All two-way-valves,
two-way-valves with inlet collar, two-way-valves with seal, two-way distributors 60° and two-way distributors 45°, are available in symmetric as well as in asymmetric form.
Symmetrical versions are optimized for an installation in vertical bulk goods lines, asymmetric ones for lines that have an inclination that corresponds to the angle between the outlets.
The pictures below only show the symmetric form.
|
|
TECHNICAL DATAS
Ball bearing axle
Inspection cap : galvanised steel
Flap that can be dismantled-high resistance dynamic gasket for Airtightness with permanent pressure
Standard finish : one-coat paint
|
|
|
|
|
|
VORTEX® QUANTUM SERIES 2-WAY WYE LINE DIVERTER
The patent pending Vortex® Quantum Series Wye Line Diverter is specifically engineered to handle dry bulk solids in vacuum or dilute phase pneumatic conveying systems with pressures up to 15 psig (1 barg). 3-way, 4-way, and Multi-Port models available.
A full flow orifice provides unrestricted conveying of material with no disk or ledges to impede flow. The diverter seat and live-loaded seals are shielded from abrasion by a metal insert, which provides superior shearing action.
The Wye Line Diverter is designed to eliminate problems, enabling you to meet your objectives by increasing production, while decreasing labour and equipment costs.
Valve Specifications:
- Size/Bore Options: 50mm to 125mm Diameters Pipe, 50mm to 150mm Tube. Consult Factory for 150mm to 300mm Pipe, 200mm to 300mm Tube Models
- Media: Powder, Pellets, Granulars
- Connection Options: ANSI, DIN, JIS, or Compression Couplings
- Media Temperature: Up to 82°C continuous to 121°C intermittent service, Modifications up to 204°C continuous to 232°C intermittent service
- Media Pressure: -0.1 MPa +0.1 MPa, 1 barg, 15 psig, depending on size
- Metal Construction Options: 304 or 316L Stainless Steel, Aluminium, and/or Carbon Steel
- Seal/Seat Material Options: Nylon, PET, UHMW, Glass Filled Teflon, Natural Rubber, and/or Silicon Rubber
- Drive/Actuation Options: Double Acting Air Cylinder, Electric Actuator, Handwheel, or Chainwheel
- Position Detection: Magnetic Reed Switch, Proximity Switch
- Compliance/Approvals: CE, ATEX, FDA
- Industry Use: Plastics, Petrochemicals, Chemicals, Foods, Minerals, Textiles, Agriculture
|
|
|
|
|
|
VORTEX® 2-WAY SEAL TITE DIVERTER
The Vortex® 2-Way Seal Tite Diverter is designed for use in gravity flow applications where material can be diverter from one source to either of two destinations. 3-way model available.
The Seal Tite Diverter offers a removable access door for replacement of blade and shaft seals. All internal ledges have been eliminated to promote cleanliness. The Seal Tite Diverter’s superior design promotes efficiency, durability, and long service life.
Valve Specifications
- Size/Bore Options: 100mm to 750mm Diameter Round, Square, or Rectangular
- Media: Powder, Pellets, Granulars
- Connection Options: SVC Standard Flange, ANSI, DIN, JIS, or Custom Flanges
- Media Temperature: Up to 82°C continuous to 121°C intermittent service, Modifications up to 204°C continuous to 232°C intermittent service
- Media Pressure: 0 barg, Gravity Flow Only
- Metal Construction Options: 304 or 316L Stainless Steel, and Carbon Steel
- Seal/Seat Material Options: Nylon, PET, UHMW, Glass Filled Teflon, Natural Rubber, Kryptane, and/or Silicon Rubber
- Drive/Actuation Options: Double Acting Air Cylinder, Electric Actuator, or Hand Lever
- Position Confirmation: Magnetic Reed Switch, Proximity Switch, or Mechanical Switch
- Compliance/Approvals: CE, ATEX, FDA
- Industry Use: Plastics, Petrochem, Chemicals, Foods, Minerals, Textiles, Agriculture
|
|
|
Diversity of 2-way-distributors with and without seal at the inner flap. 2-way valves, pressed version up to diameter 300 mm with an optional fitting of the inner flap. No reduction of cross-sectional area by convex shape. This ensures less wear and tear of the 2-way valve and of the conveyed product.
|
|
|
|
|
|
The MV-11 Manual 3 Way Diaphragm Valve is designed for use in high purity semiconductor applications. It is also ideally suited for ultra-pure water and aggressive chemical or gas applications. The design utilizes a molded high purity PFA body with precision machined sealing areas. One piece machined modified PTFE diaphragms are also utilized for excellent flexibility and life. A full 1/2" orifice provides maximum flow capability in a compact package.
