Pick-up-type CNC vertical turning center with inverted spindle; the pick-up concept provides complete machining capabilities and automated loading and unloading of workpieces. Four basic versions are available:
DVH – application oriented machines
DVH E – optimum cost/performance ratio
DVH I – an innovative, ennergy efficient new concept with many options
DVH DUO – twin spindle pick-up vertical turning machines.
The series comes in 6 different models with workpiece capacity up to 750 mm. Flexible automation, an additional cross-slide for 4-axis-machining, optional technologies: Turnmill, Turngrind etc.
|
|
The CTV linear series ensures unparalleled speed and reliability from its cast iron construction for maximum production safety and performance in 3-shift operation. Innovative DMG features have become the benchmark in vertical turning, these include dynamic linear technology, fast- and high-torque main spindle, and advanced control technology. Due to the expansion of the machine series by the CTV 400 linear with a twin turret, the application range has been extended to include workpieces requiring a large number of tools.
In addition, the CTV linear series offers customer-specific expansion options:
2-sided machining: on a single machine (turn-around station 180°)
Cycle machining: on two machines with the same pallet size
Linear chain-linking: for two machines or more with the same pallet size
|
|
High precision
- Highly reliable, stable machining is guaranteed to the design that allows the workpiece to rest on the chuck
- Enables high precision to be maintained, even when subjected to outside shock and vibration, due to highly rigid structured base and column
Independent Operation of Spindles
- Parts can be easily transferred from one spindle to the other.
- Work flexibility-different types of operation for safe, independent operation
- Machine has partition between spindles allowing for safe, independent operation.
- Independent spindle design allows for machining on each spindle without transferring vibration or heat to the other spindle
|
|
|
Vertical turning center for large part machining up to 2m diameter. Flexible automation, uo to 2 cross slides and turrets or tool changer and optional dual station mode.
|
|
VL 3, VL 5, VL Y and VSC 7: the standard vertical turning machine for chucked components
The VL series distinguishes itself by its excellent productivity rating, its high degree of constantly maintained accuracy, its exceptional reliability and its operator-friendliness. The pick-up work spindle fully automatically loads and unloads the machine. Short travels and a compact design result in extremely short loading and cycle times. Turning + automation on a single machine. On a minimum footprint!
|
|
|
|
|
|
The VLC turning centers complete-machine workpieces of up to 1200 mm dia. in a single set-up. They replace the vertical turret lathes previously used for this size of component. With their exemplary chip capacity these gantry-design, multi-functional production centers are ideally suited to complete-machine large workpieces. Soft and hard machining, interrupted cuts, turning, drilling, milling, grinding, ...
The advantages of the VLCLoading and unloading, machining and measuring: all on a single machine
Complete-machining (with optional Y-axis) : integration of turning, grinding and milling technologies
6 to 8 times the vibration dampening effect of cast iron machine bases with MINERALIT® polymer granite
Ideal chip flow conditions, as the tools are located below the workpiece
The hydro-static bearings of the work spindle in Z-axis guarantee outstanding component quality and an extended tool life for soft and hard machining
All machine assemblies with a bearing on accuracy are fluid-cooled
|
|
|
Vertical lathes with turning diameter of 1600mm to 3000mm are constructed with a single column with a complete cast iron structure. Vertical lathes with turning diameters between 3600mm and 6300mm are constructed with double columns. The machine has hydrostatic guidance on the X and Z axes. These lathes are constructed in an entirely modular and compact design and the structure is cast iron. A "C" axis option is also available with milling as well as different accessories such as tool exchange and head tool measurement and work piece measurement systems, independent operator platform and other accessories, etc
|
|
The SKIQ vertical turning lathes are traditional machine generation of vertical turning machines made by TOSHULIN, a.s.
These vertical lathes have been manufactures in TOSHULIN since the seventieth of the 20th century.
At present, the considerable modernized machine finds its application practically in all industry branches and the number of the sold SKIQ machines reaches some hundreds.
|
|
POWERTURN and POWERTURN Y vertical turning centers
POWERTURN and POWERTURN Y vertical turning centers are the most technologically advanced machine generation of vertical turning machines made by TOSHULIN, a.s. The first prototype of POWERTURN machine originated in 1998 and since that time a great number of these machines have found their application, especially in the aircraft industry range.
To enlarge possibilities of the machine, POWERTURN Y vertical turning centre has been launched to a market in 2005. This vertical machining centre has a table located on a linear guide way system, which moves in the Y-axis.
|
|
- Powerful motor spindle
- Large, ergonomic, and easily accessible work area
- Flexible tooling area for specialized machining methods
- More possibilities with a second turret
- Y/B-axis for angular and off-axis drilling and milling
- Easy linking of single machines with the circulating pallet system PUS
|
|
SKG vertical lathes and vertical turning centers
The SKG vertical lathes are manufactured with the table diameters of 4.000 and 5.000 mm. The machines have a robust two-column design that enables machining of heavy workpieces with big dimensions. The table is carried in the hydrostatic bearing.
|
|
Camu's Vertical Lathe :
The machines are built from used structures, the working surfaces have been remachined. The result is a new machine with CE mark.
The machines are supplied with movable cross rails and one vertical head for turning operations. Upon request it is possible to have one or two steel vertical heads fitted, with an automatic clamp and a tool loader.
The CNC can be ECS4802, FANUC 21i-TB or SIEMENS 840 D and the measuring systems with linear scales and Heidenhain encoder .
The manual platform can be modified with automatic 4 self centering jaw built by Rotomors.
