This rugged, cost-effective instrument is an industry standard. It provides high sensivity and accuracy, low noise and excellent stability.
• 200 µV to 3.0 V measurement range (300 V optional)
• 10 kHz to 1.2 GHz frequency range (10 Hz optional)
• Large analog scale, RMS volts and dBm
• Full range of 50 ohm and 75 ohm accessories available
|
|
9230 RF Voltmeter
The 9230 series RF Voltmeter performs highly accurate and sensitive measurements. Fully programmable, the unit is versatile for benchtop or system applications.
• 200 µV to 300 V measurement range
• 10 kHz to 1.2 GHz frequency range
• Single or dual channel
• Different measurements in dual-channel mode
• 50ohm and 75ohm accessories available
• GPIB or optional RS232
* Probes must be ordered separately .
Probe choices include:
952063
Standard Frequency Range 10 kHz to 1.2 GHz
952064
Low Frequency 10 Hz to 100 MHz
|
|
500 Clamp-On Meters
The Clamp-On Meter Model 500 is a general-purpose professional clamp-on. A strong mechanical case design, quality materials, full ranges and compliance to international safety and quality standards ensure a professional and reliable tool. The Model 500 is auto-ranging, and provides the user with AC Volts, AC Amperes, resistance, and continuity. The large and complete 4000-count LCD features comprehensive user interface symbols such as a low battery indicator. It is equipped with a Data Hold function, which freezes the measurement. The Model 500 is compact for comfortable one-handed operation, and the hooked jaw design is easy to maneuver in crowded wiring and breaker panels. The jaw opening for the Model 500 is 1.1” (28mm)
|
|
Featuring
Precision DC & AC to 70 KV Voltage Measurements
Accuracy Traceable to NIST
20KV-40KV-70KV Ranges Full Scale
Battery Powered Portable
Measurement Resolution: 1:20000
Calibrator for Hipot Testers
TRMS Technology for AC Measurements
Ideal for Calibrating HV Power Supplies & TV's
Tests to UL/IEC Specifications
|
|
Voltage sources and nanovoltmeters for low voltage measurement.
Nanovoltmeters
- Model 1801 Nanovolt Preamp (for Model 2001 and 2002)
- Model 2182A Nanovoltmeter
- Model 78B Nanovolt Scanner Test System
With just 0.6nV p-p noise, the Model 1801 Nanovolt Preamp for the Model 2001 and 2002 is the most sensitive room temperature digital nanovoltmeter available. But it's equally suitable for a wide range of low-level AC voltage, 4-wire ohms, frequency/period, and differential temperature measurement applications. It extends the low-level measurement ranges and amplifies the voltage sensitivity of the Model 2001 and 2002 DMMs by 1000 times.
Programmable Voltage Sources
|
|
Flexible output options make this meter the right choice for many applications. With display scaling
the user can display engineering units from a linear DC input.
• 14.2mm character high visibility LED display.
• 1/8 DIN (96mmX48mm) bezel.
• Simple user programming.
• Display scaleable to show engineering units.
• True RMS voltage indication.
• Programme lock out facility.
• AC and DC powered models available.
• Analogue re transmission option.
• Dual relay output option for alarms or ON/OFF control.
• RS485 communications option.
• CE approval (UL and cUL pending).
|
|
| ... products without technical information |
| |
Especially developed for indication and supervision of the three-phase tension, the VTL replaces an analogical voltmeter, a selective key of tension and a relay of lack of phase, reducing installation manpower and optimizing the used one of spaces in the panel. Ideal for protection of three-phase networks is monitored and generally to own alarm superior and inferior. Protection of the parameters of programming by password.
Dimensions: 72x72x95mm;
Approximate weight: 340g;
Feeding: 110/220Vca, 50-60Hz;
Exit to relay 5A;
Configurable alarm;
Scale of 0 to 600Vca.
|
|
|
|
