Available in a full range of colours including our new long life white
Wide choice of viewing angles and intensities. Long life white version now available
|
|
ACULED® VHL – ACULED Standard Very High Lumen Products
(Very High Lumen)
The ACULED® VHLTM (Very High Lumen) is available standard in monochromatic (UV, Blue, Green, Yellow, Red, IR) as well as multi-colored four-chip combinations including an RGBY version.
The ACULED VHL delivers superior brightness, luminous efficacy and excellent thermal management. It is based on an enhanced IMS-board.
|
|
The high-luminance white-light source installs a semiconductor laser diode as an excitation light source.
Laser beam are extremely dangerous to human eyes. Never look at laser beam directly and/or through optical lens. When handling the LDs, wear appropriate safety glasses to prevent laser light, even any reflections from entering to the eye.
|
|
LED Products for Everyday Life
Light emitting diodes (LEDs) play a major role in people's lives, delivering ultra-reliable performance in countless everyday applications. Although often unnoticed, LEDs are used in everything from traffic signal lights to cellular phone and digital camera backlighting.
|
|
SLLUB Backlights by PHLOX® offer the BEST LIFE CYCLE,
THE BEST CHROMATICITY STABILITY AND THE BEST LUMINANCE on the market,
all in an ultra compact and IP-65 body.
Backlight 200x200 SLLUB:
- Luminance Minimum: 40.000 cd/m2 (up to 280 000 in strobe mode)
- Uniformity Minimum: 95 % (+/- 10%)
- Input current: 2 A
- Expected life: > 100 000 hours
Application: Lighting for industrial vision
|
|
SLLUB Backlights by PHLOX® offer the BEST LIFE CYCLE,
THE BEST CHROMATICITY STABILITY AND THE BEST LUMINANCE on the market,
all in an ultra compact IP-65 body.
Backlight 50x50 SLLUB:
- Luminance Minimum: 70.000 cd/m2 (up to 500 000 in strobe mode)
- Uniformity Minimum: 95 % (+/- 10%)
- Input current: 440 mA
- Expected life: > 100 000 hours
Application: Lighting for industrial vision
|
|
SLLUB Backlights by PHLOX® offer the BEST LIFE CYCLE,
THE BEST CHROMATICITY STABILITY AND THE BEST LUMINANCE on the market,
all in an ultra compact IP-65 body.
Backlight 100x100 SLLUB:
- Luminance Minimum: 60.000 cd/m2 (up to 420 000 in strobe mode)
- Uniformity Minimum: 95 % (+/- 10%)
- Input current: 1 A
- Expected life: > 100 000 hours
Application: Lighting for industrial vision
|
|
The PHLOX® High Bright white LED Backlights are a new generation of backlights which enhances the MTBF and the efficiency, superior to competitive systems. PHLOX® technology is the result of several years of research in optics and electronics.
Backlight for 20" LCD NVIS:
- Luminance on the backlight (typical): 6000 cd/m2 - NVIS 100 cd/m2
- Luminance on the backlight (max.): 8000 cd/m2 - NVIS 485 cd/m2
- Luminance trough LCD: 660 cd/m2 (11%) - NVIS 11 cd/m2
- Input current (typical): 2 A - NVIS 0.1 A
- Input current (max.): 3.5 A - NVIS 0.5 A
- Power Consumption (typical): 50 W - NVIS 2.1 W
- Expected life: 50 000 hours (with typical luminance)
- Weight: 2,68 kg (5.9 lbs)
Application: Aerospace, backlight for LCD
|
|
The PHLOX® High Bright white LED Backlights are a new generation of backlights which enhances the MTBF and the efficiency, superior to competitive systems. PHLOX® technology is the result of several years of research in optics and electronics.
Backlight for 4ATI LCD NVIS:
- Luminance on the backlight (typical): 6000 cd/m2 - NVIS 200 cd/m2
- Luminance on the backlight (max.): 7000 cd/m2 - NVIS 700 cd/m2
- Luminance trough LCD: 660 cd/m2 (11%) - NVIS 21 cd/m2
- Input current (typical): 0.3 A - NVIS 0.03 A
- Input current (max.): 0.36 A - NVIS 0.2 A
- Power Consumption (typical): 6.3 W - NVIS 0.6 W
- Expected life: 50 000 hours (with typical luminance)
Application: Aerospace, backlight for LCD
|
|
The PHLOX® High Bright white LED Backlights are a new generation of backlights which enhances the MTBF and the efficiency, superior to competitive systems. PHLOX® technology is the result of several years of research in optics and electronics.
Backlight for 12" LCD NVIS:
- Luminance on the backlight (typical): 12000 cd/m2 - NVIS 100 cd/m2
- Luminance on the backlight (max.): 16000 cd/m2 - NVIS 1400 cd/m2
- Luminance trough LCD: 1320 cd/m2 (11%) - NVIS 11 cd/m2
- Input current (typical): 2.75 A - NVIS 0.6 A
- Input current (max.): 3.5 A - NVIS 1 A
- Power Consumption (typical): 60 W - NVIS 11 W
- Expected life: 50 000 hours (with typical luminance)
Application: Aerospace, backlight for LCD
|
|
The PHLOX® High Bright white LED Backlights are a new generation of backlights which enhances the MTBF and the efficiency, superior to competitive systems. PHLOX® technology is the result of several years of research in optics and electronics.
Backlight for 3ATI LCD NVIS:
- Luminance on the backlight (typical): 7000 cd/m2 - NVIS 200 cd/m2
- Luminance on the backlight (max.): 8000 cd/m2 - NVIS 700 cd/m2
- Luminance trough LCD: 770 cd/m2 (11%) - NVIS 21 cd/m2
- Input current (typical): 0.25 A - NVIS 0.03 A
- Input current (max.): 0.32 A - NVIS 0.2 A
- Power Consumption (typical): 5 W - NVIS 0.6 W
- Expected life: 50 000 hours (with typical luminance)
Application: Aerospace, backlight for LCD
|
|
Copal develops and manufactures slim high-luminance backlights (light-conduction plates) for ultra-fine liquid crystal displays using our high-grade optical design, high-precision die design, and high-precision processing technologies. Backlights are used in mobile phones, portable navigation devices (PNDs), etc., manufactured by major manufacturers.
Liquid crystal backlights (light-conduction plates)
Our advanced technology provides high image quality, such as uniform-surface luminescence using one LED lamp. The ultra-thin liquid crystal backlight (light-conduction plate) is manufactured using high-grade fine shape processing technology.
|
|
