BGA.Inspector
The endoscopic inspection system BGA.Inspector permits really easy control of BGAs to flip chips.
The comfortable and easy to assemble XY-table with sample holder facilitates fast inspection. The modular HD design for various types of endoscopes delivers images in brillant quality. The high-power LEDs can be adjusted to exactly illuminate the inspection object with individual settings for front and back light respectively.
Advantages
• for various types of endoscopes
• endoscope may be rotated independently of back light
• XY-table with fine adjustment
• magnetic sample holder
• high-tech camera system for high resolution images
• illumination by high-power LEDs (front and back light)
• all degrees of freedom
• upgrade to professional system possible
• safe investment thanks to modular design
• for use with standard PC*
Options
• various camera systems
• special lenses
• traceability software
|
|
Location And Inspection
* The RIDGID SeeSnake® is rugged and maneuverable.
* The NaviTrack II and the NaviTrack Scout are the easiest to learn and use. Ideal for those primarily locating sondes.
* SeekTech provides confident locating of utility lines.
* Best-built, best-backed cameras and locators on the market.
|
|
The Evolutis range enables the video inspection of pipes that are 55 to 1200 mm in diameter.
Available in a portable version, the system is compact, evolutionary and uses the same camera tractor installations as the "equipped van" version.
|
|
3D PIPE DIGITAL VISION
Digital video recording of the entire pipe
3D navigation and pipe unfolded view on computer
Pipe Ø 150 to 600 mm
ADVANTAGES
Report and inspection analysis in the vehicle or at the office
Compatible with our inspection report software HYDROSCAN (EN 13508-2 standard)
Strongly built (axial camera)
Full pipe video recording in one examination
|
|
HYDROZOOM equipment is intended to carry out a quick visual inspection of pipe work from a manhole.
It consists of a console with screen connected by a cable to a camera module.
The camera integrates a zoom feature and power LED lighting enabling the general condition of the networks to be quickly assessed.
. Pipe inspection Ø 100 à 1000 mm, from manholes
. Camera with optical zoom X 18
. Cable length 15 meters max.
. LED light
. Integrated batteries 12 V DC
. Photo and video memory card recorder
|
|
HYDROVIDEO has designed two reliable, portable systems that are completely autonomous for inspecting small diameter pipes
(HV mini and ball camera).
These systems are either intended for the connections of sewage networks or industrial pipes.
|
|
Mini range
HYDROVIDEO has designed two reliable, portable systems that are completely autonomous for inspecting small diameter pipes
(HV mini and ball camera).
These systems are either intended for the connections of sewage networks or industrial pipes.
|
|
| ... products without technical information |
| |
iShot Imaging XtendaCam Pole Systems
These slender, hand held XtendaCam pole cameras view and illuminate inaccessible areas, delivering crisp video to the pole mounted display. Internal cabling and lightweight design make them highly maneuverable, while their small collapsed size maximizes portability.
|
|
New Hirox All in one Digital Microscope System with 2 Zoom Lenses (20x-160x and 50x-400x) and Standard Stand
Very easy to use and to transport, excellent image quality, Remote control for more ease of use.
Main unit with 2.1 Mega pixel video CCD
- Image recording,
- High resolution UXGA 15 inches Flat Screen with Multi Screen fonction
- TWAIN connection with PC,
- Compact Flash Card recording.
2 Zoom Lenses with LED directional Lighting:
- 20x to 160x magnification (Working distance: 44mm - Field of view: 15.4 - 2.0mm)
- 50x to 400x magnification (Working distance: 54 mm - Field of view: 6.1 - 0.78mm)
Standard Stand with Extension Pole (ST-HE)
Options: 2D measurement software, XY table, Lens Contact Adapter
|
|
|
KH-7700 Digital Microscope System is HIROX's newest most advanced development. The digital camera, light source, LCD monitor, computer and software are all integrated into this one unit. The KH-7700 provides the user with the ultimate in high performance observation, measurement, analysis, recording, management, and output.
|
|
EasyInspector
The EasyInspector is a portable high-resolution video microscope with autofocus (Full HD resolution available).
The device has a modular design and is suitable for visual quality control, i.e. as a video magnifying glass with a magnification rate of up to 300.
The EasyInspector is a fully integrated system appropriate for visual tests. The camera has a resolution of 0.5 mega pixels, and the system includes a 8.5" TFT LCD display.
|
|
The StarLite GX is the newest design in a complete non-contact inspection system with interactive measurement capabilities at your fingertips. It is everything you need for accurate video measurement.
Interactive Measurement at your fingertips
StarLite GX - fast, accurate and repeatable results you expect from a measurement system.
