Moving head lifting shackle max. 120 t

with safety bolt and nut

Product Type: Shackles Type : Anchor Finish: Galvanized Pin Type: Bolt, Nut and Cotter Working Load Limit: 120 Ton Product Code: MC864G Bolt & Nut Anchor/Chain Shackles provide the most secure pin arrangement and will resist axial loading and torsional loading, but should only be used in applications where shackle is infrequently or never removed. All shackles meet or exceed Federal Specification RRC-271D Working Load Limit and traceability codes shown as permanent marking on body and pin Available in painted, galvanized and self-colored finishes (Dacromate coating upon special request only) All shackles have alloy quenched and tempered pins Shackles exhibit extreme deformation before failure* Special testing and certification including magnetic particle, proof load, and fatigue test available upon request at time of order Special products engineering available to fit your special lifting, tie down, and pulling needs Design factor 5:1
