The E2x warning horns are available in two outputs levels 110dB(A) and 117dB(A) @ 1m, both featuring 45 tones and three stages. The E2x-range of hazardous area products provides signalling solutions for every Zone 2 or Class I Division 2 application. Containing the latest in electronic circuit design, they provide unparalleled performance and reliability.
Features:
- Constructed from lightweight corrosion free PPS and impact resistant ABS
- ATEX certified products: dual M20 cable entries and in & out terminals
- UL approved products: single 1/2” NPT entry pre-wired with flying leads
- Mounted via a fully adjustable ‘U’ bracket
The E2x-range includes:
- 110dB(A) and 117dB(A) alarm sounders
- 5 & 10J Xenon Beacon
- Combined Alarm Horn and Xenon Beacon
- 15W PA Loudspeaker
|
|
|
|
|
|
The EEx II signalling hooter dGH21was developed for warning, calling and indicating purposes in areas with explosive atmospheres in group II and for rough ambient conditions. Thanks to its compliance with the explosion protection class II 2G EEx de IIC T6, this signalling device can be used without restriction in all areas with explosive atmospheres in zones 1 and 2. The hooter produces a volume of appr.105dB(A) . The characteristic hooting sound can be clearly heard above any other higherfrequency sounds in the area. The dRGH21 comprises a telephone calling relay and reproduces the signals in the pulse rate of the overriding telephone call. The explosion protection is given through the flameproof chamber and the chamber “increased safety”. The flameproof chamber contains the electromagnetic drive system and, for the dRGH21, an additional telephone calling relay. The signal membrane is mounted outside of the flameproof room beneath a closing cap with the appropriate sound control. The housing is made of GRP thus guaranteeing protection against corrosion. Furthermore the construction is lowweight and highly robust. All DC versions are equipped with an electronic contact breaker which considerably increases service life compared with other commercially available devices.
|
|
Dust Line Signalling Devices for Zone 22 ( Dust )
Now available in EEx for use in dust areas like mills and concrete-plants
|
|
The trumpet horn has been designed to provide an effective penetrating low frequency buzzer sound which is generated electronically, replacing the traditional electro-mechanical generator.
They produce an identical sound with the increased reliability of an all-electronic solution.
Features:
- Three version:
- H100T – electronic signal horn with trumpet flare – 100 dB(A) @ 1m
- H100B – electronic signal horn (without trumpet flare) – 100 dB(A) @1m
- H110T – electronic signal horn with trumpet flare – 110 dB(A) @1m
- Incorporated volume control
- IP65
- Three alarm sounds
- Also available in combination with xenon strobe, LED beacon and halogen rotating beacon (H110T only) to give visual reinforcement of the audible warning.
|
|
|
The HPW 11 signalling hooter is a signalling device for warning and calling which, thanks to its sturdy housing, can be used indoors in both dry and damp rooms as well as outside. The version with telephone call relay allows the device to be used as an additional, loud acoustic signalling device for a telephone. The driver system consists of a strong, non-polarised lectromagnet, whose striker hits the diaphragm between 100 and 120 times a second. The housing of the signalling hooter is made of impactresistant thermoplastic. A self-sealing grommet M20 is proveded as cable gland for cable diameters of 8 to 1 mm. The signalling hooter with telephone relay is equipped with two self-sealing grommets M20.
|
|
Federal Signal offers a line of air horns in a variety of tones and sizes for the industrial marketplace. High, medium and low tones are available which provides a wide range of frequencies and high sound output.
- Available in 120VAC
- Wide variety of tones and sizes
- For indoor/outdoor use
- Type 4X enclosure
|
|
The Model 350WB (AC current) Vibratone® horn produces sound by the electro- mechanical vibration of a stainless steel diaphragm. The horn mechanism with diaphragm is attached to the grille. Indoor or outdoor use is made possible by the water- and dust- tight backbox.
- Available in 120VAC and 240VAC
- Effective range 200 feet
- Coded or sustained tones
- Wall mount
- Produces 100dBa @ 10' (110dBa @ 1m)
- Type 4X, IP65 enclosure
- UL and cUL Listed, CSA Certified, and FM Approved
|
|
Plenty of innovations in WERMA’s Ex range
WERMA has manufactured explosion-protected signal devices in out-standing quality for over 50 years. Many years of experience and know-how in the field of signal technology make WERMA a reliable partner with an extensive range of innovative Ex products. Our Ex-products are developed and designed in accordance with the new-est norms and guidelines and are certified by accredited testing boards.
The guidelines concerning explosion protection and the demands made upon the signal devices themselves have changed enormously over the last few years. WERMA has invested in the development of innovative Ex products which meet the most exacting standards in order to fulfil customer needs.
Our new high-impact programme ranges from Ex signal beacons to optical and audible Ex signal devices. The new WERMA products can even be used in gas and dust explosion endangered areas (Zone 1 and 2, Zone 21 and 22).
|
|
GN 1 SERIES
Warning horns signaling the lift arrival at floor.
* Supply 6 - 24 V dc
* 1 - 2 - 3 tones electronic horn
GN 2 SERIES
Warning horns signaling the lift arrival at floor.
* Supply 6 - 24 V dc
* 1 - 2 - 3 tones electronic horn, with opto-isolated activation control
GN 3 SERIES
Warning horns signaling the lift arrival at floor.
* Supply 6 - 24 V dc
* 1 tone UP, 2 tones DOWN electronic horn with opto-isolated activation control
|
|
* PLC compatible models
* Corrosion resistant finish
* Volume adjustable
* Completely assembled
* NEMA Type 4X rated
The Edwards 870P AC & 871P DC Series are low-current, high decibel panel mount vibrating horns for heavy-duty use. Supplied complete with gasket and UL listed to NEMA 4X enclosure requirements.
|
|
Horn multi-tension with electronic technology. Power of 115 dB (A) to 1 Mr. Très great reliability. Duty ratio: 15 min One; 1 min Off. Frequency 420 Hz. Diam: 124 Misters Poids: 0,5 kg. Accessories available:
- Case of embedding FL IP65
- Box of sealing FL IP 65 (projection)
|
|
