Sub-Zero Temperatures From Compressed Air
Using only factory compressed air, ITW Vortec's Vortex Tubes generate temperatures down to -40¢XC for spot cooling in a wide variety of industrial applications and processes. A Vortex Tube separates compressed air into hot and cold air streams, lowering the supplied air temperature by as much as 40¢XC and delivering refrigeration up to 6000 BTUH. With no moving parts to break or wear out, Vortex Tubes offer reliable, maintenance-free operation and easy installation. Various models are available for specific cooling requirements and, at only 150 mm to 330 mm long, they serve as a very compact, cooling component on machinery and equipment.
|
|
|
Meech Stainless Steel Vortex Tubes convert compressed air into two airflows, one extremely cold and the other extremely hot. Compressed air enters the spin chamber tangentially. This causes the column of air inside the tube to rotate at very high speed (up to 1 million rpm). The air at the outside of the column, moving very fast has a lot of energy and is hot. The air at the centre of the air at the centre of the column, moving relatively sowly has little energy and is cold. The hot outer air is bled of off at one end of the tube and and the cold inner air at the other. Vortex Tubes have no moving parts and can produce temperatures as low as 50°C below the inlet air temperature and as high as 110°C.
|
|
|
Coldstream Air Guns from Meech Air Technology provide a cold airflow that is commonly used for spot cooling. The Vortex Tube is a the heart of the Coldstream Gun, encased within hot and cold end silencers. The cold air produced by the vortex tube is easily directed on to the area to be cooled by use of the knuckle trunking. The hot air created by the opposite end of the Vortex tube flows to the atmosphere via a silencer. The cold airflow can be as low as 50°C below inlet air temperature and be maintained to +/- 0.6°C.
|
|
|
|
|
|
Vortex Tubes With Metal Generators, Stainless Steel Body:
Vortex Tubes are devices that work on a standard compressed air supply. Air enters the vortex tube and literally splits the air flow into two parts - cold air at one end, and hot air at the other - all without any moving parts.
Vortex Tubes have an adjustable valve at the "hot" end controls the volume of the air flow, and the temperature exiting at the cold end. By adjusting the valve, you control the "cold fraction" which is the percentage of total input compressed air the exits the cold end of the vortex tube.
Inside is the interchangeable brass "generator" which can alter the air used in the vortex tube, and control the temperature ranges you wish to have at the cold and hot ends. There are several ranges of generators for compressed air capacity. There are also two basic types of generators - one to produce the extreme cold temperatures (maximum cold temperature out called the C generator) and one type to produce the maximum amount of cooling (maximum refrigeration called the H generator).
WHY USE Frigid-X Vortex Tubes over others?
Vortex Tubes - Frigid-X are constructed of stainless steel and use a generator and valve made of brass and sealed with viton o-rings to allow their use in the widest range of environments. Others use plastic generators and standard Buna N O-Rings and charge extra for brass and viton. The unique design and quality of materials used in Frigid-XT™ products will deliver years of maintenance-free operation.
Frigid-X™ Vortex Tubes Advantages:
- No moving parts, reliable, maintenance free
- No coolant
- Compact and lightweight
- Low cost application
- Maintenance free units
- Instant cold air in environmental chambers
- No spark or explosion hazard
- Interchangeable generators
|
|
An effective, low cost solution to a wide variety of industrial spot cooling and process cooling needs. Using an ordinary supply of compressed air as it's power source, Vortex Tubes create two streams of air, one cold and one hot, with no moving parts. Cold airflow and temperature are controlled by adjusting the valve at the "hot" end using a simple screwdriver. Temperatures from Temperatures from -40 °F (-40 C) to +250 °F ( 110 C)
VORTEX TUBE ADVANTAGES
- No moving parts, reliable, maintenance free
- Compact and lightweight
- Instant on/off, easy to control, cools without waste
- No spark or explosion hazard
> > > > (SPECIFICATIONS)
- Streamtek Vortex Tubes are constructed of stainless steel and use a generator and valve made of brass. The unit is sealed with viton o-rings to allow their use in the widest range of environments. Others use plastic generators and Buna N O-Rings.
