The Fairchild Model 17 Vacuum Regulator is designed for systems that require system vacuum control up to full vacuum. The Model 17 control diaphragm is balanced by a set of three range springs to provide the most stable, responsive and reliable operation. Stability of regulated vacuum or pressure is maintained under varying flow conditions through the use of an aspirator tube which adjusts the inner valve in accordance with the flow velocity. The Model 17 pneumatic vacuum regulator features control sensitivity of 1/2" water column and a balanced supply valve to deliver consistent and reliable precision accuracy to maintain your desired set point regardless of supply pressure changes or conditions. In fact, it will deliver this performance with a vacuum supply effect of less than 0.15 of any change in supply vacuum. The Fairchild Model 17 will handle a 40 in Hg, 762 Torr, 102 kPa maximum supply vacuum and offers three (3) output vacuum ranges from 0-5 in Hg, 0-127 Torr, 0-17 kPa, up to 0-30 in Hg, 0-762 Torr, 0-102 kPa. The Fairchild Model 17 pneumatic vacuum regulator offers up to 12 SCFM, 20.4 m3/hr flow capacity.
Features
* Full vacuum capability
* Control sensitivity of 1/2" water column
* High flow capacity
* Balanced vacuum Valve
* Aspirator Tube
* Separate Control Chamber
* Unit construction
|
|
Description: Patent Pending. The VRD-ANB-CD vacuum regulator sets an industry standard for both miniaturization and light weight. It designed to control output vacuum from 0 psig to full vacuum. It is particularly useful when space and weight are critical. The VRD weighs approx. 25 grams in brass and stainless steel.
Both the inlet and outlet ports are tapped 10-32 UNF. Its lightweight design allows convenient in-line mounting however a 10-32 threaded panel mount option is also offered. Applications include medical equipment, instruments, laboratory equipment, ink jet print engines, and semiconductor manufacturing equipment.
Material: Brass or 303 stainless steel.
Seals: Buna-N. Optional materials: EPDM and Viton®
|
|
DV Series: Vacuum Pressure Control
Elastomeric diaphragm - highly sensitive
Highly accurate: ±1%
Dome loaded option
Choice of constant or no bleed
44-4700 Series: Absolute-Back Pressure
High Flow capacity
Negative spring bias
Controls sub-atmospheric to positive pressures
|
|
They maintain the required reduced pressure level constant during use
Specific vacuum pressure reducers for the range of use (high vacuum - low vacuum)
Versions with remote pneumatic piloting or simple manual screw adjustment
|
|
General description :
The M 20 RC System of Vacuum Regulators is designed for dosing gas chlorine and with minor alterations also for other gases, working on the indirect vacuum principle.
The M 20 RC System consists of an M 20 C vacuum regulatorwith dosing valve and an M 300 C ejector.
Dosing can be set manually by means of the dosing valve on the regulator. It starts or stops when the ejector pump switches on or off .
|
|
|
|
|
|
World first: The new Pirani sensor VSP 3000 from VACUUBRAND offers the world first fine vacuum sensor with outstanding corrosion resistance and mechanical robustness. Primarily designed for applications in chemistry laboratories and process engineering, it benefits from a ceramic-encapsulated measuring element, an embedded reference element for temperature stability and wetted parts made of high-grade chemically resistant plastics. This technological breakthrough means that the VSP 3000 is a high shock proof sensor that will even survive in the event of sudden gas bumping – a typical cause of failure for standard sensor filaments.
This new patent pending sensor design is unique in fine vacuum measurement and sets a new benchmark standard for chemical fine vacuum measurement. The new Pirani sensor VSP 3000 from VACUUBRAND can be used in conjunction with both the DCP 3000 vacuum gauge and the CVC 3000 vacuum controller respectively and offers therefore not only a versatile fully chemically resistance in the measuring range from atmosphere down to 10-3 mbar, but also the innovative possibility of accurate 2-point vacuum control within this extended range. In addition, up to four external gauge heads can be connected simultaneously to the DCP 3000 vacuum gauge for easy and cost effective multi-point measurement. With small flange connection KF DN 16 at the gauge head and a screw-in hose nozzle for DN 6 to DN 10, the sensor offers flexible connection options for existing vacuum apparatus. Finally, the VACUU•BUS™-system also allows cable extensions up to 30 m, enabling remote application usage.
|
|
Do you attach special value to the durability and performance of your vacuum instrumentation? We as developer and manufacturer of vacuum transducers, gauges, vacuum meters and controllers supply products which will exceed your expectations.
Thyracont Vacuum Instruments GmbH supplies vacuum measurement and control instruments for rough to ultrahigh vacuum.
