Auto-transformers, open model, for switchboard mounting, to control the rotational speed of voltage controllable motors (230 Vac, 50/60 Hz) (professional fans, pumps, among others).
<< According to: EN61558-2-13
<< Compact design
<< Connecting terminal blocks suppliers, finger proof, IP20
<< Mounting brackets
<< Insulation class: T60/F
<< Dielectric sensitivity: 2.500 V
<< Maximal admissible temperature: 155 °C
<< Maximal ambient temperature: 35 °C |
|
| An extensive range of high quality current transformers offering comprehensive measuring and protection class accuracies. The range provides accurate measurement of high primary currents and ratio matching to a consistent 5 or 1 Amp secondary current, proportional to the main current. To suit the requirements of every application, the range offers moulded case, miniature, core balanced, tape wound and split core current transformers and integral transducers in a wide range of system current ratings, busbar sizes, case widths and apertures, with various mounting options. |
|
DISTRIBUTION TRANSFORMERS
CHARACTERISTICS:
Power: 15 to 300 kVA
High Voltage: 15 and 24,2 kV
Low Voltage: 380/220 or 220/127V
Standards: according to ABNT / IEC
APPLICATION:Power Distribution
SELF-PROTECTED TRANSFORMERS
CHARACTERISTICS:
Power: 45 to 150 kVA
High Voltage: 15 or 24,2 kV
Low Voltage: 380/220; 220/127V
Standards: according to ABNT / IEC
APPLICATIONS:Protection of distribution systems against overloads;
Short-circuit Protection for the secondary network;
Protection against internal transformer faults.
UNDERGROUND TRANSFORMERS
CHARACTERISTICS:
Power: 150 to 2.000 kVA
High Voltage: 15 or 24,2 kV
Low Voltage: 216.5/125; 220/127; 380/220; 400/231V
Standards: according to NBR 9369/1986 ABNT
APPLICATIONS:Installation into chambers, at any level;
Can be eventually immersed in water.
INDUSTRIAL TRANSFORMERS
CHARACTERISTICS:
Power: 500 to 5000 kVA
High Voltage: 15; 24,2; 36,2 or 72,5 kV
Low Voltage: 4160/2402; 440/254; 380/220; 220/127V
or according to customer specifications.
Standards: according to ABNT / IEC
APPLICATIONS:Industrial Substations.
POWER TRANSFORMERS
CHARACTERISTICS:
High Voltage: up to 550 kV
Top Rate: from 5 to 300MVA
Standards: IEC / ANSI
APLICATIONS: Utilities Substations
|
|
The STVS1 transformer speed controllers are based on the principle of voltage control with auto-transformers. They are applicable to voltage-controllable motors (230 V, 50/60 Hz)to control the rotational speed (of professional fans, pumps, etc.). By combining the transformer outs and a relay board, it is possible to select these predetermined speeds by a 0-10 Vdc signal. They are fitted out with (TK) contacts for thermal motor protection.
<< 230 Vac - 50/60 Hz - from 1,5 up to 13 A
<< Enclosure: Plastic or sheet steel, IP54
<< Control signal input: 0 - 10 Vdc
<< Supply: 12 Vdc
<< Power / control: galvanic separated
<< Several voltage ranges possible
<< Indicator lamps, Run/Fault indication
<< Current industrial fuse
<< 230 V, unregulated output
<< Ready mounted industrial cable glands
<< Maximal ambient temperature: 35 °C
Sentera offers a wide range of transformer controllers for different HVAC&R applications. All models have mono and three phase versions. |
|
Variable Transformers - Three Phase Type
Autotransformers:
Up: 400 V
Us: 0 to 400 V or
0 to 450 V
Is: 0.8 to 32 A
General Data Frequency range:
50 to 400 Hz
|
|
Power ratings from 5 MVA to 575 MVA/525 kV
Special transformer types:
- HVDC-station transformers up to 315 MVA/500 kV DC
- autotransformers up to 700 MVA/525 kV
- industrial generator step-up transformers
- phase-shifting transformers up to 500 MVA/525 kV
- transformers feeding a industrial converter
- transformers feeding two (or more) separate systems
- mobile transformers |
|
Product for marine and off-shore application.
Distribution, Propulsion industrial transformers
6, 12, 24 pulse.
High reliability expecially looking at the insulation characteristics
of the transformers.
