Vertical drilling and milling machine VMD-828G

vertical drilling and milling machine
vertical drilling and milling machine
vertical drilling and milling machine
vertical drilling and milling machine
vertical drilling and milling machine
vertical drilling and milling machine
vertical drilling and milling machine
Add to favorites
Compare this product


Characteristics

Other characteristics
vertical
Drilling diameter

1.5 in, 3 in

Description

Don’t have the space for both a gear-driven Drill Press and a Milling machine? The VMD-828G combines 2 functions in 1 space-efficient machine. This Mill Drill lets you set the right speed for a given application, providing greater control and extending tooling life. Features Includes 29” x 8” milling-style table which expands the machine’s possible uses Gear-driven head allows you to run tooling at the proper speed for each mill, Rigid base and very wide cast column adds to machine’s strength and eliminates flexing when milling or drilling at full capacity Comes standard with coolant system, R8 spindle taper, and a flexible halogen light Specifications. Motor (HP) - 2 hp Number of Spindle Speeds - 90, 210, 345, 670, 1180, 1970 RPM Prop 65 - Cancer and Reproductive Harm T-Slots Number and Size (In.) - .550" Table Size (L x W) (In.) - 29" X 8" Weight (Lbs.) - 815
