Trencher - 3 point-mounted: DECTRA 600
- Tractor power: 70 up to 130HP
- 3-point linkage n°2
- PTO: 540rpm
- Slow recommended forwarding speed:600 up to 800m/h.
- Important: Slow speeds are necessary for working at 60cm deep in hard soills (Tractor forwarding speed from 200m/h up to 1Km/h)
- Transmission with clamp 1¾ inch,with 6 fluted rollers on ditching device 1'3/8 inch and 6 fluted rollers on tractor's side.
- 2 hydraulic dual-way circuits are needed on the tractor for controlling the lowering of the rotor and the openning of the rear hood.
- Total weight of the ditching machine: 1 500kg.
|
|
Vermeer is the track leader. Proven Vermeer hydrostatic trenching units offer high torque, excellent horsepower, deep digging depths and work-condition flexibility. The exclusive TEC 2000 and TEC 2000.2 control systems monitor operating conditions, increase productivity and reduce machine wear. Features like heavy-duty track chains and durable construction enhance machine efficiency.
With nine models to choose from, an optional Vantage Track 3-year/3000-hour or 5-year/5000- hour Extended-Care Service Program and a worldwide network of on-site support, Vermeer is the clear choice for your track trenching needs - talk to your dealer today.
Track trenchers from a trusted source for trenching equipment.
|
|
|
Compact design, simple features. Less really is more when it comes to the Vermeer RT350. Contractors can appreciate the Vermeer RT350 and its compact design for smaller weekday projects. Rental stores can appreciate the RT350 for its simple design, making it more attractive to the do-it-yourself weekend warriors. No matter what day of the week it is the RT350 is priced affordably and can be used in various trenching applications.
|
|
Vermeer rockwheel trenchers - rugged and reliable. Vermeer rockwheels are the utility contractors solution for jobs that run through rock. Vermeer high-performance rockwheels are equipped with shank rotary carbide teeth that help increase cutting performance in tough conditions. The rockwheel attachment is available on the Vermeer LM42, RT950, RT1250, T555 Commander and T855 Commander III.
Rockwheels from a trusted source for trenching equipment.
|
|
|
|
|
|
Trenching equipment - Walk-behind and pedestrian trenchers
Our walk-along and walk-behind trenchers are built to stand up to rugged use, while retaining maneuverability, easy operation, and low maintenance. With flexible power options, responsive controls, and cutting-edge designs, Vermeer trenchers match your work site needs.
Vermeer walk-behind trencher parts and accessories
Like everything we manufacture, our trenching equipment parts and accessories are precision engineered and manufactured to exacting tolerances to provide longer-lasting service in the field. Additionally, Vermeer personnel are readily available to meet your service needs.
Superior design and functionality
At Vermeer, all of our trenchers are built to provide you with the strength and flexibility you need, along with ease of operation. Control knobs are color-coded for instant recognition, and the on/off switch is conveniently placed for start-up.
One of our priorities in designing our equipment is to ensure operator safety. For this reason, all of our trenchers feature a heavy-duty operator presence system - insulated handles provide a measure of protection against electric shock, and also act as an automatic shut-off to the digging chain and ground drive. Simply release the handles, and your trencher stops.
For more information on individual walk-behind model specifications, browse our pedestrian trencher product sheets and brochures in the Literature section.
|
|
The T560 is a hydrostatic drive chain trencher with a 185-horsepower Cummins turbocharged, after-cooled diesel engine. It features a two-speed infinitely variable digging chain drive for changing ground conditions and machine leveling capability for trenching on sloped surfaces.
The forged tailwheel provides smooth chain operation. True load sensing helps maintain balance between track speed and trencher speed for maximum productivity. The low-profile digging chains allow for optimum tooth penetration. This unit can achieve trenching depths from four to eight feet and widths from 10 to 24 inches. Routine service points are easily accessible from the ground.
|
|
|
|
|
|
Hard rock trenching series
ENGINE Model Cummins© QSM 11
Number of Cylinders 6
Power @ 1,800 RPM 335 hp (250 kw)
Electric starting 24 V
TANK CAPACITIES Diesel Fuel 400 litre
Hydraulic Oil 435 litre (tank refill)
WEIGHT 49,000 kg (approx)
UNDERCARRIAGE Heavy Duty Track Frame
type equivalent to D5B
pad type triple bar grouser 450mm width
rollers lifetime lubricated std.