AN-AF-ANWF professional cooling system
IP00 to ip55
Aluminium or Copper windings. |
|
| The traditional products made by REO are grouped under the name of Classics. New developments of these existing products are no longer possible because we always come back to the old and well tried methods. True to the company slogan 'Innovation from Tradition' REO INDUCTIVE COMPONENTS AG is still able to offer to customers a complete range of components for adjusting voltage, current and resistance. Whether is a fixed or variable transformer, toroidal or tubular our products are still suitable for today's industrial environment. The demand is falling for products such as fixed or variable resistors (rheostats), with motor drive or connected in series, and so the manufacturing of these products is becoming more cost-intensive. Therefore by using our engineering, production and selling competences we are able to offer modern equivalents, with higher dynamic characteristics and the same level of quality. REO will remain committed to manufacturing these products for as long as there is still a need for them. |
|
The Pauwels Group is a full-line supplier, offering a wide product range of transformers like :
autotransformers up to 700 MVA/525 kV |
|
Autotransformer VT-EN Range
Common input and output windings without electrical isolation
Designed for continuous duty |
|
Cast resin distribution transformers: Power ratings from 100 kVAto 10,000 kVA/36 kV
An alternative option to liquid-filled distribution transformers with the emphasis on reduced environmental impact and increased fire safety.
Cast resin distribution transformers are manufactured in Mechelen (Pauwels Trafo Belgium N.V) |
|
| Providing both quality and experience the Setzermann division of REO INDUCTIVE COMPONENTS AG produces toroidal current-transformers from with power ratings from 10 VA up to 500 VA. These are available in either standard or custom designs, built to specification and proved in our own test laboratory. The toroidal current-transformers conform to all relevant standards whilst double-isolation and the use of UL approved encapsulation materials are always incorporated in their design. The Setzermann range of current-transformers includes many different styles from those for pcb-mounting to panel-mounting types. We offer our customers a prototyping service before commitment to a final design. Details of all products can be downloaded from our website. Setzermann current-transformers have a good reputation for high-protection and longevity. |
|
Liquid-filled distribution transformers: Power ratings from 15 kVA to 10,000 kVA/36 kV
Cast resin distribution transformers: Power ratings from 100 kVAto 10,000 kVA/36 kV
An alternative option to liquid-filled distribution transformers with the emphasis on reduced environmental impact and increased fire safety.
Special transformer types:
- single phase transformers
- autotran sformers
- multiple voltage transformers (mostly dual voltage transformers)
- medium voltage/medium voltage transformers
- transformers feeding a static professional converter (rectifier transformers)
- transformers fed by a static converter
- phase-shifting transformers
- earthing transformers
- special transformer connections
- transformers feeding two (or more) separate systems
- transformers with core in amorphous metal (only oil-filled transformers) |
|
Marine, Traction, Industrial application.
Cast Resin or Dry Type (vacuum impregnation technology).
Voltage up to 36kV and power up to 20MVA.
From IP00 to IP55.
AN-AF-AFWF industrial cooling systems.
AL or CU windings.
|
|
| There is no other market sector that is as safety conscious as the Medical Industry where health and protection of patients are the main concern. REO INDUCTIVE COMPONENTS AG is prepared for the special technical requirements of this market, in particular the Medical Devices Directive first introduced on 14th June 1993, with an exclusive range of products. |
|
Liquid-filled distribution industrial transformers: Power ratings from 15 kVA to 10,000 kVA/36 kV
Liquid-filled distribution transformers are manufactured in Mechelen (Pauwels Trafo Belgium N.V.).
Cavan (Pauwels Trafo Ireland Ltd). Washington/Missouri-USA (Pauwels Transformers Inc.) |
|
Control transformer BUST Range
Low profile
Screw type terminals
Control transformer to IEC 61558-2-2, DIN EN 61558-2-2,
VDE 0570 part 2-2 |
|
With separate windings for use as single-phase voltage supply unit for 12 V or 24 V. Designed for very efficient operation in stand-by mode. Ideal for applications where full power is required for a very short duration, such as automatic doors, hospital beds and motor-adjusted work-stations.
|
|
Using an auto-transformer is always an economical solution when you need to step down the voltage from 230V to 120 V or vice versa, and the equipment already has a fully isolated transformer or when the components do not require an isolated transformer.
The toroidal construction of an auto-transformer offers important advantages in comparison with an E/I lamination core transformer, like smaller physical size and weight, 30-70% reduction (depending on secondary voltage) and very low magnetic strayfields. The auto-transformer can be mounted horizontally using a steel washer or our Poly-Mount, a plastic insert, or an epoxy potted center with a 1/4" mounting hole. |
|
We manufacture an extensive range of indoor current transformers for metering and relaying applications. All of our current transformers have a 105°C or higher insulation system and most models are UL recognized.