StarLite GX is designed for ease of use, with ergonomic controls, and innovative full-featured software. Increase your productivity with optional front panel controls - motorized zoom, XYZ zero set, enter point button, skew alignment, and an inch/millimeter switch.
eGx metrology software guides users through measurement routines with graphical icons, and unique tools for fast results on a manual measurement system.
|
|
| ... products without technical information |
| |
GE Inspection Technologies brings you an array of VideoProbe® systems, a comprehensive offering of technologically advanced video borescopes that are diverse enough to meet your application-specific needs. Plug them in, turn them on—our VideoProbe systems are designed for ease of use while delivering video images of unsurpassed quality. Distinguished by an intuitive, patented joystick and one-handed operation, the VideoProbe systems feature an integrated LCD video display and a variety of imaging and measurement functions to meet your inspection needs. Engineered for durability and a vailable in many diameters and lengths, VideoProbes can be used for a wide range of industry applications.
|
|
|
|
|
|
iRis
Intelligent Remote Inspection System
Extremely compact dimensions, minimal weight and optimal handling are the outstanding attributes of the iRis Videoscope System by IT Concepts.
- Videoscope for the mobile use
- ready for use in no time
- very compact & portable
- sturdy & reliable
- 1.5kg lightweight
- real one-handed operation
- integrated high-power LED light source
- intuitive use
- intelligent camera control
Inspections in remote or inaccessible areas of the harsh industrial environments now are feasible in no time and with an undreamed easiness. Only little efforts and iRis is ready for use within seconds. You can move the distal end to any desired position fast, easy and precisely, thanks to the approved tactile 4-way articulation of up to 180°.
Adjustable and interchangeable objectives with different fields of view, f-stops and working distances as well as the high brightness of the LED light source guarantee, that you don´t miss any detail on the 4.0" high resolution TFT display.
The integrated, changeable and rechargeable high power batteries assure 2 hours of opera-ting time. The balanced handle - designed for real one-handed operation - allows long and effortless working.
With diameters of 6.0mm or 8.0mm and lengths from 1.5m to 3.0m the iRis leaves nothing to be desired.
|
|
|
|
|
|
iCapturesmartSystem
Extremely compact in size – light weight for maximum portabi-lity. The 580g of this lightweight imaging and documentation hub is barely noticeable when climbing or walking. The iCapturesmart enables a user to carry out inspections conveniently and effortlessly in remote or inaccessible places, or in confined spaces.
iCapture smart System - here, too, the tried-and-tested iSeries Videoscope is at the heart of each top-quality, clear, true-to-life inspection image. Together with the extremely portable, ultra-compact iCapturesmart imaging and documentation hub, it forms a high-performance system that is ideally suited for use in confined spaces or especially remote or inaccessible inspection environments. Thanks to its high-quality, heavy-duty shell and sturdy aluminium profiles, the ABS plastic system carrying case is extremely hard-wearing, making it well-suited for carrying your inspection system around.
A CCD image sensor is the vital centre of the Videoscope providing unsurpassed resolution and image clarity for true-to-life images with realistic colours. The Videoscopes feature handpiece camera control electronics. This means many different videoscopes can be used with a variety of imaging and documentation hubs. With their one-handed and user-friendly operation, the Videoscopes are well suited for use in the industrial work environment.
- Working length from 1.0-15.0m
- Diameters of 4.0mm, 6.0mm and 8.0mm
- Articulation choices are 2-way and 4-way.
- Bright 4.0 inch TFT display
- On-screen menu
- On-screen text generator
- Personalised camera control
- Extensive documentation features
- smart hold holding device t
|
|
|
|
|
|
iTool System
...the intelligent inspection system
The iTool System is made up of three components: the iTool Video Imaging Hub as the ima-
ging and documentation hub; the iSeries Videoscope; and the compact Case for transportation.
- Specifically developed for industrial applications
- Compact and portable
- Entire system weighs just 4.0kg
- Dynamic 180° articulation
- Sturdy and reliable
- Easily transported
The iSeries Videoscope with CCD image sensor provides a high-quality video signal and exceptional resolution. The videoscope's precise and extreme articulation allows you to manoeuvre it into any position you need.
With its intelligent software, the iTool Video Imaging Hub visualises inspection images
on the high-resolution TFT display and saves images at the touch of a button. With the
iTool, inspection images can be precisely marked and documented.
iCase and iCaseplus are clever and compact transportation solutions.
This mobile inspection system solution is uncomplicated to set up and easy to use.
Key Facts:
• Large, bright 6.8” TFT display
• On-Screen menu
• On-screen text generator
• Personalised camera control
• Image capture with audio commentary
• State of the art documentation functions
• Integrated 24W Metal Halide Light Source
• Rechargeable powerBelt
• maxhold holding device for iTool and iSeries Videoscope
• CCD camera technology
• Convenient one-handed operation
• Image capture button on handpiece
• Working lengths from: 1.0m – 15.0m
• Diameters of: 4.0mm, 6.0mm, 8.0mm
• Articulation: 2- br 4-way
• Custom-built versions available
|
|
|
|
