DIN rail-mounted three-phase solid-state relay
100 A, 4 - 32 V | APC6010 Anacon Power & Controls

Anacon's "Cool One" heat sink designs provide a thermally optimized DIN mounting platform for today's high performance solid state relays. The listings below provide the actual load currents that each part type will support. If you're not sure about how to select the correct product for your application, call Anacon, toll free and discuss your application with us. (800-466-9080)

All Anacon Solid State Relay Assemblies use relays tested to UL508A SCCR standards.
Current Ratings 100AMP Continuous
Zero Cross Relays
Output voltages from 24Vac to 660Vac
Standard DC or AC Control Versions
Standard LED Status Indicator
Regulated Inputs- Back to Back SCR Design
Standard Relays, UL/cUL Recognized, TUV Approved & CE Compliant Version
Provision for overtemp bimetal switch
Safety & Noise Immunity Compliance
135mm DIN Relay w/Removable Touch Safe Cover Includes:
Safety Cover, Relay, Heat Sink & DIN Clip