FEATURES:
* Precision machined diaphragm manufactured from the latest technology modified PTFE. Provides over five times the flexural life as compared to conventional PTFE. Tongue and groove seal for positive diaphragm to body seal. Benefits are high cycle life, lower replacement costs and less downtime
* PVDF coated stainless steel spring reduces effects of corrosive environments
* Submergible option isolates all valve components from the external environment. Benefit is valve remains functional while operating in wet or gaseous corrosive environments
|
|
The PRS6 is a three-way pressure reducing valve that has been developed to give reduced pressure in a particular part of the hydraulic system. The valve maintains the secondary pressure setting constantly, regardless of pressure variations on the primary side. Common applications include pilot circuits in hydraulic and electro-hydraulic servo systems.
Compact and easy to install
Easy to adjust within respective pressure range
Can be factory set and sealed to prevent unauthorized pressure changing
Highly suited for use as a reducing valve in pilot circuits where the pilot pressure is taken from the main circuit
|
|
80000 Series
Masoneilan's 80000 Series 3-way control valve is designed for either combining or diverting flow applications. It provides large flow capacities with low-pressure recoveries, using a flow-to-open plug design.
Consolidated Pressure Relief Valves
Dresser Consolidated is a worldwide leader and full service provider of dependable pressure relief valve solutions. We design, engineer, manufacture, market and service the critical equipment that forms the backbone of pressure relief management throughout industries across the world.
|
|
|
These manifolds are generally used in differential pressure application with pressure gauges, pressure switches & pressure transmitters. Two isolating valves of 1/2" NPTF inlet & out let & one equililizing valve is provided in a single unit 1/4" NPTF vent port is provided as an option.
|
|
|
These manifolds are designed for remote mounting an instruments using threaded instrument & process connections. These valves are having two isolation, one equilizer & two vent/calibration valves. The standard process & instruments connections are 1/2" NPT. Two vent connections are 1/4" NPT in all manifolds & provided with blanking plugs.The instrument connections are positioned at 54 mm center distances but can easily be used with instruments other then 54 mm C.D via screwed fittings. Different options are available as shown.
|
|
M2s
Proportional Pneumatic Control Valve
The M2s is an instrument-grade, proportional, directional control pneumatic valve for high performance applications such as medical equipment, test & measurement systems, advanced automation and animatronics. The valve is designed to be paired with Enfield Technologies driver or controller/driver electronics such as the LS-C10, LS-C41, and C2s
Features:
* Proportional
* High Speed and Flow
* Whisper Quiet
* Vacuum Capable
* High Linearity
|
|
Controlling water distribution.
Water distribution is becoming more and more complex, with the strong development of urban networks, the rising quality standards and the necessity to improve efficiency by lowering energy consumption.
Danfoss Socla offers in this Regulation section a wide range of control valves; but also different air control devices (air valves, pulsairs, injectors).
|
|
AKO – Innovations in Pinch Valves
The valve solution for abrasive, corrosive and fibrous products like granulates, powders and slurries (ISO 9001, CE,...).
Advantages:
• Free passage
• Optimum tightness
• Low resistance
• No plugging
• Low air consumption
• Low weight
• Easy maintenance
|
|
TECHNICAL DATAS
Ball bearing axle
Inspection cap : galvanised steel
Flap that can be dismantled-high resistance dynamic gasket for Airtightness with permanent pressure
Standard finish : one-coat paint
|
|
Automatic recirculation valves (sometimes referred to as pump or minimum flow recirculation valves) are used to ensure the protection of centrifugal pumps during low load operation. This prevents the pumps from running dry and is therefore ideal for boiler feeding, pump start up, or water cooling plants.
The performance of the unique SchuF design has been perfected through simulation and joint research and development with the universities of Magdeburg and Darmstadt.
|
|
Combustion Control Accessories Automatic Shut-off Valves (ASOV)
Automatic shut off valves are necessary in combustion systems to provide reliable, positive shut off of fuels.
|
|
Free flow balancing valve, threaded model from Ø 1/2" to Ø 2" manufactured on brass series PN 25, flanged model from DN 65 to DN 300 manufactured on cast iron series PN 16, with piezometric inlets.
|
|
|
Preso offers 2 type of balancing valves for HVAC systems: B+ and C+. The B+ and C+ Valves offer 2% accuracy and are available in sizes from 1/2" (12 mm) to 10" (254 mm), with sweat, FNPT, flanged or grooved-end connections. Valve options include pressure and temperature ports, quick-disconnect fittings, read-out gages and transmitters.
|
|
DESCRIPTION
The Apollo® 58 series provides system balance hydronic control with proven ASTM grade materials and US manufacturing.
