Communication gateway IO-Link Master DR-8-PNIO

EthernetModbusIO-Link Master

IO-Link Master DR-8-PNIOThe IO-Link Master DR-8-PNIO provides eight IO-Link ports and two dedicated DIO ports featuring PROFINET IO communication and dual Ethernet ports with screw terminal connections in a compact DIN rail design.Part Number: 99592-0 Eight port IO-Link Master to PROFINET IO with additional digital inputs on every port allowing for a possible 10 DI ports with the two dedicated DI/DO ports PROFINET Certification Screw terminal connectors for IO-Link, Power, and Digital IO IP20 DIN rail mount enclosure Dual Ethernet ports Additional digital input on every port MultiLink™ – Simultaneously provides IO-Link device access to multiple controllers PLC access to IO-Link ISDU blocks without complex programming PROFINET Certification GDSML files Supports OPC UA Powerful web GUI for configuration and diagnostics, including: IO-Link device management using the IO-Link device manufacturers IODD file for easy device configuration, Automatic data storage (upload and download), Manual data storage (upload and download), Device validation, and Data validation. Works with PortVision DX - a discovery management application LEDs for device, network, and port status Wide operating temperature (-40° to +70°C) IO-Link V1.0 and V1.1 compatibility IO-Link COM1, COM2 and COM3 (230K baud rate) support