suspension oscillating undercarriage
track drive independent hydrostatic
track tension hydraulic - grease gun type
track length 4.6 m
SPOIL DISCHARGE Conveyor system
discharge swing conveyor to either left or right hand side thro 180°
discharge speed stepless adjustable from 0 to 5 m/s
TRENCH UNIT Fixed offset to left hand side
Trenching method heavy duty digging chain with bolt on digging plates and cutting drums
Cutting tools conical rotary carbide point attack
Cutting drums 1.5m diameter (over pick tips)
Chain drive hydrostatic, by one direct coupled, low speed high torque motor
Chain tension remote hydraulic with mechanical lock
TRENCH SIZE
Trench width 0.65 m
Trench depth ground level to 2.5 m
|
|
All different types of trenchers with chainsaw, rockwheel and "bucket" wheel digging attachments as well as the surface miners are designed and manufactured in the plants of Alvarado - Texas and Grassobbio - Italy.
These machines offer advanced technology and state-of-the-art solutions to solve any problem of excavation or rock crushing, providing high productivity and cost effective work.
The wide range of machines allows different trench sizes and the capability to dig in the hardest conditions and difficult terrains like solid rock and frozen soil.
It is possible to trench for different applications, such as:
- fibre optics and power cables
- oil and gas pipelines, water and sewer lines, drainages
- automatic laying of cables, conduits and plastic pipes
- excavation and crushing of solid rock in the quarries
- reclamation of rocky soils to be used for agriculture.
|
|
It's a big world, and a big world demands a big, powerful machine to civilize it. Ditch Witch heavy-duty tracked and wheeled trenchers can take whatever nature throws in their path.
RT55
The powerful, compact and incredibly versatile Ditch Witch RT55 is designed to drive a wide range of attachments.
RT75
The compact, 74-hp (55.2 kW) Ditch Witch RT75 has the muscle you need for tight working spaces.
RT95
The 99-hp (73.8 kW) Ditch Witch RT95 comes with your choice of hydrostatic or powershift transmissions.
HT115
The Ditch Witch HT115 offers an easy-to-use track drive system, a wide selection of attachments, and a choice of rubber or steel tracks.
RT115
The rubber-tired, four-wheel drive Ditch Witch RT115 is ideal for both paved and off-road work.
HT220
The Ditch Witch HT220 trenches up to 8 feet (2.4 m) deep and up to 24 inches (610 mm) wide.
HT300
The HT300 can trench up to ten feet (3.1 m ) deep and 36 inches (914 mm) wide in the most extreme jobsite conditions.
|
|
|
|
|
|
Astec TF300B
This 18.5 horsepower mechanical trencher is a favorite for footing and flush trenching, as it can trench right next to the side of a house or other building. This model is available with steel or rubber tracks.
Astec Maxi-Sneaker Series D
The Astec Maxi-Sneaker Series D is the most popular drop plow in the world. It delivers 37 horsepower with a fthree-cylinder, liquid-cooled diesel engine. Hydraulic power steering allows unit to articulate a full 28-degrees to the left or right of center for minimum inside turning radius of 72 inches (1,829 mm).
Astec RT360
This is a powerful, but compact, trencher with a 30-horsepower Deutz air-cooled engine. It can dig trenches to depths of 60 inches. The operator can use the backhoe or trencher attachment without having to leave his seat. The backhoe can carry 1000 pounds.
Astec RT460
This trencher is equipped with a 37 horsepower Kubota engine with a rigid-frame. The only trencher in its class to feature a full-floating axle design to withstand heavy loads for long life, it can dig to depths of 60".
Astec RT560
This very popular trencher comes standard with a six-way blade, Outboard planetary axles, a heavy duty fly wheel trencher, four wheel steering, and four wheel drive.
Astec RT660 II
Built for performance, the Astec 660 II has a 75 horsepower engine and a limited slip differential to boost traction. It has a heavy duty radiator for high capacity cooling.
Astec RT960
This 99.5 horsepower trencher consistently outperforms and out maneuvers all other hydrostatic trencher models.
Astec RT1160
The exciting design of the RT1160 reflects Astec’s vision for the future of its utility trencher lineup.
|
|
|
|
|
|
Each Zahn power unit includes the engine, operator's console, and the articulation joint. The R230 and R300 also have a unique InterChange connection that accepts up to seven types of front ends: trencher, plow, dumper, tiller, backhoe, stump grinder, and a tool carrier that can drive more than 40 quick-change attachments. The R150 2WD is essentially a dedicated trencher. The 2WD R230 and R300 accept two trencher front ends, while their 4WD counterparts accept all seven types of front ends-with more planned for the near future.