All our products are "Made in Germany"
|
|
|
High-accuracy vacuum gauge controller that offers pressure measurement and process automation never before available in a single instrument. It measures pressure from Bayard-Alpert ionization gauges, convection-enhanced Pirani gauges, and capacitance manometers providing uninterrupted pressure readings from 1000 Torr to UHV.
|
|
Features:
- Expandable Design - System may be assembled by combining modules to form the desired multi-functional instruments, up to 10 channels.
- Exceptional Readability - Large, bright LEDs.
- Selectable Units - Torr, microns, psi, mBar, or Pascal.
- System Leakup Rate - Digitally displayed in microns per hour.
- Computer Interface - RS232/RS485 digital communications with host computer.
- 0 - 10V, mV outputs for each sensor.
- Easy to use - All controls accessible through front panel.
- Gas compensation - Argon, Nitrogen.
|
|
|
The MKS line of single vacuum gauge controller systems include Pirani, convection-enhanced Pirani and cold cathode sensor technologies. The controller/sensor systems can measure from 10-10 to 1,000 Torr.
|
|
These days, it is hard to imagine modern laboratories
without controller-operated vacuum
pump systems. They deliver precise vacuum
and offer widely diverse control functions for a
huge range of applications in the laboratory.
The new vacuum pump system SC 920 now
supports remote control over a portable hand
terminal, thus ensuring maximum flexibility in
the laboratory. Fast process times and high precision
are further outstanding features of this
new product.
Thanks to wireless remote control, it is
no longer essential for the vacuum
pump system to be located in the immediate
vicinity of the processing equipment.
The pump system can now be
easily stowed away, i.e. in units under
the work bench or in a fume hood,
without the hassle of laying cables.
|
|
LABOPORT Vacuum Systems: chemiecall-resistant Diaphragm Vacuum Pumps with modular Accessories
With each of the LABOPORT vacuum pumps it is possible to construct a system suitable to individual requirements - easily and without special tools. The final building is a system with two vacuum controllers (SCC System) for two independent processes.
|
|
Laboratory diaphragm pump Capex 8C
Contamination free pumping
The capex 8C vacuum pump/compressor provides a clean oil free vacuum and pressure source ideal for laboratory benchtop use.
|
|
| ... products without technical information |
| |
| ... products without technical information |
| |
Pressure Switches
Better under pressure. For years, manufacturers and operators of heavy-duty equipment have trusted Honeywell pressure and vacuum switches. They're proven under pressure, in applications constantly under attack from chemical splashes, performance spikes and other harsh environments. These switches sense a change in the pressure or vacuum, opening or closing an electrical circuit when the designated point is reached.
Honeywell offers an impressive line:
-Compact size
-Durable construction
-Enhanced set point integrity
-Customisation and modifications available
|
|
| ... products without technical information |
| |
|
|
|
|
Nor-Cal offers an extensive selection of commonly used quartz crystal feedthroughs, sensors and multi-channel monitors, cables, quartz crystals, accessories and replacement parts for use in semiconductor, optical and industrial thermal deposition processes. Custom feedthroughs are available with a variety of flanges in all sizes.
Our coating instrumentation products support one of the more popular methods of thin film measurement and rate control _ the crystal monitor, which utilizes the piezoelectric properties of a quartz crystal.
The electrical characteristics of the crystal, which is held in place by the sensor, change during deposition. Single sensors are generally used for short deposition runs, whereas, dual sensors allow for longer runs. Dual sensors require an airline to operate a pneumatic shutter which covers one crystal at a time. The sensor is either welded to the feedthrough or attached with connectors. Most sensors are available with cooling lines.
The application determines the correct choice of sensor. The sensor determines compatible feedthroughs and cabling. The chamber determines the appropriate feedthrough and flange. For application temps up to 150°C, electrical connection between the sensor and feedthrough is accomplished with a vacuum coaxial cable. A bakeable, one piece sensor/feedthrough replaces the standard in-vac cable with a stainless steel high-temp coaxial line for high temperature applications up to 300°C.
|
|
INFICON market-leading thin film deposition controllers and monitors control deposition rate and thickness of the most complex processes with unsurpassed measurement speed and precision. Enhanced software and logic I/O features allow the INFICON Thin Film Deposition Controller to be fully integrated into the vacuum system for automatic process control. To control less complex processes, use INFICON economical, precision controllers and monitors that measure films with 100 times more precision than conventional techniques.
All INFICON crystal-based instruments use our patented measurement system, ModeLock, making them the most advanced instruments available.
INFICON superior quartz crystals offer the highest reliability for millions of successful process runs. Available in 5 or 6 MHz with gold or silver electrodes, INFICON crystals are 100% factory tested to ensure quality.
|
|