- Air flow rates up to 40 SCFM @ up to 2,800 BTU/Hr Refrigeration.
|
|
Adjustable Spot Cooler - Frigid-X™ is a low cost and maintenance free Adjustable Spot Cooler system which utilizes a vortex tube to produce cold air at one end.
Adjustable Spot Cooler - Frigid-X™ temperature can be adjusted using a knob at the hot end to set the temperature precisely to your requirements. Temperatures range from approximately minus 30ºF to room temperature and can be easily set with a thermometer.
Adjustable Spot Cooler - Frigid-X™ comes with three brass generators for flow rate adjustment - 15 SCFM (425 SLPM), 25 SCFM (708 SLPM) and 30 SCFM ( 850 SLPM) providing refrigeration up to 2100 BTU/hr (615 Watts).
Features:
- No moving parts or electricity
- Compact and lightweight
- Low cost
- Maintenance free
- Instant cold air
- Quiet
- Magnetic base
- Interchangeable generators
|
|
An effective, low cost solution to a wide variety of industrial spot cooling and process cooling needs. Using an ordinary supply of compressed air as it's power source, Vortex Tubes create two streams of air, one cold and one hot, with no moving parts. Cold airflow and temperature are controlled by adjusting the valve at the "hot" end using a simple screwdriver. Temperatures from Temperatures from -40 °F (-40 C) to +250 °F ( 110 C)
VORTEX TUBE ADVANTAGES
- No moving parts, reliable, maintenance free
- Compact and lightweight
- Instant on/off, easy to control, cools without waste
- No spark or explosion hazard
SPECIFICATIONS
- Streamtek Vortex Tubes are constructed of stainless steel and use a generator and valve made of brass. The unit is sealed with viton o-rings to allow their use in the widest range of environments. Others use plastic generators and Buna N O-Rings.
- Air flow rates up to 40 SCFM @ up to 2,800 BTU/Hr Refrigeration.
|
|
Vortex Tubes and Spot Cooling Products
EXAIR's stainless steel Vortex Tubes convert an ordinary supply of compressed air into cold air at -50°F (-46°C) on one end, up to 260°F (127°C) on the other. There are no moving parts or refrigerants. They are commonly used to cool electronic controls, machining operations, gas samples, environmental chambers and more.
|
|
|
Vortex Coolers from ITW Vortec keep electrical cabinets and control panels cool, clean and protected. An affordable, maintenance-free alternative to air conditioners, the easy-to-install Coolers have no moving parts to wear out. Vortex Coolers incorporate vortex tube technology that uses filtered compressed air to produce a refrigerated air stream distributed throughout the enclosure. Unlike fans that pull in hot, dirty air, the enclosure Coolers maintain a light positive pressure inside the cabinet to effectively seal out the surrounding contamination, heat and humidity that can wreak havoc on sensitive electronic controls. Refrigerated air produced by the vortex tube enters the cabinet while hot air is expelled through a relief valve. Models are available to deliver up to 5000 BTUH of refrigeration. The UL-listed enclosure cooler systems are thermostatically controlled and are available in NEMA 12, 4 and 4X rated models.
|
|
|
Meech Air Technology Stainless Steel Cabinet Cooler Systems provide a cold air source to stop cabinets overheating and prevent ingress of contamination such as dust or moisture. When compared to fans that are commonly found in cabinets, Meech Cabinet Cooling Systems provide the ideal cooling solution. The Vortex tube is at the heart of the Cabinet Cooler. The cold air produced by the Vortex tube flows into the cabinet through the bulkhead fitting and is then ducted to a known problem component or to the centre of the cabinet. The hot air created by the opposite end of the Vortex tube flows to the atmosphere via a silencer.
|
|
Cabinet Enclosure Cooler - Frigid-X™ series for electronic control panels provide a low cost method of both purging and cooling electrical and electronic control panels by using a stainless steel vortex tube to create cold air from ordinary compressed air.