R150 2WD
No trencher in the 15-hp class performs on the level of the Zahn R150.
R230 2WD
The Zahn R230 2WD tackles traditional trenching tasks with non-traditional power, speed, and efficiency.
R300 2WD
With a 30-hp (22.4 kW) engine and choice of trenchers, the Zahn R300 2WD delivers superior trenching performance.
R230 4WD
The Zahn R230 4WD gives you lots of options, all of them good.
R300 4WD
The R300 4WD accepts all seven types of Zahn front ends, providing an unprecedented combination of power and versatility.
|
|
Seated in the remarkably roomy operator stations of these powerful, compact machines, you'll appreciate the undisturbed view of the work in front, behind, and beside you. Because you won't want to miss a moment of the spectacular performances of Ditch Witch compact trenchers and plows.
RT40
The Ditch Witch RT40 tractor is equipped with a composite hood, an easy-to-read instrument panel and two-wheel power steering.
RT36
The Ditch Witch RT36 has intuitive controls, automotive-style steering and a maintenance-free mechanical drive.
420SX
The Ditch Witch 420sx vibratory plow installs more feet of product per minute than anything in its class.
|
|
Trencor Wheel Trenchers
Trencor offers two state-of-the-art industry mechanical drive wheel trenchers for utility and pipeline work.
Trencor wheel trenchers feature extended length crawlers, fully enclosed and oil bath lubricated chain final drives, multiple drilled digging rims, and in most cases, double segmented rims. Direct mounted hydraulic hoist cylinders for optimum digging performance are standard on all models.
Contractors have found that in certain conditions, one wheel trencher can replace an entire fleet of backhoes.
|
|
Astec RT60 Walk Behind
The 13 horsepower Astec 60 trencher is perfect for light trenching jobs, yet if offers big-trencher features like hydrostatic ground drive and hydraulic boom raise and lower.
RT130 Trencher
The Astec RT130 is the industry's first automatic differential lock for a pedestrian trencher. It's fully hydrostatic design and 13-horsepower Honda engine ensure reliable operation.
RT160 Trencher
The RT160 walk-behind trencher features a powerful 24-horsepower Honda gasoline engine and compact size to make it perfect for a variety of weekend trenching chores. Hydrostatic ground drive means low maintenance costs because it eliminates troublesome belts, clutches, chains and sprockets.
|
|
|
|
|
|
The word "pedestrian" has several meanings, including "ordinary, everyday, lacking distinction or vitality." This definition never enters your mind when you're on the job with a Ditch Witch pedestrian trencher or plow-machines with power and performance second to none.
1030
The Ditch Witch 1030's hydraulic ground drive system allows infinitely variable speeds to better match digging conditions.
1230
The Ditch Witch 1230 walk-behind trencher is equipped for multiple sizes and types of digging chains, including the Shark Chain II.
1330
The Ditch Witch 1330 trencher is a compact walk-behind that is clearly in front of the 13-hp (9.7 kW) trencher field.
1820
The Ditch Witch 1820 is a compact pedestrian trencher that helps you install underground service lines at residential and commercial sites.
100SX
The Ditch Witch 100sx vibratory plow's high-flotation tires provide the traction you need without manhandling the turf.
255SX
The Ditch Witch 255sx vibratory plow was built, tested and proven to provide outstanding productivity and reliability.
410SX
The Ditch Witch 410sx is the most outstanding articulated-steer vibratory drop plow in the 30-hp (22 kW) class.
|
|
The Eagle 4500 & 5500 are high production, low maintenance Bucket Wheel Trenchers. The Eagle Foundation Trenchers are the most cost effective way to increase profitability. The trencher digging wheel is mechanically driven for the maximum transfer of horsepower, all other machine functions are hydraulic. All controls are well marked and positioned for ease of operation and optimum operator visibility. G&Z is committed to producing high production, low maintenance trenchers. Eagle Trenchers are the most cost effective way to increase the profitability of your job. The Eagle 4500 and 5500 are excellent choices for a wide variety of applications, such as foundations, utilities, irrigation and fiber optic installations in friable soils.