FEATURES
- Solder connection
- 100% Factory Leak Tested
- Easy Adjustment
- Dezincification resistant material
|
|
Circuit Balancing Valves
Whether a system is designed for heating, cooling or water distribution, it must be properly adjusted and balanced for optimum design performance. An unbalanced system may produce temperature variation of up to 14ºF between rooms, which can typically add up to 35% to energy costs.
|
|
|
Streamlined flow valves, inside and outside screw with bellows, maintenance free, manufactured of grey cast iron PN 16, nodular cast iron PN 16-25, carbon steel and stainless steel PN40.
|
|
High Purity
Pneumatic line valve
Working pressure : 240.00 bar
Material : Stainless steel
Gas : Uhp gases
|
|
SchuF is the inventor of the Piston Bottom Outlet category of valves (Patents received in 1923 and 1926). They are widely used in the Petrochemical, Pharmaceutical, Fine Chemicals, Biochemical, Coal, and Aluminium industries.
The valves are most commonly used for the dead space free draining and feeding of vessels, reactors and pipelines. They are particularly suited to applications that require quick vessel drainage, or where crystals can form.
|
|
|
Every air system is unique...and Clippard has the air valve you need. Clippard control valves are available in poppet or spool design; 2-, 3-, or 5-way functions, in sizes from #3-56 and #10-32 (M5) through 1/8" NPT (G1/8"); and for pressure to 300 psi(21 bar). They are available with solenoid, air pilot, manual and mechanichal actuators. Mounting styles include inline, panel mount, manifold mount or clearance holes for mounting screws.
|
|
The unique ELEVENT® valve design with deep-drawn full stainless steel metal housing, modular assembly as well as interchangeable components offers an optimised protection for low pressure applications.
The set pressures range from 2 mbar to 200 mbar. The ELEVENT® provides advanced seal technology and extreme stability despite low weight. The uncomplicated assembly of the valve and the very easy disassembly by means of clamp body connections are additional path-finding features of the ELEVENT®.
The optimised “air cushion“ sealing principle provides a smooth valve stroke and re-seating during operation and prevents from valve flutter and wear.
Installation and storage costs are reduced to a minimum and costs for maintenance and inspection have never been lower!
|
|
Typically associated with relatively high flows, slip-in cartridge valves are targeted for efficient, fast and compact hydraulic systems. Eaton cartridge valve system technology meets the changing needs of new generations of hydraulically operated machinery and equipment. Today's machines need controls that are exceptionally cost effective and energy efficient. Vickers cartridge valves fulfill these needs.
Benefits & Customer Values
- Lowered installation costs
- More efficient operation
- Elimination of external leakage
- Greater contamination resistance
- System design flexibility and improved reliability
Size - NG16-100
- Rated pressure up to 350 bar/5000 psi
- Rated flow up to 5000 lpm/1300 GPM
- Function - pressure, direction, flow, and proportional
|
|
The CV629 is suitable for high cycling automated dispensing applications and can also be used for hand dispensing applications due to its lightweight design. Cartridge valves can be used for silicone dispensing, RTV and silicone oil dispensing, grease dispensing and lubricant dispensing.
Features
• Suitable for all types of materials
• Air and material inlets are aligned for side-by-side mounting of multiple valves
• Stroke adjustment to fine-tune shot size
• Replaceable cartridge seals
• Designed to deliver precise Microshot deposits
|
|
This is a compact and space saving valve of AMD, MMD 3-type, 4-type and
5-type which is popular as an air operated valve and manual valve for
chemicals used with high purity chemical liquid systems.
The performance and model variations are similar to the conventional
models. The diaphragm valve structure that eliminates the cause of
particle generation and the PFA forming body have been incorporated.
This product can be used widely for processes using chemicals and
pure water in IC manufacturing lines.
|
|
Control of vacuum, gaseous, liquid, gelatinous, abrasive, soiled and aggressive media. In comparison to conventional valves, the installation of a coaxial valve allows the control of high pressure with a simultaneously large flow of volume
- No energised port P closed by spring return (NC).
- Connection: DN 10 - 25, G 1/4" - G 1 1/2"
- Flow medium: Neutral, gaseous, gelatinous, abrasive, soiled and liquid media as well as vacuum.
|
|
|
|
|
|
« SAK » stands for « Silo-AustragsKegel » , which means in English « Extraction cone valve for silo». The SAK is designed to control the discharge of powder or granulates out of silos.
The SAK is particullarly efficient in the following cases:
- For a « fast » silo discharge (high extraction capacity)
- For dosing the discharged powder or granulate
- For discharging a silo at different flow
- Garanty a proof closing of the silo (self closed without energy)
- For extracting and discharging “difficult” flowing powders
Working Principle:
- The cone valve is guided in a hopper located at the bottom of the silo
- The cone valve is lifted by a pneumatic bellows
- The adjustment of the opening is set by the stroke of the guiding rod one for all (basic version)
- The continuous adjustment is set by a pneumatic drive adjusting the stroke from 0 to 100% (dosing version)
- Dosing of the discharged product by adjustment of the opening of the cone valve versus the weight on scale, through an interface terminal IT 9000.
- Vibration of the cone in open position
|
|
|
|