Applications
600V Indoor Commercial Grade Toroid
600V Indoor Commercial Grade Bar
600V Indoor Instrument Grade Toroid
600V Indoor Rectangular Window
600V Indoor Three Phase
600V Indoor Multi-Ratio Toroid
600V Indoor Split Core
600V Indoor Wound Primary/Auxiliary
5kV - 34.5kV Class Indoor
720V Indoor IEC Rated |
|
Ventilated Dry-Type
GE Type "QHV" distribution industrial transformers are designed to step down incoming distribution voltages for direct utilization or further plant distribution. The construction of the GE distribution units is similar to that of the general purpose line.
Features and Benefits
Factory NEMA 3R option is available
Standard product offering is wound with Aluminum conductor. Copper is available as an alternative on many designs.
Non standard voltage designs can be created to meet individual customers needs.
Applications:
Step Down Incoming Distribution Voltages
Product Scope:
Voltages up to 600V
Confirms to ANSI and NEMA standards
Single phase is offered in ratings 25 to 333 KVA.
Three phase is offered in ratings 15 to 500 KVA
Standard BIL levels of 30 and 60 can be increased on many ratings to 60 and 95 KV BIL. |
|
- No minimum order quantities
- Same day ship on in-stock products |
|
We offer numerous Power transformers in the toroidal design. For your convenience, we have added the expected DC output, should the transformer be rectified.
The DC output is calculated with a standard full-wave bridge rectifier with a large supplier of capacitor. Any of these primaries can be easily used to configure custom secondaries at a reduced cost compared to a full custom design. |
|
| For SCR (Silicon Control Rectifier) variable speed motor drive applications, a transformer is needed to magnetically isolate the incoming line from the motor drive. The transformer must also provide a voltage change to match the required voltage of the SCR Drive. Standard designs are delta primary and wye secondary to match the common power sources required in most three phase rectifier circuits. |
|
* Standard Insulation transformers are UL recognized to UL1411.
Comply with CSA/TUV/IEC 742/IEC 950, 4000V hi-pot tested, 8mm creep distance. Supplied with metal washer and rubber pads.
Dual Primaries (2 x 117V), 50-60Hz Operation.
* Standard Isolation Transformers UL recognized to UL544. Comply with CSA/TUV/IEC 601.1, with 50µA leakage current, 4000V hi-pot tested, 8 mm creep distance, auto resetable industrial fuse, static shield. Transformers 1500VA or larger are supplied with epoxy potted center with hole for mounting bolt specifications. Steel washer and rubber pads are supplied for smaller power ratings.
Quad Primaries - (100V, 120V, 220V, 240V) à 50-60Hz Operation. |
|
The Sola/Hevi-Duty K-Factor design is a specialized transformer that offers these benefits:
Conductors capable of carrying the harmonic currents of non-linear loads without exceeding the temperature rating of the insulation system. Paralleled conductors are used to reduce and control skin effect losses.
A transformer design that takes into account the increase in naturally occurring "stray" losses caused by non-linear loads. These losses cause standard transformers to dramatically overheat and substantially shorten design life. The K-Factor is designed to function within safe operating temperatures.
A core and coil design that manages the DC flux caused by triplen harmonics*. As these harmonics increase, they cause additional current to circulate in the delta winding. This produces a DC flux in the core which leads to core saturation, voltage instability and overheating.
K-Factor transformers are UL 1561 listed.
Designed to supply non-linear loads without overheating the windings or saturating the core.
All Sola/Hevi-Duty K-Factor transformers have a rated temperature rise of 150°C. |
|
Control Power Transformer
Our wide range of control power transformers is designed to provide control power in medium voltage switchgear. Units are available in both single and three phase configurations with some models capable of vertical mounting to conserve space.
Features and Benefits:
Manufactured to meet the requirements of IEEE C57.12.01
Primary windings are vacuum cast for high dielectric strength and ruggedness. Vacuum cast secondary coils are available in some models.
Constructed with high quality grain-oriented core steel and copper conductor
Units are partial discharge tested in accordance with Canadian Standard C9-M1981 (reaffirmed 1997)
Standard voltages are 120/240 for single phase units and 208Y/120 for three phase units with other voltages available.
Product Scope:
Voltage Class: 5 to 34.5 kV
BIL ratings: 60 to 150 kV
Thermal Ratings: 0.5 to 150 kVA |
|
Commercial Pole-Mounted
GE three phase pad-mounted and single phase pole-mounted industrial transformers are a safe and effective way to provide power distribution to residential, commercial, industrial, and institutional loads. GE COMPAD transformer distribution units are designed in neat, clean, and modern packages to meet your power distribution needs.
Commercial Pad-Mounted
GE three phase pad-mounted and single phase pole-mounted transformers are a safe and effective way to provide power distribution to residential, commercial, industrial, and institutional loads. GE COMPAD transformer distribution units are designed in neat, clean, and modern packages to meet your power distribution needs.
|
|
|
|
