*Watt:500m, 1W, 3W, 5W; Package: DO-35,DO-41,DO-15, DO-27
*Watt:100m, 200m, 410m, 500m, 1W, 5W;Package:SOD-523, SOD-323, SOT-323, SOD-123, SOT-23,Mini Melf, SMA, SMB,SMC
-Eris employs strict quality control and various reliability tests by our precision equipments allowing us to provide the high quality products to our customers.
-If you need favorable quotation of Zener diode or more information, please contact with Ms. Cindy Lin through her email address: cindy.lin@eris.com.tw
Looking forward to give you support someday soon!
Best Regards,
Eris Technology Corporation
|
|
FEATURES
• Voltage range 7.5 - 75 Volts
• 5000 Watt peak pulse power
• 100 Watt steady state @ 25°C
• 75 Watt steady state @ 65°C
• Glass passivated junction
• 5000 Watt surge capability at 1 ms
• Typically IR less than1 μA above 10V
• Excellent clamping capability
• Stud cathode & stud anode
• Operating temperature -55°C to +175°C
• 100% tested
MECHANICAL CHARACTERISTICS
• Case: Hermetically sealed DO5 outline
• Finish: All external surfaces are corrosion resistant and
terminal solderable
• Polarity: Indicated by direction of zener symbol
• Weight: 14 grammes excluding mounting kit (approx)
• Torque Setting 30inch/lb
ELECTRICAL DATA
• Forward voltage Vf 1.5V max @ If ≤ 10A 300μS square
wave pulse
• Vz measured with pulse ≤ 100μS and duty cycle ≤ 0.001
• Rz determined with DC plus 10% superimposed AC @ 1KHz
|
|
3.0 Watts Surface Mount Silicon Zener Diode
Features
- For surface mounted applications in order to optimize board space
- Low profile package
- Built-in strain relief
- Glass passivated junction
- Low inductance
- High temperature soldering guaranteed: 260C / 10 seconds at terminals
- Plastic package has Underwriters Laboratory Flammability Classification 94V-0
Mechanical Data
- Case: Molded plastic over passivated junction
- Terminals: Pure tin plated lead free, solderable per MIL-STD-750, Method 2026
- Polarity: Color Band denotes positive end (cathode)
- Standard packaging: 12mm tape (EIA-481)
- Weight: 0.064 g
|
|
