Micro worm gear screw jack
400 daN
COSTRUZIONI MECCANICHE WEINGRILL
MICRO SCREW JACKS
Suitable for slow and fine adjustments.
Standard Jacks are self locking, for non vibrating applications.
Capacity: 450 daN.
Gear ratios: 40:1.
Anti-Backlash device.
Manual model: knob and centesimal dial indicator.
Motorized model: AC or DC motor. Position detection with linear transducer and signal conditioning system.
Execution: Body in anodized cast Brass, Worm Screw in Stainless Steel, Worm Gear in special Bronze, Work Screw in high tensile Stainless Steel.
Sealing to avoid internal contamination.
Screw Jacks complete with greaser nipples.
