PCI interface card OR8, R8
TTLindustrialmulti-channel

PCI interface card
PCI interface card
PCI interface card
PCI interface card
PCI interface card
PCI interface card
PCI interface card
PCI interface card
PCI interface card
Add to favorites
Compare this product


Characteristics

Bus standard
PCI
Bus
TTL
Applications
industrial
Other characteristics
multi-channel

Description

CONNECT DIGITIAL SIGNALS. QUITE SIMPLE. The optocoupler and relay boards OR8 and R8 are ideal to monitor and control digital states. The digital inputs and outputs can be connected directly via a screw-clamp connection. 8 OPTOCOUPLER INPUTS (OR8). 8 RELAY OUTPUTS (OR8, R8). The eight optocouplers on the OR8 convert digital inputs in the voltage range of 5..30V into TTL signals. Via relays, the OR8 and R8 switch eight control lines (TTL) with up to 6A. CLEARLY SAFE. Due to the galvanic isolation of the channels from each other and from the data acquisition and control system, the whole system is perfectly protected. CURRENT STATES. Eight LEDs each dedicated to the inputs and outputs signalize if a channel is high or low.