Key Features
- Hydraulic Crumb Shoe
- Hydraulic Wheel Lift and Tilt
- Bridge Type Boom Frame
- Dozer Blade with Stake Pockets
- Berm Scrapers
- Roll Over Protection Structure (ROPS) Not shown in photos
- Back-Up Alarm
|
|
RIV152 TR82
CUMMINS engine 113kW (152HP)
6 cylinders in line turbo 3056 DIT
Wheel : trench depth : 0 to 600mm
Trench width : 80 to 180mm
Weight : 9.5T
|
|
RIV300 TC150
CATERPILLAR engine C9 224 kW (305 hp)
Certified emission CARB and EPA stage II
Operation :
- Trench depth : 650 to 1500 mm
- Trench width : 250 - 350 - 450 mm
Weight : 19 t
Conveyor belt for soil evacuation - Radio control (optional)
|
|
RIV152 TC120
CUMMINS engine 113 kW (152 HP)
6 cylinders in line, turbo
Operation :
-Trench depth : 350 to 1200 mm
-Trench width : 180 to 300 mm
Weight : 9.5 T
Constant working angle : from 350 to 1200 mm
|
|
The 250SC trencher resembles, at first sight, the 200SC trench excavator.
But not only is it more powerful and with superior mass, above all it has a much higher excavation capacity. The 250SC can escavate down to depths of 1 m with the rocksaw and 1.80m with the chain.
The caterpillar tracks and commands are identical to those of the 200SC trencher.
|
|
UNAC builds two types of trenchers : on tyres or on caterpillar tracks. The 200SC, on caterpillar tracks, is light and compact. With its tool offset, it is possible to work in towns without blocking the traffic.
The 200SC stands out for its three main subsets :
-The carrier on caterpillar tracks, guided from a cabin or with a remote control.
-The trenching tool. A rotary rocksaw that can dig down to depths of 800 mm. A chain that can dig down to depths of 1400mm.
-conveyor belts, to remove excavated material.
Each subset can be dismounted. From the carrier on caterpillar tracks, the user can choose to work with the rocksaw or the chain. He can choose to evacuate the material into a truck or not. This principle, which is available on all the trencher in the range, provides considerable versatility for network installation companies.
|
|
RIV503 TR250
CATERPILLAR C15 engine 403 kW (547 hp)
Certified emission CARB and EPA stage III
Wheel :
- Trench depth : 0 to 1750 mm
- Trench width : 250 to 380 mm
Mechanised laying
Radio control (optional)
|
|
RIV300 TR130
CATERPILLAR C9 engine 224 kW (305 hp)
Certified emission CARB and EPA stage II
Wheel :
- Trench depth : 0 to 1300 mm
- Trench width : 180 to 270 mm
Weight : 15 t
Mechanised laying
|
|
|
|
|
|
Considered mainly as a trenching specialist, UNAC has used its know-how for activities as varied and complex as the forest or railroad industries. UNAC trenchers are available on caterpillar tracks or tyres. Their power transmission is entirely hydrostatic, which makes it possible to :
- Obtain continuous speed transition.
- Ensure hydrostatic braking due to circuit reversibility.
- Limit efforts : a pressure-limiting valve placed on the hydrostatic circuit eliminates overloads
- Obtain device flexibility : the heat engine is positioned in such a way as to contribute to the machine's equilibrium.
UNAC platform trucks are multi-purpose. Changing from one tool to another (saw, chain or ploughshare) can be done in approximately one hour. This means the same platform truck can be available on all types of sites. Thanks to the turntable levelling system and the hudraulic offset, the tool remains vertical at all times. The power mechanizations available are CATERPILLAR 180CV - 275CV and DEUTZ 450CV - 550CV. The standard tools are the saw (0.50 m to 1.40 m deep by 60 mm to 550 mm wide) and the chain (0.50 m to 2.50 m deep by 150 mm to 600 mm wide).
|
|
The improvements made as a result of the experience of the 300P series 1 to 3 have made it possible for UNAC research department to design and produce the UNAC series 4 300P, equipped with a new generation 300hp CATERPILLAR diesel engine. The UNAC 300P carrier is versatile. Changing from one tool to another - saw, chain or vibrating ploughshare - can be done in an average time of one hour. This makes it possible for the same carrier to be availbale for all types of worksite. Thanks to the tilt corrector and hydraulic offset, the tool remains permanently vertical.
The 300P also exists in a 500hp version. On the same basis as the 300P carrier, UNAC has developed the 300C carrier, on caterpillar tracks. It has been studied for work in all conditions, and is equipped with a chain and vibrating ploughshare.
|
|
|
|