All machines are equipped with resistant protective panels and chips conveyers.
|
|
The VL series VTL have been designed to satisfy machining demand of generic metallic parts and in the four (4) versions available: 20, 30, 32 and 50 they can be made in the standard right version, as well as, in the special left version. This construction flexibility, it allows, under request, to realize twin-spindle VTL by putting side by side two (2) specular machines properly linked their basis.
The already experienced IMT technique to produce machines by standard moduls, jointly with the availibility of a large range of accessories, allows the realization of customized solutions capable to satisfy any possible machining needs.
|
|
The Vertical Turning Centres VTC has a high quality production capability and is of a modular design which provides the following machine specification options for each basic size of machine:
· Fixed cross rail models provide high rigidity and operating accuracy.
· Elevating cross rail models are recommended for greater working heights.
· Live spindle and full contouring ‘C’ axis is available on both fixed and elevating cross rail models, which enable to do turning, drilling, threading, milling and grinding operations.
Table diameter: 1000-5000 mm
Turning diameter: 1200-6000 mm
Altura mecanizable: up to 2800 mm
Maximum height table to Ram: 1200-3000 mm
Table drive motor: up to 100 kW
Ram size: 250 x 250 mm - 300 x 300 mm
Live spindle power: 17-37 kW
Vertical travel of cross rail: 600-1000 mm
|
|
Pick-up-type CNC vertical turning center with transfer technology
Highly productive complete machining
Unique, patented transfer technology: complete machining on one machine, direct transfer from the inverted to the fixed spindle with maximum precision.
The series comes in 6 different models with workpiece capacity up to 750 mm. Flexible automation, an additional cross-slide for 4-axis-machining, optional technologies: driven tools, Turnmill, Turngrind etc.
|
|
Flexible, Productive Automation System Vertical Turning Center
Heavy Duty cutting, highly stabilized spindle structure (Loading & clamping by self-weight structure)
One piece column, square type stabilized structure
Variety accessories can be adopted for flexible machining
The most Mechanical, Electrical, and hydraulicaly optimized machine structure
Design space arrangement for easy Chip Flow
|
|
REV vertical lathes and vertical turning centers
The REV machines are manufactured in three sizes with table diameters of 1.250, 1.600 and 2.000 mm and are available as 2-axis or 3-axis vertical turning centers.
The REV machines are designed and built to perform efficient machining of one-off work pieces or in repeated production of small and medium-sized series. The high quality design of this machine is result of long-term experience in the manufacture of vertical turning centers which takes into account customers‘ requirements for accurate, reliable and cost effective machines.
|
|
REV vertical lathes and vertical turning centers
The REV machines are manufactured in three sizes with table diameters of 1.250, 1.600 and 2.000 mm and are available as 2-axis or 3-axis vertical turning centers.
The REV machines are designed and built to perform efficient machining of one-off work pieces or in repeated production of small and medium-sized series. The high quality design of this machine is result of long-term experience in the manufacture of vertical turning centers which takes into account customers‘ requirements for accurate, reliable and cost effective machines.
|
|
|
Okuma's broad range of lathes offers a variety of bore sizes, bed lengths and optional features, 427 combinations in all. This variety allows us to create custom lathe solutions capable of meeting any production need. Many parts can be completed on a single machine. The ability to hold tight tolerances eliminates the need for separate finishing or grinding operations. Okuma's industry-leading THINC - OSP Control creates optimal operating efficiency. The Absolute Position Encoder allows for the immediate return to production in case of power loss or other machine interruption.
|
|
SKA vertical lathes and vertical turning centers
Vertical lathes SKA are manufactured in sizes from 12 to 40 (i.e. with the table diameter from 1.250 till 4.000 mm). At these machines the railhead with the ram and the rotary tool drive, the automatic tool exchange and protective guards have been designed in the entirely new way. The SKA vertical lathes are designed for efficient turning, boring, threading, drilling, milling and grinding of components. The machine enables external and internal surfaces to be machined and faces to be turned at constant cutting speed.
|
|
|
Pumps, bearings and valves are just a few of the parts well suited for a Giddings & Lewis vertical turning center. The addition of a pallet-shuttle, live spindle or four-axis cutting capability adds machining flexibility. Table sizes range from 1250 to 3500 mm with swings of 1400 to 3700 mm.
|
|
Compact vertical turning machine with up to 3 turrets offers maximum productivity Chuck size up to 200 mm
- Powerful motor spindles
- Short idle times due to the linear motor for the
X axis
- Simple part loading through "balcony type"
- Large, ergonomic, and easily accessible work area
- More possibilities with up to 3 turrets
- Y/B-axis for angular and off center drilling and milling
- Flexible tooling area for specialized machining methods
- Easy linking of single machines
|
|
|
Okuma's broad range of lathes offers a variety of bore sizes, bed lengths and optional features, 427 combinations in all. This variety allows us to create custom lathe solutions capable of meeting any production need. Many parts can be completed on a single machine. The ability to hold tight tolerances eliminates the need for separate finishing or grinding operations. Okuma's industry-leading THINC - OSP Control creates optimal operating efficiency. The Absolute Position Encoder allows for the immediate return to production in case of power loss or other machine interruption.
|
|
The machines are supplied with movable cross rails and one vertical head for turning operations. Upon request it is possible to have one or two steel vertical heads fitted, with an automatic clamp and a tool loader.
The CNC can be ECS4802, FANUC 21i-TB or SIEMENS 840 D and the measuring systems with linear scales and Heidenhain encoder .
The manual platform can be modified with automatic 4 self centering jaw built by Rotomors.
All machines are equipped with resistant protective panels and chips conveyers.
|
|
TUE Series
TUE Series of Vertical Boring and Turning Mills are the TUE 150(S) and TUE 200(S) with greater feedrate and table speeds.
|
|
