Rotor-stator homogenizer OMOG01
batchverticalside-loading

rotor-stator homogenizer
rotor-stator homogenizer
Add to favorites
Compare this product


Characteristics

Technology
rotor-stator
Batch/continuous
batch
Configuration
vertical
Loading
side-loading

Description

Entirely built in stainless steel, with a working capacity of kg/h 150/400. Vertical axle agitator finishing with thrust Archimedean screw to favour the pump feeding, driven by an electric motor with a 20 rev/min circa motor-reducer. Stainless steel lobe pump with a capacity of kg 10/min at 10 bar pressure. Pump movement group constituted by 3 hp electric motor with gear motor-reducer and continuous motor-variator from 79 to 450 rev/min. Homogenization head with continuous regulation up to 10 bar pressure. Stainless steel piping range with three way tap for the eventual product recycling and to allow the washing and the cleaning to a sanitary level of the closed circuit machine. Hopper of the machinery is able to contain ricotta coming from one flocculator with a.m. mentioned. Hopper will closed completely to be arranged with automatic CIP cleaning, by means of total modulating cover through with panel made of stainless steel AISI304L. Completely openable on the side and complete of safety proximities assembled in the general panel of control (to stop machinery if someone opens during working). Covers are assembled, through a special structure made of in stainless steel AISI304L according machine structural characteristics

Catalogs

Other Comat products

Flocculation tanks, belts and homogenizers for ricotta
