Direct-operated solenoid valve A-EVC series
3-wayNCNO

direct-operated solenoid valve
direct-operated solenoid valve
direct-operated solenoid valve
direct-operated solenoid valve
Add to favorites
Compare this product


Characteristics

Control
direct-operated
Ports/positions
3-way
Function
NC, NO
Medium
air, for vacuum
Body
male, manifold, IP65, brass, stainless steel, aluminum
Process connection
G 1/8
Other characteristics
electrically-operated
DN

0.8 mm, 1.6 mm, 2.3 mm
(0.031 in, 0.063 in, 0.091 in)

Voltage

24 V

Temperature

Min.: 0 °F
(-18 °C)

Max.: 149 °F
(65 °C)

Pressure

Min.: 0 bar
(0 psi)

Max.: 101.5 bar
(1,472.1 psi)

Description

Electrically controlled valves, Series 3/2 A-EVC, for vacuum and compressed air applications. Three body styles to choose from: • Manifold Mount A-DI: For mounting directly to a Mounting Plate. Gaskets and screws are included. Ports 1 and 2: 0.07″, Port 3: M5. • Body Ported A-DP: All body ports are M5. • A-DG: G 1/8 male output port for mounting directly to suction cups, air cylinder, or the pilot port of a larger valve. Ports 1 and 3 are M5.
