The wheel diameter has significant influence on the performance of a castor.
Wheel-ø 30 mm up to ø 645 mm
|
|
The wheel diameter has significant influence on the performance of a castor.
Wheel-ø 58 mm up to ø 200 mm
|
|
Demag LRS travel wheel system:
The Demag LRS travel wheel system is a robust, universal travel wheel system for a wide range of applications. It is designed for travel applications with wheel loads up to 6.5 t (at 100 m/min) and travel speeds up to 240 m/min. It can even be used at extreme ambient temperatures from -20 °C to +60 °C. Engineers who want to develop their own drive systems can also achieve fast and reliable solutions using the versatile modular construction system.
|
|
High and Medium Capacity Charges
Diameter: 50 to 250 mm
Charge Capacity : 54 - 800 kgs
Assemblies:
Fixed
Swivel
Bolt Hole
Swivel with Brake
Bolt hole with brake
Wheels:
HG- Rubber Tyred and Cast Iron Centred Wheel
PO-Polyurethane Tyred and Nylon Centred Wheel
HU- Polyurethane Tyred and Cast Iron Centred Wheel
FT- Reinforced Nylon Wheel
TA- Cast Iron Wheel
DE- Elastic Rubber Tyred and Aluminium Centred Wheel
TPG-Rubber Tyred and Nylon Centred Wheel
TN-Reinforced Nylon Wheel
TD- Phenolic Resin Wheel
TT- Phenolic Resin Wheel
TP-Polypropylene Wheel
TND- Polypropylene Wheel
PS- Rubber Tyred and Polypropylene Centred Wheel
BS- Rubber Tyred and Metallic Centred Wheel
PGA- Grey Rubber Tyred and Polypropylene Centred Wheel
PGM-Blue Rubber Tyred and Polypropylene Centred Wheel
PU- Grey Polyurethane Tyred and Polypropylene Centred Wheel
AUB- Polyurethane Tyred and Aluminium Centred Wheel
POL- Polyurethane Tyred and Polyprolylene Centred Wheel
UT-Polypropylene Wheel
|
|
Series 72: Sigma Elastic rubber tread; hardness 70+/-3 Shore A; good resistance to wear and to tearing; aluminium and cast iron centre. Standard duty (NL), medium-heavy duty (P), extra-heavy duty (EP) and electro-welded (EE) castors. Diameter: 100-300 mm, Carrying capacity: 180-950 daN.
Series 73: Sigma Elastic rubber tread; hardness 70+/-3 Shore A; good resistance to wear and to tearing; polyamide 6 centre. Standard duty (NL), medium-heavy duty (P), stainless steel medium-heavy duty (PX) castors. Diameter: 100-200 mm, Carrying capacity: 150-450 daN.
Series 73AE: Non-marking blue elastic rubber wheels, hardness 70 Shore A; polyamide 6 centre. Standard duty brackets (NL) and medium-heavy duty brackets (P). Diameter: 100-200 mm, Carrying capacity: 150-350 daN.
|
|
TR polyurethane wheels with electrowelded castors.
These castors are suitable for use in heavy-duty conditions (high impact and speed). To increase the maximum load capacity and resistance to side-impact, a forged fixing plate has been developed with integrated pin and the fork sides have been shaped by drawing.
It is possibile to combine total or directional braking systems and the foot-guard.
|
|
Series 60: Injection TPU 60D polyurethane wheels, hardness 55 Shore D, excellent rolling resistance and elasticity, good resistance to wear and to tearing; polyamide 6 centre. Standard duty (NL), stainless steel standard duty (NLX), medium-heavy duty (P), stainless steel medium-heavy duty (PX) castors and castors for mobile scaffoldings. Diameter: 80-200 mm, carrying capacity: 120-450 daN
Series 61: Injection TPU 80A polyurethane wheels, hardness 80 Shore A, excellent rolling resistance and elasticity, good resistance to wear and to tearing; polyamide 6 centre. Standard-duty (NL) and stainless steel standard duty (NLX) castors. Diameter: 80-200 mm, carrying capacity: 75-300 daN
|
|
|
Castors are available in a range of sizes, in the form of Swivel Castors, Swivel Castors with double brake (brake for wheel axis and swivelling axis) and F
|
|
APPLICATION :
traction for cleaning machines, material handling, pushers, etc..