Cabinet Enclosure Cooler - Frigid-X™ series are compact and can be installed in minutes through a standard electrical knockout. There are virtually no moving parts.
Cabinet Enclosure Cooler - Frigid-X™ series are ideal for all NEMA 12 and NEMA 4 rated panels.
Cabinet Enclosure Cooler - Frigid-X™ - Advantages:
- Low in cost
- Compact
- No CFC's
- Fast installation
- Stabilize enclosure temperature and humidity
- Virtually maintenance free (No Moving Parts)
- Mounts in a standard electrical knockout
- Stops heat damage and nuisance tripping
- Eliminates fans and filters
- Prevents dirt contamination by keeping enclosure at positive pressure
- Units applicable to all environments including high temperature to 200ºF
|
|
|
|
|
|
Using our extremely low-cost, reliable Vortex Tube, STREAMTEK Cabinet Panel Coolers will purge AND cool electronic/electrical enclosures with filtered air that's up to 45F colder than the compressed air supply. Built into the cooler is a relief valve that exhausts the hot air from the cabinet, while the cooler continues to supply clean cold air. Our Cabinet Panel Coolers are ideal for all NEMA 4/4X and NEMA 12 rated panels. They mount in minutes through a standard knockout.
ADVANTAGES - CABINET PANEL COOLER
- Virtually maintenance free (No moving parts).
- Low in cost, compact, and No CFC's.
- Mounts in a standard electrical knockout.
- Prevents direct contamination by keeping enclosure at positive pressure.
- Units applicable to all environments including high temperature to 205ºF.
SPECIFICATIONS - CABINET PANEL COOLER
- Streamtek's Cabinet Panel Coolers are constructed of stainless steel and use a generator and valve made of brass. The unit is sealed with viton o-rings to allow their use in the widest range of environments. Others use plastic generators and Buna N O-Rings.
- Air flow rates up to 40 SCFM @ up to 2,800 BTU/Hr Refrigeration.
- Cabinet Panel Cooler systems include cooling unit, filter, cold air distribution kit, thermostat, and solenoid valve.
|
|
|
EXAIR Cabinet Coolers are a low cost, reliable way to cool and purge electronic control panels. They provide air conditioning for the electrical enclosures, eliminating electronic control downtime due to heat, dirt and moisture! These panel cooling systems for enclosures incorporate a vortex tube to produce cold air from compressed air - with no moving parts. The compact Cabinet Cooler is an easy to use air conditioner that can be installed in minutes through a standard electrical knockout. NEMA 12, 4 and 4X Cabinet Coolers that match the NEMA rating of the enclosure are available in many cooling capacities for large and small control panels.
|
|
Sub-Zero Temperatures From Compressed Air
Using only factory compressed air, ITW Vortec's Vortex Tubes generate temperatures down to -40¢XC for spot cooling in a wide variety of industrial applications and processes. A Vortex Tube separates compressed air into hot and cold air streams, lowering the supplied air temperature by as much as 40¢XC and delivering refrigeration up to 6000 BTUH. With no moving parts to break or wear out, Vortex Tubes offer reliable, maintenance-free operation and easy installation. Various models are available for specific cooling requirements and, at only 150 mm to 330 mm long, they serve as a very compact, cooling component on machinery and equipment.
|
|
|
Meech Stainless Steel Vortex Tubes convert compressed air into two airflows, one extremely cold and the other extremely hot. Compressed air enters the spin chamber tangentially. This causes the column of air inside the tube to rotate at very high speed (up to 1 million rpm). The air at the outside of the column, moving very fast has a lot of energy and is hot. The air at the centre of the air at the centre of the column, moving relatively sowly has little energy and is cold. The hot outer air is bled of off at one end of the tube and and the cold inner air at the other. Vortex Tubes have no moving parts and can produce temperatures as low as 50°C below the inlet air temperature and as high as 110°C.
|
|
|
|
|
|
Vortex Tubes With Metal Generators, Stainless Steel Body:
Vortex Tubes are devices that work on a standard compressed air supply. Air enters the vortex tube and literally splits the air flow into two parts - cold air at one end, and hot air at the other - all without any moving parts.
