cannot be used with thin-walled work pieces.
Standard setting masters can be utilised, as well as the corresponding dial indicator or digital dial indicator IKT-MU1086W.
External taper gauge (AKT)
Direct gauging of minor diameter of external taper
Models with 60°, 90° and 127° plungers
Application range: Ø 5 mm to 120 mm
Measuring range: 11 mm for 60° plunger/19.5 mm for 90° and 127° plunger (except for size 1)
Chamfer gauge (KT/KT-B)
Direct gauging of 45° chamfers on rectangular and cylindrical pieces, even bores or slots
Measuring range: chamfers up to 7 mm (radii 1 mm up to 9.5 mm via conversion)
Chamfers in bores from approx. Ø 28 mm
|
|
GT2 series Digital Contact Sensor
General Purpose Digital Contact Sensor with Push Button Calibration
For full details, download the PRODUCT CATALOG using the CATALOG icon in the Online Support and Services box above
|
|
Automated version fitted with TESASTAR-m – Provides enhanced measuring
capabilities through the use of dedicated accessories such as the modular
probe changer.
|
|
The optional integration of several optical beam paths in a vertical or horizontal orientation, the fitting of highly-accurate rotary stages as fourth and fifth axes of measure-ment and the design of separate measurement axes for certain sensors allow for application-related system configurations.
|
|
DG805BL/FL, DG810B/BL, DG810F/FL
Light Touch Miniature Design Probes (spring push with carbide tip)
* Utilizes precision Magnescale® linear encoder technology
* Radial cable exit models accept a vacuum line for spindle lift
* 5.2 and 10mm strokes
* 8mm mounting diameter (special flange mounting optional)
* About 5 times lower measuring force than standard type probes
* Designed to gauge delicate surfaces like auto windshields, CRTs, electronic components, etc.
* Dust proof bellows
* A/B open collector output
* Accuracy: 1µm
* Resolution: 0.5µm
|
|
Developed to measure both internal and external diameters and lengths, the gauge’s aluminium extrusion beam gives it a rigid, yet lightweight quality – making it ideal for shop-floor environments. The simple release of a locking thumb screw enables the gauge’s measuring direction to be changed easily and quickly.
The four gauges in the Intex range have been designed to measure components from 200mm up to 1m long; however extended lengths are available on request.
Features:
* Lightweight and rigid - typically weighing less than 2kg
* Internal and external measurement
* 2mm travel on moving contacts
* Adjustable fixed contacts with a range of adjustment up to 250mm
* Digital or mechanical readout display
* Hardened steel wear pads locate gauge on to the component aiding accuracy, repeatability and prolonging the life of the instrument
|
|
Incremental length gauges from HEIDENHAIN offer high accuracy over long measuring ranges. These sturdily made gauges are available in application-oriented versions.
They have a wide range of applications in production metrology, in multipoint inspection stations, measuring equipment monitoring, and as position measuring devices.
|
|
Solartron Analogue Gauging Probes incorporate a precision linear bearing, which gives exceptional repeatability.
• Spring Push
• Pneumatic Push or Vacuum Retract
• Feather Touch
The ultimate in rapid, high accuracy measurement.
|
|
We offer three main versions of our Digital Probe
• Spring Push
• Pneumatic Push
• Feather Touch
The Probe is an absolute measuring device that delivers accurate results when switched on, regardless of any 'OFF' movements.
|
|
Incremental Length Gauge
- for multipoint measuring applications
- stroke length 30 mm
- compact version
- mounting clamping shaft sleeve
- pneumatic plunger actuation option
- sealing bellows option
|
|
General Purpose Digital Contact Sensor
• Tough, Rugged: IP-67 Enclosure Rating
• Error-free Design W/ Co-transformer Method
• Total Cost Reduction W/ Simplified Set-up
• Easy and Simple Set-up
• One-push Zero Point Adjustment
• Data Communication with 10 Amplifiers
Tough and rugged general purpose digital contact sensor with push button calibration.
|
|
Using LVDT technology, Trans-Tek manufacturers three different lines of Gaging Transducers capable of measuring up to 20 inches. Gaging transducers are often selected over free-unguided LVDTs when a hard connection cannot be made to the moving object. All units consist of a spring-loaded shaft guided through a phosphorous bronze, leaded bearing. A hardened steel contact tip touches the object to be measured.
Click on the Product Line most closely matching your requirements:
Series 310-320 AC Gaging: 0.5 to 20 inch stroke, 0.875 OD, connector term.
Series 330 AC Gaging: 0.01 to 2.0 inch stroke; 0.375 OD, cable term.
Series 350 DC Gaging: 0.10 to 6.0 inch stroke; various ODs and terminations
|
|
GS-1000 is a long range contact type linear gauge sensor which has a linear type displacement converter and converts spindle displacement directly into electric signals.
The adoption of ball spline bearings in the spindle has resulted in increased torsional rigidity (10 times as much as our conventional one) and of durability (practical durability of more than 10 million times) of the spindle.
The sensor is suitable for use in dangerous places and where measured values cannot be directly observed and for being incorporated in machines.
Features
- Long range of 100 mm
- High durability (2.5 times as much as our conventional one)
- Optimum for machine production, building and civil engineering fields
|
|
A comprehensive range of precision-engineered styli for maximum measurement accuracy.
Styli and stylus accessories for Renishaw's CMM, machine tool and scanning probes, as well as for sensors from other manufacturers
|
|
We do not exclusively manufacture cutting tools but also wear parts.
These are in carbide and can be commissioned in numerous forms: punches, balls, high precision probes.
Some prestigious manufacturers of measurement and metrology machines have depended upon us for decades.
The touches, punches and probes are manufactured according to your designs. For the balls, our standard tolerances are ±1µm.
|
|