FEATURES :
Type of motor mounted: permanent magnet – shunt wound
Gearbox: planetary gearbox with steel gears
Reduction ratio: 18/1
Brake solutions: band brake, electromagnetic brake
|
|
APPLICATION :
traction for cleaning machines, material handling, pushers, etc..
FEATURES :
Type of motor mounted: permanent magnet – shunt wound
Gearbox: planetary gearbox with steel gears
Reduction ratio: 18/1
Brake solutions: band brake, electromagnetic brake
|
|
Polyamide 6 solid wheels. Standard duty (NL), stainless steel standard duty (NLX), medium-heavy duty (P), stainless steel medium-heavy duty (PX), electro-welded (EE) castors and castors for mobile scaffoldings.
Diameter: 65-250 mm, carrying capacity: 120-1200 daN
|
|
|
|
|
|
Series 62: TR-ROLL polyurethane wheels, hardness 75 Shore A, excellent sliding and elasticity, good resistance to wear and tear; core made of cast aluminium. Standard duty (NL), medium-heavy duty (P) and electro-welded (EE) brackets.
Series 64: TR polyurethane wheels, hardness 95 +/-3 Shore A, excellent rolling resistance and elasticity, highly resistance to wear and to tearing; cast iron centre. Standard-duty (NL), medium-heavy duty (P), extra-heavy duty (EP) and electro-welded (EE-EEG) castors. Diameter: 80-400 mm, Carrying capacity: 300-3500 daN
Series 65: TR polyurethane wheels, hardness 95 +/-3 Shore A, excellent rolling resistance and elasticity, highly resistance to wear and to tearing; aluminium and cast iron centre. Standard-duty (NL), medium-heavy duty (P), extra-heavy duty (EP) and electro-welded (EEG) castors. Diameter: 80-300 mm, Carrying capacity: 220-2200 daN
Series 66: TR polyurethane wheels, hardness 95 +/-3 Shore A, excellent rolling resistance and elasticity, highly resistance to wear and to tearing; polyamide 6. Standard-duty (NL), medium-heavy duty (P), extra-heavy duty (EP) and electro-welded (EEG) castors. Diameter: 80-250 mm, Carrying capacity: 150-1000 daN
|
|
Series 22: Non-marking grey rubber wheels, hardness 80 Shore A, polypropylene centre. Standard duty (NL) and stainless steel standard duty (NLX) castors. Diameter: 80-200 mm, Carrying capacity: 65-225 daN
Series 23: Non-marking grey rubber wheels, hardness 80 Shore A, centre made of two riveted galvanized pressed steel discs. Standard duty castors (NL). Diameter: 80-200 mm, Carrying capacity: 65-230 daN
Series 52: Standard rubber wheels, hardness 83 Shore A, polypropylene centre. Standard duty castors (NL). Diameter: 80-250 mm, Carrying capacity: 65-300 daN
Series 53: Standard rubber wheels, hardness 83 Shore A, centre made of two riveted galvanized pressed steel discs. Standard duty castors (NL). Diameter: 80-280 mm, Carrying capacity: 65-390 daN
Series 71: Grey non-marking thermoplastic rubber wheels, hardness +85 /- 4 Shore A, polypropylene centre. Standard duty castors (NL) and stainless steel standard duty (NLX) brakets. Diameter: 80-200 mm, Carrying capacity: 70-225 daN
|
|
|
Pneumatic tyred wheels with rib or country profile and 2 plies; working pressure: 2 bars; polypropylene centre. Standard duty castors (NL). Diameter: 260 mm; carrying capacity: 150 daN
|
|
|
New range of wheels, casters and rollers EMILE MAURIN In order to offer the best possible choice to you, Emile MAURIN still extended his range of wheels and casters. The constraints of the environment are taken into account thanks to materials used corrosion resistant, to the strong temperatures and the chemicals. The casters are swivelling or fixed, with fixing by platinum, central hole or expansible casing. They can be twinned to support very important, and deliverable loads with or without brake. We propose mountings out of steel, stainless and cast iron having load capacities of 15 kg to 12 tons; as well as a multiple choice of binding (standard rubber or not staining, polyamide, polyurethane…). To contact your interlocutor, it will help you in the selection of the model good adapted to your use… A knowledge to make with your service!
