truck-mounted crane / folding / hydraulic / lifting
W 130 S3 BOB SISTEMI IDRAULICI SPA

{{requestButtons}}

Characteristics

  • Configuration:

    truck-mounted

  • Structure:

    folding

  • Other characteristics:

    hydraulic, lifting

  • Lift capacity:

    Min.: 1 kg (2 lb)

    Max.: 2,150 kg (4,740 lb)

  • Working height:

    Min.: 0 m (0'00")

    Max.: 12 m (39'04")

Description

FOLDABLE
• Class of calculation H1B4
• Lifting moment = kNm 130
• Hydraulic outreach = 9,30 m
• First arm with hydraulic extension
• Jib with two hydraulic extensions with
integrated service hoses inside jib
• Compensated proportional flow control
• Top seat control with two additional functions
at the jib extension
• Stabilizers ground bilateral controls with
extension and 180° hydraulic rotation
• Rotation 425° with double rack
• Construction to Machinery Directives
2006/42/CE+UNI EN 12.999
• Basic crane weight*: 2.720 kg
* The weight is indicative and referred to the
basic crane without options or accessories,
protection carters and ancillary equipments
(grab, clamp, glass handling device)
