CHARACTERISTICS
- Standard watt density over the surface of the heater: 10 W/cm²
- Max. operating temp. over the surface of the heater: 800°C, under specific conditions.
- Diameter : 25 to 70 mm
Height : 25 to 60 mm
Wattage : from 200 to 880 W, 230 V .
- Covering sheath in stainless steel.
- High watt density, electric mineral insulation.
- Standard connection : nickel core, silicone fiberglass insulated high temperature. Leads protected by a galvanized metallic braid, length 330 mm.
- Axial cap, at the edge of the band heater.
- Standard clamping : clamping sheath + barrel nuts.
Special clamping : sliding keyway (see below).
- Products are in accordance with the EN 60335-1 norm:
Wattage tolerance : +5% -10%
Leakage current < 0.75 mA/kW