|
|
Diameter: 160 to 200 mm
Charge Capacity : 215 - 700 kgs
Wheel + Assembly Brake
Wheels:
TN-Reinforced Nylon Wheel
HU- Polyurethane Tyred and Cast Iron Centred Wheel
HG- Rubber Tyred and Cast Iron Centred Wheel
PS- Rubber Tyred and Polypropylene Centred Wheel
BS- Rubber Tyred and Metallic Centred Wheel
|
|
The main feature of these castors is the possibility to transform them from swivel castors into fixed castors, by engaging the brake and as such eliminating the offset. This not only increases the stability of the trolley, but also increases the stationary load capacity by approximately 30% with respect to the offset model. These castors are available in the following models:
- with top plate fitting systeme
- with unthreaded stem fitting systeme
- with threaded stem fitting systeme, which allows the mobile scaffoldin to be positioned horizontally, even in unlevel conditions.
Complies with EN 1004:2005
Available with double pedal.
|
|
|
|
|
|
Wheel description
Standard non-marking rubber tread; hardness 85 +/-3 Shore A. Centre made of two riveted galvanized pressed steel discs.
The version with roller bearings of these wheels is also available with an antistatic strip. To order the anti-static wheel, add the suffix "AS" to the wheel+castor assembling cod
Bush bearing bore or roller bearing bore
In the bush bearing bore, the hub contains a bush made of polyamide 6 with molybdenum disulphide to make it self-lubricating.
In the roller bearing bore, the bearing housing contains cylindrical roller bearings with polyamide 6 cage.
Axle
Axle composed of ground steel bush with bolt according to UNI EN 24017 and nut according to UNI EN 24032.
Swivel top plate bracket NL with central lock
Swivel top plate bracket type NL. The plate, the ball rice ring and the fork are made of pressed steel zinc plated finish; swivel actions: double ball greased race with dust protection seal made of polyethilene. The king pin is integral with top plate and duly rivetted. The hexagonal brake system locks at the same time the rotation of two wheels.
|
|
Diameter: 50 to 200 mm
Charge Capacity: 25 - 125 kgs
Assemblies:
Fixed
Swivel
Bolt Hole
Swivel with Brake
Bolt hole with brake
Bolt hole fitting
Wheels:
PGA- Grey Rubber Tyred and Polypropylene Centred Wheel
PGAIB-Grey Thermoplastic Rubber Tyred and Polypropylene Centred Wheel
CB- Grey Rubber Tyred and Metallic Centred Wheel
PGC- Grey Polyurethane Electrically Conductive Tyred and Polypropylene Centred Wheel
PU- Grey Polyurethane Tyred and Polypropylene Centred Wheel
PGI- Grey Rubber Tyred and Polypropylene Centred Wheel
BP- Grey Polypropylene Wheel
PPI- Red Polyurethane Tyred and Polypropylene Centred Wheel
I- Grey Polypropylene Wheel
|
|
Series 32: Polyamide 6 institutional wheels with zinc-plated brackets. Diameter: 40-60 mm; carrying capacity: 30-60 daN
Series 37: Grey rubber institutional wheels, polyamide centre with threadguards. Zinc-plated brackets. Diameter: 50-125 mm, carrying capacity: 35-80 daN.
