Rotary vane compressor Comp-3™ series

breathing airACon casters

Rotary vane air compressor rated for continuous duty Pressure range to 110psi output 2 HP electric motor, 1750rpm continuous duty - thermally protected 115/230 VAC 1-phase, 60Hz, 17.2 amps (Requires 20amp service) Low maintenance - 500 hours between oil changes 10" pneumatic tires 50,000 hour minimum vane life Built-in skid plate for stair climbing USDA approved food grade oil in compression end Automatic pressure unloading - full modulation air control Breather Box™ Grade-D filtration package required Noise level below 70 dbA at 3 feet 8 Gallon Twin-Air™ tank assembly, 8.5cf air storage @ 110psi, ASME coded 1/2" 5000 series Hansen style coupling on air outlet Optional explosion-proof motor (230/3 VAC only), Model TA-3EXP Dimensions: 46"L x 24"W x 22"H Weight: 150 lbs.