Vortex Tubes have an adjustable valve at the "hot" end controls the volume of the air flow, and the temperature exiting at the cold end. By adjusting the valve, you control the "cold fraction" which is the percentage of total input compressed air the exits the cold end of the vortex tube.
Inside is the interchangeable brass "generator" which can alter the air used in the vortex tube, and control the temperature ranges you wish to have at the cold and hot ends. There are several ranges of generators for compressed air capacity. There are also two basic types of generators - one to produce the extreme cold temperatures (maximum cold temperature out called the C generator) and one type to produce the maximum amount of cooling (maximum refrigeration called the H generator).
WHY USE Frigid-X Vortex Tubes over others?
Vortex Tubes - Frigid-X are constructed of stainless steel and use a generator and valve made of brass and sealed with viton o-rings to allow their use in the widest range of environments. Others use plastic generators and standard Buna N O-Rings and charge extra for brass and viton. The unique design and quality of materials used in Frigid-XT™ products will deliver years of maintenance-free operation.
Frigid-X™ Vortex Tubes Advantages:
- No moving parts, reliable, maintenance free
- No coolant
- Compact and lightweight
- Low cost application
- Maintenance free units
- Instant cold air in environmental chambers
- No spark or explosion hazard
- Interchangeable generators
|
|
An effective, low cost solution to a wide variety of industrial spot cooling and process cooling needs. Using an ordinary supply of compressed air as it's power source, Vortex Tubes create two streams of air, one cold and one hot, with no moving parts. Cold airflow and temperature are controlled by adjusting the valve at the "hot" end using a simple screwdriver. Temperatures from Temperatures from -40 °F (-40 C) to +250 °F ( 110 C)
VORTEX TUBE ADVANTAGES
- No moving parts, reliable, maintenance free
- Compact and lightweight
- Instant on/off, easy to control, cools without waste
- No spark or explosion hazard
> > > > (SPECIFICATIONS)
- Streamtek Vortex Tubes are constructed of stainless steel and use a generator and valve made of brass. The unit is sealed with viton o-rings to allow their use in the widest range of environments. Others use plastic generators and Buna N O-Rings.
- Air flow rates up to 40 SCFM @ up to 2,800 BTU/Hr Refrigeration.
|
|
|
|
|
|
measuring tube inside diameter:
25 mm; 32 mm; 40 mm; 50 mm; 80 mm; 100 mm
flange connection
alternatively with / without integrated transducer
initial smallest measurable flow rate:
0.7 m³/h (diameter 25 mm)
terminal flow rate:
1130 m³/h (40 m/s in diameter 100 mm)
working temperature range:
-40° C... 180 °C
maximum working pressure:
up to 10 bar above atmospheric
materials:
stainless steel; hastelloy, titanium, tantalum
explosion-proof type of protection:
Category 1G, 1D (Zone 0, Zone 20); Category 2G, 2D (Zone 1, Zone 21)
special designs on request
====================================================
Compact units for use in Ex-applications:
for gas: Ex II 1/2 G Ex d e [ia] IIC T6 and
for dust: Ex II 1/2 D Ex iaD20/tDA21 IP6x TX
sensor for use in category 1 (Ex-zone 0 rsp. 20)
transducer housing for use in category 2 (Ex-zone 1 rsp. 21)
measuring tube inside diameter:
25 mm; 32 mm; 40 mm; 50 mm; 80 mm; 100 mm
flange connection
initial smallest measurable flow rate:
0.7 m³/h (diameter 25 mm)
terminal flow rate:
1130 m³/h (40 m/s in diameter 100 mm)
working temperature range:
-40° C... 180 °C
maximum working pressure:
up to 10 bar above atmospheric
materials:
stainless steel; hastelloy, titanium, tantalum
|
|
|
|
