Servo harnessing according to SIEMENS® 6FX5002-
This cable to SIEMENS® Standard 6FX5002 is the high-quality yet more economical version of the highly flexible 6FX8002 version; 100% compatible with SIEMENS® systems; The oil-resistant PVC sheath allows them to be used particularly in industrial areas; For fixed / static installation.
Application range
Plant engineering and construction
Servo drives and Servo harnessings
Design
Design according to SIEMENS® standard 6FX 5002.
Outer sheath: special PVC vinyl compound, flame-retardant according to IEC 332.1,
Design
Further versions and lengths can be delivered quickly.
Note
Maximum length of the cables must agree with the manufacturers' instructions of the servo drives
Afterwards the Technical Data of the used cables
|
|
Directory of the Workings
Cut, sguainatura, spelatura from 0,12 to 200 mmq
Seam finishes them and capocorda to knots or preblocks, nastrati or melted.
Labelling to warmth or jet or with labels.
Working cables plates step 1,27 and 3,96
Supply Harmonized, special cables, UL, AFUMEX, TEFLON, TEFZEL
Resinatura cables with I rendered some epoxy
Sovrastampaggio cables
Realization cables details, antioil, immersion.
Visual tests and work them
Test of rigidity, isolation, short circuit, continuity.
Fatigue tests
Tests of traction
|
|
| ... products without technical information |
| |
|
|
|
|
SOLID EDGE Wiring Harness
Solid Edge Wire Harness Design is a dedicated process driven environment for the efficient creation, routing and organization of wires, cables and bundles in a Solid Edge assembly. Wire Harness Design allows electrical and mechanical design teams to collaborate on designs to create complete and accurate digital mockups containing both mechanical and electrical components, and removes the need for expensive physical prototypes. Design violations such as exceeding physical bundle size or a bend radius being too tightly routed are constantly monitored as the harness is being designed; live feedback immediately displays any problems. Reporting of cable and wire cut length and attributes (allowing for a slack percentage and wire stripping) are captured during the harness design process. The export of ready-to-use 'net list' files adds these mechanical attributes to generate harness designs that are ready for manufacturing.
Automatic wire harness design
Once electrical engineers have developed and proven their designs using electrical prototypes (a task becoming increasingly important as the size and complexity of electrical systems increase), the harness wizard allows mechanical engineers to automatically generate and route physical wires and cables. The harness wizard uses input from dedicated electrical schematics applications such as Mentor Graphics, Cimteam and Vesys to automatically transfer any net-list components and connections to Solid Edge.
|
|
|
|