|
|
Diameter: 200 to 400 mm
Charge Capacity : 75 - 200 kg
Assemblies :
Fixed
Swivel
Wheels :
EM- Unpunctured Vulcanized Elastic Tyred and Metallic Center
EP- Unpunctured Vulcanized Elastic Tyred and Polypropylene Center
RIL- Grey Pneumatic Tyred and Metallic Center
RIT- 4 P.R. Pneumatic Tyred and Metallic Center
RICB- 4 P.R. Pneumatic Tyred and Metallic Center
RIP- 4 P.R. Pneumatic Tyred and Polypropylene Center
RIPC- 4 P.R. Pneumatic Tyred and Polypropylene Center
|
|
Wheels and rollers of handling
The range of the wheels and casters presented is most important by its diversity of models and its unit load capacities
|
|
- Series: G 200 - 1400 kg Cast iron wheels
- Series: L-G, B-G, BH-G 200 - 600 kg Pressed steel swivel and fixed castors, medium duty brackets
- Series: LK-G, BK-G, BH-G 250 - 600 kg Pressed steel swivel and fixed castors, medium heavy duty brackets
- Series: LH-G, BH-G 250 - 900 kg Pressed steel swivel and fixed castors, heavy duty brackets
- Series: LT-G, BT-G 150 - 750 kg Malleable cast iron swivel and fixed castors
- Series: LO-G, BO-G 750 - 1200 kg Welded steel heavy duty swivel and fixed castors
- Series: LS-G, BS-G 750 - 1400 kg Welded steel heavy duty swivel and fixed castors, extra strong swivel head design
|
|
Cast iron wheels
LINE GG GK
wheel. :made of special grey cast iron, rolling surface neatly turned, with plain or deep groove ball bearing, low rolling resistant to metal shavings.
|
|
features:
Acetal races as standard
Polypropylene races also available
Stainless steel 420 balls as standard
Glass ball grades available
advantages:
Corrosion resistant
Lubrication free
Lightweight
Low friction
Quiet
Hygienic
Can be washed down
Maintenance free
In excess of 30 years proven performance
|
|
Elastic wheels
LINE EKR BL EKK BL
Wheel body : made of polyamide 6 black with plain, roller, or ball bearing.
Tyre: Made of elastic solid rubber, blue, non removable vulcanized, low rolling resistance
|
|
- Series: SPK 400 - 3500 kg Cast iron flanged wheels
- Series: BS-SPK 900 - 3500 kg Welded steel heavy duty fixed castors
- Series: SPKGSPO 220 - 900 kg Cast nylon flanged wheels
- Series: SPKVS 500 - 7000 kg Solid-steel flanged wheels
- Series: DSPK 300 - 1200 kg Solid-steel double flanged wheels
|
|
Heat resistant wheels baker – compact
LINE PHG100HI PHB100HI PHK 100HI
Wheel : High quality phenolic wheels, combined with special fibers, trackless.
Available with plain bore, temp ball bearings and HT selflube bushes.
|
|
|
|
|
|
Series: VEHI
65 - 180 kg
Wheels with heat-resistant Blickle®-Hot solid rubber tyres, pressed steel rim
Series: LI-VEHI, B-VEHI
65 - 180 kg
Heat-resistant pressed steel swivel and fixed castors
Series: LIR-VEHI
65 - 90 kg
Heat-resistant pressed steel swivel castors with bolt hole fitting
Series: VKHT
100 - 100 kg
Wheels with heat-resistant Blickle® Hotline-Special solid rubber tyres, synthetic rim
Series: LI-VKHT
100 - 100 kg
Heat-resistant pressed steel swivel castor
Series: LIR-VKHT
100 - 100 kg
Heat-resistant pressed steel swivel castor with bolt hole fitting
Series: LIX-VKHT
100 - 100 kg
Heat-resistant stainless steel swivel castor
Series: LIXR-VKHT
100 - 100 kg
Heat-resistant stainless steel swivel castor with bolt hole fitting
Series: PHN
100 - 500 kg
Heat-resistant synthetic wheels
Series: LI-PHN, B-PHN
100 - 400 kg
Heat-resistant pressed steel swivel and fixed castors
Series: LIR-PHN
100 - 150 kg
Heat-resistant pressed steel swivel castors with bolt hole fitting
Series: LIX-PHN, BEX-PHN, BX-PHN
100 - 400 kg
Heat-resistant stainless steel swivel and fixed castors
Series: LIXR-PHN
100 - 150 kg
Heat-resistant stainless steel swivel castors with bolt hole fitting
Series: G
250 - 1400 kg
Cast iron wheels
Series: LI-G, B-G
150 - 400 kg
Heat-resistant pressed steel swivel and fixed castors
|
|
|
|
